C8051F30x-DK

C8051F30XDEVELOPMENT KIT USER’SGUIDE

1. Kit Contents

The C8051F30x Development Kit contains the following items:

• C8051F30x Target Board

• C8051Fxxx Development Kit Quick-Start Guide

• Silicon Laboratories IDE and Product Information CD-ROM. CD content includes:

• Silicon Laboratories Integrated Development Environment (IDE)

• Keil Software 8051 Development Tools (macro assembler, linker, evaluation ‘C’ compiler)

• Source code examples and register definition files

• Documentation

• C8051F30x Development Kit User’s Guide (this document)

• AC to DC Power Adapter

• USB Debug Adapter (USB to Debug Interface)

• USB Cable

2. Hardware Setup using a USB Debug Adapter

The target board is connected to a PC running the Silicon Laboratories IDE via the USB Debug Adapter as shown

in Figure 1.

1. Connect the USB Debug Adapter to the DEBUG connector on the target board with the 10-pin ribbon cable.

2. Connect one end of the USB cable to the USB connector on the USB Debug Adapter.

3. Connect the other end of the USB cable to a USB Port on the PC.

4. Connect the ac/dc power adapter to power jack P1 on the target board.

Notes:

• Use the Reset button in the IDE to reset the target when connected using a USB Debug Adapter.

• Remove power from the target board and the USB Debug Adapter before connecting or disconnecting the

ribbon cable from the target board. Connecting or disconnecting the cable when the devices have power can

damage the device and/or the USB Debug Adapter.

Figure 1. Hardware Setup using a USB Debug Adapter

USB

Cable

USB Debug Adapter

AC/DC

Adapter

Target Board

SILICON LABORATORIES

PWR

P1.6

P3.7RESET

Port 4Port 3Port 1

Port 2 Port 0

MCU

Silicon Laboratories

USB DEBUG ADAPTER

Run

StopPower

C8051F30x-DK

2 Rev. 0.5

3. Software Setup

The included CD-ROM contains the Silicon Laboratories Integrated Development Environment (IDE), Keil software

8051 tools and additional documentation. Insert the CD-ROM into your PC’s CD-ROM drive. An installer will auto-

matically launch, allowing you to install the IDE software or read documentation by clicking buttons on the Installa-

tion Panel. If the installer does not automatically start when you insert the CD-ROM, run autorun.exe found in the

root directory of the CD-ROM. Refer to the readme.txt file on the CD-ROM for the latest information regarding

known IDE problems and restrictions.

4. Silicon Laboratories Integrated Development Environment

The Silicon Laboratories IDE integrates a source-code editor, source-level debugger and in-system Flash program-

mer. The use of third-party compilers and assemblers is also supported. This development kit includes the Keil

Software A51 macro assembler, BL51 linker and evaluation version C51 ‘C’ compiler. These tools can be used

from within the Silicon Laboratories IDE.

4.1. System Requirements

The Silicon Laboratories IDE requirements:

• Pentium-class host PC running Microsoft Windows 98SE or later.

• One available COM or USB port.

• 64 MB RAM and 40 MB free HD space recommended.

4.2. Assembler and Linker

A full-version Keil A51 macro assembler and BL51 banking linker are included with the development kit and are

installed during IDE installation. The complete assembler and linker reference manual can be found under the Help

menu in the IDE or in the “SiLabs\MCU\hlp” directory (A51.pdf).

4.3. Evaluation C51 ‘C’ Compiler

An evaluation version of the Keil C51 ‘C’ compiler is included with the development kit and is installed during IDE

installation. The evaluation version of the C51 compiler is the same as the full professional version except code

size is limited to 4K bytes and the floating point library is not included. The C51 compiler reference manual can be

found under the Help menu in the IDE or in the “SiLabs\MCU\hlp” directory (C51.pdf).

4.4. Using the Keil Software 8051 Tools with the Silicon Laboratories IDE

To perform source-level debugging with the IDE, you must configure the Keil 8051 tools to generate an absolute

object file in the OMF-51 format with object extensions and debug records enabled. You may build the OMF-51

absolute object file by calling the Keil 8051 tools at the command line (e.g. batch file or make file) or by using the

project manager built into the IDE. The default configuration when using the Silicon Laboratories IDE project

manager enables object extension and debug record generation.

Refer to Applications Note

AN104 -

Integrating

Keil 8051 Tools Into the Silicon Labs IDE

in the “SiLabs\MCU\Documentation\Appnotes” directory on the CD-

ROM for additional information on using the Keil 8051 tools with the Silicon Laboratories IDE.

To build an absolute object file using the Silicon Laboratories IDE project manager, you must first create a project. A

project consists of a set of files, IDE configuration, debug views, and a target build configuration (list of files and tool

configurations used as input to the assembler, compiler, and linker when building an output object file).

