Scantronic 500r+ Manual de usuario
+
Scantronic
USER GUIDE
WIREFREE CONTROL PANEL
UK
GUIDE UTILISATEUR
CENTRALE D’ALARME RADIO
F
GUÍA DEL USARIO
CENTRAL INALAMBRICA
E
MANUALE UTENTE
CENTRALE RADIO
I
GEBRUIKERSHANDLEIDING
DRAADLOOS CONTROLEPANEEL
NL
UK
four digit user
code
ZONENUMBER
TO FULL SET
Key in your user code and press (or press on
the 525r remote setting device). The exit tone starts.
Leave the premises by the designated exit route.
The exit tone stops after a preset time. The alarm
system is then set.
TO PART SET
To set your alarm system so that you can move
around part of the area normally covered by
detectors:
Key in your user code and press . The panel
lights all the zones that will work in part set. Key in
the numbers of the zones you want to switch on or
off. Press when you have finished. The exit tone
starts. Leave the protected area. The tone stops
after a preset time. The system is then set.
The panel remembers the zones you selected for
part set. The next time you want to part set, enter
your user code, press and then
. The system
sets after sounding the exit tone.
(If you have a 525r remote setting device, press .
The panel part sets in 3 seconds.)
Note: The installer may have disabled the part set
facility. Contact them if you have any difficulty.
IF THE SYSTEM WILL NOT SET
If you are setting or part setting the system, but the
panel gives an interrupted tone and zone lights are
on, then one or more detectors are being triggered.
Check that doors and windows are closed and there
is no movement in areas covered by movement
detectors.
Try to set the system again. If the fault persists call
the installer.
TO SWITCH OFF
Enter by
designated
route
Go to
panel Enter by the designated entry route. The entry tone
starts. Go to the control panel and key in your four
digit user code (or press on your 525r remote
setting device). The system switches off.
Why is the panel beeping? If the panel starts
“beeping” once a second after you have switched off
using your remote setting device then there has
been an alarm while you were out. The lights on the
panel indicate the cause of the alarm. Press to
silence the tone.
2 496307 Issue 1
Checkthepremises
old
new
code
user code
AFTER AN ALARM
Fire Alarm: The system gives a fire alarm by
sounding a continuous tone from the internal
sounder, if you have a smoke detector.
1. Evacuate the premises and call the Fire Brigade.
Do not attempt to unset the alarm.
2. When the premises are safe, silence the alarm
and reset the sytem.
Intruder Alarm: The panel gives a warbling tone
from its internal sounder, and triggers the external
bell and strobe (if you have one).
Tamper Alarm: If the panel gives an internal alarm
while on Standby then go to the control panel. The
tamper light will be on. Call the installer for service.
To Silence an Alarm
Go to the panel, key in your user code. The panel
stops the tone and switches off the external bell/
strobe. The lights on the panel indicate the cause of
the alarm.
To Reset The System
Press . The panel goes to Standby. If the panel
does not go to Standby, call the installer.
Why does the panel beep occasionally? The
panel gives five short beeps once a minute to call
attention to a fault. The lights on the panel indicate
the cause of the alarm: a low battery (either in a
detector or in the panel itself), a mains failure, or
R.F. trouble. Press to silence the tone and then
contact your installer.
TO CHANGE YOUR USER CODE
Your new code can be any four digit code not
starting with 0 (zero).
Enter your existing user code and press 2. The first
four zones light.
Enter your existing user code again. The zone lights
go out as you enter the code. After the last digit the
panel gives a double bleep and lights the bottom
four zones.
Enter your new user code. The zone lights go out as
your enter the new code. The panel gives a double
bleep when it accepts the new code.
496307 Issue 1 3
UK
UK
Walkpast
detectors
TO READ THE LOG
Your alarm system keeps a record of the last 16
alarm events.
Enter your user code and press . The panel lights
show the last event.
Press repeatedly to see earlier alarms. The panel
gives a low tone when you reach the end of the log.
Press at any time to leave the log.
TO WALK TEST THE DETECTORS
Enter your user code and press . The Standby
light flashes.
Activate each detector in turn. The panel gives a
short double bleep and briefly lights the correspond-
ing zone when it receives a signal from a detector.
When you have checked all the detectors press .
The panel returns to Standby.
Note: Make sure the movement detectors do not
see any movement for three minutes before starting
the walk test.
TO TEST BELLS
Enter your user code and press 5. The panel
sounds the external bell. Press to switch the bell
off.
Enter your user code and press 4. The panel
flashes the strobe. Press to switch the strobe off.
4 496307 Issue 1
Scantronic
Scan House
Xerox Business Park
Mitcheldean
Gloucestershire
GL17 0SN ENGLAND
Tel: +44 (0)1594 543343
Fax: +44 (0)1594 544136
Scantronic
Nieuwe Haven 11
3311 AP Dordrecht
NEDERLAND
Tel: +31 (0)78 6134888
Fax: +31 (0)78 6134343
Scantronic
5 Avenue del Villa Antony
94410 Saint Maurice
FRANCE
Tel: +33 (0)1 49 76 00 71
Fax: +33 (0)1 49 76 00 58
Scantronic Spain S.A.
Dist. Oficial J.M. Systems-Com, S.A
c/ Llanterners, 7
Pol. D’Obradors
46110 GODELLA
VALENCIA
ESPAÑA
Tel: +34 (9)6 363 97 08
Fax: +34 (9)6 390 38 72
BBS. +34 (9)6 364 50 00
Scantronic by Si-Tronic
Via S. Allende 12/14
20091 Bresso -MI-
ITALIA
TEL: +39 (0)2 66 500 073
FAX: +39 (0)2 61 40 557
20 496307 Issue 1
