Silvercrest STK 36 B2 Especificaciones técnicas

WIRELESS DOORBELL STK 36 B2

IAN 295968

WIRELESS DOORBELL

Assembly, operating and safety instructions

BEŽIČNO ZVONO

Szerelési, használati és biztonsági tudnivalók

SONERIE WIRELESS

Navodila za montažo, uporabo in varnostna

navodila

БЕЗЖИЧЕН ЗВЪНЕЦ

Pokyny k montáži, obsluze a bezpečnostní

pokyny

FUNKTÜRKLINGEL

Montage-, Bedienungs- und Sicherheitshinweise

ΑΣΎΡΜΑΤΟ ΚΟΎΔΟΎΝΙ

ΠΟΡΤΑΣ

okyny pre montáž, obsluhu a bezpečnostné

pokyny

GB Assembly, operating and safety instructions Page 5

HU Szerelési, használati és biztonsági tudnivalók Oldal 21

SI Navodila za montažo, uporabo in varnostna navodila Stran 37

CZ Pokyny k montáži, obsluze a bezpečnostní pokyny Strana 54

SK Pokyny pre montáž, obsluhu a bezpečnostné pokyny Strana 69

DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 85

Il vous faut

U hebt nodig

Sie benötigen:

ø 6mm

HG03569

109

GB 5

Introduction...................................................................................... Page 6

Intended use ........................................................................................... Page 6

Technical data ........................................................................................ Page 6

Included items......................................................................................... Page 7

Parts and features................................................................................... Page 8

Safety..................................................................................................... Page 9

General safety information .................................................................... Page 9

Safety instructions for batteries/ rechargeable batteries..................... Page 10

Assembly ............................................................................................ Page 12

Preparing for use ........................................................................ Page 13

Inserting/ replacing the batteries .......................................................... Page 13

Operation........................................................................................... Page 14

Synchronising transmitter/ receiver....................................................... Page 14

Setting the signal type............................................................................ Page 15

Setting the volume .................................................................................. Page 16

Selecting the chime................................................................................. Page 16

Troubleshooting...................................................................................... Page 16

Cleaning and maintenance................................................. Page 17

Disposal................................................................................................ Page 17

Information....................................................................................... Page 19

Simplified EU declaration of conformity................................................ Page 19

Warranty............................................................................................ Page 19

GB6

Wireless Doorbell

Introduction

We congratulate you on the purchase of your new product.

You have chosen a high quality product. The instructions for

use are part of the product. They contain important informa-

tion concerning safety, use and disposal. Before using the product,

please familiarise yourself with all of the safety information and instruc-

tions for use. Only use the product as described and for the speciﬁed

applications. If you pass the product on to anyone else, please ensure

that you also pass on all the documentation with it.

Intended use

This product is intended for the wireless transmission of the doorbell

chime. The product is not intended for commercial use.

Technical data

Range: 150m (unobstructed area)

Transmission frequency: 433MHz

GB 7

Transmitting power: <10dBm

Battery types: Receiver: 2x 1.5V (direct current)

(type AA/LR6),

Transmitter: 1x 3 V (direct current)

(type CR2032)

Receiver: Audible signal volume (at maximum volume

setting): min. 73dB (at a distance of 1 m

from the device)

Transmitter: IP rating: IP44

Included items

1 Transmitter

1 Receiver

2 Batteries 1.5V (direct current), type AA (receiver)

1 Batteries 3V (direct current), type CR2032 (transmitter)

4 Screws (for transmitter and for mounting the receiver on a wall)

3 Dowels

5 Exchangeable name plates (for the doorbell)

1 Doorbell cover

1 Operating instructions

GB8

Parts and features

Receiver (Figs. A/B):

1Signal indicator

2Speaker

3Signal type selector button (optical, acoustic, optical and acoustic

signal)

4Melody selection button

5Stand

6Volume button

7Synchronisation button

8Hanger

9Battery compartment

10 Battery compartment cover

Transmitter (Figs. C/D):

11 Chime button

12 Signal indicator

13 Name plate

14 Battery compartment

15 Holder (for wall mounting)

Mounting (Figs. E/ F):

16 Screw

17 Dowel

GB 9

18 Screw (for transmitter)

19 Protective foil

Safety

Read all safety information and instructions. Failure

to comply with the safety information and instructions may cause ﬁre

and/ or serious injury.

YOU SHOULD STORE ALL SAFETY INFORMATION AND

INSTRUCTIONS IN A SAFE PLACE IN CASE YOU NEED TO REFER

TO THEM AGAIN IN THE FUTURE!

General safety information

Children often underestimate risks.

Always keep children away from the product. This is not

a toy.

This product can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they have been given super-

vision or instruction concerning use of the product in a safe way and

understand the hazards involved. Children shall not play with the

GB10

product. Cleaning and user maintenance shall not be made by chil-

dren without supervision.

Check that all parts are in sound condition. If you use damaged

parts when assembling the product, you risk injury.

Check that all parts have been assembled correctly. There is a risk

of injury if the product is not properly assembled.

Keep the product away from open ﬂames or sources of heat (e.g.

burning candles).

Safety instructions for batteries /

rechargeable batteries

DANGER TO LIFE! Keep batteries/ rechargeable batteries out of

reach of children. If accidentally swallowed seek immediate medical

attention.

DANGER OF EXPLOSION! Never recharge non-

recharge

able batteries. Do not short-circu

it batteries/

rechargeable batteries and/or open them. Overheating,

ﬁre or bursting can be the result.

Never throw batteries/ rechargeable batteries into ﬁre or water.

Do not exert mechanical loads to batteries/rechargeable batteries.