The following sections illustrate the steps necessary to manually create a project with one or more source files, build

a program and download the program to the target in preparation for debugging. (The IDE will automatically create a

single-file project using the currently open and active source file if you select

Build/Make Project

before a project is

defined.)

C8051F30x-DK

Rev. 0.5 3

4.4.1. Creating a New Project

1. Select Project→New Project to open a new project and reset all configuration settings to default.

2. Select File→New File to open an editor window. Create your source file(s) and save the file(s) with a rec-

ognized extension, such as .c, .h, or .asm, to enable color syntax highlighting.

3. Right-click on “New Project” in the Project Window. Select Add files to project. Select files in the file

browser and click Open. Continue adding files until all project files have been added.

4. For each of the files in the

Project

Window

that you want assembled, compiled and linked into the target

build, right-click on the file name and select

Add file to build

. Each file will be assembled or compiled as

appropriate (based on file extension) and linked into the build of the absolute object file.

Note:

If a project contains a large number of files, the “Group” feature of the IDE can be used to organize.

Right-click on “New Project” in the

Project Window

. Select

Add Groups to project

. Add pre-defined

groups or add customized groups. Right-click on the group name and choose

Add file to group

. Select files

to be added. Continue adding files until all project files have been added.

4.4.2. Building and Downloading the Program for Debugging

1. Once all source files have been added to the target build, build the project by clicking on the Build/Make

Project button in the toolbar or selecting Project→Build/Make Project from the menu.

Note: After the project has been built the first time, the Build/Make Project command will only build the

files that have been changed since the previous build. To rebuild all files and project dependencies, click

on the Rebuild All button in the toolbar or select Project→Rebuild All from the menu.

Before connecting to the target device, several connection options may need to be set.

Open the

Connection Options

window by selecting

Options

→

Connection Options...

in the IDE menu. First, select

the appropriate adapter in the “Serial Adapter” section. Next, the correct “Debug Interface” must be selected.

C8051F30x

family devices use the Silicon Labs 2-wire (C2) debug interface. Once all the selections are

made, click the OK button to close the window.

3. Click the

Connect

button in the toolbar or select

Debug

→

Connect

from the menu to connect to the device.

4. Download the project to the target by clicking the Download Code button in the toolbar.

Note: To enable automatic downloading if the program build is successful select Enable automatic con-

nect/download after build in the Project→Target Build Configuration dialog. If errors occur during the

build process, the IDE will not attempt the download.

5. Save the project when finished with the debug session to preserve the current target build configuration,

editor settings and the location of all open debug views. To save the project, select Project->Save Project

As... from the menu. Create a new name for the project and click on Save.

C8051F30x-DK

4 Rev. 0.5

4.5. Example Source Code

Example source code and register definition files are provided in the “SiLabs\MCU\Examples\

C8051F30x

” directory

during IDE installation. These files may be used as a template for code development. Example applications include

a blinking LED example which configures the green LED on the target board to blink at a fixed rate.

4.6. Register Definition Files

status bits. They are installed into the “SiLabs\MCU\Examples\C8051F30x” directory during IDE installation. The

also installed in the default search path used by the Keil Software 8051 tools. Therefore, when using the Keil 8051

tools included with the development kit (A51, C51), it is not necessary to copy a register definition file to each

project’s file directory.

4.7. Blinking LED Example

The example source files blink.asm and blinky.c show examples of several basic C8051F300 functions. These

include; disabling the watchdog timer (WDT), configuring the Port I/O crossbar, configuring a timer for an interrupt

routine, initializing the system clock, and configuring a GPIO port. When compiled/assembled and linked this pro-

gram flashes the green LED on the C8051F300 target board about five times a second using the interrupt handler

with a C8051F300 timer.

C8051F30x-DK

Rev. 0.5 5

5. Target Board

The

C8051F30x

Development Kit includes a target board with a

C8051F30x

device pre-installed for evaluation and

preliminary software development. Numerous input/output (I/O) connections are provided to facilitate prototyping

using the target board. Refer to Figure 2 for the locations of the various I/O connectors.

P1 Power connector (accepts input from 7 to 15 VDC unregulated power adapter)

J1 34-pin Expansion I/O connector

J3 Port I/O Configuration Header

J4 DEBUG connector for Debug Adapter interface

J5 DB-9 connector for UART0 RS232 interface

J6 Analog I/O terminal block

J7 Low pass filter connector

J9, J10 External crystal enable connectors

Figure 2. C8051F300 Target Board

RESET P0.3

PWR

DEBUG

Pin 1

Prototyping Area

I/O Connection Points

C8051F30x

P0.2

Pin 1

Pin 2

Pin 1

C8051F30x-DK

6 Rev. 0.5

5.1. System Clock Sources

The

C8051F300

device installed on the target board features a calibrated programmable internal oscillator which is

enabled as the system clock source on reset. After reset, the internal oscillator operates at a frequency of

3.0625MHz (+/-2%) by default but may be configured by software to operate at other frequencies. Therefore, in

many applications an external oscillator is not required. However, if you wish to operate the C8051F300 device at a

frequency not available with the internal oscillator, an external crystal may be used. Refer to the

C8051F30x

data

sheet for more information on configuring the system clock source.

