Sanyo Xacti VPC-C6 Manual de usuario

VPC-C6EX

VPC-C6EXE

VPC-C6E

VPC-C6

INSTRUCTION MANUAL

Digital Movie Camera

Please read these instructions carefully before using the camera.

Make sure to read and understand the separate booklet “SAFETY MANUAL”.

Keep this manual in a safe place for later reference.

Important note

This manual explains how to safely operate the VPC-C6EX, VPC-C6EXE,

VPC-C6E and VPC-C6.

Any information regarding only one of these products will be labeled as such.

iEnglish

Warning

TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT

EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE

FOR AMERICAN USERS

The following advisory is included in accordance with the laws of the State of

California (USA):

WARNING:

This product contains chemicals, including lead, known to the State of

California to cause cancer, birth defects or other reproductive harm. Wash

hands after handling.

iThis equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

hReorient or relocate the receiving antenna.

hIncrease the separation between the equipment and receiver.

hConnect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

hConsult the dealer or an experienced radio/TV technician for help.

iChanges or modifications not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

Model number: VPC-C6

Trade Name: SANYO

Responsible party: SANYO FISHER COMPANY

Address: 21605 Plummer Street, Chatsworth, California 91311

Telephone No.: (818) 998-7322

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interfer-

ence that may cause undesired operation.

Declaration of Conformity

English ii

FOR CANADIAN USERS

iThis Class B digital apparatus complies with Canadian ICES-003.

FOR EU USERS

Note:

iThis symbol mark and recycle system apply only to EU

countries and do not apply to countries in other areas of

the world.

Your SANYO product is designed and manufactured with

high quality materials and components which can be

recycled and reused.

This symbol means that electrical and electronic

equipment, at their end-of-life, should be disposed of

separately from your household waste.

Please dispose of this equipment at your local community

waste collection/recycling centre.

In the European Union there are separate collection

systems for used electrical and electronic products.

Please help us to conserve the environment we live in!

Symbols used in this manual

HINT Points giving some extended instructions or special points to pay

attention to.

CAUTION Points that require special attention.

(page xx) Refer to the page indicated for detailed information.

You may find the answers to questions or problems concerning camera

operation in the sections “COMMONLY ASKED QUESTIONS”(page 155)

and “TROUBLESHOOTING”(page 162).

iii English

GETTING UP AND RUNNING

Install the card

1 Insert the card.

2 Connect the AC adaptor to the camera.

1Open

2Insert 3Close

To power outlet

DC IN terminal

Supplied AC adaptor

Supplied power cord

Docking station terminal

Supplied cable adaptor

English iv

Shooting

kVideo clip recording

1 Open the monitor unit, and

press the ON/OFF button

for at least 1 second to turn

the camera on.

2 Set the main switch to REC.

3 Press the video clip

recording button [ ].

hRecording begins.

hTo stop recording, press

the video clip recording

button again.

kStill image

photography

1 Open the monitor unit, and

press the ON/OFF button

for at least 1 second to turn

the camera on.

2 Set the main switch to REC.

3 Press the still image

shooting button [ ].

hThe image is captured.

31 01:10:15

01:10:15

ON/OFF

button

Main switch

Video clip recording button

[]

Still image shooting button

[]

vEnglish

Playback

kVideo clip playback

Set the main switch to PLAY.

hThe display switches to the

Playback Screen.

hToggle the SET button to

the left or right to display the

video clip you wish to play

back.

hVideo clips are indicated by

a video clip pattern along

the top and bottom of the

screen.

2 Press the SET button.

hPlayback of the selected

video clip begins.

hWhen the main switch is

moved to REC, the display

changes to the Shooting

Screen.

kStill image playback

Set the main switch to PLAY.

hThe display switches to the

Playback Screen.

hTo view other images,

toggle the SET button to the

left or right.

hWhen the main switch is

moved to REC, the display

changes to the Shooting

Screen.

When you are finished using the camera...

