Preface
II
Manual Revision
Revision Date
Revision Level
Description
Aug., 2018
1
SL700 GNSS RTK System User Guide
SL700 GNSS RTK System Getting Started
III
Preface
Introduction
Welcome to the SATLAB SL700 receiver. This introduction describes how touse this product.
Experience Requirement
In order to help you use SATLAB series products better, SATLAB suggests you carefully read
the instructions. If you are unfamiliar with the products, please refer to
http://www.satlabgps.com.
Tips for safe use
Notice: The contents here are special operations, and need your special
attention. Please read them carefully.
Warning: The contents here generally are very important. Wrong operation
may damage the machine, lose data, even break the system and
endanger your safety.
Exclusions
Before using the product, pleaseread these operating instructions carefully, they will help you
to use it better.SATLAB Geosolutionsassumesno responsibility if you fail to operate the
product according to theinstructions, or operatewrongly due to misunderstanding
theinstructions.
SATLAB is committed to constantly perfecting product functions and performance,
Preface
IV
improvingservice quality and reserves the rights to change these operating instructions without
notice.
We have checked the contents of the instructions and the software & hardware, without
eliminating the possibility of deviation. The pictures in the operating instructions arefor
reference only. In case of non-conformity with products, the products shall prevail.
Technology and Service
If you have any technical issues, please call SATLAB technology department for help, we will
answer your question.
Relevant Information
You can obtain this introduction by:
1. After purchasing SATLAB products, you will find this manual in the instrument container to
guide you on operating the instrument.
2. Log onto the SATLAB official website, download the electronic version introduction at the
product page.
Advice
If you have any suggestionsfor this product, pleaseemailhttp://www.satlabgps.com. Your
feedback information will help us to improvethe product and service.
SL700 GNSS RTK System Getting Started
V
Contents
Preface..................................................................................................................... III
Overview................................................................................................................... 1
1.1 Foreword....................................................................................................... 2
1.2 Features........................................................................................................ 3
1.3 Use and precautions.................................................................................... 3
Product Introduction................................................................................................ 5
2.1 Overall appearance ...................................................................................... 6
2.1.1 Upper cover........................................................................................... 6
2.1.2 Bottom cover......................................................................................... 7
2.2 Button & indicator lamp............................................................................... 8
2.2.1 Button function...................................................................................... 8
2.2.2 Indicator lamp.......................................................................................10
2.3 Static survey................................................................................................11
2.3.1 Steps of static survey ...........................................................................11
2.3.2 Static data storage ...............................................................................12
2.3.3 Static data download............................................................................13
Contents
VI
2.4 Dynamic RTK survey...................................................................................15
2.5 Firmware upgrade.......................................................................................17
Technical Parameters..............................................................................................19
3.1 Technical parameters..................................................................................20
Accessories and Interfaces ....................................................................................24
4.1 SIM card installation....................................................................................25
4.2 Data cable....................................................................................................26
4.3 Antenna........................................................................................................28
4.4 Benchmark...................................................................................................28
4.5 Battery & charger ........................................................................................29
4.5.1 Battery installation and unload..............................................................29
4.5.2 Battery and charger model ...................................................................31
4.5.3 Power supply mode..............................................................................31
4.5.4 Cautions for charging...........................................................................32
4.5.5 Operation of charging...........................................................................33
SL700 GNSS RTK System Getting Started
1
Overview
This chapter contains:
Foreword
Features
Use and precautions
CHAPTER
1
Overview
2
1.1 Foreword
A new generation of miniaturized SL700 GNSS RTK system, condensing our ultimate
professional pursuit, with enthusiast performance configuration, using magnesium alloy
structure, supporting tilt measurement, using Wi-Fi wireless connection, control distance up to
100 meters; built-in transceiver integrated radio, working distance farther. In addition,
equipped with a new generation of quad-core full-strength Android handbook, with Satsurv
professional measurement software, let you enjoy the comfortable work experience brought by
professional quality.
Cautions: This manual does not represent the standard configuration. The
contents of the box are adjusted according to different user requirements. The
specific configuration is subject to the outbound order at the time of
purchase. Before using the machine, it is recommended that you first check
the package of the product for damage; please carefully open the package to
confirm whether the contents of the box match the delivery order; if you find
any loss of the product and its accessories or If it is damaged, please contact
your local office or dealer immediately. Please read the instruction manual
carefully before carrying, handling and using.
SL700 GNSS RTK System Getting Started
3
1.2 Features
1. New design, magnesium alloy structure, smaller size, lighter weight and higher quality;
2. Linux operating system, more powerful and more reliable;
3.The transceiver UHF radio enables switchable working modes between base and rover;
4.Built-in 8G storage space, support for inserting an external SD card;
5. Support long-distance Bluetooth and Wi-Fi connection for remote data transmission;
6.The new generation controller CHC30, rugged, dexterous and super endurance, accessible in
various environments;
7.Based on Android system,developed a customized intelligent measurement software: Satsurv,
with richer graphical performance and improved work efficiency;
8.Multi-function by one key, simple and convenient NFC operation, making your measurement
quick and easy;
9. Double formats storage of static data (*.GNS / RINEX).
1.3Use and precautions
The SL700 receiver is designed with chemical and impact resistance, but precision instruments
require careful use and maintenance.
Overview
4
Notice: The receiver must be within the specified temperature range when
used and stored. Detailed requirements, please refer to Chapter 3: Technical
Parameters.
In order to ensure the continuous tracking observation of the satellite and the quality of the
satellite signal, it is required that the space above the station should be as wide as possible, and
there should be no obstacles above the 15° elevation angle; in order to reduce the interference
of various electromagnetic waves on the GNSS satellite signal, There should be no strong
electromagnetic interference in the range of about 200m around the station, such as TV towers,
microwave stations, high-voltage transmission lines; in order to avoid or reduce the occurrence
of multi-path effects, the station should be away from the terrain and features that strong
reflectors. Such as high-rise buildings, waters, etc.
