Seco i-PAN7 Manual de usuario
Version 2.0 i-PAN7 1 of 14
i-PAN7
Documentation version 2.0
1INTRODUCTION
The i-PAN7 is a flat panel ready to go solution, which can be easily integrated in
customer devices. It
consists of a 7" touch-display combined with a thin metal hous-
ing including most peripherals needed
by todays typical panel-applications. To
make it easy for customers to attach their own peripherals or to
put connectors on a
desired place in a product, the i-PAN7 additionally has extensions connectors.
The device offers the following features:
WVGA (800 x 480) 7" TFT-display with resistive or capacitive touch
Small metal housing with mounting possibility
Single Power supply, 7...24 Volt range
SDIO/SD/MMC card socket
USB Host
3-axis accelerometer
2,6W stereo speaker output
20 bit stereo headphone output
Mic input (mono) for electret-capacitor microphones
Analog video/camera input via mini BNC
Quad-band GSM/GPRS or UMTS modem
GPS receiver
Realtime clock
Version 2.0 i-PAN7 2 of 14
Interfaces / Signals accessible over extension connectors:
10/100 MBit Ethernet
2 x USB Host
USB Slave
I2C
SD/MMC Card1
RS232 COM12 FF_UART
RS232 COM23 BT_UART (if GSM not used4)
COM35 STD_UART (if GPS not used6)
RS485 (instead of COM2 BT_UART7)
Audio out
Mic input (mono) for electret-capacitor microphones
3 x 10 bit ADC
IrDA
Programmable input and output pins (CPLD)
CAN bus
▪Please do not use the card socket on i-PAN7 and Connector Board at same time! This can
cause data loss on the memory card!
▪level converter: 24V
▪level converter: 24V
▪if mounted modem uses COM2 for communication with CPU
▪CPU signals: 3,3V
▪if mounted GPS module uses COM3 for communication with CPU
▪customer can choose between RS232 or RS485, see also note 3
Version 2.0 i-PAN7 3 of 14
GSM
GPS
Acceleration
RTC
Trizeps IV-M, IV-WL, V, VI, VII
Extension
connector 1
Extension
connector 2
FIGURE 1.
Simplified block diagram
Fingerprint Fingerprint
Analog camera SD/MMC
2 x Audio (amp)
Audio headphone
Microphone
GSM antenna UFL
External antenna
Ethernet
USB Host
USB Slave
SD/MMC
COM1 FF_UART
COM2 BT_UART/RS485*
COM3_ ST_UART*
Audio Headphone
Microphone
3 * ADC 10 or 12 bit
I2C
ProgrammableI/O
s
IrDa
CAN bus
Version 2.0 i-PAN7 4 of 14
2CONNECTORS
TABLE 1.
Overview of all connectors on top side
Name
Function
Type
J1/J4
PCB F-antenna
UFL
J2
Extension Connector 1
ERNI - SMC-B-80, Part No. 114806
J3
Audio out right
JST-SM02B-SRSS-TB, optional BL2 Con.
J5
SD/MMC card
Push-push-connector
J7
Connector for capacitive Touch
JST-08FHJ-SM1-TB
J9
Mic/Audio in
Audio-Jack 3.5mm
J11
Video in
Mini BNC
J12
Extension Connector 2
ERNI - SMC-B-26, Part No. 054595
J13
Power in
Power Jack
J14
Sim Card
Push-pull-connector
J15
Fingerprint
JST-08FHJ-SM1-TB
J16
Backlight Connector
SM02B-BHSS-1-TB
J19
CPLD programming
JST - 08FHJ-SM1-TB
J20
Display Connector 16-Bit
40pin 0.5mm pitch bottom contact
J21
Headphone
Audio-Jack 3.5mm
J23
USB Host
Standard A
J24
Audio out left
JST - SM02B-SRSS-TB, optional BL2 Con.
J26
active GPS antenna
MCX
J28
Display Connector 18-Bit
40pin 0.5mm pitch bottom contact
J31
Display touchscreen
JST - 04FMS-1.0SP-TF
TABLE 2.
Connectors on bottom side
Name
Function
Type
J6
GSM antenna
UFL
J8
alternative extension connector 2
Samtec - FTSH Series, 26 pin
J10
I2C Connector
SL-1
J17
SPDIF Audio
Everlight PLT133/T6A
J22
alternative extension connector 1
Samtec - FTSH Series, 80 pin
J25
optional Power in
Phoenix - MSTBA2,5/2-G-5.08
J27
Ethernet
RJ45
J30
Display Connector LVDS
40pin 0.5mm pitch bottom contact
J32/33/34
Touch Connector for 10“ LVDS
SMD ZIF, TC 0.5mm Pitch 5-lead
Version 2.0 i-PAN7 5 of 14
Extension Connectors
The extension connectors offer a possibility to extend the functionality of the
i-PAN7 to a custom specific requirement. All signals are listed in the following
tables 3 and 4.
Figure 3 shows how to identify the pins of the dual row type connec-
tors. The bottom row is the
A-row and the upper is the B-row.
FIGURE 2.
Connectors on i-PAN7
FIGURE 3.
Connectors on i-PAN7
Version 2.0 i-PAN7 6 of 14
2.1.1 Extension Connector 1 (J2)
Pin
Signal
Pin
Signal
Function
A1
n.c.