Press the ON/OFF button to turn the camera off.

Main switch

SET button

<Example: After recording

a video clip>

Video clip pattern

1English

QUICK SEARCH BY OPERATION

Your camera has an abundance of convenient features and functions. From

creating precisely the photo you want, to viewing images using various

techniques, you can locate the exact operation for your purposes in the

following table.

Basic operation Convenient

functions Additional functions

Shooting/recording

Getting started

shooting/recording

•“Recording video clips”

on page 34

•“Capturing still images”

on page 36

•“Shoot a still image

while recording a video

clip”on page 38

•“MAKE AN AUDIO

RECORDING”on

page 41

Log the date and

time of your photos

•“DATE AND TIME

SETTING”on page 107

Zoom in on the

subject

•“Using the zoom”on

page 39

Take vertical

(portrait) format

photos

•“Still image mode

(resolution) setting”on

page 56

Close-up

photography

•“FOCUS RANGE”

(super macro mode) on

page 66

For more accurate

focus

•“FOCUS RANGE”

(manual focus) page 66

Set the focus to a

narrow range

•“FOCUS AREA

SETTING”on page 68

Optimize the photo

quality

•“Video clip mode

(image quality) setting”

on page 55

•“Still image mode

(resolution) setting”on

page 56

Reduce video clip flicker

•“FLICKER-REDUCTION”on page 117

Set the camera’s color/contrast

characteristics

•“ADJUST THE IMAGE QUALITY”on page 116

English 2

Shooting/recording

Capture fast-moving subjects

•“SCENE SELECT”(sports mode) on page 57

Shoot in dark conditions

•“Exposure correction”on page 40

•“FLASH SETTING”on page 60

•“SCENE SELECT”(night view mode/fireworks mode/lamp mode) on page 57

Increase the camera’s sensitivity

•“ISO SENSITIVITY”on page 70

Photographing people

•“SCENE SELECT”(portrait mode/night view mode) on page 57

•“FILTERS”(cosmetic filter) on page 59

Photographing landscapes

•“SCENE SELECT”(landscape mode) on page 57

Take a self-photo

•“SELF-TIMER”on page 62

Make images lighter

or darker

•“Exposure correction”

on page 40

Measure the

brightness of a

specific area

•“LIGHT-MEASURING

MODE SETTING”on

page 69

Adjust the camera’s

sensitivity

•“ISO SENSITIVITY”on

page 70

Change the color of

the images

•“FILTERS”

(monochrome filter/

sepia filter) on page 59

Make white appear

natural

•“WHITE BALANCE”on

page 71

Basic operation Convenient

functions Additional functions

3English

QUICK SEARCH BY OPERATION

Playback

Getting started

viewing images

•“Playing back a video

clip”on page 46

Adjust the speaker

volume

•“PLAYBACK VOLUME”

on page 78

Smooth out video

clip playback

•“SMOOTH PLAYBACK”

