Sanyo VPC E1 - Xacti Camcorder - 6.0 MP Manual de usuario
VPC-E10EX
VPC-E10
VPC-E10GX
INSTRUCTION MANUAL
Digital Camera
Please read these instructions carefully before using the camera.
Make sure to read and understand the separate booklet “SAFETY MANUAL”.
Keep this manual in a safe place for later reference.
Important note
This manual explains how to safely operate the VPC-E10EX, VPC-E10 and
VPC-E10GX.
Any information regarding only one of these products will be labeled as such.
iEnglish
Warning
TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE
kFOR AMERICAN USERS
The following advisory is included in accordance with the laws of the State of
California (USA):
WARNING:
This product contains chemicals, including lead, known to the State of
California to cause cancer, birth defects or other reproductive harm. Wash
hands after handling.
iThis equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
hReorient or relocate the receiving antenna.
hIncrease the separation between the equipment and receiver.
hConnect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
hConsult the dealer or an experienced radio/TV technician for help.
iChanges or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Declaration of Conformity
Model number: VPC-E10
Trade Name: SANYO
Responsible party: SANYO FISHER COMPANY
Address: 21605 Plummer Street, Chatsworth, California 91311
Telephone No.: (818) 998-7322
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
English ii
kFOR CANADIAN USERS
iThis Class B digital apparatus complies with Canadian ICES-003.
kFOR EU USERS
Note:
iThis symbol mark and recycle system apply only to EU
countries and do not apply to countries in other areas of
the world.
Your SANYO product is designed and manufactured with
high quality materials and components which can be
recycled and reused.
This symbol means that electrical and electronic
equipment, at their end-of-life, should be disposed of
separately from your household waste.
Please dispose of this equipment at your local community
waste collection/recycling centre.
In the European Union there are separate collection
systems for used electrical and electronic products.
Please help us to conserve the environment we live in!
FOR RUSSIAN USERS
This product certified by official certification company
which is authorized by Russian Federation.
SANYO FISHER Sales (Europe) GmbH
Stahlgruberring 4, D-81829 München, Germany
SANYO Electric Co., Ltd.
1-1, Sanyo-cho, Daito City, Osaka 574-8534, Japan
iii English
kSymbols used in this manual
HINT Points giving some extended instructions or special points to pay
attention to.
CAUTION Points that require special attention.
(page xx) Refer to the page indicated for detailed information.
You may find the answers to questions or problems concerning camera
operation in the sections “COMMONLY ASKED QUESTIONS” (page 130)
and “TROUBLESHOOTING” (page 136).
English iv
SHOOT, PLAY BACK AND SAVE
Install the battery pack
1 Use the supplied charger to charge the battery pack.
hThe CHARGE indicator is lit during charging.
hThe CHARGE indicator will turn off when the battery pack is fully charged.
hCharging takes approximately 2 hr. 30 min.
2 Open the battery/card compartment cover, and insert the battery pack.
hThe battery/card compartment cover is located on the bottom of the
camera.
hPress the ON/OFF button to turn the camera on.
CHARGE indicator
Battery pack
To power outlet
[o] mark
Battery pack charger
[o] mark ON/OFF button
vEnglish
SHOOT, PLAY BACK AND SAVE
Before capturing those important shots, be sure to first take a
test shot to confirm that your camera is set up and ready to go
iSanyo declines any claim for compensation for recorded contents etc. in
case of photographing or recording failure due to a chance camera or card
flaw.
Shooting
1 Press the [m] button.
hThe shooting mode menu
appears.
2 Press the [l] or [m] button to
select the shooting mode.
3 Press the SET button.
hThe shooting mode is
indicated by an icon in the
upper left area of the monitor.
4 Press the shutter button.
Single-shot mode:
A still image is captured.
Sequential shots mode:
Shooting begins. Release the
shutter button to discontinue
shooting.
Video clip recording mode:
Recording begins. To stop
recording, press the shutter
button again.
Shutter button
[l] / [m] buttons
6
s:
Single-shot mode
O:
Sequential shots mode
X:
Video clip recording mode
<Shooting mode>
PHOTOGRAPH 1 IMAGE
Single-shot
Video clip recording
Sequential shots
English vi
Playback
kStill image playback
1 Press the playback button [=].
hThe display switches to the
Playback Screen.
hTo view other images, press the
[l] or [m] button.
hIf the playback button [=] is
pressed, the display returns to
the Shooting Screen.
kVideo clip playback
1 Press the playback button [=].
hThe display switches to the
Playback Screen.
hPress the [l] or [m] button to
display the video clip you wish to
play back.
hVideo clips are indicated by a
video clip pattern along the top
and bottom of the screen.
2 Press the SET button.
hPlayback of the selected video
clip begins.
hIf the playback button [=] is
pressed again, the display
changes to the Shooting Screen.
When you are finished taking pictures...
Press the ON/OFF button to turn the camera off.
PLAY
ON/OFF button
Video clip pattern
[l] / [m] buttons
<Video Clip Playback
Screen>
Playback button
[=]
vii English
SHOOT, PLAY BACK AND SAVE
Save the photographed image data to your
computer (Windows XP)
The Adobe Photoshop Album Starter Edition (in this manual referred to
as Photoshop Album SE) program in the supplied SANYO Software
Pack lets you easily copy the data from your camera to your computer.
Install Photoshop Album SE
1 Set the supplied CD-ROM (SANYO Software Pack) in your
computer’s CD-ROM drive.
hThe installation window opens.
2 Click on the application program you wish to install.
hAfter clicking on an application program, follow the instructions shown
on the monitor to install the program.
hWhen the installation is complete, the product registration window will
appear, but click on the Exit button to close the window.
3 In the installation window, click on [Finish].
hThe installation window closes.
hRemove the CD-ROM from your computer’s CD-ROM drive.
<About the Kodak online service>
hWhen the installation window closes, a dialog box to connect to the
website introducing Kodak’s online service appears. Check the [No
thanks !] option button, and then click on the [OK] button.
Install Photoshop Album SE.
English viii
Copy data from your camera to the computer
Connect your camera to a computer, and copy the desired data to the
computer.
1 Turn on the computer, and use the supplied dedicated USB interface
cable to connect your camera to the computer.
hConnect the cable between the camera’s USB/AV terminal and the
computer’s USB connector.
2 Turn on the camera (page 23).
hThe USB Connection Screen appears on the camera’s monitor.
SELECTOK
USB CONNECTION
CANCEL
PRINTER
COMPUTER
To USB connector
on the computer
Supplied dedicated USB
interface cable
To the USB/AV terminal
ix English
SHOOT, PLAY BACK AND SAVE
3 Select “COMPUTER”, and press the
SET button.
hThe screen to select the connection
mode appears.
4 Select “CARD READER”, and press the SET button.
hThe screen to import data to the computer appears on your
computer’s monitor.
5 Click the [IMPORT] button.
hCopy the camera data to the following folder:
My Pictures\Adobe\Digital Camera\Date folder
hWhen the data has been successfully copied, a dialog box appears to
confirm whether or not you wish to delete the original data from the
camera.
6 Click the [YES] button if you wish to delete the data from the
camera’s memory, or [NO] if you do not wish to delete it.
hThe Photoshop Album SE catalogue screen appears.
hThe data you copied appears on the computer monitor. Confirm that
the desired data was correctly copied. If it was not copied, from the
[Import] menu select [From camera, mobile phone or card reader],
and copy the desired data.
USB CONNECTIONUSB CONNECTION
CARD READER
SCREEN CAPTURE
PC CAMERA
MTP
OKOK
SELECTSELECT
