Introducing the HDMI Extender

The HDMI Extender over 2 CAT5e with IR boosts your

audio/video transmission distance up to 60m (200ft) in

HDTV 1080i format. With two cost effective CAT5e/6

cables, users can readily extend an HDMI source such as

a DVD player, Blu-ray Disc player, game console, PC,

and any other TMDS compliant devices to a remote

HDMI/DVI TV or LCD monitor. This cost effective

solution provides flexibility for HDMI enabled devices

to transmit high quality audio/video to greater distances

at minimal cost.

FeaturesandBenefits

•HDMI 1.3a and HDCP compliant

•Extends audio/video transmission from an HDMI

source to an HDMI display over two economical

CAT5e/6 cables

•Controls source devices from the remote side

instantly

•Embedded IR control path

•Minimize cable skew with the adjustable 8-level

equalization knob

•Supports distances up to 60m/200ft @ 720p/1080i

or 40m/130ft @ 1080p

04-0508A

HDMI Extender over 2

CAT5e with IR

Quick Installation Guide

PackageContents

•HDMI transmitter (TX)

•HDMI receiver (RX)

• 1xPoweradapter(5V,4A)

•IR transmitter extension cable (90cm/3ft)

•IR receiver extension cable (90cm/3ft)

•Quick Installation Guide

Layout

Figure 1: Transmitter (front & back)

• HDMI In: connect to a HDMI source with an HDMI

M-M cable (not included) here

• IR Extender: this is the IR sending socket, connect

the IR transmitter extension cable here

• TMDS: plug in a CAT5e/6 cable, links to the TMDS

connector of the receiving unit

• DDC: plug in a CAT5e/6 cable, links to the DDC

connector of the receiving unit

Figure 2: Receiver (front & back)

• HDMIOut:connectanHDMIdisplaywithanHDMI

M-M cable (not included) here

• EQ: adjusts the equilization of the received signal

from 0 (strongest) to 7 (weakest). It is recommended

to switch from 0 to 7 to find the optimal visual

experience

• IR Extender: this is IR receiving socket, connect the

IR receiver extension cable here

• TMDS: plug in a CAT5e/6 cable, links to the TMDS

connector of the transmitting unit

• DDC: plug in a CAT5e/6 cable, links to the DDC

connector of the transmitting unit

• +5V DC: connect to the included 5V power adapter

Figure 3: IR Transmitter Figure 4: IR Receiver

Hardware Installation

1. Connect your HDMI source to the transmitter.

2. Connect the IR transmitter cable to the transmitting

unit and point the emitter directly to the IR of the

HDMI source.

3. Connect your HDMI display to the receiving unit.

4. ConnectyourCAT5ecablesbetweenthetransmitting

and receiving units. Make sure the cables are

securely connected and not loose.

5. Connect the IR receiver cable to the receiver, and

point the IR receiver directly to the IR of the HDMI

display.

6. Plug the power adapter into the receiver, then plug

the power adapter into a reliable power source.

Note:thetransmitter does not need a power adapter.

7. If needed, adjust the EQ switch from 0 - 7 (strongest

- weakest) to find the optimal visual experience.

Notes

1. When transmitting non-HDCP compliant audio/

video,youcan use just oneCAT5e/6cableconnected

through TMDS.

2. All transmission distances in this manual are

measuredusingCAT5ecable(s). Actual transmission

length and quality of the received display depends

on the quality of your CAT5e/6 cables.

3. To reduce EMI interference over long transmission

distances, use shielded CAT5e/6 cables.

4. For resolutions greater than 1080i or 1280 x 1024, a

CAT6 cable is recommended.

Blank Page

Technical Support and Warranty

QUESTIONS? SIIG’sOnline Support hasanswers! Simply visit our

web site at www.siig.com and click Support. Our online support

database is updated daily with new drivers and solutions. Answers

toyourquestions could be just a few clicks away. You canalsosubmit

questions online and a technical support analysts will promptly

respond.

SIIGoffers a 2-year manufacturer warrantywith this product. Please

see our web site for more warranty details. If you encounter any

problems with this product, please follow the procedures below.

A) If it is within the store's return policy period, please return the

product to the store where you purchased from.

B) Ifyour purchase has passed the store's returnpolicyperiod, please

follow these steps to have the product repaired or replaced.

Step 1: Submit your RMA request.

Go to www.siig.com, click Support, then RMA to submit a

request to SIIG RMA. If the product is determined to be

defective, an RMA number will be issued.

Step 2: After obtaining an RMA number, ship the product.

•Properly pack the product for shipping. All software, cable(s)

and any other accessories that came with the original package

must be included.

•Clearly write your RMA number on the top of the returned

package. SIIG will refuse to accept any shipping package, and

will not be responsible for a product returned without an

RMA number posted on the outside of the shipping carton.

•You are responsible for the cost of shipping. Ship the product

to the following address:

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

RMA #:

•SIIG will ship the repaired or replaced product via Ground

in the U.S. and International Economy outside of the U.S. at

no cost to the customer.

HDMIExtenderover2CAT5ewithIRisatrademarkofSIIG,Inc. SIIGandtheSIIGlogoareregistered

trademarks of SIIG, Inc. Other names used in this publication are for identification only and may be

trademarksoftheirrespectivecompanies.

About SIIG, Inc.

Foundedin1985,SIIG,Inc.isaleadingcomputerupgrademanufacturer

of I/O connectivity products, including PCIe, PCI & ISA serial and

parallel ports, USB, Serial ATA & UltraATA controllers, FireWire

(1394a/b),networking,soundcards, and other accessories. SIIG isthe

premier one-stop source of upgrades.

SIIGproductsoffer comprehensive user manuals,manyuser-friendly

features, and are backed by an extensive manufacturer warranty.

High-quality control standards are evident by the overall ease of

installation and compatibility of our products, as well as one of the

lowest defective return rates in the industry. SIIG products can be

found in computer retail stores, mail order catalogs, through major

distributors, system integrators, and VARs in the Americas and the

UK, and through e-commerce sites.

PRODUCT NAME

HDMI Extender over 2 CAT5e with IR

FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS

B OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE

FCCCOMPLIANCESTATEMENT:

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

Ph: 510-657-8688
