Siemens SIMATIC USB-Prommer Instrucciones de funcionamiento

USB-Prommer

SIMATIC

USB-Prommer

Commissioning Manual

04/2020

A5E50041544

-AA

Usage and Function

Hardware Installation

Software Installation

Connecting to the PC

Working with the SIMATIC

USB-Prommer

Firmware Update

Fault Diagnostics

Specifications

Additional Support and Sales

Information

Certificates, Guidelines and

Declarations

Siemens AG

Division Digital Factory

Postfach 48 48

90026 NÜRNBERG

GERMANY

A5E50041544-AA

Ⓟ

06/2020 Subject to change

All rights

reserved

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by personnel qualified for the specific

task in accordance with the relevant documentation, in particular its warning notices and safety instructions.

Qualified personnel are those who, based on their training and experience, are capable of identifying risks and

avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended

or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

maintenance are required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication

may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

USB-Prommer

Commissioning Manual, 04/2020, A5E50041544-AA 3

Table of contents

1 Usage and Function................................................................................................................................... 4

2 Hardware Installation................................................................................................................................. 5

3 Software Installation .................................................................................................................................. 8

4 Connecting to the PC................................................................................................................................. 9

5 Working with the SIMATIC USB-Prommer............................................................................................... 10

6 Firmware Update ..................................................................................................................................... 11

7 Fault Diagnostics ..................................................................................................................................... 12

8 Specifications .......................................................................................................................................... 13

9 Additional Support and Sales Information................................................................................................ 15

10 Certificates, Guidelines and Declarations ................................................................................................ 16

USB-Prommer

4Commissioning Manual, 04/2020, A5E50041544-AA

Usage and Function

Scope of delivery

With your SIMATIC USB-Prommer, you will receive:

●A "SIMATIC USB-Prommer" CD with software and documentation

●A SIMATIC S5 programming adapter

●A USB cable

●A plug-in power supply with primary connection adapter for Europe and the United States

●A carrying bag

Software requirements

The following software must be installed on your PC for working with the SIMATIC USB-

Prommer:

●The SIMATIC software STEP 5 V7.2 or STEP 7 V5.1+SP2 or later.

●Windows 98SE, Windows Me, Windows 2000, Windows XP, Windows Server 2003

Standard Edition, Windows Vista, Windows 7.8 or Windows 10 operating system.

Hardware requirement

You will need a PC with a USB port.

Usage of the SIMATIC USB-Prommer

Together with the associated SIMATIC software, you can use the SIMATIC USB-Prommer to

read and program SIMATIC S5 memory modules, SIMATIC Memory Cards and SIMATIC

Micro Memory Cards. For editing SIMATIC S5 EPROM modules, the SIMATIC S5

programming adapter must be plugged in. The adapter is included in the product package.

The SIMATIC USB-Prommer is compatible with USB V1.1 and meets the specifications for a

"high-powered" USB device.

The SIMATIC USB-Prommer supports power-saving mode (Hibernate mode).

Function

The SIMATIC USB-Prommer comes equipped with

●SIMATIC Micro Memory Card interface:

●SIMATIC S5/S7 Memory Card interface: MEM-CARD

The SIMATIC USB-Prommer is connected to the PC via the USB port.

If you operate the SIMATIC USB-Prommer without plug-in power supply, you can only edit

SIMATIC Micro Memory Cards.

To edit S5/S7 Memory Cards and S5 EPROM modules, the plug-in power supply must

always be plugged in.

USB-Prommer

Commissioning Manual, 04/2020, A5E50041544-AA 5

Hardware Installation

Rear of the device

On the device rear, you will find:

●The power supply connector for connection of the plug-in power supply

●The USB port type B for connection to the PC

Front of the device

On the device front, you will find:

●SIMATIC Micro Memory Card interface:

●SIMATIC S5/S7 Memory Card interface: MEM-CARD

●Two operating state displays

–BUSY

–POWER

Hardware Installation

USB-Prommer

6Commissioning Manual, 04/2020, A5E50041544-AA

Operating state displays

Name

Color

Meaning

BUSY

Green

Lights up when a programming interface is active.

