Siemens SCD 1897-M Manual

The reproduction, transmission or use

of this document or its contents is not

permitted without express written

authority. Offenders will be liable for

damages. All rights, including rights

created by patent grant or registration

of a utility model or design, are

reserved.

Print No.:

Rehm

Display

Replacements of Parts

2001

TD00-000.841.02.04.02

Replaces: TD00-000.841.02.03.02

English

Doc. Gen. Date: 05.05

18” Color TFT Monitor (SCD 1897-M)

Applicable for Part Number 30 80 991

03080991

2 Revision / Disclaimer

Display TD00-000.841.02.04.02 Siemens AG

05.05 CSPS21

Page 2 of 22 Medical Solutions

1Revision / Disclaimer

Document revision level

The document corresponds to the version/revision level effective at the time of system

delivery. Revisions to hardcopy documentation are not automatically distributed.

Please contact your local Siemens office to order current revision levels.

Disclaimer

The installation and service of equipment described herein is to be performed by qualified

personnel who are employed by Siemens or one of its affiliates or who are otherwise

authorized by Siemens or one of its affiliates to provide such services.

Assemblers and other persons who are not employed by or otherwise directly affiliated

with or authorized by Siemens or one of its affiliates are directed to contact one of the

local offices of Siemens or one of its affiliates before attempting installation or service pro-

cedures.

Siemens AG TD00-000.841.02.04.02 Display

05.05 CSPS21

Table of Contents 3

Page 3 of 22

Medical Solutions

1- 0Table of Contents

1 _______ General Information______________________________________________ 4

General Remarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Safety Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Monitor Remarks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Repair / Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Test and Auxiliary Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Adjustment Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

2 _______ System-related Adjustments ______________________________________ 7

General Remarks regarding System-related Adjustments . . . . . . . . . . . . . . . . . . . . . . . . 7

AX Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

AXIOM Artis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Leonardo. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

SP Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Mammomat Novation DR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

3 _______ Changes to Previous Version_____________________________________ 22

4 General Information

Display TD00-000.841.02.04.02 Siemens AG

05.05 CSPS21

Page 4 of 22 Medical Solutions

1General I nformation

General Remarks 0

Safety Information 0

DHHS Regulations (Department of Health and Human Services) skipped (no high volt-

age).

Assuming a complete replacement, no contact points for line power, etc. are present.

NOTE ARTD-002.732.17.. (Safety-technical Regulations for Installation

and Repair) must be observed.

WARNING Certain components inside the units are under high voltage!

If there is contact with these components, it can cause damage,

serious bodily injury or death.

¹Do not open the monitor housing; this is not necessary

in a service situation.

WARNING A damaged power cable can lead to fire or electric shock!

If these components are operated with a damaged power cable, it

can cause damage, serious bodily injury or death.

¹Use only power cables that are in good condition! When

disconnecting the power line, hold the power cable only

by the connector.

WARNING If objects are inserted into the housing, this can cause electrical

shock.

This can cause damage to the unit, to other damage, serious bodi-

ly injury or death.

¹Do not insert objects into the housing!

WARNING When handling connection cables, no contact with the patient may

be made.

This can cause damage, serious bodily injury or death of the pa-

tient.

¹Do not connect the unit in the patient area!

Monitor Remarks 0

•The SCD 1897-M is a high-resolution 18" display (46 cm).

•Prerequisite for the adjustment is the Instruction Manual that is shipped with each dis-

play.

Siemens AG TD00-000.841.02.04.02 Display

05.05 CSPS21

General Information 5

Page 5 of 22

Medical Solutions

•A laptop, etc. is not required; the adjustment is performed using the push-buttons on the

side of the unit and an on-screen menu.

•The display can be controlled using RGB as well as S/W.

For configuration for S/W control, see the Instruction Manual.

•For technical data, etc., see the Instruction Manual.

•Video norm:

- The display detects the video norm that is present and sets itself automatically to this

norm.

