Simplicity 1694376 Manual de usuario

Parts Manual

Rev. 04/2003

2005 Rapid

Series Lawn Tractor & Mower Deck

TP 400-3825-00-RG-UV

. No. Descri

tion

17HP Tractors

1694376 2005 Rapid, 17HP Hydro (CE)

. No. Descri

tion

Mower Decks

1694377 40" Mower Deck (CE)

Table Of Content

Torque Specification Chart ..................................................................... Inside Back Cover

TRACTOR / MOWER DECK COMPONENTS PAGES

Frame Group ......................................................................................................................... 4

Steering Group ...................................................................................................................... 6

Engine & Electric Clutch - 17HP Briggs & Stratton ................................................................ 8

Transmission Group .............................................................................................................. 12

Transmission SERVICE PARTS - Tuff Torq K-46Z Transaxle .............................................. 14

Controls Group ...................................................................................................................... 20

Electrical Group ..................................................................................................................... 22

Hood, Dash & Fuel Tank Group ............................................................................................ 24

Seat & Seat Deck Group ....................................................................................................... 26

Wheels & Tires Group ...........................................................................................................28

Decals Group - Safety & Common ........................................................................................ 30

40" Mower Deck - Belt, Idler Arm & Hitch Group ................................................................... 32

40" Mower Deck - Height Adjustment & Roller Bar ............................................................... 34

40" Mower Deck - Housing, Arbors & Blades ........................................................................ 38

Frame Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

Insert Must

Face Out

17 16

985858

The above parts group applies to the following Mfg. Nos.:

1694376 - 2005 Ra

TP 400-3825-00-RG-UV

PART NO. DESCRIPTIONREF NO QTY.

Frame Group

Footnotes

1 1723077 1 FRAME ASSEMBLY

2 1715015 1 PLUG, Hole

3 1714418 1 PAD, Footrest RH

4 1714417 1 PAD, Footrest LH

5 1704351 12 FASTENER, Panel

6 1935255 4 NUT, Speed 5/16-18

7 1930591 4 SCREW, Hex Head Flange Lock, 5/16-18 x 3/4

8 1723021 1 WRAPPER ASSEMBLY, Hydro

9 1920328 2 CAPSCREW, Hex Head, 1/2-13 x 1-1/2

10 1918431 3 WASHER, 1/2

11 1709235 1 SPACER

12 1930644 2 NUT, Hex , 1/2-13

13 1721013 1 CARRIER ASSEMBLY, Hydro

14 1717286 1 SPACER

15 1717424 1 BAR, Torsion

16 960641 1 NUT, Hex Lock Aluminum Insert, 3/8-16

17 1924356 1 WASHER, 3/8

18 176440 6 BUSHING, 3/4, Nylon

19 1719868 1 SPACER

20 1719869 1 HITCH, Hook "J"

21 1960614 1 CAPSCREW, Hex Head, 3/8-16 x 3

The above parts group applies to the following Mfg. Nos.:

1694376 - 2005 Ra

TP 400-3825-00-RG-UV

Steering Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

Note: See

Wheels & Tires

Group

985576B

The above parts group applies to the following Mfg. Nos.:

1694376 - 2005 Ra

TP 400-3825-00-RG-UV

PART NO. DESCRIPTIONREF NO QTY.

Steering Group

Footnotes

1 1713841 1 STEERING WHEEL ASSEMBLY, (Includes Ref. No. 2)

