SERVICE MANUAL

CODE: 00ZARRB1//A1E

DIGITAL FULL COLOR COPIER/PRINTER/

MULTIFUNCTIONAL SYSTEM OPTION

DUPLEX BYPASS/INVERTER UNIT

MODEL AR-RB1

CONTENTS

[1] SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

[2] UNPACKING AND INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . 1-1

[3] INTERIOR CONSTRUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1

[4] DESCRIPTION OF OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1

[5] DISASSEMBLY, ASSEMBLY AND MAINTENANCE . . . . . . . . . . . 5-1

[6] ELECTRICAL SECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1

PARTS GUIDE

Parts marked with “ ” are important for maintaining the safety of the set. Be sure to replace these parts with

specified ones for maintaining the safety and performance of the set.

SHARP CORPORATION This document has been published to be used

for after sales service only.

The contents are subject to change without notice.

AR-RB1 SPECIFICATIONS 1 - 1

[1] SPECIFICATIONS

1. Type

2. System

3. Paper size

4. Paper weight

5. Paper capacity

6. Paper feed transport speed

7. Paper feed speed

8. Power supply

9. Weight

10. Drive pattern

11. Outer dimensions

12. Power consumption

[2] UNPACKING AND

INSTALLATION

1. UNPACKING

Note: Never put the reverse bypass module down by the dotted sec-

tion on the floor. (The full actuator may be damaged.)

2. Installation

Before installation

•Start installation after checking that the DATA indicator on the oper-

ation panel is neither lit nor blinking.

•For installation of AR-RB1, an optional stand (AR-D17/AR-D18/AR-

D19) must have been installed.

•Ensure that the connecting plate located on the front side of the

optional stand and the connecting plates on the sides (one on the

right side and left side respectively) are securely attached.

Duplex bypass with paper delivery reverse

Straight path Face-up paper delivery

Reverse path Face-down delivery

Duplex bypass Reverse direction and delivery to duplex unit

A3W/A3/B4/A4/A4R/B5/B5R/A5/A6R/Custom

(12 ×18/11 ×17/8.5 ×14/8.5 ×13/8.5 ×11/8.5 ×11R/7.25 ×10.5R/

8.5 ×5.5/EXERA)

Face-up delivery 64 –105g/m2, 106 –300g/m2

Face-down delivery/

ADU delivery

64 –105g/m2, 106 –200g/m2

250 sheets

(conditions: A4/letter size recommended, face-down delivery)

58.5mm/s –550mm/s

(speed based on signal commands from the copier)

Full color 26 sheets/min. (A4 landscape feed)

Monochrome 33 sheets/min. (A4 landscape feed)

5V, 24V supplied by the desk control PWB

6.5 kg

Paper feed, upper and lower turnover motors (stepping motors) and

drive PWB built-in

442.6 (W) ×126.2 (D) ×431.8 (H) mm

24V: 1A/24W

5V: 0.1A/0.5W

Packing case

Spacer

Accessories

Restraining tape

(remove)

Restraining tape (remove)

AR-RB1 UNPACKING AND INSTALLATION 2 - 2

Parts included

1. Turn off the main switch of the main unit.

1) Turn the main switch located on the left side of the main unit to the

"OFF" position.

2) Then remove the power plug of the main unit from the outlet.

2. Remove the actuator.

1) If the exit tray is installed to the main unit, remove it.

2) While holding the base of the exit actuator of the main unit with one

hand, pull the end of the actuator with the other hand to remove

the actuator.

3. Remove the paper output section covers.

1) Pull the centers of the two paper output section covers on the left

side of the main unit to remove them.

In the case of AR-D17/D18:

1) Pull the lock release lever on the left side of the main unit to pull

out the left cover until it stops.

2) Pull the upper part of the paper input section cover on the left side

of the optional stand to remove the paper input section cover.

Transport guide holder: 2 pcs.

Actuator: 1 pc.

Transport guide: 1 pc.

"OFF"

Exit actuator

Paper output

section covers

Lock release lever

Left cover

Paper input section cover

AR-RB1 UNPACKING AND INSTALLATION 2 - 3

4. Attach the duplex bypass/inverter unit to the main

unit.

1) Close the left cover.

2) Hold the duplex bypass/inverter unit as shown in the illustration

and hang the two positioning bosses at the upper part in the two

positioning holes on the left cover of the main unit.

At this time, check that the two positioning bosses are hung

securely in the two positioning holes of the main unit.