- “New” norms that have not yet been set, can (must) be set. The next time this norm is

used, the display sets the norm again automatically.

- There is separate set of parameters in the display for each norm. This means that

each norm used must be set individually (also contrast / brightness).

•Pixel drop-outs:

- Manufacturer-related pixel drop-outs are always possible; up to 15 pixels (light or

dark) are permissible.

•Backlight control:

- The backlight is automatically adjusted. This means that the maximum contrast that

is set is retained as long as the control is not set to stop.

- When set to control stop, the maximum contrast is will be less with lower emission or

luminance. For the minimum values, see the chapter “System-related Adjustments”.

If there is a drop below the “minimum value”, replace the display.

Repair / Troubleshooting 0

In a malfunction situation, the display is only replaced completely.

To adapt to the particular system, see chapter “Application-related Adjustments”.

NOTE Every defective display must be returned with an exact description

of the error. It is virtually impossible to find sporadic and / or tem-

perature-related errors or also system-related causes without a

description of the malfunction.

Test and Auxiliary Equipment 0

•All required settings, see the Adjustment chapter, must be performed using the

push-buttons on the side of the unit. A laptop is not required.

•"SMFit test meter" luminous density meter, see the SPC.

6 General Information

Display TD00-000.841.02.04.02 Siemens AG

05.05 CSPS21

Page 6 of 22 Medical Solutions

Adjustment Note 0

Tab. 1 Push buttons

NOTE Adjustments may be performed only after a warm-up time of 15

minutes!

NOTE As a rule, the push-buttons are not locked in replacement units

(from the E-warehouse).

They must be locked following installation.

All required adjustments are made using the push-buttons on

the side of the unit.

The push-buttons are locked when shipped (new system).

For the function of the push-buttons, see the Instruction Man-

ual included in the shipment.

Unlocking or locking them is done as follows:

- Press the “SET” button 1x.

- Press the “ Up” button (arrow pointing up) 3x.

Fig. 1:

Siemens AG TD00-000.841.02.04.02 Display

05.05 CSPS21

System-related Adjustments 7

Page 7 of 22

Medical Solutions

2System-related Adjustments

General Remarks regarding System-related Adjustments 0

NOTE

•For the function of the push-buttons, see the Instruction Manu-

al included in the shipment.

•All values listed, including the listed tolerances, are "setting

values”.

The listed tolerances are not values for the constancy check of

the display!

•The monitor must be switched on at least 20 minutes prior to

beginning the adjustment.

8 System-related Adjustments

Display TD00-000.841.02.04.02 Siemens AG

05.05 CSPS21

Page 8 of 22 Medical Solutions

AX Application 0

AXIOM Artis 0

Size and Position

Check the size and position in the norm being used. The picture must be displayed “full

screen".

The emergency mode norm is used “only” as a display; it is displayed in reduced size.

If this is not the case, if needed, the size and position (only position is possible) must be

performed manually.

Frequency / Phase (Focus)

NOTE This adjustment ensures that the picture is correct for the screen

size.

Incorrect adjustment is manifested as unsharp focus.

The adjustment can be performed using the SMPTE test pattern

(quick adjustment) or by generating a text page.

•Using SMPTE:

Tab. 2 SMPTE

•Using the Text Page (more exactly adjustable)

Select Explorer to specify the background color of Notepad and to select Notepad.

Select Explorer:

Select the SMPTE test pattern in the

system.

The 5 high-frequency line groups must

be equally well visible!

The adjustment is performed under: =>

Menu => Other => using the sliders:

Frequency and Phase

Fig. 2:

Siemens AG TD00-000.841.02.04.02 Display

05.05 CSPS21

System-related Adjustments 9

Page 9 of 22

Medical Solutions

-Select<Utilities> in the Service Main menu.

-Select<Escape to OS> in the Utilities (Source) window.

-Select<NT Command Interpreter> under Command.

-Enter<explorer> under Parameters.

- Start Explorer with “Enter”.