2 1714097 1 CAP, Steering Wheel

3 1714400 1 TUBE, Flex

4 1960540 1 PIN, Spring, 5/16 x 2-1/2

5 1719472 1 SHAFT ASSEMBLY, Steering

6 1931350 2 CARRIAGE BOLT, 3/8-16 x 1

7 1960114 4 WASHER, 3/4

8 1928352 2 NUT, Hex Flange Whiz Lock, 3/8-16

9 1920415 1 CAPSCREW, Hex Head 3/8-16 x 1-1/4

10 1922611 1 WASHER, 3/8

11 1713375 1 STEERING GEAR ASSEMBLY

12 1713469 1 DRAG LINK

13 1930645 3 NUT, Hex Flange Lock, 3/8-16

14 1611710 4 KLIPRING

15 1721472 1 ARM, Steering, LH

16 1960160 2 WASHER, 3/4

17 1721542 2 SPINDLE ASSEMBLY

18 1713791 2 SPACER

19 1919314 1 PIN, Cotter, 3/16 x 1-1/4

20 1713454 1 TIE ROD

21 1721473 1 ARM, Steering, RH

22 1960268 2 CARRIAGE BOLT, 3/8-16 x 1-1/4

23 1931335 1 CARRIAGE BOLT, 5/16-18 x 1

24 1710437 1 SPACER

25 1935048 1 NUT, Hex Flange Lock, 5/16-18

26 1664847 2 CAPSCREW, Taptite Hex Washer Head, 5/16-18 x 3/4

27 1666001 1 BUSHING

28 176440 1 BUSHING

29 1703508 1 PLATE, Steering, Mounting

The above parts group applies to the following Mfg. Nos.:

1694376 - 2005 Ra

TP 400-3825-00-RG-UV

Engine & Electric Clutch - 17HP Briggs & Stratton

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

RH Rear

RH Front

LH Front & LH Rear

29 28

15 14

21 23

E985943

The above parts group applies to the following Mfg. Nos.:

1694376 - 2005 Ra

TP 400-3825-00-RG-UV

PART NO. DESCRIPTIONREF NO QTY.

Engine & Electric Clutch - 17HP Briggs & Stratton

Footnotes

1 1708405 1 VALVE, Shut Off

2 920427 1 LOCKWASHER, External Tooth 3/8

3 916950 1 NUT, Hex 3/8-16

4 1723212 1 SEAL, Foam

5 * 1 ENGINE, 17HP B&S INTEK, Domestic, Model 31F770, Type 0110

5 * 1 ENGINE, 17HP B&S INTEK, Export, Model 31F777, Type 0111

6 173206 1 FUEL FILTER

7 960112 2 CLAMP

8 1718678 1 HOSE, 12" Long

9 1715897 1 KNOB, Slot

10 1960498 2 CAPSCREW, Hex 1/4-14 x 5/8

11 1707388 1 CONTROL, Throttle Cable

12 1704419 2 STOP, Belt

13 1930598 3 CAPSCREW, Hex Head Taptite, 3/8-16 x 1-1/2

14 905100 1 KEY

15 1723497 1 PULLEY & HUB ASSEMBLY, Engine

16 1933263 2 WASHER

17 960361 1 CAPSCREW, Hex Head Taptite, 3/8-16 x 2

18 1723213 1 SEAL, Foam

19 1708537 1 SLEEVE, Clutch Anchor

20 1717664 1 CLUTCH, Electric, OGURA

21 1708264 1 WASHER, Hex, Special

22 1918199 1 LOCKWASHER, 7/16

23 960631 1 CAPSCREW, Hex Head, 7/16-20 x 3

24 1701011 1 TIE, Wire

25 1935255 4 NUT, Speed 5/16-18

26 1717993 1 DUCT, Muffler, Lower

27 1930595 2 CAPSCREW, Hex Head Flange Lock, 5/16-18 x 1-1/4

28 1705248 2 PIVOT

29 1705249 2 SPACER

30 1723337 1 INSULATION, LH (Export)

31 1921333 1 CAPSCREW, Hex Head, 5/16-18 x 1

32 1919381 1 WASHER, 5/16

33 1930591 2 CAPSCREW, Hex Head Flange Lock 5/16-18 x 3/4

34 1723338 1 INSULATION, RH (Export)

35 1723336 1 INSULATION, Foam, 6 x 11-3/8 (Export)

36 1715006 1 DUCT, Muffler Upper, Domestic

36 1723086 1 DUCT, Muffler Upper, Export

37 1715509 1 STRAP, Torque (Export)

38 1919326 1 WASHER, 5/16

* See your local Briggs & Stratton dealer / distributor for parts and service.

The above parts group applies to the following Mfg. Nos.:

1694376 - 2005 Ra

TP 400-3825-00-RG-UV

Engine & Electric Clutch - 17HP Briggs & Stratton

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

RH Rear

RH Front

LH Front & LH Rear

29 28

15 14

21 23

E985943

The above parts group applies to the following Mfg. Nos.:

1694376 - 2005 Ra

TP 400-3825-00-RG-UV
