Siemens Simatic S7-1500 Manual de usuario

Digital output module

DQ 16x230VAC/2A ST Relay

(6ES7522-5HH00-0AB0)

___________________

SIMATIC

S7-1500/ET 200MP

Digital output module DQ

16x230VAC/2A ST Relay

(6ES7522-5HH00-0AB0)

Manual

03/2015

A5E34934019

-AA

Preface

Documentation guide

Product overview

Wiring

Parameters/address space

Interrupts/diagnostics alarms

Technical specifications

Dimensional drawing

Parameter data records

Open Source Software

Siemens AG

Division

Digital Factory

Postfach 48 48

90026 NÜRNBERG

GERMANY

A5E34934019-AA

Ⓟ

03/2015 Subject to change

Legal information

Warning notice system

This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent

damage to property. The notices referring to your personal safety are highlighted in the manual by a safety alert

symbol, notices referring only to property damage have no safety alert symbol. These notices shown below are

graded according to the degree of danger.

DANGER

indicates that death or severe personal injury will result if proper precautions are not taken.

WARNING

indicates that death or severe personal injury may result if proper precautions are not taken.

CAUTION

indicates that minor personal injury can result if proper precautions are not taken.

NOTICE

indicates that property damage can result if proper precautions are not taken.

If more than one degree of danger is present, the warning notice representing the highest degree of danger will

be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relating to

property damage.

Qualified Personnel

The product/system described in this documentation may be operated only by

personnel qualified

for the specific

task in accordance with the relevant documentation, in particular its warning notices and safety instructions.

Qualified personnel are those who, based on their training and experience, are capable of identifying risks and

avoiding potential hazards when working with these products/systems.

Proper use of Siemens products

Note the following:

WARNING

Siemens products may only be used for the applications described in the catalog and in the relevant technical

documentation. If products and components from other manufacturers are used, these must be recommended

or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and

maintenance are required to ensure that the products operate safely and without any problems. The permissible

ambient conditions must be complied with. The information in the relevant documentation must be observed.

Trademarks

All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publication

may be trademarks whose use by third parties for their own purposes could violate the rights of the owner.

Disclaimer of Liability

We have reviewed the contents of this publication to ensure consistency with the hardware and software

described. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the

information in this publication is reviewed regularly and any necessary corrections are included in subsequent

editions.

Digital output module DQ 16x230VAC/2A ST Relay (6ES7522-5HH00-0AB0)

4Manual, 03/2015, A5E34934019-AA

Preface

Purpose of the documentation

This manual supplements the system manuals:

●S7-1500 Automation System

●ET 200MP Distributed I/O System

Functions that relate in general to the systems are described in these system manuals.

The information provided in this manual and in the system/function manuals supports you in

commissioning the systems.

Conventions

CPU: When the term "CPU" is used in this manual, it applies to the CPUs of the S7-1500

automation system as well as to the interface modules of the ET 200MP distributed I/O

system.

STEP 7: In this documentation, "STEP 7" is used as a synonym for all versions of the

configuration and programming software "STEP 7 (TIA Portal)".

Please also observe notes marked as follows:

Note

note contains important information on the product described in the documentation, on the

handling of the product or on the section of the documentation to which particular attention

should be paid.

Security information

Siemens provides products and solutions with industrial security functions that support the

secure operation of plants, solutions, machines, equipment and/or networks. They are

important components in a holistic industrial security concept. With this in mind, Siemens’

products and solutions undergo continuous development. Siemens recommends strongly

that you regularly check for product updates.

For the secure operation of Siemens products and solutions, it is necessary to take suitable

preventive action (e.g. cell protection concept) and integrate each component into a holistic,

state-of-the-art industrial security concept. Third-party products that may be in use should

also be considered. You can find more information about industrial security on the Internet

(http://www.siemens.com/industrialsecurity).

To stay informed about product updates as they occur, sign up for a product-specific

newsletter. You can find more information on the Internet

(http://support.automation.siemens.com).

Preface

Digital output module DQ 16x230VAC/2A ST Relay (6ES7522-5HH00-0AB0)

Manual, 03/2015, A5E34934019-AA 5

Open Source Software

Open-source software is used in the firmware of the product described. Open Source

Software is provided free of charge. We are liable for the product described, including the

open-source software contained in it, pursuant to the conditions applicable to the product.

