Silvercrest SPWS 180 B2 Manual de usuario

IAN 96202

TALKING SCALE SPWS 180 B2

TALKING SCALE

Operating instructions

CÂNTAR DE PERSOANE

CU FUNCŢIE VOCALĂ

Instrucţiuni de utilizare

ΦΩΝΗΤΙΚΗ ΖΥΓΑΡΙΑ

Οδηүίες χρήσης

OSOBNA VAGA KOJA GOVORI

Upute za upotrebu

SPRECHENDE PERSONENWAAGE

Bedienungsanleitung

GB / CY Operating instructions Page 1

HR Upute za upotrebu Stranica 11

RO Instrucţiuni de utilizare Pagina 21

GR / CY Οδηүίες χρήσης Σελίδα 31

DE / AT / CH Bedienungsanleitung Seite 41

- 1 -

Index Page

Overview of the appliance 2

Introduction 4

Intended Use 4

Items supplied 4

Description of the appliance 4

Technical Data 4

Safety instructions 5

Using the scale 7

Warning indicators 8

Replacing the batteries 8

Usage and safe-keeping 8

Cleaning 8

Troubleshooting 9

Disposal 9

Warranty and Service 10

Importer 10

Read the operating instructions carefully before using the device for the first time and preserve this booklet

for later reference. Pass this manual on to whoever might acquire the device at a future date.

- 2 -

Talking Scale

alking Scale

Overview of the appliance

Model 1

- 3 -

Model 2

- 4 -

Introduction

Congratulations on the purchase of your new appli-

ance.

You have clearly decided in favour of a quality pro-

duct. These operating instructions are a part of this

product. They contain important information in regard

to safety, use and disposal. Before using the product,

familiarise yourself with all of these operating and

safety instructions. Use the product only as described

and only for the specified areas of application. In ad-

dition, pass these documents on, together with the

product, to any future owner.

Intended Use

This scale is intended solely

• for use as a bathroom scale

• in a domestic environment.

This appliance is not intended for commercial or

industrial use.

Items supplied

Talking Scale

3 x Batteries Type AAA/Micro/LR03

Operating instructions

Before using the appliance for the first time, check

to ensure that the contents are complete and un-

damaged.

Description of the appliance

1Battery compartment

2Display

3Volume control

4Language button

5Safety glass

Technical Data

Maximum weighing capacity: 180 kg / 396 lb

Tolerance range: +/- 3%

Minimum measurable

weight/Minimum Weight: 3 kg / 6.6 lb

Division: 0.1 kg / 0.2 lb

Operating temperature: 10°C - 40°C

Power supply : 4.5 V =

Batteries: 3 x 1.5 V DC

(Type AAA/Micro/LR03)

Display for weak battery

Overload indicator

Error indicator

Abbreviations for the selected display

languages 2:

Display Language

GB English

HR Croatian

RO Romanian

GR Greek

BG Bulgarian

- 5 -

Safety instructions



Danger!

• Ensure that no liquids permeate into the scale, the display or the speaker. There is

a risk of receiving an electric shock!

• This appliance may be used by children aged 8 over and by persons with

reduced physical, sensory or mental capabilities or lack of experience and

knowledge, provided that they are under supervision or have been told how

to use the appliance safely and are aware of the potential risks. Children must

not play with the appliance. Cleaning and user maintenance tasks may not

be carried out by children unless they are supervised.



Warning!

• Do not place the scale in the immediate vicinity of sources of heat. The scale and

the display may only be operated at temperatures between 10° and 40°C.

Higher or lower temperatures can lead to malfunctions or to permanent damage.

• Never burden these bathroom scales with a weight of more than 180 kg /

396 lb! This could irreparably damage the scales.



Information regarding the handling of batteries

This appliance uses batteries. For your interaction with batteries, please take note

of the following:

Risk of explosion!

Do not throw batteries into a fire. Do not recharge the batteries.

- 6 -

• Never open batteries, never solder or weld batteries.

The risk of explosions and injuries exists!

• Regularly check the condition of the batteries. Leaking batteries can cause

damage to the appliance.

