Samsung SCC-833 Manual de usuario

Super WDR & Low Light

Digital Color Camera

SCC-833(P)

SCC-835(P)

SCC-803P/805P

Part No.: AB68-00107A

Printed in Korea

Operating Instructions

00107A SCC-833P/855P - gb 11/22/00 3:36 PM Page 44

Operating Instructions

Contents

1. Introduction..................................................... 2

2. Features........................................................... 3

3. Installation ...................................................... 5

Precautions in Installation and Use...................... 5

Connecting Auto Iris Lens Connector ................. 6

Mounting lens......................................................... 7

Setting Lens Selection Switch............................... 8

Adjusting Back Focus ............................................ 9

Connecting Cable ................................................. 11

4. Name and Functions of Parts...................... 14

Name and Functions of Camera Parts............... 14

Camera Setup........................................................ 19

5. Product Specifications................................. 39

00107A SCC-833P/855P - gb 11/22/00 3:36 PM Page 1

2. Features

High Sensitivity

Adopting the Super-HAD CCD that has the latest

built-in microchip lens, the high sensitivity is

realized.

SWDR Function

With built-in SWDR (Super Wide Dynamic Range)

function using Dual Shutter method, distinction of

light and darkness is clear in areas where the

illumination levels differ greatly or the light source

is right behind the subject.

Low Illumination Function

It is possible to shoot in the worst situation where

there is no light by adopting a low illumination

function based on the Digital Signal Technology.

Excellent Back Light Compensation

Even when an intense light source or sunlight is in

the back of your subject, a clear image can be

provided due to the ideal combination of the

excellent performance of the high light

compression (Knee Compensation) function and

the BLC (Back Light Compensation) function.

Operating Instructions

1. Overview

Adopting the latest Super-HAD CCD (Charge

Coupled Device), the CCTV COLOR CAMERA

SCC-833(P)/835(P)/803P/805P are monitoring

camera which can provide the best monitoring

function when connected to the CCTV system

equipment by realizing SWDR (Super Wide

Dynamic Range) and low illumination function.

Broadcasting System

• SCC-833/835 : NTSC

• SCC-833P/835P/803P/805P : PAL

Number of CCD Pixel

• SCC-833 : 1/3" NTSC 410K

(High resolution type)

• SCC-835 : 1/2" NTSC 410K

(High resolution type)

• SCC-833P/803P : 1/3" PAL 470K

(High resolution type)

• SCC-835P/805P : 1/2" PAL 470K

(High resolution type)

Power Source

• SCC-833(P)/835(P): AC 24V, DC12V

• SCC-803P/805P : AC 220V ~ 240V

Operating Instructions

00107A SCC-833P/855P - gb 11/22/00 3:36 PM Page 2

Operating Instructions

Digital Line-lock

The control and reliability has been enhanced due

to the Full Digital Line Lock, which allows users to

adjust the Line Sync Phase.

Resolution

High resolution is realized due to the Full Digital

Image Processing utilizing the best Digital Signal

Technology.

Output Signal Selection

Video output signal reverse function and frame

setting (horizontal, vertical) function are

incorporated.

Remote Control

The operation of the camera can be remotely

controlled due to the built-in remote control

protocol of the RS-485 Standards.

* Remote control using PC requires additional

RS485/232C Interface Jig.

Operating Instructions

3. Installation

Precautions in Installation and Use

1) Do not attempt to disassemble the camera

yourself.

2) Be cautious in handling the camera. Avoid

striking or shaking the camera. Make sure to

avoid damage on the camera caused by improper

storage or operation.

3) Do not expose the camera to rain or moisture.

Do not operate the camera on a wet place.

4) Do not use strong or abrasive detergents when

cleaning the camera body. Use a dry cloth to

clean the camera.

5) Keep the camera at a cool place away from the

direct sunlight. Leaving the camera under the

direct sunlight may result in a malfunction of the

unit.

00107A SCC-833P/855P - gb 11/22/00 3:36 PM Page 4

Operating InstructionsOperating Instructions

Connecting Auto Iris Lens Connector

Prepare the Auto Iris Lens Connector, which is

supplied along with the camera.

Connect the cable of the control cable, whose

covering is stripped, to the Auto Iris Lens

Connector as shown below.

