Siemens FCI2011-U1 Guía

FCI2011-U1

NAC module (1A/2B)

Mounting

Installation

A6V10315036_d_en_--

Siemens Industry, Inc.

2018-03-16 Building Technologies Division

Legal notice

2 | 14

Siemens Industry, In

A6V10315036_d_en_

Building Technologies Division

2018

Legal notice

Technical specifications and availability subject to change without notice.

Transmittal, reproduction, dissemination and/or editing of this document as well as

utilization of its contents and communication thereof to others without express

authorization are prohibited. Offenders will be held liable for payment of damages. All

rights created by patent grant or registration of a utility model or design patent are

reserved.

Issued by:

Siemens Industry, Inc.

Building Technologies Division

8 Fernwood Road

Florham Park, NJ 07932

Tel. +1 973-593-2600

www.sbt.siemens.com/FIS

Edition: 2018-03-16

Document ID: A6V10315036_d_en_--

3 |

Siemens Industry, Inc.

A6V10315036_d_en_

Building Technologies Division

2018

Table of contents

1Description............................................................................................... 5

2Mounting.................................................................................................. 6

3Views....................................................................................................... 7

4Pin assignments for NAC 2......................................................................... 8

4.1 X5 NAC 2 class A and NAC 2-1 and NAC 2-2 class B terminal block................. 8

5Adjusting elements for NAC 2..................................................................... 9

5.1 X602 Jumper DEGRADED MODE ENABLE/DISABLE

for NAC 2 class A or NAC 2-1 class B............................................................... 9

5.2 X603 Jumper DEGRADED MODE ENABLE/DISABLE for NAC 2-2 class B...... 9

5.3 X604, X605 and X606 NAC 2 class A/B selection jumper................................ 10

6Technical data..........................................................................................11

7FCC Statement........................................................................................12

Siemens Industry, Inc.

A6V10315036_d_en_

Building Technologies Division

2018

4 | 14

Description

5 |

Siemens Industry, Inc.

A6V10315036_d_en_

Building Technologies Division

2018

1Description

The notification appliance expansion module (NAC) provides an additional class A

circuit or 2 additional class B circuits. Each class A circuit or each of the two class B

circuits has a rating of 3 A. The header is connected to X901 on the periphery board.

The same jumpers have to be configured on the card as with the periphery board for

class A/B circuit selection and degraded mode. All jumpers must be configured, and

the module in place on X901 before power is applied to the system.

Properties

●Additional NAC circuits with 3 A power for one class A circuit or 3 A for each class

B circuit

●Protected against voltage surge and shorted outputs

●Circuit monitored for short, open, and ground fault

●Ground faults detected at <1 kΩ

●Circuits are power limited

Mounting

6 | 14

Siemens Industry, Inc.

A6V10315036_d_en_

Building Technologies Division

2018

2Mounting

The NAC module (1A/2B) FCI2011 is installed on the periphery board as shown and

screwed onto the back box. Slot X901 is also used for the releasing module.

Figure 1: Installing the NAC module on the periphery board

1Periphery board (250p) or periphery board (500p)

2 Threaded standoffs on back box

3NAC module (1A/2B) FCI2011

42x fixing screw

X901 Slot in periphery board

X5 Connection terminal on NAC module (1A/2B)

1. Plug the NAC module (3) into slot X901 on the periphery board as shown.

2. Fasten the NAC module to the threaded standoffs (2) in the back box using the two

fixing screws (4).

3. Wire up the NAC module according to the pin assignment.

Views

7 |

Siemens Industry, Inc.

A6V10315036_d_en_

Building Technologies Division

2018

3Views

Figure 2: Printed circuit board view for FCI2011

Element Des. Function

Connector X1 Connection to periphery board

X5 NAC 2 output

X602 DEGRADED MODE ENABLE/DISABLE for NAC 2 class A or NAC 2-1 class B

X603 DEGRADED MODE ENABLE/DISABLE for NAC 2-2 class B

X604 NAC 2 class A/B selection

X605 NAC 2 class A/B selection

X606 NAC 2 class A/B selection

X602

X603

X605

X606

X604

Pin assignments for NAC 2

X5 NAC 2 class A and NAC 2

1 and NAC 2

2 class B terminal block

8 | 14

Siemens Industry, Inc.

A6V10315036_d_en_

Building Technologies Division

2018

4Pin assignments for NAC 2

4.1 X5 NAC 2 class A and NAC 2-1 and NAC 2-2 class B

terminal block

Pin Designation Description

4NAC2-1 (+) Positive feed for notification appliances for NAC 2 class A or NAC 2

3NAC2-1 (-) Return feed for notification appliances for NAC 2 class A or NAC 2

2NAC2-2 (+) Positive feed for notification appliances for NAC 2 class A or NAC 2

1NAC2-2 (-) Return feed for notification appliances for NAC 2

Admissible cable cross-section: 1 x 12…18 AWG or 2 x 16…18 AWG

The jumpers must be set correctly for the class A/B selection.

Figure 3: Pin assignment for NAC circuit class A

Figure 4: Pin assignment for NAC circuit class B

* EOL resistance must be connected during non-use. EOL resistance: 2.4 kΩ, 0.5 W.

See also

2X604, X605 and X606 NAC 2 class A/B selection jumper [➙10]

Adjusting elements for NAC 2

X602 Jumper DEGRADED MODE ENABLE/DISABLE for NAC 2 class A or NAC 2

1 class B

9 |

Siemens Industry, Inc.

A6V10315036_d_en_

Building Technologies Division

2018

5Adjusting elements for NAC 2

5.1 X602 Jumper DEGRADED MODE ENABLE/DISABLE

for NAC 2 class A or NAC 2-1 class B

Errors of the power PC are displayed on the PMI & mainboard when degraded mode is

activated.

Switching on the degraded mode function of the NAC circuit 2 class A or

circuit 2-1 class B

X602 Jumper position Function Meaning

3 - 2 Disable degraded mode for

NAC 2 class A or NAC 2-1

class B.

Circuit will not activate the notification appliances if

degraded mode is activated and an alarm is present.

1 - 2 Enable degraded mode for

NAC 2 class A or NAC 2-1

class B.

Circuit will activate the notification appliances if

degraded mode is activated and an alarm is present.

5.2 X603 Jumper DEGRADED MODE ENABLE/DISABLE

for NAC 2-2 class B

Errors of the power PC are displayed on the PMI & mainboard when degraded mode is

activated.

Switching on the degraded mode function of the circuit 2-2 class B

X603 Jumper position Function Meaning

3 - 2 Disable degraded mode on

NAC 2-2 class B. Circuit will not activate the notification appliances if

degraded mode is activated and an alarm is present.

1 - 2 Enable degraded mode on

NAC 2-2 class B. Circuit will activate the notification appliances if

degraded mode is activated and an alarm is present.

Adjusting elements for NAC 2

X604, X605 and X606 NAC 2 c

lass A/B selection jumper

10 | 14

Siemens Industry, Inc.

A6V10315036_d_en_

Building Technologies Division

2018

5.3 X604, X605 and X606 NAC 2 class A/B selection

jumper

Class A/B setting of the additional NAC circuit

X604

X605

X606

Jumper position Function Meaning

3 - 2 Class A Configures periphery board NAC 2 for class A circuit

1 - 2 Class B Configures periphery board NAC 2-1 and NAC 2-2 for

class B circuit

The setting for class A/B must also be configured with the Engineering tool set. If the

configuration does not match the onboard jumper settings, an error will post on the

PMI.
