2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

Manual, 04/2007, A5E01076940-01 3

Preface

Purpose of the manual

This manual supplements the

ET 200S Distributed I/O System

Operating Instructions.

General functions for the ET 200S are described in the

ET 200S Distributed I/O System

Operating Instructions.

The information in this document along with the operating instructions enables you to

commission the ET 200S.

Basic knowledge requirements

To understand these operating instructions you should have general knowledge of

automation engineering.

Scope of the manual

This manual applies to this ET 200S module. It describes the components that are valid at

the time of publication.

Recycling and disposal

Thanks to the fact that it is low in contaminants, this ET 200S module is recyclable. For

environmentally compliant recycling and disposal of your electronic waste, please contact a

company certified for the disposal of electronic waste.

Additional support

If you have any questions relating to the products described in these operating instructions,

and do not find the answers in this document, please contact your local Siemens

representative.

http://www.siemens.com/automation/partner

The portal to our technical documentation for the various SIMATIC products and systems is

available at:

http://www.siemens.com/automation/simatic/portal

The online catalog and ordering system are available at:

http://www.siemens.com/automation/mall

Preface

2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

4 Manual, 04/2007, A5E01076940-01

Training center

We offer courses to help you get started with the ET 200S and the SIMATIC S7 automation

system. Please contact your regional training center or the central training center in D -

90327, Nuremberg, Germany.

Phone: +49 (911) 895-3200.

http://www.siemens.com/sitrain

Technical Support

You can reach technical support for all A&D projects

● using the support request web form:

http://www.siemens.com/automation/support-request

● Phone: + 49 180 5050 222

● Fax: + 49 180 5050 223

For more information about our technical support, refer to our Web site at

http://www.siemens.de/automation/service

Service & Support on the Internet

In addition to our documentation services, you can also make use of our comprehensive

online knowledge base on the Internet.

http://www.siemens.com/automation/service&support

There you will find:

● Our Newsletter, which constantly provides you with the latest information about your

products.

● The right documentation for you using our Service & Support search engine.

● The bulletin board, a worldwide knowledge exchange for users and experts.

● Your local contact for Automation & Drives in our contact database.

● Information about on-site services, repairs, spare parts. Lots more can be found on our

"Services" pages.

2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

Manual, 04/2007, A5E01076940-01 5

Table of contents

Preface ...................................................................................................................................................... 3

1 Properties .................................................................................................................................................. 7

1.1 2AO U HF analog electronic module (6ES7135-4LB02-0AB0) .....................................................7

2 Parameters.............................................................................................................................................. 11

2.1 Parameters...................................................................................................................................11

3 Diagnostics.............................................................................................................................................. 13

3.1 Diagnostics using LED display.....................................................................................................13

3.2 Error types....................................................................................................................................14

4 Analog value representation .................................................................................................................... 15

4.1 Introduction ..................................................................................................................................15

4.2 Analog value representation for measuring range with SIMATIC S7 ..........................................15

4.3 Output ranges ..............................................................................................................................16

4.4 Effect on analog value representation .........................................................................................17

4.4.1 Effect of the supply voltage and the operating state on analog output values ............................17

4.4.2 Effect of the value range on the 2AO U HF analog output ..........................................................18

5 Connecting .............................................................................................................................................. 19

5.1 Connecting analog outputs ..........................................................................................................19

Index........................................................................................................................................................ 21

Table of contents

2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

6 Manual, 04/2007, A5E01076940-01

2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

Manual, 04/2007, A5E01076940-01 7

Properties 1

1.1 2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

Properties

● 2 outputs for voltage output

● Output range:

– ±5 V, resolution 15 bits + sign

– ± 10 V, resolution 15 bits + sign

– 1 V to 5 V, resolution 15 bits

● Isolated from the load voltage L+

● Supports isochronous operation

– Minimum time for the synchronous DP cycle (TDPmin): 0.7 ms

– Minimum conversion time of the output modules: (TWAmin): 0.5 ms

● Supports I&M functions

General terminal assignment

Note

Terminals A4, A8, A3 and A7 are only available on certain terminal modules.

