SimPal-S460
4G LTE Power Socket
User Manual
Manual version 1.0
SimPal-S460 User Manual
1
SimPal-S460 4G LTE Power Socket
Thank you for purchasin the SimPal-S460 power socket.
SimPal-S460 workin with 4G LTE SIM card, is a simple and powerful device to remote control
the power to the electrical devices or electrical outlets at home via SMS or app in mobile.
SimPal-S460 supports power meter function and power loadin monitor, can be used to monitor
connected device workin status. It will send SMS when connected device power consumption
abnormal. S460 come with built-in power capacitor and temperature sensor, functions as an
alarm durin a power failure or temperature deviations.
All services and functions need to be supported by the 4G network and a SIM card.
This brochure suits for SimPal-S460 model.
Details of the functionin and advanced operation of this socket are described in this instruction
manual.
SimPal-S460 User Manual
2
For your safety......................................................................................................................... 5
Exception clause...................................................................................................................... 7
1.1 Package contents............................................................................................................ 11
1.2 Sockets instructions........................................................................................................ 12
1.3 Light indicator.................................................................................................................. 14
2.1 ser authorization level..................................................................................................15
2.2 About the SMS Command............................................................................................. 16
3.1 Start to use....................................................................................................................... 16
3.2 Download “GSM Socket” APP.......................................................................................18
3.3 Register Master-number.................................................................................................19
3.3.1 Change Master number.............................................................................................. 19
3.4 Turn on/off power............................................................................................................ 21
3.5 Delay control the socket output..................................................................................... 22
SimPal-S460 User Manual
3
3.6 Schedule control..............................................................................................................23
3.7 Temperature control........................................................................................................ 26
3.8 Temperature alarm..........................................................................................................28
3.9 Power loading alarm....................................................................................................... 30
3.10 SMS when on/off button pressed................................................................................32
3.11 Power failure alarm....................................................................................................... 33
3.12 SMS notification to ser...............................................................................................33
3.13 Calling control settings................................................................................................. 34
3.14 Check status.................................................................................................................. 35
3.15 Weak GSM signal notification..................................................................................... 36
3.16 Resetting the socket..................................................................................................... 37
4. Main Technical Parameters..............................................................................................39
Appendi : SMS commands list........................................................................................ 40
SimPal-S460 User Manual
4
1. Purchase a GSM SIM card (mobile phone card) from GSM
network service provider and install it in the socket. This SIM
card number is referred as SimPal-S460 number on this
brochure.
2. The user needs to activate the Caller ID Presentation function
of SIM card, and deactivate PIN code of the SIM. Contact with
GSM network service provider for support.
SimPal-S460 User Manual
5
For your safety
This socket was desi ned for home or office use. Do not use it on the electrical
appliance which is for industry or business operation, for example, iatrical appliances,
lar e heaters and refri erates.
Before usin this socket, make sure that the mobile phones can be used well in the
area, otherwise, do not put this socket into operation.
The power consumption of the appliances connected with the socket cannot exceed
3500W and the current cannot exceed 16A.
The electrical appliance which power consumption is hi her than 1500W must be
rounded.
Do not make two plu s of socket short circuit.
Do not touch the socket jack by any metal objects or hand.
This socket was desi ned for indoor use. Don’t use it in wet, chemically a ressive or
dusty environment. Device workin temperature ran e is -10℃~+35℃, stop to use this
product when environment
temperature
out of workin ran e.
SimPal-S460 User Manual
6
Do not plu this socket in a row, only allow connect other electricity device on the
socket. (nicht hintereinander stecken, nur andere Strom eräte an der Steckdose
anschließen lassen).
Do not open the case unless maintenance needed.
Do not keep shakin or fall down this socket, otherwise it can be dama ed.
This socket is a wireless si nal transmission socket. Keep it away from electronic
equipment likely to interfere with the wireless si nals, in order to avoid si nals
interference.
Switch off this socket and mobile phone when enterin areas marked "Explosive",
"Mi ht explode", "Closed wireless transceiver sockets" etc.
Do not cast this socket in a fire, as this may cause explosion.
This socket should only be operated from power approved by the socket manufacturer.
The use of any other types of power may dama e the socket.
Keep the socket and its accessories out of the children reach.
SimPal-S460 User Manual
7
FCC Radiation E posure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
FCC Warnin
This device complies with Part 15 of the FCC Rules. Operation is subject to the followin
two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, includin interference that may cause undesired operation.
SimPal-S460 User Manual
8
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B
di ital device, pursuant to part 15 of the FCC Rules. These limits are desi ned to provide
reasonable protection a ainst harmful interference in a residential installation. This
equipment enerates uses and can radiate radio frequency ener y and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no uarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turnin the equipment off and on, the user is
encoura ed to try to correct the interference by one or more of the followin measures:
- Reorient or relocate the receivin antenna.
SimPal-S460 User Manual
9
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any chan es or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
