Singer VC1120 Manual de usuario
GB
INSTRUCTION MANUAL
GR
ΒΙΒΛΙΟ ΟΔΗΓΙΩΝ
BG
ИНСТРУКЦИИ ЗА ЕКСПЛОАТАЦИЯ
Vacuum cleaner
Ηλεκτρική σκούπα
Електрическа прахосмукачка
VC1120
2
ENGLISH
SAFETY INSTRUCTIONS
When using your vacuum, basic safety precau-
tions should always be observed, including the
following:
1. Check if the voltage indicated on the appliance
corresponds to the local mains voltage before you
connect the appliance.
2. Do not use with damaged cord or plug. Do not use
vacuum cleaner if it has been dropped or dam-
aged, left outdoor or dropped into water. Return
appliance to a SINGER service center for exami-
nation repair or adjustment.
3. Do not use the machine without dust bag and fil-
ters properly fitted.
4. Do not leave vacuum cleaner unattended when it
is plugged in.
5. Unplug from outlet when not in use and before
pulling filters out.
6. To avoid the risk of electric shock-do not use out-
doors or on wet surfaces.
7. Do not allow children to use as a toy. Close atten-
tion is necessary when used near children.
8. Use only as described in this manual. Use only
3
ENGLISH
manufacturer’s recommended attachments.
9. Do not pull or carry by cord. Do not use the cord
as a handle. Do not close a door on cord, or pull
cord around sharp edges or corners. Do not run
appliance over cord. Keep cord away from heated
surfaces.
10. Do not unplug by pulling on cord. To unplug, grasp
the plug, not the cord.
11. Do not handle plug or vacuum cleaner with wet
hands.
12. Do not put any objects into air openings. Do not
use with any air openings blocked and do not re-
strict airflow. Keep all openings free of dust, lint,
hair, and anything that may reduce airflow.
13. Do not pick up hard or sharp objects such as glass,
nails, screws, coins, etc.
14. Do not pick up anything that it is burning or smok-
ing such as hot ashes, cigarette or matches.
15. Turn off all controls before plugging or unplugging
vacuum cleaner.
16. Use extra care when vacuuming on stairs.
17. Do not pick up toxic material (chlorine bleach, am-
monia, drain cleaner, etc.)
18. Do not use to pick up flammable or combustible
liquids, such as gasoline, or use in areas where
they may be present.
4
ENGLISH
19. Keep hair, loose clothing, fingers and all parts of
the body away from openings and moving parts.
20. Always unplug this appliance before connecting or
disconnecting vacuum flexible hose.
21. Do not allow plug to whip when rewinding.
22. Use only on dry, indoor surfaces.
23. Store your appliance indoor in a cool, dry area.
24. Do not immerse the machine into water or other
liquids.
25. Do not use the cleaner to clean your pets or any
animal.
26. Keep your face (eyes, ear, mouth, etc.) away from
the openings, when the vacuum is turned on.
27. All repairs must be carried out by an authorized
SINGER service center
28. Use only original dust bag, original filters and orig-
inal accessories from your local SINGER dealer.
Use of unauthorized dust bags and filters will void
the warranty.
29.The appliance may be used by children over the
age of 8 years and by persons with reduced physi-
cal, sensory or mental capacity or by persons with
a lack of experience or knowledge if they are su-
pervised or have been instructed on the safe use
of the appliance and the have understood the po-
tential dangers of using the appliance.
5
ENGLISH
30.Children must never play with the appliance.
31.Cleaning and user maintenance must never be
carried out by children without supervision.
32.Plastic bags and films must be kept out of the reach
of children before disposal. Risk of suffocation.
IMPORTANT SAFETY INSTRUCTIONS
1. This appliance is for household only. Only dry sur-
faces should be vacuumed. Do not vacuum build-
ing materials. The manufacturer cannot be held
responsible for damage caused by noncompliance
with the “Safety Instructions” and the warranty will
automatically be voided.
2. Do not vacuum toner dust. Toner, such as that used
in printers and photocopiers, can conduct electric-
ity.
3. To avoid danger of suffocation, keep packaging ma-
terial (plastic bags, box etc) away from babies and
children.
4. The partial or total non-respect of the safety instruc-
tions in the present instruction manual will automat-
ically release Singer of any type of responsibility
in case of malfunction of the machine or injuries to
persons or animals.
6
ENGLISH
5. In case of manipulation, repairing or any modifica-
tion of the machine made by unqualified persons
or in case of improper use, the guarantee will be
automatically cancelled.
SERVICE & REPAIR
1. For service or repair under warranty, please contact the authorized service company that is
mentioned on the guarantee card that accompanies the product.
2. Do not operate any product with a damaged cord or plug. If the supply cord is damaged,
return the appliance to a SINGER service center for examination repair or adjustment. Do
not attempt to dismantle any part of the appliance. This should only be done at an authorized
SINGER service center.