Siemens accepts no liability for the use of the open source software over and above the

intended program sequence, or for any faults caused by modifications to the software.

For legal reasons, we are obliged to publish the original text of the license conditions and

Digital output module DQ 16x230VAC/2A ST Relay (6ES7522-5HH00-0AB0)

6Manual, 03/2015, A5E34934019-AA

Table of contents

Preface ................................................................................................................................................... 4

1 Documentation guide .............................................................................................................................. 7

2 Product overview .................................................................................................................................... 9

2.1 Properties................................................................................................................................. 9

3 Wiring ................................................................................................................................................... 11

4 Parameters/address space ................................................................................................................... 14

4.1 Parameters............................................................................................................................. 14

4.2 Declaration of parameters...................................................................................................... 15

4.3 Address space ....................................................................................................................... 15

5 Interrupts/diagnostics alarms................................................................................................................. 21

5.1 Status and error displays ....................................................................................................... 21

5.2 Interrupts ................................................................................................................................ 23

5.3 Diagnostics alarms................................................................................................................. 23

6 Technical specifications ........................................................................................................................ 24

A Dimensional drawing............................................................................................................................. 29

B Parameter data records ........................................................................................................................ 31

B.1 Parameter assignment and structure of the parameter data records .................................... 31

C Open Source Software.......................................................................................................................... 34

C.1 Open Source Software........................................................................................................... 34

Digital output module DQ 16x230VAC/2A ST Relay (6ES7522-5HH00-0AB0)

Manual, 03/2015, A5E34934019-AA 7

Documentation guide

The documentation for the SIMATIC S7-1500 automation system and the SIMATIC

ET 200MP distributed I/O system is arranged into three areas.

This arrangement enables you to access the specific content you require.

Basic information

The System Manual and Getting Started describe in detail the configuration, installation,

wiring and commissioning of the SIMATIC S7-1500 and ET 200MP systems. The STEP 7

online help supports you in the configuration and programming.

Device information

Product manuals contain a compact description of the module-specific information, such as

properties, wiring diagrams, characteristics and technical specifications.

General information

The function manuals contain detailed descriptions on general topics regarding the SIMATIC

S7-1500 and ET 200MP systems, e.g. diagnostics, communication, Motion Control, Web

server.

You can download the documentation free of charge from the Internet

(http://www.automation.siemens.com/mcms/industrial-automation-systems-

simatic/en/manual-overview/tech-doc-controllers/Pages/Default.aspx).

Changes and supplements to the manuals are documented in a Product Information.

Documentation guide

Digital output module DQ 16x230VAC/2A ST Relay (6ES7522-5HH00-0AB0)

8Manual, 03/2015, A5E34934019-AA

Manual Collection S7-1500/ET 200MP

The Manual Collection contains the complete documentation on the SIMATIC S7-1500

automation system and the ET 200MP distributed I/O system gathered together in one file.

You can find the Manual Collection on the Internet

(http://support.automation.siemens.com/WW/view/en/86140384).

My Documentation Manager

The My Documentation Manager is used to combine entire manuals or only parts of these to

your own manual.

You can export the manual as PDF file or in a format that can be edited later.

You can find the My Documentation Manager on the Internet

(http://support.industry.siemens.com/My/ww/en/documentation).

Application examples

Application examples support you with various tools and examples for solving your

automation tasks. Solutions are shown in interplay with multiple components in the system -

separated from the focus in individual products.

You can find application examples on the Internet

(https://support.industry.siemens.com/sc/ww/en/sc/2054).

CAx Download Manager

The CAx Download Manager is used to access the current product data for your CAx or CAe

systems.

You configure your own download package with a few clicks.

In doing so you can select:

●Product images, 2D dimension drawings, 3D models, internal circuit diagrams, EPLAN

macro files

●Manuals, characteristics, operating manuals, certificates

●Product master data

You can find the CAx Download Manager on the Internet

(http://support.industry.siemens.com/my/ww/en/CAxOnline).