Terminal assignment for 2AO U HF (6ES7135-4LB02-0AB0)

Terminal Assignment Terminal Assignment Notes

1 QV

0 5 QV

2 S

0+ 6 S

3 M

ana 7 M

ana

4 S

0- 8 S

A4 AUX1 A8 AUX1

A3 AUX1 A7 AUX1

•QVn: Analog output voltage, Channel n

•Sn+: Tracer line positive, Channel n

•Sn-: Tracer line negative, Channel n

•Mana: Ground of the module

•AUX1: Protective-conductor terminal or potential bus (freely usable

up to 230 VAC)

Properties

1.1 2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

8 Manual, 04/2007, A5E01076940-01

Usable terminal modules

Usable terminal modules for 2AO U HF (6ES7135-4LB02-0AB0)

TM-E15C26-A1

(6ES7193-4CA50-

0AA0)

TM-E15C24-01

(6ES7193-4CB30-

0AA0)

Spring terminal

TM-E15S26-A1

(6ES7193-4CA40-

0AA0)

TM-E15S24-01

(6ES7193-4CB20-

0AA0)

Screw-type terminal

TM-E15N26-A1

(6ES7193-4CA80-

0AA0)

TM-E15N24-01

(6ES7193-4CB70-

0AA0)

Fast Connect

















$8; 























6

6

DQD

6

6

DQD

ZLUH

ZLUH

:LULQJH[DPSOHV

Block diagram

'$8



9



/



0



'$8



















$1$



















$1$



$1$



3



3



(7b6

%DFNSODQHEXV

LQWHUIDFH

%DFNSODQHEXV

Figure 1-1 Block diagram of the 2AO U HF

Properties

1.1 2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

Manual, 04/2007, A5E01076940-01 9

2AO U HF technical specifications (6ES7135-4LB02-0AB0)

Dimensions and weight

Width (mm) 15

Weight Approx. 40 g

Module-specific data

Supports isochronous operation Yes

Supports I&M functions Yes

Number of outputs 2

Cable length

•Shielded Max. 200 m

Max. 100 m where TWA < 2 ms

Analog value representation S5 and S7 format

Parameter length 7 bytes

Address space 4 bytes

Voltages, currents, potentials

Rated load voltage L+ (from the power module) 24 VDC

•Reverse polarity protection Yes

Electrical isolation

•Between the channels and backplane bus Yes

•Between the channels and load voltage L+ Yes

•Between the channels No

Permissible potential difference

•Between MANA and the central grounding point

(Uiso) 75 V DC/60 V AC

Insulation tested 500 VDC

Current consumption

•From load voltage L+ Max. 80 mA

Power dissipation of the module Max. 1.2 W

Status, interrupts, diagnostics

Diagnostics function

•Group error display Red "SF" LED

•Diagnostic information readable Supported

Substitute values can be applied Yes, parameterizable

Analog value generation

Cycle time per module 0.5 ms

Resolution (including overshoot range) ±5 V/15 bits + sign

±10 V/15 bits + sign

1 V to 5 V/15 bits

Settling time

•For resistive load 0.3 ms

•For capacitive load 0.5 ms

•For inductive load 0.5 ms

Properties

1.1 2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

2AO U HF analog electronic module (6ES7135-4LB02-0AB0)

10 Manual, 04/2007, A5E01076940-01

Suppression of interference, limits of error

Crosstalk between the outputs Min. -60 dB

Operational limit ± 0,1 %

Intrinsic error limit ± 0,05 %

Temperature error (with reference to the output

range)

±0.003%/K

Linearity error (with reference to the output range) ± 0,01 %

Repeatability (in steady state at 25°C with

reference to output range)

± 0,01 %

Transmitter selection data

Output range (rated value) ±5 V

±10 V

1 V to 5 V

Load impedance (in the rated range of the output)

