Siemens CP 443-5 Basic Manual de usuario

SIMATIC NET

S7–CPs for PROFIBUS

Manual Part B3

CP 443-5 Basic

6GK7 443-5FX01-0XE0 Version 3 and higher (Firmware version V3.2 and higher)

for SIMATIC S7-400 / S7-400H

PROFIBUS interface

(9-pin sub-D female

connector)

Mode Selector

Status and fault LEDs

该文档是极速PDF编辑器生成，

如果想去掉该提示,请访问并下载：

http://www.jisupdfeditor.com/

长沙工控帮教育科技有限公司

www.gkbpx.com

Notes on the Product

2CP 443-5 Basic for PROFIBUS / Manual Part B3 –

Release 11/2002

C79000-G8976-C161-03

Notes on the Product

Note

All notes in the product information bulletin, which is supplied with this product,

are valid and must be observed.

Compatibility with the Previous Version

Note

Make sure that you read the information regarding extended functionality and

restrictions in Chapter 6 of this manual!

该文档是极速PDF编辑器生成，

如果想去掉该提示,请访问并下载：

http://www.jisupdfeditor.com/

长沙工控帮教育科技有限公司

www.gkbpx.com

B3–3

CP 443-5 Basic for PROFIBUS / Manual Part B3 –

Release 11/2002

C79000-G8976-C161-03

Contents

Contents – Part A

PROFIBUS CPs – General Information See General Part. . . . . . . . . . . . . .

Note

Please remember that Part A of the manual also belongs to the description of the

CP. Among other things, it contains explanations of the safety notices and general

information that applies to all S7 CPs for PROFIBUS.

You can also download this general part from the Internet:

http://www4.ad.siemens.de/view/cs/de/8774037

Contents – Part B3

1 Properties / Services B3–4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Requirements for Use B3–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 Use with the Current CPU Types B3–7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Converting older Systems B3–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Setup and Installation B3–10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 Displays and Mode Selector B3–11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5 Performance Data B3–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.1 Supported Transmission Rates B3–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.2 Data of S5-Compatible Communication (SEND/RECEIVE Interface)

on FDL Connections B3–13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.3 Data of FMS Connections B3–14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.4 Characteristics of S7 Communication B3–16. . . . . . . . . . . . . . . . . . . . . . . . . . .

5.5 Maximum Number of Connections in Total B3–17. . . . . . . . . . . . . . . . . . . . . . .

5.6 Time-of-day Synchronization B3–17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.7 Use in Fault-Tolerant Systems B3–18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.8 Other Characteristics B3–19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6 Compatibility with the Previous Product B3–20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.1 Extended Functionality Compared with Previous Product B3–20. . . . . . . . . .

6.2 Replacing Older Modules / Replacing Defective Modules B3–21. . . . . . . . . .

7 Technical Specifications B3–22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

该文档是极速PDF编辑器生成，

如果想去掉该提示,请访问并下载：

http://www.jisupdfeditor.com/

长沙工控帮教育科技有限公司

www.gkbpx.com

Properties / Services

B3–4 CP 443-5 Basic for PROFIBUS / Manual Part B3 –

Release 11/2002

C79000-G8976-C161-03

Properties / Services

Application

The CP 443-5 Basic communications processor is designed for use in a SIMATIC

S7-400 (standard) and S7-400H (fault-tolerant system) programmable controller. It

allows the S7-400 / S7-400H to be connected to a PROFIBUS field bus system.

Services

The current version of the CP 443-5 Basic supports the following communication

services in the standard and H systems:

SPROFIBUS FMS (complying with EN 50170, FMS client and server function)

as FMS master for the following types of connection:

– MMAC: Master-master acyclic

– MSAC: Master-slave acyclic

– MSAC_SI: Master-slave acyclic with slave initiative

– MSCY: Master slave cyclic

– BRCT (broadcast): Sending to all FMS stations

SS7 communication and PG/OP communication

– PG functions with upload / download of FM modules, configuration /

diagnostics and routing

Note on routing: Dynamic switchover to alternative paths (for example if

there is a problem on one of the possible transmission paths) is not

supported.

