Sennheiser Evolution E 602-II Manual de usuario

e 602-II

Bedienungsanleitung

Insruction manual

Notice d‘emploi

Instruzioni per l‘uso

Instrucciones de uso

Manual de instruções

Gebruiksaanwijzing

Stage Microphones







123

125 Hz

250 Hz

500 Hz

1,000 Hz

2,000 Hz

4,000 Hz

8,000 Hz

16,000 Hz

30°

0°

180°150°

120°

60°

90°

30°0°

180°

150°

120°

60°

90°

- 50

- 60

- 70

- 80

- 90

- 40

dBV

100

200

500

1,000

2,000

5,000

10,000

20,000

0°, 1 m

0°, 5 m

+ +

XLR6.3 mm

XLR

6.3 mm

symmetrical

XLR

ENFRITPTNLRUZH ES DE

Important safety information

• Please read this instruction manual carefully and completely before

using the product.

• Make this instruction manual easily accessible to all users at all

times.

• Always include this instruction manual when passing the product on

to third parties.

Before operation

• Never open the housing of the product. If products are opened by

customers in breach of this instruction, the warranty becomes null

and void.

• Only use attachments, accessories or spare parts specified by

Sennheiser.

During operation

• Liquids entering the product can short-circuit the electronics or

damage the mechanics. Keep all liquids away from the product.

• Solvents or cleansing agents can damage the surface of the product.

Only use a soft, slightly damp cloth to clean the product.

• Do not expose the product to extreme temperatures.

After operation

• Handle the product with care and store it in a clean, dust-free

environment.

Intended use

Intended use includes:

• having read this instruction manual, especially the chapter

“Important safety information”,

• using the product within the operating conditions and limitations

described in this instruction manual.

“Improper use” means using the product other than as described in

this instruction manual, or under operating conditions which differ

from those described herein.

The e 602-II

Feel more bass.

Don‘t just hear it. Feel it. Punching and vibrating, the e 602-II follows

bass instruments down to the low frequencies that shake things up.

The punch of the kick drum keeps its forceful volume at the bottom

of the sound image; the attack remains precise throughout the mic’s

entire frequency response.

The e 602-II hears bass guitars and tubas with the same attention to

detail: warm, dynamic, and always with substance. It sounds as solid

as it looks and, thanks to its lightweight aluminum body, is easy to

position – in studios, clubs, rehearsal rooms, at smaller gigs or for

home recording.

Features

• dynamic microphone with expanded bass range

• fast transient response

• designed for extreme sound pressure levels

• rugged lightweight aluminum body for stable positioning on long

microphone boom arms

• extremely lightweight voice coil construction

• humbucking coil

• integral stand mount

Delivery includes

1 e 602-II microphone

1 pouch

1 instruction manual

Product overview A*

1 sound inlet basket

2 XLR-3 connector

3 integral stand mount

Diagrams can be found on the cover pages.

ENFRITPTNLRUZH ES DE

Using the microphone

Positioning the microphone on a kick drum B

XMount the e 602-II using the integral stand mount C.

Pos. Resulting sound Commentary

B.1 • much attack

• little resonance

• dry

Position the microphone at a

distance of a few centimeters

from the batter head.

B.2 • less attack

• much resonance

• smooth and voluminous

Position the microphone at the

level of the resonant head.

B.3 • less Attack Position the microphone in the

middle between the batter head

and the resonant head.

For less attack in all three positions, turn the microphone away from

where the beater strikes.

Positioning the monitor loudspeakers

XTo prevent feedback and crosstalk, postion your monitor loudspeak-

ers in the angle area of the highest cancellation of the microphone

(approx. 180°).

Cleaning and maintaining the e 602-II

Caution Liquids can damage the electronics of the product!

Liquids entering the housing of the product can cause a

short-circuit and damage the electronics.

Keep all liquids away from the product.

Do not use any solvents or cleansing agents

XUnscrew the sound inlet basket 1.

XRemove the foam insert from the sound inlet basket 1.

XUse a slightly damp cloth to clean the sound inlet basket 1 from

the inside and ouside.

XReinsert the foam insert into the sound inlet basket 1and replace

the sound inlet basket on the microphone and screw it tight.

Specifications

Transducer principle dynamic

Frequency response 20 … 16,000 Hz

Pick-up pattern cardioid

Sensitivity (free field, no load) 0.9 mV/Pa (at 50 Hz)

0.25 mV/Pa (at 1 kHz)

Nominal impedance (at 1 kHz) 350 Ω

Min. terminating impedance 1 kΩ

Connector XLR-3

Dimensions Ø 60 mm, length 153 mm

Weight 318 g

The polar diagram and the frequency response curve Ccan be found on

the cover pages.

The XLR-3 connector assignment Dcan be found on the cover pages.

ENFRITPTNLRUZH ES DE

Manufacturer Declarations

Warranty

Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on

this product.

For the current warranty conditions, please visit our website at

www.sennheiser.com or contact your Sennheiser partner.

FOR AUSTRALIA ONLY

Sennheiser goods come with guarantees that cannot be excluded

under the Australian Consumer Law. You are entitled to a replacement

or refund for a major failure and compensation for any other reason-

ably foreseeable loss or damage. You are also entitled to have the

goods repaired or replaced if the goods fail to be of acceptable quality

and the failure does not amount to a major failure.

This warranty is in addition to other rights or remedies under law.

Nothing in this warranty excludes, limits or modifies any liability of

Sennheiser which is imposed by law, or limits or modifies any remedy

available to the consumer which is granted by law.

To make a claim under this warranty, contact

Sennheiser Australia Pty Ltd, Unit 3, 31 Gibbes Street Chatswood NSW

2067, AUSTRALIA.

Phone: (02) 9910 6700, email: [email protected].

All expenses of claiming the warranty will be borne by the person

making the claim.

The Sennheiser International Warranty is provided by Sennheiser

Australia Pty Ltd (ABN 68 165 388 312), Unit 3, 31 Gibbes Street

Chatswood NSW 2067 Australia.

In compliance with the following requirements

• WEEE Directive (2012/19/EU)

Please dispose of this product at the end of its operational lifetime

by taking it to your local collection point or recycling center for such

equipment.

CE Declaration of Conformity

• RoHS Directive (2011/65/EU)

The declaration is available at www.sennheiser.com/download.

e 608

e 614

e 609 silver

e 604

e 602-II

e 835

e 845

e 865

e 901

e 902

e 904

e 906

e 908

e 914

e 935

e 945

e 965

Sennheiser electronic GmbH & Co. KG

Am Labor 1, 30900 Wedemark, Germany

www.sennheiser.com

Printed in Germany, Publ. 12/16, 515863/A03