The target board is designed to facilitate the installation of an external crystal. Remove resistors R7 and R8 and

install the crystal at the pads marked Y1. Install a 10 MΩresistor at R9 and install capacitors at C14 and C15 using

values appropriate for the crystal you select. Refer to the C8051F30x data sheet for more information on the use of

external oscillators.

5.2. Switches and LEDs

Two switches are provided on the target board. Switch SW1 is connected to the RESET pin of the C8051F300.

Pressing SW1 puts the device into its hardware-reset state. Switch SW2 is connected to the C8051F300’s general

purpose I/O (GPIO) pin through headers. Pressing SW2 generates a logic low signal on the port pin. Remove the

shorting block from the header to disconnect SW2 from the port pins. The port pin signal is also routed to a pin on

the J1 I/O connector. See Table 1 for the port pins and headers corresponding to each switch.

Two LEDs are also provided on the target board. The red LED labeled PWR is used to indicate a power connection

to the target board. The green LED labeled with a port pin name is connected to the C8051F300’s GPIO pin

through headers. Remove the shorting block from the header to disconnect the LED from the port pin. The port pin

signal is also routed to a pin on the J1 I/O connector. See Table 1 for the port pins and headers corresponding to

each LED.

Table 1. Target Board I/O Descriptions

Description I/O Header

SW1 Reset none

SW2 P0.3 J3[3-4]

Green LED P0.2 J3[1-2]

Red LED PWR none

C8051F30x-DK

Rev. 0.5 7

5.3. Expansion I/O Connector (J1)

The

-pin Expansion I/O connector J1 provides access to all signal pins of the C8051F300 device. Pins for +3V, dig-

ital ground and the output of an on-board low-pass filter are also available. A small through-hole prototyping area is

also provided. All I/O signals routed to connector J1 are also routed to through-hole connection points between J1

and the prototyping area (see

Figure 2 on page 5

). Each connection point is labeled indicating the signal available at

the connection point. See Table 2 for a list of pin descriptions for J1.

5.4. Target Board DEBUG Interface (J4)

The

DEBUG

connector (J4) provides access to the

DEBUG

(C2) pins of the C8051F300. It is used to connect the

Serial Adapter to the target board for in-circuit debugging and Flash programming. Table 3 shows the

DEBUG

definitions.

Table 2. J1 Pin Descriptions

Pin # Description

1 +3VD (+3.3VDC)

2 PWM Output

3P0.0

4P0.1

5P0.2

6P0.3

7P0.4

8P0.5

9P0.6

10 P0.7

11 GND (Ground)

12 /RST (Reset)

Table 3. DEBUG Connector Pin Descriptions

Pin # Description

1 +3VD(+3.3VDC)

2, 3, 9 GND (Ground)

4C2D

5/RST(Reset)

6P3.0

7C2CK

8,10 Not Connected

C8051F30x-DK

8 Rev. 0.5

5.5. Serial Interface (J5)

A RS232 transceiver circuit and DB-9 (J5) connector are provided on the target board to facilitate serial connec-

tions to UART0 of the C8051F300. The TX, RX, RTS and CTS signals of UART0 may be connected to the DB-9

connector and transceiver by installing shorting blocks on headers J3.

J3[5–6] - Install shorting block to connect UART0 TX (P0.4) to transceiver.

J3[7–8] - Install shorting block to connect UART0 RX (P0.5) to transceiver.

J3[9–10] - Install shorting block to connect UART0 RTS (P0.2) to transceiver.

J3[11–12] - Install shorting block to connect UART0 CTS (P0.3) to transceiver.

5.6. Analog I/O (J6)

Several of the C8051F300 target device’s port pins are connected to the J6 terminal block. Refer to Table 4 for the

J6 terminal block connections. Install a shorting block on J7[2-3] to connect the AIN6 input to the P0.6 pin of the

target device.

5.7. Low-Pass Filter (J7)

The C8051F300 target board features a low-pass filter that may be connected to port pin P0.6. Install a shorting

block on J7[1-2] to connect the P0.6 pin of the target device to the low-pass filter input. The output of the low-pass

filter is routed to the PWM signal at J1[2]. The C8051F300 may be programmed to generate a PWM (Pulse-Width

Modulated) waveform which is then input to the low-pass filter to implement a user-controlled PWM digital-to-ana-

log converter. Refer to Applications Note “AN107: Implementing 16-Bit PWM Using the PCA” in the “documenta-

tion” directory on the CD-ROM for a discussion on generating a programmable dc voltage level with a PWM

waveform and low-pass filter.