•At voltage outputs

Capacitive load

Min. 1.0 kΩ

Max. 0.5 µF

Voltage output

•Short circuit protection

•Short circuit voltage

yes

approx. 25 mA

Destruction limit against voltages/currents applied

from outside

•Voltage at the outputs to MANA Max. 15 V continuous; 75 V for max. 1 ms

(sampling ratio 1:20)

Connection of actuators

•Voltage output

2-wire connection

4-wire connection

Possible, without compensation of the line

resistances

Possible

I&M functions

The I&M data can be read from the module using interface modules with the following order

numbers or firmware/product versions (or higher):

Interface module Order number Firmware version Product version

IM151-1 HIGH FEATURE 6ES7151-1BA01-0AB0 V2.0 02

IM151-3 PN 6ES7151-3AA20-0AB0 V4.0 01

IM151-3 PN HIGH FEATURE 6ES7151-3AA20-0AB0 V4.0 01

IM151-3 PN FO 6ES7151-3BB21-0AB0 V4.0 01

Note

Using the module after an IM151-7 CPU

If the module is positioned after an IM151-7 CPU, it outputs the last values before a RUN-

STOP transition, provided no values were output by the user program after the STOP-RUN

transition.

Take this into account when programming the control function startup (OB100 or OB1).

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Unidad de control de Siemens

Siemens

Siemens SIMATIC ET 200S Manual de usuario

Siemens

Siemens SIRIUS 3RW5 series Manual de usuario

Siemens

Siemens SIRIUS 3RA2711 C Series Manual de usuario

Siemens

Siemens CU240S DP-F Manual de usuario

Siemens

Siemens SIRIUS ACT 3SU14 Manual de usuario

Siemens

Siemens 6ES7134-4FB51-0AB0 Manual de usuario

Siemens

Siemens SIRIUS 3RT1916-4KA Manual de usuario

Siemens

Siemens SIMATIC ET 200SP CM 1xDALI Manual de usuario

Siemens

Siemens SIMADYN D FM 458 Manual de usuario

Siemens

Siemens SINAMICS G120 Manual de usuario

Siemens

Siemens MJ-XL Manual de usuario

Siemens

Siemens SIMATIC Documento técnico

Siemens

Siemens SINUMERIK 840D sl Manual del propietario

Siemens

Siemens Simatic S7-1500 Manual de usuario

Siemens

Siemens MOD-16 Manual de usuario

Siemens

Siemens SIMATIC ET 200S IM151-1 FO STANDARD Manual de usuario

Siemens

Siemens Simatic S7-400 Manual de usuario

Siemens

Siemens SINAMICS DCM Hoja de datos

Siemens

Siemens XC1003-A Manual de instrucciones

Siemens

Siemens SIMATIC 505 Instrucciones de funcionamiento

Siemens

Siemens SINAMICS G130 Manual de usuario

Siemens

Siemens SINUMERIK 840D sl Manual de usuario

Siemens

Siemens SINUMERIK 840D sl Manual de usuario

Siemens

Siemens ACVATIX PS53 Manual de usuario

Manuales populares de Unidad de control de otras marcas

Festo

Festo Compact Performance CP-FB6-E Manual de lista de piezas

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manual de usuario

JS Automation

JS Automation MPC3034A Manual de usuario

JAUDT

JAUDT SW GII 6406 Series Guía rápida

Spektrum

Spektrum Air Module System Manual de usuario

BOC Edwards

BOC Edwards Q Series Manual de usuario

KHADAS

KHADAS BT Magic Manual de usuario

Etherma

Etherma eNEXHO-IL Manual de usuario

PMFoundations

PMFoundations Attenuverter Manual de usuario

GEA

GEA VARIVENT Manual de usuario

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manual de usuario

Altronix

Altronix LINQ8PD Instrucciones de montaje

Eaton

Eaton Powerware Series Manual de usuario

WAGO

WAGO 750-407/040-000 Manual de usuario

Sony

Sony CCU-590 Manual de usuario

Graco

Graco 25D614 Manual de usuario

Task Force Tips

Task Force Tips YE-RF-900 Manual de programación

Shini

Shini SPV-U Series Manual de usuario