3) Ensure that there is no clearance between the main unit and the

duplex bypass.

5. Secure the duplex bypass/inverter unit.

1) Close the cover of the duplex bypass/inverter unit and tighten the

two built-in screws to secure the duplex bypass to the main unit.

At this time, take care not to damage the transport surface with the

tip of a screwdriver.

2) Close the cover of the duplex bypass/inverter unit and reattach the

exit tray that has been removed in step 2<1> in the raised position

as shown in the illustration.

3) Insert the supplied actuator into the duplex bypass.

6. Attach the transport guide.

1) Pull the lock release lever to pull out the left cover.

2) Insert the transport guide into the paper input section (upper

groove) of the stand.

Positioning bosses

Positioning holes

Transport surface

Actuator

Lock release lever

Transport guide

AR-RB1 UNPACKING AND INSTALLATION 2 - 4

3) Attach the transport guide to the duplex bypass/inverter unit and

insert the two transport guide holders into the two transport guides

respectively. At this time, ensure that the transport guide holders

are secured at the notch positions.

4) After checking that the transport guide is aligned with the guide of

the stand, close the left cover of the main unit securely.

7. Connect the harness of the duplex bypass/

inverter unit.

1) Remove the screw from the power supply cover on the rear side of

the optional stand and then remove the power supply cover.

2) Cut out the portion (indicated with H) of the removed power supply

cover shown in the illustration.

3) Connect the relay harness of the duplex bypass/inverter unit to the

connector of the optional stand.

Then, insert the snap band into the mounting hole shown in the

illustration to secure the relay harness.

4) Pass the relay harness through the cut out hole, hang the two

pawls of the power supply cover on the rear cabinet, and attach the

cover with the screw.

Installation of AR-RB1 is now complete.

Transport guide holders

Front side

Rear side

Transport guide holder Transport guide holder

Transport guide Transport guide

Front side Rear side

Notch Notch

Notches

Power supply cover

Screw

Cut-out portion

Snap band

Relay harness

Connector

Power supply cover

Pawls

Screw

Relay harness

AR-RB1 INTERIOR CONSTRUCTION 3 - 1

[3] INTERIOR CONSTRUCTION

Motors and solenoid

PWB and sensors

No. Name Abbreviation Function/operation

1 Paper feed motor BIM Transports paper to the paper feed section

2 Gate solenoid BGSOL Switches the gate for straight delivery and reverse delivery

3 Upper turnover motor BRM Paper transport in upper section

4 Lower turnover motor BTM Paper transport in lower section

No. Name Abbreviation Function/operation

1 Door open/closed detector 1 BDD1 Detects open/closed status of upper door

2 Paper delivery sensor BPOD Detects discharged paper

3 Full capacity detection sensor BPFD Detects full capacity status in paper tray

4 BY drive PWB BY drive PWB INVERTER drive and controller

5 Transport sensor 1 BPPD1 Detects transport of paper

6 Reverse section detection sensor BPRD Detects presence of paper in the reverse section

7 Transport sensor 1 BPPD2 Detects transport of paper

8 Door open/closed detector 2 BDD2 Detects open/closed status of lower door

AR-RB1 INTERIOR CONSTRUCTION 3 - 2

Cross-section diagram

No. Name Function/operation

1 Delivery roller Discharges paper to the tray, or transports paper to the finisher.

2 Idle roller Applies a pressure to the delivery roller to transport and discharge paper.

3 Idle roller Applies a pressure to the paper feed roller to transport paper.

4 Paper feed roller Transports paper being transported from the main unit to the paper-out and reverse bypass direction.

5 Upper reverse roller Transports paper to the paper-out and reverse bypass direction.

6 Upper transport roller Transports paper to the paper-out and reverse bypass direction.

7 Lower reverse roller Reverses paper and transports it to ADU.

8 Idle roller Applies a pressure to the lower reverse roller to transport paper.

9 Idle roller Applies a pressure to the lower transport roller to transport paper.

10 Idle roller Applies a pressure to the paper exit roller to transport paper.

11 Paper exit roller Transports paper to ADU.

12 Lower transport roller Transports paper to ADU.

13 Idle roller Applies a pressure to the upper transport roller to transport paper.

14 Idle roller Applies a pressure to the upper reverse roller to transport paper.

123

AR-RB1 DESCRIPTION OF OPERATION 4 - 1

[4] DESCRIPTION OF OPERATION

[Outline of operation]

•The operations include straight delivery, reverse tray delivery, reverse finisher delivery, and ADU delivery (when AR-D19 is installed) operations.