TIA Selection Tool

With the TIA Selection Tool, you can select, configure and order devices for Totally

Integrated Automation (TIA).

This tool is the successor of the SIMATIC Selection Tool and combines the known

configurators for automation technology into one tool.

With the TIA Selection Tool, you can generate a complete order list from your product

selection or product configuration.

You can find the TIA Selection Tool on the Internet

(http://w3.siemens.com/mcms/topics/en/simatic/tia-selection-tool).

Digital output module DQ 16x230VAC/2A ST Relay (6ES7522-5HH00-0AB0)

Manual, 03/2015, A5E34934019-AA 9

Product overview

2.1

Properties

Article number

6ES7522-5HH00-0AB0

View of the module

Figure 2-1 View of the DQ 16x230VAC/2A ST module

Product overview

2.1 Properties

Digital output module DQ 16x230VAC/2A ST Relay (6ES7522-5HH00-0AB0)

10 Manual, 03/2015, A5E34934019-AA

Properties

The module has the following technical properties:

●16 digital outputs (relays)

●Supply voltage of the 24 V DC relay coils

●Rated output voltage 230 V AC (24 V DC up to 120 V DC/24 V AC up to 230 V AC)

●Rated output current 2A (per channel)

●Configurable substitute values (per channel)

●Configurable diagnostics

●Suitable for solenoid valves, DC contactors, and indicator lights

The module supports the following functions:

Table 2- 1 Version dependencies of the module functions

Function

Firmware version

of the module

Configuration software

STEP 7

V13, SP1 or higher

with HSP 0119

GSD file in

STEP 7 V12 or higher or

STEP 7 V5.5 SP3 or higher

Firmware update

V1.0.0 or higher

--- / X

Identification data I&M0 to I&M3

V1.0.0 or higher

--- / X

Reconfiguration in RUN V1.0.0 or higher X X

Module-internal Shared Output (MSO) V1.0.0 or higher X

(PROFINET IO only)

Configurable submodules / submodules for

Shared Device

V1.0.0 or higher X

(PROFINET IO only)

You can configure the module with STEP 7 and with a GSD file.

Accessories

The following accessories are supplied with the module and can also be ordered separately

as spare parts:

●Labeling strips

●U connector

●Universal front door

Other components

The following component must be ordered separately:

Front connectors, including potential jumpers and cable ties

For more information on accessories, refer to the S7-1500/ET 200MP system manual

(http://support.automation.siemens.com/WW/view/en/59191792).

Otros manuales para Simatic S7-1500

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de Siemens

Siemens

Siemens MVS661 N Series Manual de usuario

Siemens

Siemens SINAMICS S120 Manual de usuario

Siemens

Siemens FS-TRI-M Manual de usuario

Siemens

Siemens V-2030 Manual de usuario

Siemens

Siemens SIRIUS 8WD4428-0BF Manual de usuario

Siemens

Siemens SINUMERIK 840DE Manual del propietario

Siemens

Siemens Flowrite 599 Series Manual del propietario

Siemens

Siemens SIMATIC ET 200SP Manual de usuario

Siemens

Siemens SINUMERIK 840D sl Manual de usuario

Siemens

Siemens SINAMICS G120P CU230P-2 Guía del administrador

Siemens

Siemens SINAMICS G120 Manual de usuario

Siemens

Siemens Simatic S7-1500 Manual de lista de piezas

Siemens

Siemens Simatic S7-1500 Manual de usuario

Siemens

Siemens SIRIUS Manual de usuario

Siemens

Siemens SINUMERIK 840Di sl Manual de lista de piezas

Siemens

Siemens SIMATIC ET 200S Manual de usuario

Siemens

Siemens SIMOTION D4 Series Documento técnico

Siemens

Siemens SIMATIC ET 200AL Manual de usuario

Siemens

Siemens SIMATIC S7 Documento técnico

Siemens

Siemens SINUMERIK Series Manual de lista de piezas

Siemens

Siemens SIRIUS 8WD4428-0B Manual de usuario

Siemens

Siemens Desigo PXC4.E16 Manual de usuario

Siemens

Siemens SIRIUS 3RW5 series Documento técnico

Siemens

Siemens 3WN 6 3WX3661-0JA00 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
