Simplicity Jack Manual de usuario

(The chances are you’re

never going to read me)

Owner’s Manual

www.simplicityvac.com

IMPORTANT SAFETY INSTRUCTIONS

When using an electrical appliance, basic precautions should always be followed, including

the following:

READ ALL INSTRUCTIONS BEFORE

USING THIS APPLIANCE

The manufacturer cannot accept responsibility for damage

caused when the appliance is not used according to the

instructions, or for uses other than those for which it

was intended.

To reduce the risk of fire, electric shock or injury:

• Do not leave appliance when plugged in.

Unplug from outlet when not in use and

before servicing.

• WARNING: ELECTRIC SHOCK COULD

OCCUR IF USED OUTDOORS OR ON

WET SURFACES.

• Do not allow to be used as a toy. Close

attention is necessary when used by or

near children.

• Use only as described in this manual.

Use only manufacturer’s recommended

attachments.

• Do not use with damaged cord or plug. If

appliance is not working as it should, has

been dropped, damaged, left outdoors,

or dropped into water, return it to your

Authorized Retailer for service.

• Do not pull or carry by cord, use cord as

a handle, close a door on the cord, or pull

cord around sharp edges or corners. Do

not run appliance over cord. Keep cord

away from heated surfaces.

• Do not unplug by pulling on cord. To

unplug, grasp the plug, not the cord.

• Hold plug when rewinding the power cord

to prevent the cord from whipping.

• Do not handle plug or appliance with

wet hands.

• Do not put any object into openings. Do

not use with any opening blocked; keep

free of dust, lint, hair and anything that

may reduce air ﬂow.

• Keep hair, loose clothing, ngers and all

parts of body away from openings and

moving parts.

• Do not pick up anything that is burning or

smoking, such as cigarettes, matches or

hot ashes.

• Do not use without vacuum bag in place.

• Turn off all controls before unplugging.

• Use extra care when cleaning on stairs.

• Do not use to pick up ammable or

combustible liquids such as gasoline or

use in areas where they may be present.

• Do not attempt to service the unit while

appliance is plugged in.

• Do not use vacuum to pick up water or

any wet materials.

SAVE THESE INSTRUCTIONS.

WARNING:

Contents

Safety Precautions 4

Replacing Vacuum Bag and Filters 5

Description and Operation 6-7

Troubleshooting Guide 8

Owner’s Information 9

Warranty 10

Safety Precautions

This vacuum cleaner should be used for normal, dry household dust and dirt. The manufacturer

cannot be held responsible for any damage caused by use or operation of the vacuum contrary

to these instructions. If the vacuum is wrongly operated for a purpose other than that for which

it is intended, no liability can be accepted for any possible damage.

• Do not vacuum areas which contain moisture or water, flammable matter, needles, pins,

razor blades, matches, cigarettes, etc., since they may damage the vacuum or vacuum bag.

• When rewinding the power cord, hold the plug before pressing the cord rewind button to

prevent the cord from whipping.

• Make sure a vacuum bag and filters are always in place.

• This product is equipped with a polarized alternating current line plug (a plug having one

blade wider than the other). This plug fits into the power outlet only one way. This is a safety

feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the

plug should still fail to fit, contact an electrician to replace the obsolete outlet. Do not defeat

the safety purpose of the polarized plug.

Replacing Vacuum Bag and Filters

Replacing the Vacuum Bag

Change the vacuum bag when the indicator is RED or

suction power is weak. The dust cover will not close without

a bag in the unit or if the bag is not properly installed.

1. Pull the bag holder straight out to access the bag.

2. Push the latch on the underside of the holder to release

the bag collar.

3. Remove and discard the used bag. NOTE: The genuine

HEPA bag cannot be reused.

4. Secure the new bag with the bag collar holder latch. Slide

the tab on the bag holder into the slot on the front of the

bag compartment.

Replacing the Secondary Filter

1. Open the bag compartment and locate the

filter behind the vacuum bag. For better

access to the secondary filter, remove the

bag holder and bag.

