Sitecom WLM-4501 Manual de usuario

WLM-4501

Wireless ADSL2+ Gigabit Modem Router

User Manual

Version: 1.0

Table of Contents

INTRODUCTION....................................................................................... 4

KEY FEATURES ................................................................................. 5

PACKAGE CONTENTS ....................................................................... 6

CAUTIONS ....................................................................................... 7

PRODUCT LAYOUT ........................................................................... 8

ACK LABEL

SYSTEM REQUIREMENTS ............................................................... 10

WLM 4501 PLACEMENT ................................................................. 10

SETUP LAN, WAN ........................................................................... 10

PC NETWORK ADAPTER SETUP ...................................................... 11

INDOWS

XP 11

INDOWS

ISTA

INDOWS

7 12

BRING UP THE WLM 4501 ............................................................. 14

INITIAL SETUP WLM 4501 ............................................................ 14

PROCEDURE

STATUS ................................................................................................. 15

TATUS

TATISTICS

DHCP

IST

IAGNOSTICS

CONFIGURATION WIZARD ............................................................ 19

BASIC SETTINGS ........................................................................... 20

LAN

ETTINGS

DHCP

ETTINGS

WAN

ETTINGS

ECURITY

ETTINGS

IRELESS

ACL 29

ADVANCED SETTINGS .................................................................... 30

DVANCES WIRELESS

S 32

P 34

OUTING

SNMP 36

DDNS 37

NA 38

R-69 39

FIREWALL SETTINGS ..................................................................... 40

IREWALL

ACL 41

ILTER

DMZ 45

IRTUAL SERVER

TOOLBOX SETTINGS ...................................................................... 47

ASSWORD

IME

ETTINGS

IRMWARE

PGRADE

EBOOT

Revision 1.0

Note: All the information contained in this manual was correct at the time of

publication.

However, as our engineers are always updating and improving the product, your

device’s software may have a slightly different appearance or modified

functionality than presented in this manual.

Introduction

Congratulations on your purchase of the WLM-4501 Wireless ADSL2+ Modem.

his modem is fully compliant with 802.11b, 802.11g and 802.11n. his modem

provides the best performance when used in combination with 802.11n client

adapters.

he WLM-4501 is not only a Modem or Wireless Access Point, but can also be

used to connect wired Ethernet devices at 10/100/1000Mbit speeds.

For data protection and privacy, the WLM-4501 can encode all wireless

transmissions with WEP, WPA or WPA2 encryption. By default, the modem is

secured with a WPA2 (AES) encryption key. ( he WPA2-key is printed on the

label underneath the modem.)

With a built-in DHCP Server & powerful SPI firewall the WLM-4501 protects your

computers against intruders and known Internet attacks, and also provides safe

VPN pass-through.

With Sitecom Cloud Security, Sitecom goes one step further and ensures that

you can surf the Internet even more safely, not only on your PC, but on all the

devices in your home which you use to access the Internet. It does not matter

whether you surf the Internet on a laptop, a tablet, a mobile telephone or your

television. hanks to the security that is integrated in the router, all the Internet

devices in your home are protected against the dangers of Internet criminality.

1Key Features

Features

Advantages

IEEE 802.11g compliant Fully Interoperable with IEEE 802.11b /

IEEE802.11g compliant devices

Based on 802.11n technology WLM-4501: Up to 6 times faster than

regular 802.11g

(in combination with a 150n or 802.11n

wireless adapter)

Four 10/100/1000 Mbps

Gigabit Port (Auto Crossover)

o connect four wired PC's as well.

Firewall supports Virtual

Server

Mapping, DMZ, IP Filter, ICMP

Blocking, SPI

Avoids the attacks of Hackers or Viruses

from Internet

Supports 802.11i

(WPA/WPA2, AES), VPN pass

through

Provide mutual authentication (Client

and dynamic encryption keys to

enhance security)

Integrated modem (Annex A)

Fully compatible with the fastest

ADSL2+ connections up-to-date.

Sitecom Cloud Security

Protect your home against cybercrime

while browsing.

2Package Contents

Open the package carefully, and make sure that none of the items listed

below are missing. Do not discard the packing materials, in case of return;

the unit must be shipped back in its original package.

1. WLM-4501 modem/router

2. 110V~240V 12V 1A Power Adapter

3. Quick Install Guide

4. CD (User’s Manual)

5. Warranty card

6. U P cable

7. RJ11 cable

3Cautions

his router’s design and manufacturer has your safety in mind. In order to

safely and effectively use this router, please read the following before usage.

3.1 Usage Cautions

he user should not modify this router. he environmental temperature

should be within +5 ~ +35 degrees Celsius.

3.2 Power

he router’s power voltage is DC 12V 1A.

When using this router, please connect the supplied AC adapter or AC adapter

cable to the router’s power jack. When placing the adapter cable, make sure

it can not get damaged or be subject to pressure. o reduce the risk of

electric shock, unplug the adapter first before cleaning it. Never connect the

adapter to the router in a humid or dusty area. Do not replace the adapter or

cable’s wire or connector.

3.3 Repair

If the router has a problem, you should take it to an appointed repair centre

and let the specialists do the repair. Never repair the router yourself, you

might damage the router or endanger yourself.

3.4 Disposing of the Router

When you dispose of the router, be sure to dispose it appropriately. Some

countries may regulate disposal of an electrical device, please consult with

your local authority.

3.5 Others

When using this router, please do not let it come into contact with water or

other liquids. If water is accidentally spilled on the router, please use a dry

cloth to absorb the spillage. Electronic products are vulnerable, when using

please avoid shaking or hitting the router, and do not press the buttons too

hard.

- Do not let the router come into contact with water or other liquid.

- Do not disassemble the router, repair the router or change the design of the

router, any damage done will not be included in the repair policy.

- Avoid hitting the router with a hard object, avoid shaking the router and

stay away from magnetic fields.

- If during electrostatic discharge or a strong electromagnetic field the

product will malfunction, unplug the power cable. he product will return to

normal performance the next time it is powered on.

4Product Layout

Port

Description

ADSL Connect your telephone/ADSL cable this port

LAN Connect the cable from your PC or network device to

this ports.

Power connector

Connect your power adapter to this port.

Power button urn the modem On or Off.

Power connector

LAN / comp ter connections

Modem connection

WPS/Reset b tton

Power b tton

Back label

he back label describes the corresponding LED indications and port functionality.

LED Description

ower

Lights up when powered ON. Blinks on ES /RESE

ADSL

Lights up when an ADSL cable is connected.

Internet

Lights up when

internet connection is UP.

WLAN

Lights up in Blue when WLAN is enabled. Blinks on traffic

OPS

Blinks when OPS mode is on

LAN

1~4

When a

LAN

cable is connected the corresponding light lights up.

5System Requirements

o begin using the WLM-4501, make sure you meet the following as minimum

requirements:

•PC/Notebook.

•1 Free Ethernet port.

•Wi-Fi card/USB dongle (802.11 b/g/n) – optional.

•Annex A, ADSL internet connection.

•PC with a Web-Browser (Internet Explorer, Safari, Firefox, Opera)

•

Ethernet compatible CA 5 cables.

6LM-4501 Placement

You can place the WLM-4501 on a desk or other flat surface, or you can

mount it on a wall. For optimal performance, place your Wireless Broadband

Modem/Router in the center of your office (or your home) in a location that is

away from any potential source of interference, such as a metal wall or

microwave oven. his location must be close to a power connection and the

ADSL/phone line should not be over 2 meters long.

7Setup LAN, AN

Modem connection

LAN / comp ter connections
