Seagull Models FOCKE-WULF FW190 Manual de usuario

WWW.SEAGULLMODELS.COM

ASSEMBLY MANUAL

www.seagullmodels.com

Specications:

Wingspan---------------80 in (203.3 cm).

Wing area---------------1083.8 sq.in ( 69.9 sq.dm).

Weight-------------------15.4 lbs ( 7.0 kg).

Length-------------------62.9 in ( 159.7 cm).

Engine-------------------33-38cc

Motor size---------------Power 160

Radio--------------------6 channels with 10 servos.

Electric Power Conversion Optional.

“ Graphics and specications may change without notice ”.

Code: SEA257

Focke- Wulf FW190 Instruction Manual.

ank you for choosing the FOCKE-WULF FW190 ARTF by SEAGULL MODELS COM-

PANY LTD,. e FOCKE-WULF FW190 was designed with the intermediate/advanced sport

yer in mind. It is a semi scale airplane which is easy to y and quick to assemble. e airframe

is conventionally built using balsa, plywood to make it stronger than the average ARTF, yet the

design allows the aeroplane to be kept light. You will nd that most of the work has been done

for you already. e motor mount has been tted and the hinges are pre-installed. Flying the

FOCKE-WULF FW190 is simply a joy.

is instruction manual is designed to help you build a great ying aeroplane. Please read this

manual throughly before starting assembly of your FOCKE-WULF FW190 . Use the parts

listing below to indentify all parts.

Please be awere that this aeroplane is not a toy and if assembled or used incorrectly it is

capable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU

ASSUME ALL RISK & REPONSIBILITY.

If you are inexperienced with basic R/C ight we strongly recommend you contact your R/C

supplier and join your local R/C model Flying Club. R/C Model Flying Clubs oer a variety

of training procedures designed to help the new pilot on his way to successful R/C ight.

ey will also be able to advise on any insurance and safety regulations that may apply.

INTRODUCTION.

WARNING.

KIT CONTENTS

WWW.SEAGULLMODELS.COM

KIT CONTENTS.

SEA25701 Fuselage

SEA25702 Wing set

SEA25703 Tail set

SEA25704 Canopy

SEA25705 Cowling

SEA25706 Aluminium tube

SEA25707 Pilot

ADDITIONAL ITEMS REQUIRED.

TOOLS & SUPPLIES NEEDED.

HINGING THE FLAP.

�33cc-38cc gasoline engine.

�Power 160

�Computer radio with 10 servos.

�Glow plug to suit engine.

�Propeller to suit engine.

�Protective foam rubber for radio

system.

in cyanoacrylate glue.

Medium cyanoacrylate glue.

30 minute epoxy.

5 minute epoxy.

Hand or electric drill.

Assorted drill bits.

Modelling knife.

Straight edge ruler.

2mm ball driver.

Phillips head screwdriver.

220 grit sandpaper.

90° square or builder’s triangle.

Wire cutters.

Masking tape & T-pins.

read-lock.

Paper towels.

Focke- Wulf FW190 Instruction Manual.

INSTALL THE AILERONS

CONTROL HORN.

Epoxy.

Aileron control horn.

Fiberglass control horn

INSTALL FLAP CONTROL HORN.

WING ASSEMBLY.

Install the ap control horn using the

same method as same as the aileron con-

trol horns.

Please see below pictures.

Epoxy.

WWW.SEAGULLMODELS.COM

INSTALLING THE AILERON SERVOS.

Servos

Small weight

Thread

Because the size of servos dier, you

may need to adjust the size of the precut

opening in the mount. e notch in the

sides of the mount allow the servo lead to

pass through.

1) Using a small weight (Weighted fuel

pick-up works well) and string, feed the

string through the wing as indicated.

2) Place the servo between the mounting

blocks and space it from the hatch. Use a

pencil to mark the mounting hole loca-

tions on the blocks.

3) Use drill bit in a pin vise to drill the

mouting holes in the blocks.

Epoxy.

Focke- Wulf FW190 Instruction Manual.

4) Apply 2-3 drops of thin C/A to each

of the mounting holes. Allow the C/A to

cure without using accelerator.

C/A glue

5) Use dental oss to secure the connec-

tion so they cannot become unplugged.

C/A glue

8) Remove the string from the wing at

the servo location and use the tape to at-

tach it to the servo extension lead. Pull

the lead through the wing and remove

the string.

6) Secure the servo to the aileron hatch

using Phillips screwdriver and the screws

provided with the servo.

7) Apply 1-2 drops of thin C/A to each of

the mounting tabs. Allow the C/A to cure

without using accelerator.

WWW.SEAGULLMODELS.COM

9) Set the aileron hatch in place and use a

Phillips screw driver to install it with four

wood screws.

2x10mm

INSTALLING THE FLAP SERVO.

Repeat the procedure for the ap servo.

50mm

M3 clevis. M3 lock nut.

AILERON PUSHROD HORN

INSTALLATION.

Please see below pictures.

Focke- Wulf FW190 Instruction Manual.

INSTALLING THE FLAP PUSHROD.

Repeat the procedure for the aileron

pushrod.

50mm

M3 clevis. M3 lock nut.

STANDARD RETRACTABLE LANDING

GEAR.

Please see below pictures.

Cut.

WWW.SEAGULLMODELS.COM

Epoxy.

Collar.

3x25mm

Focke- Wulf FW190 Instruction Manual.

Insert bomb onto the wing.

3x10mm

50mm

M3 clevis. M3 lock nut.
