USER’S MANUAL

Wired Remote Controller

MWR-WH01

DB98-31483A(1)

System Air Conditioner

SE F I P GD

Ne Po

ENGLISHESPAÑOLFRANÇAISITALIANOPORTUGUÊSDEUTSCHEΛΛHNIKA

NEDERLANDS

POLSKIMAGYARRUSSIAN

MWR-WH00_IB_E_31218-1.indd 21 2009-12-14 ｿﾀﾈﾄ 5:24:58

Get user manuals: See SafeManuals.com

E-2

Safety Precautions

Do not attempt to install or repair this wired remote

controller by yourself.



This remote controller contains no user-serviceable parts.

Always consult authorized service personnel for repairs.

When moving, consult authorized service personnel for

disconnection and installation of the remote controller.

Ensure that the wall is strong enough to support the

weight of the remote controller.

Must install the remote controller with rated power

supply.

In the event of a malfunction (burning smell, etc.),

immediately stop operation, turn off the electrical

breaker, and consult authorized service personnel.

WARNING

CAUTION



Do not use inflammable gases near the remote

controller.



Do not spill water into the wired remote controller.



Do not operate the remote controller with wet hands.



Do not install the remote controller in a location where

it will come into contact with the combustible gases,

machine oil, sulphide gas, etc.



Do not press buttons with a pointed thing.



Do not pull or bend the wired remote controller cable

excessively.



Do not use this wired remote controller for other

purpose.



Do not spray an insecticide or other combustible things

on the wired remote controller.



Do not clean the wired remote controller with benzene,

solvents or other chemicals.



Do not give a shock to the wired remote controller or

disassemble it by yourself.

• Before using the wired remote controller, read carefully these instructions.

• After reading the instructions, keep this user's manual in a handy and safe place.

If a user is changed, you must hand over the manuals.

• Never attempt to install the air conditioning system or to move the wired remote

controller by yourself.

MWR-WH00_IB_E_31218-1.indd 2 2009-12-14 ｿﾀﾀ・9:46:53

Get user manuals: See SafeManuals.com

E-3

ENGLISH

Contents

 WIRED REMOTE CONTROLLER

.........................................................

 GETTING STARTED

...........................................................................

 SELECTING THE AUTOMATIC OPERATING MODE

..........................

 SELECTING THE COOLING MODE

....................................................

 SELECTING THE DRY MODE

............................................................

 SELECTING THE FAN MODE

.............................................................

 SELECTING THE HEATING MODE

....................................................

 SELECTING THE QUIET MODE

.........................................................

 SELECTING THE SLEEP MODE

..........................................................

 ADJUSTING THE AIR SWING DIRECTION

........................................

 CHECKING THE ROOM TEMPERATURE

............................................



LOCKING THE WIRED REMOTE CONTROLLER

......................................

 SETTING THE ON TIMER

..................................................................

 SETTING THE OFF TIMER

.................................................................

 SETTING THE AUTO STOP FUNCTION

.............................................

 SETTING THE TEMPERATURE LIMITS

................................................

 LOCKING THE PARTS OF THE WIRED REMOTE CONTROLLER

.........

MWR-WH00_IB_E_31218-1.indd 3 2009-12-14 ｿﾀﾀ・9:46:53

Get user manuals: See SafeManuals.com

E-4

Getting Started

You have just purchased a wired remote controller and it has been installed

by your installation specialist.

Your User’s Manual contain much valuable information on using

your wired remote controller. Please take the time to read them as they will

help you take full advantage of the unit’s features.

In the manual, you will find a series of step-by-step procedures for each

function available.

The illustrations in the step-by-step procedures use 3 different symbols:

PRESS PUSH HOLD DOWN

Wired remote controller

The wired remote controller is installed on the wall.

Note 

DIP switch setting is recognized during the initialization. If any changes are

mode to the DIP switch setting after the initialization, you have to initialize

the system by pressing and or reset the power.



Press the button after cleaning the air filter. sign will be off.

The remote controller will display the filter sign to alert the user to clean the

filter and turn off the display when the button are pressed.

 will be displayed if you press the button of the function that the

indoor unit does not support.

ON/OFF timer/

Error Status display

Operation mode

display

Fan speed/

Air swing display

Special function

display

ON/OFF time setup

Swing button(Except duct type)

Room temperature

check button

Filter Reset button(Except duct type)

Temperature

display

Operation ON/OFF buttonTemperature setting

button

Fan speed setting

button

Mode selection

(”Quiet“ ”Sleep“:Except duct type)

MWR-WH00_IB_E_31218-1.indd 4 2009-12-14 ｿﾀﾈﾄ 12:52:26

Get user manuals: See SafeManuals.com

E-5

ENGLISH

Getting Started

You have just purchased a wired remote controller and it has been installed

by your installation specialist.