[Sensor and solenoid operation]

BIM (paper in-motor) changes the transport path of the fed paper when BGSOL (gate solenoid) straight delivery is ON and all other operations are

OFF.

•In the case of straight delivery, BPOD (paper discharge detect) detects the passing paper.

•In the case of reverse tray delivery operation, the paper-in motor and the upper reverse motor operates, the paper is fed, and BPPD1 is detected.

Afterward, the upper reverse motor stops, and the paper transport stops.

Next, the upper reverse motor rotates in reverse to transport paper to the direction of paper exit tray.

After BPOD (paper discharge detect) detects the passing paper, it turns off the upper reverse motor.

•In the case of reverse finisher delivery operation, the same as reverse tray delivery operation.

•In the case of ADU operation, the lower reverse motor operates, and the paper being transported to the reverse roller is detected by BPRD.

After being detected, the lower reverse motor stops, then it rotates in reverse, and the paper is transported to ADU.

After BPPD2 detects the passing paper, it turns off the motor.

+24V

+5V

GND

BRM/A

BRM/B

BPOWD

BTMA

BTMB

/BDD2

BFM

BIMA

BIMB

Vref1

/BPOD

/BPPD1

/BPRD

+24V

GND

32 /BYSET

BRMA

BRMB

BTM/A

BTM/B

26 +24V

BGSOL

BIM/A

BIM/B

BPOWD2

16 Vref2

/BPFD

/BPPD2

6/BDD1

GND

/BPOD

+5V

GND

/BPFD

+5V

GND

/BPRD

+5V

GND

/BPPD2

+5V

CN-H (6pin)

CN-E (3pin) CN-D (6pin) CN-C (8pin)

CN-G (9pin) CN-F (10pin)

CN-A (32pin)

BY drive PWB

Desk control PWB

CN-G (32pin)

BTM/B

+24V

BTMB

BTMA

BTM/A

BIM/B

+24V

BIMB

BIMA

BIM/A

BRM/B

+24V

BRMB

BRMA

BRM/A

+5V

/BPPD1

GND

123 123

+24V

/BGSOL

ADU

BRM

BPPD2

BPPD1

BGSOL

BPRD

BTM

BIM

BPODBPFD Paper feed motor

Upper turnover

motor

Transport of

paper

detected

Lower turnover

motor Presence of

paper in reverse

section detected

Transport of

paper detected

AR-RB1 DESCRIPTION OF OPERATION 4 - 2

(1) Initial operation

When the power to the copier is turned on, in order to confirm whether

or not there is paper in the transport path, the paper input motor, upper

turnover motor and lower turnover motor revolve for a predetermined

time.

Even after the predetermined time has passed, if all the transport sen-

sors are OFF and it is determined that there is no paper in the trans-

port path, if within a given period of time at least one transport sensor

turned ON, it is interpreted as paper being present in the transport path

(paper jam).

(2) Straight delivery operation

In this operation, the paper discharged from the copier is sent directly

to the paper exit tray or transported to the finisher.

When the paper input motor and upper turnover motor revolve, the

paper input roller and delivery roller rotate in the directions as shown in

the figure below to discharge the paper.

If the paper is delivered to the finisher, it is transported at the same

speed at which it is discharged from the copier.

As the paper is discharged to the paper exit tray, when the trailing

edge reaches a point 50mm from the delivery roller on the copier side,

the speed of the delivery roller increases, and the paper is discharged

to the tray.

Unit: mm/s

Sensor input, motor output, solenoid output timing is as below.

Paper input motor

BPOD

BPPD1

BPRD

BPPD2

Upper turnover motor

Lower turnover motor

Paper kind Copier process

speed

RB1 tray delivery

speed

Thick paper 2 58.5 58.5

Envelope 117 117

OHP (priority: quality) 58.5 120

OHP (priority: speed) 117 160

Paper input roller

Delivery roller

BPOD

(Paper exit sensor)

BIM

(Paper-in motor)

BRM

(Upper reverse motor)

Process speed

BGSOL

(Gate solenoid)

Delivery speed

(Direction of

paper-in)

(Direction of

paper-out)

AR-RB1 DESCRIPTION OF OPERATION 4 - 3

(3) Reverse tray delivery operation

A. When paper length is 249mm or less (letter size or less)

(Both the paper input motor and upper turnover motor operate)

The relation between the process speed and the transport speed in

RB1 is as follow.