• If you do not intend to use the appliance for an extended period, remove the

batteries.

• In the event of the batteries leaking acids, put on a pair of protective gloves.

Then clean the battery compartment and the battery contacts with a dry cloth.

• In the event of skin contact with leaked battery acid, immediately rinse the

affected area with lots of clean water.

• Keep batteries away from children. Children can put batteries into their mouths

and swallow them. If a battery is swallowed, medical assistance must be

sought immediately.



Notice!

Avoid electrostatic charging and discharging. These can cause erroneous

displays and/or the sudden deactivation of the scales.

For damage caused by...

• opening of the scales housing

• repairs attempted by non-qualified personnel and

• improper usage of the scales

no liability/warranty will be accepted by the manufacturer!

- 7 -

Using the scale

1. Open the battery compartment 1. Insert the

batteries as per the polarity diagram in the

battery compartment 1.

2. Close the battery compartment 1. The battery

compartment lid must audibly engage.

3. Place the scale on a flat and stable surface.

Ensure that neither the floor at the location of the

scale nor the upper surface of the scale are wet,

otherwise there is a risk of slipping!



Notice!

This scale contains sensitive electronic components

and it should therefore NOT be located:

• close to sources of heat

• in environments with extreme air humidity.

Attention:

Never burden the scales one-sidedly.

Always step onto the scales in the

middle and with both feet. Otherwise,

the scales could tip and become irre-

parably damaged. Additionally, there

is the risk of falling over!

Attention:

Never use the scale if it is wet or moist.

Never step onto the scale with wet or

moist feet. There would be a serious

risk of slipping and personal injury!



Attention:

NEVER jump onto the glass scale, this could irre-

parably damage it.

4. Stand briefly on the scales so that the device

turns itself on.

5. Press the language button 4repeatedly until the

desired language appears on the left of the dis-

play 2.

6. Set the desired volume level using the volume

control 3. To deactivate the voice, turn the

volume control 3towards the "-" until you hear

a click.



Notice!

The language and the sound volume must only be

adjusted on the first use.

7. Stand with both feet on the scales. Stand as still

as possible and without displacing your weight.

8. During the weighing process (about 5 seconds)

the displayed value increases until your weight

is determined.

9. When your weight is determined, the result blinks

twice on the display 2and it speaks your deter-

mined weight.

After you have stepped down from the scale it

sounds "Ready for operation" and you can then

start another measurement.

If you simply wait, the scale will indicate by a dou-

ble beep that it has switched itself off.

68.8

- 8 -

Warning indicators

Should your weight exceed the maximum weighing

capacity of 180 kg / 396 lb, "0 - Ld" is shown in the

display 2. You should IMMEDIATELY step down

from the scale, otherwise it could be damaged.

If the display 2shows "L0" and "Low Battery"

sounds, you must replace the batteries.

If the display 2shows "Err" and "Error" sounds, the

scale cannot measure. In this case, step down from

the scale, wait a few seconds and then try again.

Take note that you need to both stand still and not

interrupt the weighing procedure.

Replacing the batteries

1. Open the battery compartment 1and remove

the batteries.

2. Insert 3 new batteries of the type Micro/AAA/

LR03 as per the polarities specified in the bat-

tery compartment 1.

3. Close the battery compartment 1. The battery

compartment lid must click in audibly.

Usage and safe-keeping

• Avoid unnecessary battery discharge.

Accordingly, do not place objects on the glass

scale when it is not being used.

Remove the batteries if you do not intend to use

the scale for an extended period.

• Keep the scale at a clean and dry location.

• Avoid electrostatic charging.

• Your scale is a sensitive electronic device. As such,

it can occasionally be disturbed by other high-

frequency appliances that are being operated in

the immediate vicinity (e.g. mobile telephones,

CB radio stations, radio remote controls and

microwave ovens).

Should irregular or inaccurate errors be indicated

in the display 2, either remove the scale from the

source of the disturbance or switch the source of the

disturbance off whilst you are using the appliance.

Cleaning

Clean your scale exclusively with a neutral detergent

and a soft cloth.