– Operator control and monitoring functions (HMI)

– Data exchange using communication function blocks on S7 connections

(fault-tolerant S7 connections also possible) 1)

Blocks for S7 communication (see also STEP 7 online help or

“System Software for S7-300/400 System and Standard Functions” manual):

BSEND SFB 12

BRCV SFB 13

PUT SFB 14

GET SFB 15

USEND SFB 8

URCV SFB 9

START SFB 19

STOP SFB 20

RESUME SFB 21

STATUS SFB 22

USTATUS SFB 23

CONTROL SFC 62

该文档是极速PDF编辑器生成，

如果想去掉该提示,请访问并下载：

http://www.jisupdfeditor.com/

长沙工控帮教育科技有限公司

www.gkbpx.com

Properties / Services

B3–5

CP 443-5 Basic for PROFIBUS / Manual Part B3 –

Release 11/2002

C79000-G8976-C161-03

SS5-compatible communication (SEND/RECEIVE Interface) over FDL

connections of the following types:

– specified FDL connections

– free layer 2 connections

– broadcast

– multicast

STime-of-day synchronization over PROFIBUS

– The CP forwards time-of-day synchronization frames from the LAN to the

station (CPU = time slave) or from the station to the LAN (CPU= time

master) or this station is synchronized via a different LAN and the

time-of-day synchronization frame must be forwarded over PROFIBUS for

the synchronization of further stations.

– Time-of-day status value, standard/daylight saving time switchover,

synchronization status

The services of the CP 443-5 Basic module listed above can be used at the same

time.

Configuration

When configuring, you must use STEP 7 version V5.1 SP2 or higher; for FDL

connections and diagnostic functions you must already have installed the NCM S7

for PROFIBUS optional package, delivered with STEP 7. Depending on the version

you are using, note the following characteristics and special features:

SSTEP 7 version 5.0 Service Pack 3

This version is the minimum requirement for the routing of PG functions and

time-of-day synchronization.

The optional package “SIMATIC S7 H Systems” must also be installed to

configure fault-tolerant systems.

The following functions of the CP are not yet supported in this configuration

environment when using fault-tolerant systems:

– Single (non-redundant) communications connections cannot be configured in

a fault-tolerant system;

该文档是极速PDF编辑器生成，

如果想去掉该提示,请访问并下载：

http://www.jisupdfeditor.com/

长沙工控帮教育科技有限公司

www.gkbpx.com

Properties / Services

B3–6 CP 443-5 Basic for PROFIBUS / Manual Part B3 –

Release 11/2002

C79000-G8976-C161-03

SSTEP 7 version 5.1 Service Pack 3

All the functions described can be used.

When configuring fault-tolerant systems you must also install the “SIMATIC S7

H Systems” optional package.

It is possible to configure over the MPI or LAN/PROFIBUS.

System modifications are possible during operation (H system).

Programming – Using Blocks

For some communication services, there are “off-the-peg” blocks (FCs/FBs)

available that implement the interface in your STEP 7 user program. You will find a

detailed description of these blocks in the NCM S7 for PROFIBUS manuals.

Notice

We recommend that you always use the latest block versions for all module types.

You will find information on the latest block version and links to download the

current blocks in our Customer Support on the Internet:

http://www4.ad.siemens.de/view/cs/en/8797900

If you are using older block types, this recommendation only applies if you also

have the latest firmware version.

You will find further information and Internet addresses in the Preface of the

General Part of this manual.

Module Replacement without PG

Depending on the setting in the project configuration, the configuration data can

also be stored in the load memory of the CPU. Therefore replacing modules is

possible without having to download the configuration data from the PG.

The stored configuration data are protected from power outage by battery backup

or by plugging an EPROM card into the CPU.

该文档是极速PDF编辑器生成，

如果想去掉该提示,请访问并下载：

http://www.jisupdfeditor.com/

长沙工控帮教育科技有限公司

www.gkbpx.com

Requirements for Use

B3–7

CP 443-5 Basic for PROFIBUS / Manual Part B3 –

Release 11/2002

C79000-G8976-C161-03

Requirements for Use

The CP 443-5 Basic described here is supported by all the CPU operating systems

listed in the table below.

The chapter also contains the following information:

SThe number of CPs that can be operated with one CPU.

SThe number of AG-SEND or AG-RECV calls on the SEND/RECEIVE interface

that can be active at the same time (data exchange on FDL connections over

PROFIBUS and corresponding connections over Industrial Ethernet).