3. The partial or total non-respect of the safety instructions in the present instruction manual
will automatically release Singer of any type of responsibility in case of malfunction of the
machine or injuries to persons or animals.
4. In case of manipulation, repairing or any modification of the machine made by unqualified
persons or in case of improper use, the guarantee will be automatically canceled.
SAVE THESE INSTRUCTIONS
For household use only.
Singer reserves the right to change specifications and details are subject to change without
prior notice.
7
ENGLISH
DESCRIPTION OF THE APPLIANCE
Assembling the vacuum cleaner
Note: Do not plug the power cord into an electrical outlet until the vacuum is fully assembled.
1. Flexible hose
When installing the flexible hose, please hold the main suction pipe button, and aim at the air
inlet, then push till it is completely locked.
1. Suction power slide
2. Flexible hose
3. Telescopic tube
4. Length adjustment switch
5. Dust container cover release
button
6. Brush nozzle
7. On/off switch
8. Carry handle
9. Grooves for the floor brush
(storage position)
10. Suction power regulation
11. Power cord with power plug
12. Cable rewinder
13. Dust container cover
1
2
3
4
5
6
7
8
9
10
11
12 13
8
ENGLISH
2. Telescopic tube
For installing a telescopic tube, connect the telescopic tube part to the hand grip of the flexible hose.
Then, extend the telescopic tube by pushing forward on the plastic button and by pulling the inner
stainless steel telescopic tube outward.
Adjust the telescopic tube to the length of you find most comfortable during vacuuming.
3. Floor Brush
To connect the tube and floor brush, you push them together until they fit. You can use the floor brush
on the carpet or on hard floors.
Controls
Note: Once the vacuum is fully assembled, unwind a sufficient length of cable and insert the
plug into the electrical outlet. A yellow mark on the power cord shows the ideal cable length. Do
not pull the power cord beyond this mark.
1. Insert the power plug into the electrical outlet.
2. Press the on/off switch in order to start or stop the vacuum cleaner.
3. To rewind the power cord, press the cord rewind button with one hand and guide the power cord
with the other hand to ensure that it does not whip causing damage or injury.
4. You can adjust the suction power with the speed control button on the vacuum cleaner. Suction
can also be controlled using the airflow regulator on the handle: closed for maximum suction,
open for reduced suction.
Replacing the dust bag
When the indicator shows red, then it is the time to change the dust bag. Always unplug the ap-
pliance before you replace a dust bag or filter.
1. Remove the flexible hose.
2. Open the dust container cover by pushing the dust container cover release button.
3. Remove the dust bag from the holder
4. When inserting the new dust bag into the holder make sure to slide it in completely.
5. Close the dust container cover
WARNING: If the dust bag is not fixed to its proper position, the dust container cover cannot
be locked.
On/off button
Rewind button
Speed control button
9
ENGLISH
CLEANING/REPLACING OF FILTERS
Pre-motor filter- inside the appliance
1. Open the cover and pull the filter out of the appliance.
2. Clean or change the filter.
Note: The sponge filter material in the cleaner will become dusty over time. This is normal and
will not affect the performance of the filter. If the sponge filter is so dusty that suction does not
return to 100%, then we suggest that the filter be removed then rinsed with lukewarm water and
then allowed to dry by for 24 hours by airing not near the fire or some high temperature objects.
This should be done once six months or when suction appears to be reduced obviously.
All filters should be checked regularly, preferably after each cleaning task. The filters must be
replaced immediately if they become damaged. Always disconnect the vacuum from the electri-
cal outlet when checking the filters.
10
ENGLISH
MACHINE STORAGE AND MAINTENANCE
Cleaning of the appliance
- Always switch off and unplug the appliance before you clean any parts.
- Do not clean any part of the vacuum cleaner in the dishwasher, if necessary, clean the parts
with a moist cloth.
- Clean the appliance with a damp cloth.
Storage
1. Switch off the appliance and remove the mains plug from the wall socket.
2. Press the cord rewind button to rewind the cord.
3. This cleaner have a special feature for handle. There is a handle on the top. In addition,
another carry-handle is in front. You can use it to conveniently carry the cleaner when the
cleaner is in vertical position.
You can storage the appliance in 2 ways:
- Horizontal parking position: insert the ridge on the floor brush into the parking slot to park the
tube and then put the appliance away.
- Vertical parking position: insert the hook on the tubes into the parking slot underneath of the
appliance, and then put the appliance away.
Disposal of old Electrical & Electronic Equipment (Applicable in the European Union and other Eu-
ropean countries with separate collection systems).
This symbol on the product or on its packaging indicates that this product shall not be treated
as household waste. Instead it shall be handed over to the applicable collection point for the
recycling of electrical and electronic equipment. By ensuring this productis disposed of cor-
rectly, you will help prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of this product. The
recycling of materials will help to conserve natural resources. For more detailed information
about recycling of this product, please contact your local city office, your household waste
disposal service or the shop where you purchased the product.