2. Slide filter holder up and out.

3. Remove the used filter and replace it with

a new filter.

4. Slide the filter holder back in place and

replace the bag holder and bag.

Replacing the HEPA Filter

1. Locate the HEPA filter inside the bag

compartment near the door hinge.

2. Press the black tab to remove the used filter

and snap in a new filter. NOTE: The HEPA

filter cannot be washed and reused.

At minimum, it’s recommended to replace the HEPA and charcoal filter after using

twelve vacuum bags.

If someone in your household is sensitive to airborne allergens, it is recommended to

change the filter set after every six vacuum bags.

When to Change Filters

Description and Operation

Storage

• Insert the tab on the neck of the wand into

either groove on canister body to store

the wand.

Hose Adapter

• To separate the hose

from the canister body,

press the buttons on

the hose adaptor and

pull it away from the

canister.

Wand

Handle

3-n-1 Tool

• This single tool conveniently converts

from a premium dusting brush to a

deluxe upholstery tool to a crevice tool.

• To clean and polish

tile, hard wood and

linoleum floors.

Bare Floor Tool with

Microfiber Pad

Dusting

Brush

Upholstery

Tool

Crevice

Tool

Power Control

Cleaning Tools Cord RewindOn/Off Switch

3-n-1 Tool

• This single tool conveniently converts

from a premium dusting brush to a

deluxe upholstery tool to a crevice tool.

Full Bag Indicator

• If the red indicator appears:

- Change the vacuum bag

- If the vacuum bag is

not full, but the full bag

indicator is red, check

the hose for a clog.

• When cleaning with a tool

(dusting brush, upholstery

tool or crevice tool), the red

indicator may appear. In this

case, continue cleaning.

• Lift here to access the

vacuum bag and filters.

Bag Compartment Latch

Troubleshooting Guide

Please check each item below if you have trouble with your vacuum.

Unplug the vacuum from the power supply before servicing.

Problem Check Point Possible Solution

Suction power is weak. Vacuum bag If vacuum bag is

full, replace it.

Wand or hose If clogged or blocked,

remove the object.

The vacuum does not work. Is the hose adapter inserted Insert it completely.

into the suction opening of the

vacuum completely?

When the vacuum bag is full Turn the vacuum off and

or any of the accessories are unplug the vacuuum.

blocked, the over-heating Check the vacuum

protection for the motor bag and accessories

is activated. and remove any

blockages. The

vacuum can be turned

on again after approximately

20 minutes.

Power cord does not rewind. Power cord Pull the power cord out a

little and press the cord

rewind button again.

Power cord won’t pull out of Power cord Do not pull it out by force.

the vacuum. Rewind it a little by

pressing the cord rewind

button and try pulling it

out again.

Model: Jack

Rating: 120V/60Hz

Amps: 10

Speciﬁcations

Owner’s Information (keep this for your records)

The model and serial number of this product may be found on the bottom of the unit. You

should note the model and serial number of your vacuum in the spaces provided below, and

retain this book as a permanent record of your purchase.

Date of purchase ____________________________________________________

Serial number _______________________________________________________

Model number ______________________________________________________

Purchased from:

Store name _______________________________________________________

Address _______________________________________________________

City, State, Zip ______________________________________________________

Telephone _______________________________________________________

For Best Performance:

• Keep your canister clean and in good operating condition.

• Change vacuum bags once a month or when the bag is 2/3 full to maximize

cleaning performance.

• Always use genuine vacuum bags and replacement parts. Use of other products may

result in poor cleaning performance, potential vacuum cleaner damage and may void

vacuum warranty. Genuine products are designed for maximum cleaning performance.

• Have your canister checked periodically by your Authorized Simplicity Retailer.

• Use only Authorized Simplicity Retailers for parts or service.

• Store your canister carefully in a dry area.

• For optimum cleaning performance and safety, follow your owner’s manual instructions.

Warranty

What is Covered:

This warranty covers any defects in material and workmanship in your new

Simplicity vacuum and applies exclusively to the original purchaser.