2.1 Use with the Current CPU Types

When operating the CP 443-5 Basic with the CPU types listed here in the table,

the following functionality is supported without exception:

SNumber of operable CPs: 14

SMulticomputing (except for H systems)

Table 2-1 Use with the Current CPU Types

CPU Order number Firmware version

Number of AG-SEND or AG-RECV

calls at same time

CPU 412 6ES7 412-1XF03-0AB0 As of V3.0 24 / 24

CPU 412-2 6ES7 412-2XG00-0AB0 As of V3.0

CPU414-2 128 KB 6ES7 414-2XG03-0AB0 As of V3.0

CPU414-3 384 KB 6ES7 414-3XJ00-0AB0 As of V3.0

CPU 414-4H 6ES7 414-4HJ00-0AB0 As of V3.0

CPU416-2 0.8 MB 6ES7 416-2XK02-0AB0 As of V3.0 64 / 64

CPU416-3 1.6 MB 6ES7 416-3XL00-0AB0 As of V3.0

CPU 417-4 6ES7 417-4XL00-0AB0 As of V3.0

CPU 417-4H 6ES7 417-4HL00-0AB0 As of V2.1

6ES7 417-4HL01-0AB0 As of V3.0

CPU416F-2 1.6 MB 6ES7 416-2FK02-0AB0 As of V3.1 64 / 64

该文档是极速PDF编辑器生成，

如果想去掉该提示,请访问并下载：

http://www.jisupdfeditor.com/

长沙工控帮教育科技有限公司

www.gkbpx.com

Requirements for Use

B3–8 CP 443-5 Basic for PROFIBUS / Manual Part B3 –

Release 11/2002

C79000-G8976-C161-03

2.2 Converting older Systems

The discontinued CPUs listed here in Table 2-2 support the following functionality

in conjunction with the CP 443-5 Basic:

SNumber of operable CPs: 8

SMulticomputing

Table 2-2 Use with Discontinued CPU Types

CPU Order number Version

Number of AG-SEND or AG-RECV

calls at same time

CPU 412 6ES7 412-1XF01-0AB0 2 or

higher 12 / 12

6ES7 412-1XF02-0AB0 2 or

higher

CPU 413 6ES7 413-1XG01-0AB0 2 or

higher

6ES7 413-1XG02-0AB0 1 or

higher

CPU 413-2 6ES7 413-2XG01-0AB0 2 or

higher

6ES7 413-2XG02-0AB0 1 or

higher

CPU414–1 6ES7 414-1XG01-0AB0 2 or

higher

6ES7 414-1XG02-0AB0 2 or

higher

CPU414-2 128 KB 6ES7 414-2XG01-0AB0 2 or

higher

6ES7 414-2XG02-0AB0 2 or

higher

CPU414-2 384 KB 6ES7 414-2XJ00-0AB0 4 or

higher

6ES7 414-2XJ01-0AB0 2 or

higher

该文档是极速PDF编辑器生成，

如果想去掉该提示,请访问并下载：

http://www.jisupdfeditor.com/

长沙工控帮教育科技有限公司

www.gkbpx.com

Requirements for Use

B3–9

CP 443-5 Basic for PROFIBUS / Manual Part B3 –

Release 11/2002

C79000-G8976-C161-03

Table 2-2 Use with Discontinued CPU Types, continued

CPU VersionOrder number

CPU

Number of AG-SEND or AG-RECV

calls at same time

Order number

CPU416–1 6ES7 416-1XJ01-0AB0 2 or

higher 32 / 32

6ES7 416-1XJ02-0AB0 1 or

higher

CPU416-2 0.8 MB 6ES7 416-2XK00-0AB0 4 or

higher

6ES7 416-1XK01-0AB0 1 or

higher

CPU416-2 1.6 MB 6ES7 416-2XL00-0AB0 4 or

higher

6ES7 416-2XL01-0AB0 1 or

higher

该文档是极速PDF编辑器生成，

如果想去掉该提示,请访问并下载：

http://www.jisupdfeditor.com/

长沙工控帮教育科技有限公司

www.gkbpx.com

Installation and Commissioning

B3–10 CP 443-5 Basic for PROFIBUS / Manual Part B3 –

Release 11/2002

C79000-G8976-C161-03

Installation and Commissioning

Procedure / Steps

Table 3-1

Step Explanation / Meaning

1. Insert the CP 443-5

Basic The CP 443-5 Basic can be inserted in all racks with slots for P and K bus

attachment:

SCentral rack CR2

SUniversal rack UR1, UR2 or UR2H

as central rack

as expansion rack with rack no. 1–6

Note

When using the universal rack as an extension rack, you require an IM with a communication bus link!