on page 102

•“VIEWING IMAGES”on

page 43

Search for image/

audio data

•“9-image display

playback”on page 44

Magnify an image

•“Magnifying (zooming

in) the image”on

page 45

Change the angle of

view

•“ROTATE IMAGE”on

page 90

•“PLAYING BACK

AUDIO DATA”on

page 48

Adjust the speaker volume

•“PLAYBACK VOLUME”on page 78

Slideshow playback

•“PLAYBACK MODE”on page 77

Adjust the LCD monitor brightness

•“LCD MONITOR BRIGHTNESS”on page 119

Playback on a TV

•“CONNECTING TO A TV”on page 137

Set the TV system

•“TV OUTPUT

SETTING”on page 121

Data managing/processing

Search for image/audio data

•“9-image display playback”on page 44

Delete data

•“ERASING DATA”on

page 81

Protect images from accidental erasure

•“IMAGE PROTECT”on page 79

Format a card

•“FORMATTING A CARD”on page 128

Edit the red-eye phenomenon in photos

•“RED-EYE CORRECTION”on page 92

Delete a part of a video clip and join video clips

•“EDITING VIDEO CLIPS”on page 95

Specify the number of prints, index print, and date imprint

•“PRINT SETTINGS”on page 83

View the settings that were in effect when the image/audio data

was recorded

•“DISPLAYING IMAGE PROPERTIES (INFORMATION SCREEN)”on page 103

Basic operation Convenient

functions Additional functions

English 4

CONTENTS

GETTING UP AND RUNNING .............................................................. iii

QUICK SEARCH BY OPERATION ........................................................1

CONTENTS ............................................................................................4

CHECKING THE INCLUDED ACCESSORIES ......................................7

GETTING THE MOST OUT OF YOUR CAMERA ................................11

SYSTEM MAP ......................................................................................15





SETUP

PARTS NAMES ....................................................................................16

INSTALLING THE BATTERY PACK AND CARD ................................19

POWER FOR THE CAMERA ...............................................................22

TURNING THE CAMERA ON AND OFF ..............................................26

OPERATION BUTTONS ......................................................................28





BASIC OPERATION

BEFORE TAKING PICTURES .............................................................30

CAPTURING IMAGES ..........................................................................34

BASIC SHOOTING FUNCTIONS .........................................................39

MAKE AN AUDIO RECORDING ..........................................................41

VIEWING IMAGES ...............................................................................43

PLAYING BACK AUDIO DATA ............................................................48





SHOOTING

DISPLAYING THE SHOOTING SETTING SCREENS .........................49

IMAGE QUALITY ..................................................................................55

SCENE SELECT ..................................................................................57

FILTERS ...............................................................................................59

FLASH SETTING ..................................................................................60

SELF-TIMER ........................................................................................62

MOTION COMPENSATION (IMAGE STABILIZER) .............................64

FOCUS RANGE ...................................................................................66

FOCUS AREA SETTING ......................................................................68

LIGHT-MEASURING MODE SETTING ................................................69

ISO SENSITIVITY .................................................................................70

WHITE BALANCE ................................................................................71

Otros manuales para Xacti VPC-C6

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Sanyo

Sanyo

Sanyo VPC HD700 - Xacti Camcorder - 720p Guía del usuario

Sanyo

Sanyo VPC-E2100 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

Sanyo

Sanyo VPC-S750P - 7-Megapixel Digital Camera Manual de usuario

Sanyo

Sanyo VPC S6 - Xacti Digital Camera Manual de usuario

Sanyo

Sanyo IDC-1000ZE iDshot Manual de usuario

Sanyo

Sanyo VPC-S122EXBL Manual de usuario

Sanyo

Sanyo VPC-S6U Manual de usuario

Sanyo

Sanyo VCC-9300 Manual

Sanyo

Sanyo VPC-E10 Manual de usuario

Sanyo

Sanyo VPC CA6 - Xacti Camcorder - 6.0 MP Guía del usuario

Sanyo

Sanyo VPC-SX 560EX Manual de usuario

Sanyo

Sanyo Xacti VPC-A5EX Manual de usuario

Sanyo

Sanyo VPC-S600 - 6-Megapixel Digital Camera Manual de usuario

Sanyo

Sanyo VPC-S1414 Manual de usuario

Sanyo

Sanyo Xacti VPC-WH1YL Guía del usuario

Sanyo

Sanyo VPC-J2EX Manual de usuario

Sanyo

Sanyo Xacti VPC-S70EX Manual de usuario

Sanyo

Sanyo VPC-X1220EX Manual de usuario

Sanyo

Sanyo VPC-S880P - 8-Megapixel Digital Camera Guía de configuración

Sanyo

Sanyo VPC-S885 Manual de usuario

Sanyo

Sanyo VPC-X1200BK Manual de usuario

Sanyo

Sanyo VPC-S1070 Manual de usuario

Sanyo

Sanyo VPC-SX560E Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario

Nikon

Nikon Coolpix 100 Manual de usuario