Pin Number DC Control Type Video Control Type

1 Damp (–) Power (+9V)

2 Damp (+) Not used

3 Drive (+) Video signal

4 Drive (–) GND

Rib

Pin1

Pin2

Pin3

Pin4

Mounting the Lens

Loosen a screw fixing the Flange Back Adjustment

Ring by turning it counterclockwise and turn the

Adjustment Ring to the “C” direction

(counterclockwise) until it stops. Failure to do so

may result in a damage caused by a bump of the

lens against the image sensor part in the camera

when mounting the lens.

Auto Iris Control Cable

LENS

VIDEO

C direction

00107A SCC-833P/855P - gb 11/22/00 3:36 PM Page 6

Operating InstructionsOperating Instructions

Setting Lens Selection Switch

When lens mounting is completed, set the Lens

Selection Switch on the lateral side of the camera

according to the type of lens mounted.

When the mounted lens is an Auto Iris Lens of DC

control type, set the Lens Selection Switch to “DC”.

When the mounted lens is an Auto Iris Lens of

video control type, set the Lens Selection Switch to

“VIDEO”.

LENS

VIDEO

AI LENS AI LENS

DC DC

VIDEO VIDEO

Adjusting Back Focus

Although the Back Focus of the camera has been

adjusted in the factory before its shipment, the

focus may not be accurate for a certain type of lens.

In this case, follow the procedures below to adjust

the back focus. First, following is how to adjust the

Back Focus of the Fixed Focus Lens.

1) Lightly loosen up the screw fixing the Back

Focus Adjustment Ring using a screwdriver.

2) Image a vivid subject (with check patterns) at a

distance of more than 10m away and turn the

Focus Ring to the infinity ( ∞) position.

3) Adjust the Back Focus Adjustment Ring to obtain

the clearest image of the subject.

4) Fasten the screw fixing the Back Focus

Adjustment Ring.

LENS

VIDEO

00107A SCC-833P/855P - gb 11/22/00 3:36 PM Page 8

Operating InstructionsOperating Instructions

The following describes how to adjust the Back

Focus when using a Zoom Lens.

1) Lightly loosen up the screw fixing the Back

Focus Adjustment Ring using a screwdriver.

2) Image a vivid subject (with check patterns) at a

distance of 3 to 5 meters away and adjust the

zoom of the lens to TELE as far as it goes. Then

adjust the Focus Ring of the lens to obtain the

clearest image of the subject.

Adjust the zoom of the lens to WIDE as far as it goes.

Then turn the Back Focus Ring of the camera to

obtain the clearest image of the subject.

4) Repeat the number 2) and 3) steps two to three

times to exactly coincide the zoom focus from

TELE with that from WIDE.

5) Fasten the screw fixing the Back Focus

Adjustment Ring.

Note:

Turning the Back Focus Adjustment Ring to the “C” direction

beyond the adjustable range makes a sound at the limit.

LENS

VIDEO

Connecting Cable

After mounting the lens and setting the Lens

Selection switch, connect the prepared cable to

each terminal of the camera.

1) First, connect one end of the BNC cable to the

Video Output Terminal (VIDEO OUT) of the

camera.

2) Then connect the other end of the BNC cable to

the Video Input Terminal of the camera.

LENS

Video A

OUT IN

Video B

OUT IN IN

Video C

OUT

ABC

VIDEO LINE AUDIO LINE

VIDEO

Video In Terminal

on the rear of the monitor

BNC cable

Video Out Terminal

(VIDEO OUT)

00107A SCC-833P/855P - gb 11/22/00 3:36 PM Page 10

Operating InstructionsOperating Instructions

3) Then connect the power adapter.

As for SCC-833/P, 835/P, connect one end of two

lines of the power adapter using a screwdriver to

the Power In Terminal of the camera as shown

below.

* Connect to the AC 24V or DC 12V power

source, without the distinction of the polarity.

LENS

110

220

VIDEO

AC24V

DC12V

4) Connect the power input cord to the AC 230V

power source. (SCC-803P/805P)

LENS

VIDEO

00107A SCC-833P/855P - gb 11/22/00 3:36 PM Page 12

Operating InstructionsOperating Instructions

4. Names and Functions of Parts

• Side View

Groove for Mount Adapter

Use this groove for fixing the mount adapter to be

connected to the bracket with screws when

mounting the camera on the bracket.

Auto Iris Lens (Option)

Lens to be mounted on the camera.

LENS

VIDEO

Auto Iris Lens Connector

Auto Iris Lens

Control Cable

ALC Lens

Selection Switch

Groove for Mount Adapter

Camera lens

Flange-Back

Adjustment Ring

Note:

When the surface of the camera lens is contaminated, wipe the

surface gently with a tissue for lens or a cotton cloth applied

with ethanol.

