Sennheiser MK 4 Manual de usuario

Instruction manual

MK 4

High quality

studio microphone

MK 4 | 1

ENFRITNLRUZH ES DE

Contents

Important safety information ..............................................................2

The MK 4 microphone ............................................................................4

Delivery includes .....................................................................................5

Putting the MK 4 into operation..........................................................6

Mounting the microphone .............................................................6

Orienting the microphone .............................................................6

Connecting the microphone ..........................................................8

Using the microphone............................................................................9

Cleaning and maintaining the MK 4................................................. 11

Specifications........................................................................................ 12

Polar diagram ................................................................................ 13

Frequency response curve .......................................................... 13

If a problem occurs ... .......................................................................... 14

Manufacturer Declarations ................................................................ 16

2 | MK 4

Important safety information

• Please read this instruction manual carefully and completely

before using the product.

• Make this instruction manual easily accessible to all users at all

times.

• Always include this instruction manual when passing the

product on to third parties.

Before operation

• Never open the housing of the product. If products are opened

by customers in breach of this instruction, the warranty

becomes null and void.

During operation

• Liquids entering the product can short-circuit the electronics or

damage the mechanics. Keep all liquids away from the product.

• Solvents or cleansing agents can damage the surface of the

product. Only use a soft, slightly damp cloth to clean the

product.

• Do not expose the product to extreme temperatures.

After operation

• Use the product with care and store it in a clean, dust-free

environment.

MK 4 | 3

Important safety information

ENFRITNLRUZH ES DE

Intended use

Intended use includes:

• having read this instruction manual, especially the chapter

“Important safety information”,

• using the product within the operating conditions and

limitations described in this instruction manual.

“Improper use” means using the product other than as described

in this instruction manual, or under operating conditions which

differ from those described herein.

Instructionmanual

Bedienungsanleitung

Noticed’emploi

Istruzioniper l’uso

Instruccionesde uso

Gebruiksaanwijzing

MK 4

High quality

studio microphone

www.sennheiser.com

www

4 | MK 4

The MK 4 microphone

The MK 4 is a large diaphragm true condenser studio microphone

for very detailed, professional studio recordings. Its outstanding

sound quality, easy handling and excellent value-for-money ratio

make the MK 4 also ideal for project studios and home recording

applications.

Features

• Large diaphragm capsule (1“) in true condenser design,

internally shock-mounted for low handling noise

• 24-carat gold-plated diaphragm

•Ruggedmetalhousing

• Designed for studio and stage use

• Low inherent self-noise and high maximum sound pressure

level

• Made in Germany

Areas of application

• Speech/vocals

• Acoustic guitars

•Guitaramplifiers

•Grandpiano

•Strings

•Windinstruments

• Drums and percussion

MK 4 | 5

Delivery includes

ENFRITNLRUZH ES DE

Delivery includes

MK 4 microphone

MZQ 4 microphone clamp

Pouch

Instruction manual

Instructionmanual

Bedienungsanleitung

Noticed’emploi

Istruzioniper l’uso

Instruccionesde uso

Gebruiksaanwijzing

MK 4

Highquality

studio microphone

6 | MK 4

Putting the MK 4 into operation

Mounting the microphone

1Screw the MZQ 4 microphone clamp to a solid and sturdy stand.

2Place the microphone from above into the microphone clamp

and screw it tight.

Orienting the microphone

왘To orient the microphone,

always loosen the wing screw.

1 2

MK 4 | 7

Putting the MK 4 into operation

ENFRITNLRUZH ES DE

To suppress structure-borne noise, you can optionally use the

MKS 4 shock mount which is available as a Sennheiser accessory.

왘Place the microphone from

above into the inner shock

mount cage and screw it

tight.

왘To orient the microphone,

always loosen the wing screw.

8 | MK 4

Putting the MK 4 into operation

Connecting the microphone

왘Use a microphone cable with XLR-3 female connector to con-

nect the microphone’s XLR-3 male connector to the microphone

preamplifier (48 ± 4 V phantom powering as per IEC 61938, at

least 3.5 mA per channel).

Pin assignment of the XLR-3 connector

CAUTION! Damage to the product due to an unsuitable power

supply!

An unsuitable power supply can cause damage to

the product.

왘Only connect the product to microphone inputs

or power supply units which provide 48 V phan-

tom powering as per IEC 61938.

XLRXLR

XLR

MK 4 | 9

Using the microphone

ENFRITNLRUZH ES DE

Using the microphone

왘Orient the microphone towards the mouth or sound source.

To eliminate disturbing noise as far as possible:

왘Make sure that there is no disturbing noise source (e.g. a PC

fan) in the sound inlet area of the microphone.

If sibilance occurs, position the microphone slightly to the

side and not directly in front of the mouth.