The CP 443-5 Basic cannot be operated in an ER1 or ER2 expansion rack

(no K bus link possible).

Suitable slots in the rack:

With the exception of the slots reserved for the power supply and IM-R, the

CP 443-5 Basic can be inserted in all slots with a P and K bus interface (in

the central or in an expansion rack no. 1–6).

2. Attachment to

PROFIBUS Note the information in the General section of this manual.

Note

When using the CR2 rack, the CPU and CP must be plugged into the same segment if you want to use

FDL/FMS connections.

3. Configuration Depending on the communication services being used, configuration involves

the following steps:

SNode initialization

This is necessary in all situations. This assigns a PROFIBUS address

and bus parameters to the PROFIBUS CP. For details, refer to /4/

SConfiguring connections:

This is necessary when using the communication services, S7 functions

and FDL connections (SEND/RECEIVE interface). For details, refer to /5/

or /4/.

4. PG/PC Attachment

for Configuration You can connect the PG when configuring the CP as follows:

Svia MPI

Svia LAN / PROFIBUS

The CP 443-5 Basic must already have a PROFIBUS address (for details

of node initialization, refer to /4/).

该文档是极速PDF编辑器生成，

如果想去掉该提示,请访问并下载：

http://www.jisupdfeditor.com/

长沙工控帮教育科技有限公司

www.gkbpx.com

Tabla de contenidos

Otros manuales de Sistema de conferencias de Siemens

Siemens

Siemens Simatic S7-1500/ET 200MP Manual de usuario

Siemens

Siemens OZW775 Manual de usuario

Siemens

Siemens CP 5623 Manual de usuario

Siemens

Siemens CP 1243-1 PCC Manual de usuario

Siemens

Siemens Hicom 150 E Office Manual de usuario

Siemens

Siemens OCI600 Manual de usuario

Siemens

Siemens Simatic S7-400 Manual de usuario

Siemens

Siemens HiPath Series Manual de usuario

Siemens

Siemens CP 5612 Manual de usuario

Siemens

Siemens SIPROTEC4 7UM62 Manual de usuario

Siemens

Siemens SIMATIC NET S7-300-PROFIBUS CP 342-5 Documento técnico

Siemens

Siemens CP 342-5 Manual de usuario

Siemens

Siemens CP 5711 Manual de usuario

Siemens

Siemens HiPath BizIP Manual de usuario

Siemens

Siemens Synco ZW775 V2.0 Manual de capacitación

Siemens

Siemens HiPath 3000 V3.0 or later Gigaset M1... Manual de usuario

Siemens

Siemens CM 1542-1 Manual de usuario

Siemens

Siemens Hicom 150 E Office Manual de usuario

Siemens

Siemens HiPath3550 Manual de usuario

Siemens

Siemens SIMATIC IO-Link system Manual de lista de piezas

Siemens

Siemens Hicom 300 optiset E Standard Manual de usuario

Siemens

Siemens Hicom Office PhoneMail Manual de instrucciones

Siemens

Siemens OCI611 Series Manual de usuario

Siemens

Siemens SIMATIC NET S7-400 Manual de usuario

Manuales populares de Sistema de conferencias de otras marcas

Kramer

Kramer VIA GO Manual de usuario

AVT

AVT MAGIC AC1 Go Manual de usuario

ProSoft Technology

ProSoft Technology AN-X4-AB-DHRIO Manual de usuario

Sony

Sony PCS-I150 Manual de usuario

Middle Atlantic Products

Middle Atlantic Products VTC Series Manual de usuario

Prentke Romich Company

Prentke Romich Company Vanguard Plus Guía

Speakerbus

Speakerbus iD 712 Manual de usuario

Trelleborg

Trelleborg SafePilot CAT PRO Manual de usuario

Sennheiser

Sennheiser ADN Manual de usuario

ADTRAN

ADTRAN NetVanta 7100 Manual de usuario

AINA

AINA PTT Voice Responder Manual de usuario

Yamaha

Yamaha ProjectPhone PJP-100H Manual de usuario

vissonic

vissonic VLI Series Manual de usuario

Panasonic

Panasonic KX-VC500 Manual de usuario

Poly

Poly Trio 8300 Manual de usuario

Crestron

Crestron Mercury CCS-UCA-SMK Dibujo dimensional

Inmarsat

Inmarsat mini M Manual de usuario

Tenveo

Tenveo ALL-IN-ONE Manual de usuario