Auto Iris Lens Connector

Used for supplying power, which is required to

control the iris of the lens, as well as control signal,

video signal, or DC signal to the Auto Iris Control

Lens

Auto Iris Lens Control Cable

Used for transmitting the control signals to the

camera to control the iris of the lens.

Flange-Back Adjustment Ring

Used for adjusting the Back Focus.

ALC Lens Selection Switch

Used when selecting the type of Auto Iris Lens to

use.

DC: Select this switch to DC when Auto Iris Lens

requiring DC control signal is mounted.

VIDEO: Select this switch to VIDEO when Auto Iris

Lens requiring VIDEO control signal is

mounted.

00107A SCC-833P/855P - gb 11/22/00 3:36 PM Page 14

• Rear Panel

SCC-803P/805P

SCC-833(P), 835(P)

Operating Instructions

16 17

Operating Instructions

1) Power Indication LED

While the power is properly supplied to the

camera, the LED is turned on.

2) VIDEO Output Terminal

This is a terminal to be connected to the Input

Terminal of the monitor and others. Through

this terminal, video signal is output.

3) Remote Input Terminal (RS485 control)

This is a connection terminal used to adjust the

camera in the factory, and it can be controlled

remotely using RS485 Half Duplex.

4) Alarm Signal Output

Alarm signal is generated when Motion

Detection of camera occurs.

ALARM OUT

GND

PWR

AC 220-240V

REMOTE

VIDEO OUT

ALARM OUT GND

PWR

REMOTE

AC 24V

DC 12V VIDEO OUT

1 A(TXD)

2 B(RXD)

3 +5V

4 GND

ALARM Signal Open/Gnd

GND GND

12 43

REMOTE

00107A SCC-833P/855P - gb 11/22/00 3:36 PM Page 16

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara de seguridad de Samsung

Samsung

Samsung iPolis SNP-5200 Manual de usuario

Samsung

Samsung SID-53 Manual de usuario

Samsung

Samsung SCO-6023R Manual de usuario

Samsung

Samsung SDC-425N Manual de usuario

Samsung

Samsung SCD-2082 Guía de instalación

Samsung

Samsung SVD-4400 Manual de usuario

Samsung

Samsung SIR-4250 Manual de usuario

Samsung

Samsung iPolis SND-460V Manual de usuario

Samsung

Samsung VG-STC4000 Manual de usuario

Samsung

Samsung Scc-C6475 Manual de usuario

Samsung

Samsung SPD-3000 Manual de usuario

Samsung

Samsung SID-500 Manual de usuario

Samsung

Samsung SCC-931TP Manual de usuario

Samsung

Samsung SNV-5080 Manual de usuario

Samsung

Samsung SmartCam SNH-E6411BN Manual de usuario

Samsung

Samsung SCP-3120V Manual de usuario

Samsung

Samsung SNV-5084 Manual de usuario

Samsung

Samsung C4203(P) Manual de usuario

Samsung

Samsung SCC-B5355(S) Manual de usuario

Samsung

Samsung SCC-C4253P Manual de usuario

Samsung

Samsung SNB-7000 Manual de usuario

Samsung

Samsung SNH-1011 Manual de usuario

Samsung

Samsung SCD-5082 Series Manual de usuario

Samsung

Samsung SCP-2430 Manual de usuario

Manuales populares de Cámara de seguridad de otras marcas

Okina USA

Okina USA SIR36-870VF650LP Manual de usuario

Divio

Divio NDR155PA Manual de usuario

Canon

Canon VB-C500D Manual de usuario

Easy Access

Easy Access EasyGuard Manual de usuario

Vivotek

Vivotek FD9389-EHV-v2 Manual de usuario

TUYA

TUYA COSMO W2 Manual de usuario

Eusso

Eusso UNC7500-IR Guía de configuración

urmet domus

urmet domus 1096/204 Manual de usuario

VC VC20 series Manual de usuario

Axis

Axis Q1614 Manual de usuario

ieGeek

ieGeek DD201 Manual de usuario

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manual de usuario

Vicon

Vicon V662-D-1 Instrucciones de funcionamiento

Grundig

Grundig GCH-K0274P Manual de usuario

Lorex

Lorex VANTAGE LBC7032 Manual de usuario

4xem

4xem WPT Manual de usuario

Vitek

Vitek VTC-C544 Manual de usuario

Lumens

Lumens VC-A50PNW Manual de usuario