Table 4. J6 Terminal Block Pin Descriptions

Pin # Description

1 P0.1 / AIN1 (ADC input 1)

2 AIN6 (ADC input 6)

3 GND (Ground)

4 P0.0 / Vref (Voltage Reference)

C8051F30x-DK

Rev. 0.5 9

6. Schematic

Figure 3. C8051F300TB Schematic

C8051F30x-DK

10 Rev. 0.5

DOCUMENT CHANGE LIST

Revision 0.3 to Revision 0.4

Section 1, added USB Debug Adapter and USB Cable.

Section 2, changed name from "Hardware Setup" to "Hardware Setup using an EC2 Serial Adapter".

Section 2, added 2 Notes bullets.

Section 2, removed Note from bottom of page.

Added Section 3, "Hardware Setup using a USB Debug Adapter".

Section 5.4.2, changed step 2 to include new instructions.

Section 7, J4, changed "Serial Adapter" to "Debug Adapter".

Target Board DEBUG Interface Section, added USB Debug Adapter.

DEBUG Connector Pin Descriptions Table, changed pin 4 to C2D.

Changed "jumper" to "header".

EC2 Serial Adapter section, added EC2 to the section title, table title and figure title.

EC2 Serial Adapter section, changed "JTAG" to "DEBUG".

Added "USB Debug Adapter" section.

Revision 0.4 to Revision 0.5

Removed EC2 Serial Adapter from Kit Contents.

Removed Section 2. Hardware Setup using an EC2 Serial Adapter. See RS232 Serial Adapter (EC2) User's

Guide.

Removed Section 8. EC2 Serial Adapter. See RS232 Serial Adapter (EC2) User's Guide.

Removed Section 9. USB Debug Adapter. See USB Debug Adapter User's Guide.

Otros manuales para C8051F30 series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Microcontrolador de Silicon Laboratories

Silicon Laboratories

Silicon Laboratories C8051F31 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051xxxDK Series Manual de usuario

Silicon Laboratories

Silicon Laboratories EFM32TG Manual de usuario

Silicon Laboratories

Silicon Laboratories Si1010 Manual de usuario

Silicon Laboratories

Silicon Laboratories EFM32G Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F02 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F41 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories Telegesis ETRX357DVK Manual de usuario

Silicon Laboratories

Silicon Laboratories UG346: BGM13S32 Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F02x-DK Manual de usuario

Silicon Laboratories

Silicon Laboratories CP2400-DK Manual de usuario

Silicon Laboratories

Silicon Laboratories EZR32WG Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F38 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F36 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories UG338 Manual de usuario

Silicon Laboratories

Silicon Laboratories EFM8BB3-SLSTK2022A Manual de usuario

Silicon Laboratories

Silicon Laboratories EFM8UB1-SLSTK2000A Manual de usuario

Silicon Laboratories

Silicon Laboratories EM35 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F300 Manual de usuario

Silicon Laboratories

Silicon Laboratories CP2102N-MINIEK Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F310-TB Manual de usuario

Silicon Laboratories

Silicon Laboratories Giant Gecko EFM32GG Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F58 Series Manual de usuario

Silicon Laboratories

Silicon Laboratories C8051F120 Manual de usuario

Manuales populares de Microcontrolador de otras marcas

AMS

AMS AS7261 Demo Kit Manual de usuario

Novatek

Novatek NT6861 Manual de usuario

Espressif Systems

Espressif Systems ESP8266 SDK Guía de configuración

Nuvoton

Nuvoton ISD61S00 ChipCorder Guía

STMicrolectronics

STMicrolectronics ST7 Assembler Linker Manual de usuario

Texas Instruments

Texas Instruments Chipcon CC2420DK Manual de usuario

Lantronix

Lantronix Intrinsyc Open-Q 865XR SOM Manual de usuario

NEC

NEC 78GK0S/K 1+ Series Instrucciones de instalación y funcionamiento

Mikroe

Mikroe SEMITECH N-PLC Click Instrucciones de instalación y funcionamiento

Intel

Intel Agilex Manual de usuario

Cypress

Cypress CY4607 HX2VL Manual de usuario

DIGITAL-LOGIC

DIGITAL-LOGIC MICROSPACE Manual de usuario

Texas Instruments

Texas Instruments TMS320F2837 D Series Manual de usuario

CYPRES

CYPRES CY14NVSRAMKIT-001 Manual de usuario

Texas Instruments

Texas Instruments INA-DUAL-2AMP-EVM Manual de usuario

Espressif Systems

Espressif Systems ESP8266EX Instrucciones de funcionamiento

Abov

Abov AC33M8128L Manual de usuario

Laird

Laird BL654PA Manual de usuario