B1
RJ45_RXI+
Ethernet
A2
ETH_AGND
B2
RJ45_RXI-
Ethernet
A3
ETH_AGND
B3
ETH_AGND
Ethernet
A4
ETH_AGND
B4
RJ45_TXO+
Ethernet
A5
ETH_AGND
B5
RJ45_TXO-
Ethernet
A6
\ETH_LINK_AKT
B6
\ETH_SPEED100
Ethernet
A7
ETH_GND1
B7
ETH_GND2
Ethernet
A8
GND
B8
GND
A9
OTG_DP1
B9
OTG_DM1
USB Host 1
A10
OTG_DP2
B10
OTG_DM2
USB Host 2
A11
USB_HOST2_PWR
B11
USB_HOST1_GND
USB Host 1
A12
USB_HOST2_GND
B12
USB_HOST1_PWR
USB Host 2
A13
GND
B13
CB_DET
SD/MMC
A14
I2C_DATA
B14
I2C_CLK
I2C
A15
+3V3
B15
+3V3
max. 500 mA
A16
+5V
B16
+5V
max. 500 mA
A17
HEADPHONE_GND
B17
VSSA_AUDIO
Audio
A18
HEADPHONE_R
B18
LINEIN_L
Audio
A19
HEADPHONE_L
B19
LINEIN_R
Audio
A20
AD0
B20
\RESET_OUT
ADC/Reset
A21
AD1
B21
AD3
ADC
A22
MMC_CMD_CON
B22
MMC_DAT3_CON
SD/MMC
A23
MMC_CLK_CON
B23
MMC_DAT2_CON
SD/MMC
A24
MMC_DET
B24
MMC_DAT1_CON
SD/MMC
A25
SD_WP
B25
MMC_DAT0_CON
SD/MMC
A26
GP00
B26
SD_EXT_PWR
A27
GP85_HOLD_TR5_ BLPWM
B27
GND
A28
GND
B28
USB_SL_VCC
USB Slave
A29
USB_SL_D+
B29
USB_SL_D-
USB Slave
A30
COM2_CTS_V24
B30
COM2_RTS_V24
COM2
A31
COM2_TXD_485H
B31
COM2_RXD_485L
COM2/RS485
A32
GND
B32
GND
A33
FF_RTS_V24X
B33
FF_DTR_V24X
COM1
A34
FF_DSR_V24X
B34
FF_TXD_V24X
COM1
A35
FF_RXD_V24X
B35
FF_CTS_V24X
COM1
A36
FF_RI_V24X
B36
FF_DCD_V24X
COM1
A37
RXD_2
B37
TXD_2
COM3
A38
GND
B38
GND
A39
V_SUP_N
B39
V_SUP_P
External Power
A40
V_SUP_N
B40
V_SUP_P
External Power
Version 2.0 i-PAN7 7 of 14
2.1.2 Extension Connector 2 (J12)
Pin
Signal
Pin
Signal
Function
A1
IN7
B1
OUT7
CPLD I/O
A2
IN6
B2
OUT6
CPLD I/O
A3
IN5
B3
OUT5
CPLD I/O
A4
IN4
B4
OUT4
CPLD I/O
A5
IN3
B5
OUT3
CPLD I/O
A6
IN2
B6
OUT2
CPLD I/O
A7
IN1
B7
OUT1
CPLD I/O
A8
IN0
B8
OUT0
CPLD I/O
A9
IRDA_MODE
B9
IRDA_SD
IrDa
A10
+3V3
B10
+3V3
max. 500 mA
A11
GND
B11
GND
A12
CAN_L
B12
CAN_H
CAN Bus
A13
GND_ISO
B13
GND_ISO
CAN Bus
Version 2.0 i-PAN7 8 of 14
3GPIO FUNCTIONALITY
TABLE 3.
GPIO’s for custom use
Signal name
GPIO
Trizeps
IV
GPIO
Trizeps
V
GPIO
Trizeps
VI
GPIO
Trizeps
VII
Function /
location
GP00
0
not
usable
50
43
GPIO, J2-A26
FP_PWR_EN
13
16
113
45
Fingerprint enable,
J15-7,
reserved on cap.
Touch
version
GP85_HOLD_
TR5_BLPWM
85
13
127
(CPLD_C
00)
69
GPIO, J2-A27
EN_GPS
107
57
49
73
enable GPS (active
high)
BL_PWM
11
17
43
77
PWM backlight
LED
50
5
CPLD
103
dual color LED, low:
red, high: yellow
Signal name
GPIO
Trizeps
IV
GPIO
Trizeps
V
GPIO
Trizeps
VI
GPIO
Trizeps
VII
Function / location
GP00
0
not
usable
50
43
GPIO, J2-A26
Version 2.0 i-PAN7 9 of 14
4POWER SUPPLY
The i-PAN7 needs a nominal power supply of 12 Volt. The device will work stable
in a power
range of 7 ... 24 Volt. Applying a voltage more than 24 Volt will damage
electronic components.
Usually connector J13 is equiped. The polarity is shown in figure 4.
FIGURE 4.
Polarity of J13
center pin diameter : 1.65mm, input hole diameter : 4.40mm
For a more ruggedized system or a rough industrial surrounding i-PAN7 can be pro-
vided with an
alternative power connector (J25, see table 1).
Power consumption @ 12V
i-PAN7 LC, idle, full backlight: 340 mA
i-PAN7 LC, idle, normal backlight: 240 mA
Suspend current @ 12V
i-PAN7 LC with Ethernet: 20,5 mA
i-PAN7 LC no Ethernet: 2,8 mA
Version 2.0 i-PAN7 10 of 14
5OUTLINES
PCB outlines top side
FIGURE 5.
PCB outlines top side