How Long Coverage Lasts:

Warranty coverage for the Simplicity Jack canister lasts two years. Household

models used commercially are only warranted for 90 days.

What is Not Covered:

• Damage to the vacuum which occurs from neglect, abuse, alterations,

accident, misuse or improper maintenance.

• Normal replacement items: lters and disposable bags.

What Simplicity Will Do:

This warranty provides, at no cost to you, all labor and parts to place this

vacuum in correct operating condition during the warranted period.

How to Get Service:

Warranty service can only be obtained by presenting the vacuum to an Authorized

Simplicity Retailer. A proof-of-purchase and product serial number will be required

before service is rendered. To locate your nearest Simplicity Retailer, please call

1-888-9-SIMPLY or visit the Simplicity website at www.simplicityvac.com.

THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ANY AND ALL OTHER

WARRANTIES WHETHER WRITTEN, ORAL, EXPRESSED OR IMPLIED,

(INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR

A PARTICULAR PURPOSE). THIS WARRANTY DISCLAIMS LIABILITY FOR

INCIDENTAL, OR CONSEQUENTIAL DAMAGES.

How State Law Applies:

This warranty gives you specic legal rights, and you may also have other

rights which vary from state to state.

Tabla de contenidos

Otros manuales de Aspiradora de Simplicity

Simplicity

Simplicity S65D Manual de usuario

Simplicity

Simplicity Symmetry Manual de usuario

Simplicity

Simplicity Synchrony S30P Manual de usuario

Simplicity

Simplicity Central Vacuum Power Units Manual de usuario

Simplicity

Simplicity S38 Manual de usuario

Simplicity

Simplicity S5 Manual de usuario

Simplicity

Simplicity Whoosh Manual de usuario

Simplicity

Simplicity Scout Plus Manual de usuario

Simplicity

Simplicity SCRS SCRD SCRP Manual de usuario

Simplicity

Simplicity Freedom S10E Manual de usuario

Simplicity

Simplicity Freedom F3300 Manual de usuario

Simplicity

Simplicity BRIO CANISTER Manual de usuario

Simplicity

Simplicity Symmetry S20S Manual de usuario

Simplicity

Simplicity Jessie Vacuum Bag and Filters Manual de usuario

Simplicity

Simplicity 7000 Series Manual de usuario

Simplicity

Simplicity 7 Series Manual de usuario

Simplicity

Simplicity a-go-go Manual de usuario

Simplicity

Simplicity SYNERGY X9.5 Manual de usuario

Simplicity

Simplicity SYMMETRY S20SC Manual de usuario

Simplicity

Simplicity S36 Manual de usuario

Simplicity

Simplicity Synergy X9 Manual de usuario

Simplicity

Simplicity S20 Manual de usuario

Simplicity

Simplicity Jill Manual de usuario

Simplicity

Simplicity WONDER Manual de usuario

Manuales populares de Aspiradora de otras marcas

Bissell

Bissell LittleGreen Proheat 1425 Series Manual de usuario

Panasonic

Panasonic MC-YL637S147-AE Manual de usuario

NEFF

NEFF N17XH10 0 Series Manual de usuario

LG A9 Series Manual de usuario

Oreck

Oreck Cordless Captura BK51700 Series Manual de usuario

Kogan

Kogan KAVACROBVWA Manual de usuario

Kränzle

Kränzle VENTOS 50 ID Guía del usuario

EVVO

EVVO Ai35 Manual de usuario

DeWalt

DeWalt DWH200D Manual de usuario

Pontec

Pontec Pondomatic Vacuum Cleaner Manual de usuario

Cleanmaxx

Cleanmaxx PC-P007E Manual de usuario

Exido

Exido 240-114 Manual de usuario

RIDGID

RIDGID WD1685AU0 Manual de usuario

Ezviz

Ezviz RE4P Manual de usuario

STG global

STG global TANVAC HDV3000 Manual de usuario

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manual de usuario

Factory

Factory M3340 Manual de usuario

Shop-Vac

Shop-Vac VN92 SERIES Manual de usuario