POWER Green * Plug-in power supply plugged in (device power supply from USB port and

plug-in power supply).

Flashes when an error has occurred.

Yellow Only USB cable is plugged in (power supply from the USB port).

Flashes when a hardware fault has occurred.

The Power LED will not light up in green until the SIMATIC USB-Prommer has been connected to

a switched-on PC with the USB cable and the plug-in power supply is plugged in.

If neither the POWER LED nor the BUSY LED light up when the USB cable is plugged in,

the SIMATIC USB-Prommer is in power-saving mode (Hibernate mode) or the PC on which

the device is operated is switched off.

Power supply

The SIMATIC USB-Prommer is supplied by the PC via the USB cable (POWER LED lights

up in yellow). In this operating mode, i.e. without plug-in power supply, the SIMATIC USB-

Prommer can only edit SIMATIC Micro Memory Cards (MMC).

If you want to edit SIMATIC S7 Memory Cards, SIMATIC S5 EPROM modules or SIMATIC

S5 Memory Cards, you must also supply the SIMATIC USB-Prommer with power via the

plug-in power supply (POWER-LED lights up in green).

The supplied power supply is a wide-range power supply; it can be adapted to fit the

respective power outlet of a specific country, e.g. the United States, by using an adapter.

Connecting the power supply

Proceed as follows:

1. Plug in the 12 V DC power supply cable of the plug-in power supply to the 12 V DC power

supply input of the SIMATIC USB-Prommer.

2. Configure your plug-in power supply with the power outlet adapters for a specific country.

The scope of delivery includes an adapter for the United States and Europe. The power

outlet adapter is fastened by pushing it onto the plug-in power supply.

3. Connect the plug-in power supply to an outlet of your 230 V AC or 115 V AC power

supply.

NOTICE

LEDs

The device is connected properly when the green POWER LED on the SIMATIC USB-

Prommer lights up. If the contacts of the plug-in power supply get dirty, problem-free

functioning of the prommer is no longer guaranteed. If the SIMATIC USB-Prommer has not

yet been connected to the switched-on PC with the USB cable, the LEDs remain unlit.

Hardware Installation

USB-Prommer

Commissioning Manual, 04/2020, A5E50041544-AA 7

WARNING

Plug-in power supply

When operating the SIMATIC USB-Prommer with an external power supply, you may only

use the supplied plug-in power supply.

CAUTION

Plug-in power supply

A power source with limited power is required for the operation of the SIMATIC USB-

Prommer (USA/Canada: NEC Class 2). The supplied plug-in power supply meets these

requirements.

USB-Prommer

8Commissioning Manual, 04/2020, A5E50041544-AA

Software Installation

The installation of the SIMATIC USB-Prommer software starts automatically after inserting

the product CD.

If this function is switched off, follow these steps:

1. Insert your SIMATIC USB-Prommer product CD into the CD-ROM drive

2. Open the root directory in this drive.

3. Start the setup program with a double-click on the "setup.exe" file.

The setup program will guide you through the entire installation. Observe the notes regarding

the installation and use of the SIMATIC USB-Prommer software in the Readme file that is

located in the root directory of the CD.

USB-Prommer

Commissioning Manual, 04/2020, A5E50041544-AA 9

Connecting to the PC

1. Insert the supplied USB cable into a USB port on your PC.

2. Insert the other end of the USB cable into the USB port of the SIMATIC USB-Prommer.

3. During initial operation of the SIMATIC USB-Prommer, you must set the programming

interface to "External prommer" at the "USB" port in the Control Panel with the "Memory

Card Parameter Assignment" panel.

When you select the setting "Detect USB prommer automatically", the connection of the

SIMATIC USB-Prommer to the PC is detected automatically.

NOTICE

USB cable

Connect the SIMATIC USB-Prommer to the PC only with the supplied USB cable.
