Siemens SIMATIC NET PS598-1 Guía del administrador

Power supply PS598-1 for SCALANCE X-500

English

A5E03275848A-01

SIMATIC NET

09/2011

A5E03275848A-01

Technical data subject to change

Compact operating instructions

Power supply PS598-1 for SCALANCE XR-500M

A5E03275848A-01, 09/2011 3

Table of contents

Introduction .............................................................................................................. 6

Safety notes ............................................................................................................. 7

Important notes on using the device ......................................................................7

Description ............................................................................................................... 8

Product characteristics ..........................................................................................8

Unpacking and checking........................................................................................9

Mounting ................................................................................................................ 10

19" rack mounting of the PS598-1 .......................................................................10

Mounting the PS598-1 on the rear panel of an XR-500M ....................................12

Connection............................................................................................................. 15

Connecting devices with 100 to 240 VAC power supply......................................15

Upkeep and maintenance....................................................................................... 20

Changing the air filter...........................................................................................20

Technical data........................................................................................................ 21

Mechanical and electrical data.............................................................................21

Dimension drawings ............................................................................................23

Approvals............................................................................................................... 24

EMC directive ......................................................................................................24

Mechanical stability (in operation)........................................................................26

4 A5E03275848A-01, 09/2011

Legal information

Qualified Personnel

The product/system described in this documentation may be operated only by personnel

qualified for the specific task in accordance with the relevant documentation, in particular its

warning notices and safety instructions. Qualified personnel are those who, based on their

training and experience, are capable of identifying risks and avoiding potential hazards when

working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the

relevant technical documentation. If products and components from other manufacturers are

used, these must be recommended or approved by Siemens. Proper transport, storage,

installation, assembly, commissioning, operation and maintenance are required to ensure that

the products operate safely and without any problems. The permissible ambient conditions

must be complied with. The information in the relevant documentation must be observed.

A5E03275848A-01, 09/2011 5

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as

well as to prevent damage to property. The notices referring to your personal safety are

highlighted in the manual by a safety alert symbol, notices referring only to property damage

have no safety alert symbol. These notices shown below are graded according to the degree of

danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

with a safety alert symbol, indicates that minor personal injury can result if proper precautions

are not taken.

CAUTION

without a safety alert symbol, indicates that property damage can result if proper precautions

are not taken.

NOTICE

indicates that an unintended result or situation can occur if the relevant information is not

taken into account.

If more than one degree of danger is present, the warning notice representing the highest

degree of danger will be used. A notice warning of injury to persons with a safety alert symbol

may also include a warning relating to property damage.

Introduction

Purpose of the compact operating instructions

Based on the compact operating instructions, you will be able to install and connect

up the PS598-1 correctly.

Validity of these compact operating instructions

These compact operating instructions apply to the product PS598-1 as of product

version 1.

Power supply PS598-1 for SCALANCE XR-500M

6 A5E03275848A-01, 09/2011

Safety notes

Important notes on using the device

Safety notices on the use of the devices

The following safety notices must be adhered to when setting up and operating the

device and during all work relating to it such as installation, connecting up, replacing

devices or opening the device.

Important notices 100 to 240 VAC

DANGER

Danger from line voltage

Devices with this mark have a 100 to 240 VAC power supply.

This product can only function correctly and safely if it is transported, stored, set up,

and installed correctly, and operated and maintained as recommended.

Connecting and disconnecting may only be performed by an electrical specialist.

Connect or disconnect power supply cables only when the power is turned off!

General notices

WARNING

Opening the device

Do not open when energized. Note that this does not apply to opening the panel in

the housing.

Power supply PS598-1 for SCALANCE XR-500M

A5E03275848A-01, 09/2011 7

Description

Product characteristics

Connectors

Type Power Input voltage Output voltage

PS598-1 300 W 100 to 240 VAC 24 VDC

Note

Two connectors for the 24 VDC output voltage

The PS598-1 has two connectors with the output voltage 24 VDC. Note that you can

only use one connector on the front or the connector on the rear of the PS598-1. You

cannot operate the device with the connectors on the front and rear at the same time.

Note

Requirement for connecting at the rear

Note that the connector on the rear of the PS598-1 can only be used if the power

supply is mounted on the SCALANCE XR-500M.

Power supply PS598-1 for SCALANCE XR-500M

8 A5E03275848A-01, 09/2011

Description

Components of the product

The following parts make up the components of the PS598-1:

● 4-pin terminal block for the 24 VDC power supply.

● 2 mounting brackets

● 8 screws (M3 x 6 countersunk, drive: Torx) for mounting the fixing brackets for

19" rack installation

● Compact Operating Instructions

Order numbers

Type Order number

PS598-1 (300 W) 6GK5 598-1AA00-3AA0

Note

Replacing the filter mat

To replace the filter mat, use the material Viledon P 15/150 G2 EN 779. The

dimensions of the filter mat are 38 x 135 x 8 mm (H x W x D).

Unpacking and checking

1. Make sure that the package is complete.

2. Check all the parts for transport damage.

WARNING

Do not use any parts that show evidence of damage!

If the consignment is incomplete or if there is damage to the exterior, contact your

supplier or your local Siemens office.

Power supply PS598-1 for SCALANCE XR-500M

A5E03275848A-01, 09/2011 9

Mounting

19" rack mounting of the PS598-1

Power supply unit for 19" rack installation

The PS598-1 was developed specifically for use with devices of the XR-500M

product group. This power supply unit can be mounted directly above or below a

SCALANCE XR-500M since the ventilation openings are on the sides of both the

basic device and the power supply unit.

CAUTION

Damage to the device due to inadequate cooling

If the ventilation grilles are fully or partly covered or the air filters are contaminated,

the temperature inside the housing can rise and exceed the maximum permitted

temperature and damage the device.

During installation, select a mounting position so that the ventilation grilles are

always free so that the air can circulate. The ventilation grilles are located on the

side panels of the housing. You will find information about cleaning the air filter in

the section "Upkeep and maintenance".

Power supply PS598-1 for SCALANCE XR-500M

10 A5E03275848A-01, 09/2011