Select Display (invert so that the highlighted elements appear on a black background):

-In“My Computer” => start “Control Panel”.

- In the window on the right => double-click on ” Display” to open it.

-Select“Appearance” in the menu bar.

-Select“Marked Elements” in display element.

-Select“black” for color.

Generate a text page with “mmmmm”:

- Open "Notepad.exe" in C/Winnt.

- Open Notepad all the way (to cover the entire screen area).

- Fill approx. 3 lines with “mmmmmmm “ => select the lines => copy => paste until the

page is filled.

- Select the entire page; when this is done, the background becomes black and the

characters are displayed white.

- Select => “Set Font..” under “Edit” => Arial / Regular / 12.

- The adjustment can now be performed using this image, a complete page full of “

m...” in white type and a black background.

- Using the sliders for frequency and phase, adjust the entire screen area for optimum

focus.

Brightness / Contrast Adjustment

NOTE The measurement is made using the Mavo monitor.

When performing the measurement, make sure that the measuring

sensor does not exert any pressure on the panel surface.

Otherwise damage to the panel cannot be ruled out!

10 System-related Adjustments

Display TD00-000.841.02.04.02 Siemens AG

05.05 CSPS21

Page 10 of 22 Medical Solutions

NOTE Contrast:

Detection of the 95% fields in the 100% field (limitation) is adjusted

using video gain (contrast).

Backlight:

The 100% field (maximum white) is adjusted using the backlight.

Brightness:

Adjustment of the black area (basic brightness and detection of

the 5% field).

•Select the test pattern (Fig.3/p.10).

- Select zoom, drag the white area to the center of the screen (Fig.4/p.10).

- Set the slider for “contrast” to the maximum.

Adjust using contrast minus so that 95% is “well” visible in the 100% field.

- Use the slider for “backlight” to adjust to 120, +/-5cd/m in the 100% field.

- Drag the black field into the center of the screen.

- Use the slider for “brightness” to adjust to 0.5, +/-0.1cd/m in the black field.

- Alternately repeat both adjustments (backlight and brightness) until the specified val-

ues are reached.

- Final Check: All steps in the test pattern must be detectable. If not, repeat the adjust-

ment.

The operating buttons must be locked again!

Leonardo 0

NOTE This display is operated at 1280 x 1024 pixels / 75 Hertz.

Fig. 3: Image1 Fig. 4: Image1

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de Siemens

Siemens

Siemens SMD 18101 CS Manual de usuario

Siemens

Siemens SCD 1515-E Manual de usuario

Siemens

Siemens MCM-21T2 Manual de usuario

Siemens

Siemens 30 64 581 B5310 Instrucciones de funcionamiento y mantenimiento

Siemens

Siemens SMD21300 Manual de usuario

Siemens

Siemens FT2014 Manual de usuario

Siemens

Siemens FT2011 Manual de usuario

Siemens

Siemens SIMATIC Industrial Flat Panel IFP2200 Guía del administrador

Siemens

Siemens SSD Manual de usuario

Siemens

Siemens CMTC1515 Manual de usuario

Siemens

Siemens INOX PRO SIMATIC IFP1900 Manual de usuario

Siemens

Siemens 19T2 Manual de usuario

Siemens

Siemens SCD 1898-I Manual de usuario

Siemens

Siemens INOX PRO SIMATIC IFP1900 Manual de usuario

Siemens

Siemens UP587/1 Series Manual de servicio

Siemens

Siemens AZL66 Series Manual de usuario

Siemens

Siemens SCD 1597-E Manual de usuario

Siemens

Siemens SIMATIC Industrial Flat Panel IFP2200 Manual de usuario

Siemens

Siemens MCM 1902 Manual de usuario

Siemens

Siemens SITRANS RD100 Guía

Siemens

Siemens SIMATIC S7-200 Guía del usuario

Siemens

Siemens SIMOMED HM Instrucciones de funcionamiento

Siemens

Siemens SINAMICS G180 Manual de usuario

Siemens

Siemens CMTC1913 Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