Unit: mm/s

Sensor input, motor output, solenoid output timing is as below.

Processing speed

The paper input motor and

upper turnover motor are

caused to turn in time with the

copier processing speed, thus

transporting the paper.

When the trailing edge of the paper

reaches a point 13mm from the copier

POD off, the transport speed in RB1

is accelerated.

Trailing edge of paper reaches

point 13mm from POD off

Transport speed

(high speed)

Transport speed

(high speed)

Transport

speed

(low speed)

When the trailing edge of

the paper reaches the upper

reverse stop point, the

motor stops.

Motor stop

(paper stop)

Motor stop

(discharge complete)

The upper turnover motor is

caused to revolve in the paper

delivery direction, and the paper

is discharged.

When the trailing edge of the paper

reaches a point 50mm before the

delivery roller, the transport speed

decreases.

Trailing edge of paper

reaches point 50mm

before delivery roller

After the trailing edge of the paper

passes the delivery roller, the

upper turnover motor stops.

Paper kind

Copier

process

speed

RB1transport

speed

(high speed)

Paper size

RB1 transport

speed

(low speed)

Normal paper 117/140 550 A3/A3W

/EXTRA

450

A4R 430

A4/B5/B5R 400

B4/A5 320

Thick paper 1 58.5 195 All size 195

POD

(Paper exit sensor)

BPPD1

(Transport sensor 1)

BPOD

(Paper-out sensor)

BIM

(Paper-in motor)

BRM

(Upper reverse motor)

BGSOL

(Gate solenoid)

(Direction of paper-out)

(Direction of paper-in)

Process speed

High speed

Low speed

Tabla de contenidos

Otros manuales de Accesorios de impresora de Sharp

Sharp

Sharp AR-NB3 Guía de configuración

Sharp

Sharp AR-FR22 U Manual de usuario

Sharp

Sharp ARFX13 - Fax Interface Card Manual de usuario

Sharp

Sharp MX-FR26U Manual de usuario

Sharp

Sharp AR-P15 Manual de usuario

Sharp

Sharp AR-NB2 Guía de configuración

Sharp

Sharp AR-NB2 Manual de usuario

Sharp

Sharp AR-FX12 Manual de usuario

Sharp

Sharp MX-LCX2 Manual de usuario

Sharp

Sharp ARNC5J Manual de usuario

Sharp

Sharp AR-DC1 Manual de usuario

Sharp

Sharp SF-S55N Manual de usuario

Sharp

Sharp MX-FN10 Manual de usuario

Sharp

Sharp AR-S11 Manual de usuario

Sharp

Sharp AR-F14N Manual de usuario

Sharp

Sharp MX-FR46U Manual de usuario

Sharp

Sharp MX-LCX5 Manual de usuario

Sharp

Sharp AR-PB9ML Manual de usuario

Sharp

Sharp AR-PB2A Manual de usuario

Sharp

Sharp FO-59A4 Manual de instrucciones

Sharp

Sharp MX-B201D Manual de usuario

Sharp

Sharp AR-PB2A Manual de usuario

Sharp

Sharp AR-FR11 Manual de usuario

Sharp

Sharp AR-D15 Manual de usuario

Manuales populares de Accesorios de impresora de otras marcas

Star Micronics

Star Micronics TSP800 Series Manual de usuario

REA

REA JET HR pro 2K Manual de usuario

HP Laserjet,Color Laserjet 4si Manual de usuario

oliser

oliser MS 45 Manual de usuario

Roland

Roland DU2-64 Instrucciones y recetas

Xerox

Xerox EFI EXP6000 Manual de usuario

Canon

Canon Finisher-T1 Manual de usuario

Labelmate

Labelmate PM-300 Manual de usuario

Epson

Epson T6248 Manual de funcionamiento

Epson

Epson OT-BZ20 Manual de usuario

Canon

Canon TonerRobot EP-27 Manual de usuario

Ricoh

Ricoh LCIT RT5100 Guía de inicio rápido

GBC

GBC 16 Series Manual de usuario

Canon

Canon INNER 2-WAY TRAY-E1 Manual de operación y mantenimiento

Develop

Develop SD-509 Manual de usuario

Kyocera

Kyocera KM-6230 Manual

Triumph Adler

Triumph Adler DF-710 Manual

Citizen

Citizen CBM-202PC Series Manual de usuario
