10. Specifications
Model Waterproof Digital Thermometer SK-270WP-K
Cat. No. 8078-40
Display range -50.0 to 300.0°C
(Measuring range is different depending on the probes connected)
Display Accuracy When operation ambient is 0 to 40°C
± (0.1 + 1 digit) at -40.0 to 200.0°C
± 0.5°C at other than above
When operation ambient is -10 to 0.1°C, 40.1 to 60°C
± (0.2 + 1 digit) at -40.0 to 200.0°C
± 1°C at other than above
Resolution 0.1°C
Sampling time About 0.5 to 1 sec.
(When the temperature changes a lot, the sampling time is 0.5 sec.
and when it is calm, it automatically changes to 1 sec.)
Grade of protection from water Conforming to JIS C0920 Protection IP67 rated
(when the probe is connected to the unit)
Operation ambient -10 to 60°C, less than 80%rh (no condensing)
Storage ambient +10 to 60°C (no condensing)
Operational Functions HOLD, Low battery mark, Auto power-off
Power requirements 3VDC ("AAA" size alkali battery x 2 pcs.)
Battery life About 1000 hours continuous
Materials PC resin
Dimensions 70(W) 171(H)
40(D) mm (exclusive of connector)
Weight Approx. 155g (including batteries)
Standard Accessories S270WP-01 standard probe, AAA size alkaline battery x 2 pcs
vinyl cover, neck strap, instruction manual
* All specifications and appearance subject to change with or without notice for improvement purpose.
* No. 8078-42 digital thermometer is without probe type. S270WP-01 probe is not attached.
WARRANTY POLICY
Warranty
Our products are warranted to be free from defects in materials and workmanship for a period of one year from
date of delivery. If repair or adjustment is necessary and has not been the result of abuse or misuse within the
one-year-period, please return the units on - Freight Prepaid – basis and correction of the defect will be made
without charges. We alone will determine if the product problem is due to deviations or customer misuse.
Out-of-warranty products will be repaired on charge basis.
Warranty during transportation
The warranty during transportation only applies to the products that we arrange the shipment. The case that the
products had been purchased in domestic and were sent to overseas by the purchaser is out of warranty.
Return of items
Authorization must be obtained from us before returning items for any reason. When applying for authorization,
please include data regarding the reasons the items are to be returned.
3-4, Kanda-kajicho, Chiyoda-ku, Tokyo 101-0045 Japan
URL: http://www.sksato.co.jp/english/