Your User’s Manual contain much valuable information on using

your wired remote controller. Please take the time to read them as they will

help you take full advantage of the unit’s features.

In the manual, you will find a series of step-by-step procedures for each

function available.

The illustrations in the step-by-step procedures use 3 different symbols:

PRESS PUSH HOLD DOWN

MWR-WH00_IB_E_31218-1.indd 5 2009-12-14 ｿﾀﾀ・9:46:55

Get user manuals: See SafeManuals.com

E-6

The room temperature and the fan speed are controlled

automatically in the auto mode.

Press the (ON/OFF) button to turn on the indoor unit.

- Do not press the (ON/OFF) button if the remote

controller is on.

Result: The air conditioner will be turned on with the

most recently used mode.

The air conditioner has a built-in protection

mechanism to prevent the unit from being damaged

when it is started immediately after being:

 Plugged in

 Stopped

The air conditioner will start up after 3 minutes.

To select the AUTO mode, press the button until Auto is

displayed on the remote controller.

Result:  The air conditioner will operate in auto mode.

 The auto fan speed will be selected

automatically in auto mode.

You cannot control the fan speed.

To adjust the temperature, press the buttons.

The temperature can be set between 18°C(65°F) and

30°C(86°F).

Result: The temperature will be adjusted by 1°C(1°F)

when the buttons are pressed.

To adjust the air swing direction, refer to page 13.

Note Fan speed in auto mode

When the room temperature is high, cool and strong

air will come out. After the room is cooled, mild air will

come out.

Selecting the Automatic Operating Mode

MWR-WH00_IB_E_31218-1.indd 6 2009-12-14 ｿﾀﾀ・9:46:56

Get user manuals: See SafeManuals.com

E-7

ENGLISH

Selecting the Cooling Mode

Select the cooling mode to lower the room temperature.

Press the (ON/OFF) button to turn on the indoor unit.

- Do not press the (ON/OFF) button if the remote

controller is on.

Result: The air conditioner will be turned on with the

most recently used mode.

The air conditioner has a built-in protection

mechanism to prevent the unit from being damaged

when it is started immediately after being:

 Plugged in

 Stopped

The air conditioner will start up after 3 minutes.

To select the COOL mode, press the button until Cool is

displayed on the remote controller.

Result: The air conditioner will operate in cooling mode.

To adjust the temperature, press the buttons.

The temperature can be set between 18°C(65°F) and

30°C(86°F).

Result: The temperature will be adjusted by 1°C(1°F)

when the buttons are pressed.

Select the fan speed by pressing the button.

Result: Each time the button is pressed, fan speed will

change in the following order:

Low Med High Auto

To adjust the air swing direction, refer to page 13.

Note If you select heating mode while the cooling mode is in

operation, cooling mode will be canceled.

MWR-WH00_IB_E_31218-1.indd 7 2009-12-14 ｿﾀﾀ・9:46:58

Get user manuals: See SafeManuals.com

E-8

Select the dry mode if the room is too humid.

Using this mode will slightly lower the room temperature.

Press the (ON/OFF) button to turn on the indoor unit.

- Do not press the (ON/OFF) button if the remote

controller is on.

Result: The air conditioner will be turned on with the

most recently used mode.

The air conditioner has a built-in protection

mechanism to prevent the unit from being damaged

when it is started immediately after being:

 Plugged in

 Stopped

The air conditioner will start up after 3 minutes.

To select the DRY mode, press the button until Dry is

displayed on the remote controller.

Result:  The air conditioner will operate in dry mode.

 The Auto fan speed will be selected

automatically in the dry mode.

You cannot control the fan speed.

To adjust the temperature, press the buttons.

The temperature can be set between 18°C(65°F) and

30°C(86°F).

Result: The temperature will be adjusted by 1°C(1°F)

when the buttons are pressed.

To adjust the air swing direction, refer to page 13.

Selecting the Dry Mode

MWR-WH00_IB_E_31218-1.indd 8 2009-12-14 ｿﾀﾀ・9:47:00

Get user manuals: See SafeManuals.com

E-9

ENGLISH

Selecting the Fan Mode

Select the fan mode to circulate air without changing the

temperature.

Press the (ON/OFF) button to turn on the indoor unit.

- Do not press the (ON/OFF) button if the remote

controller is on.

Result: The air conditioner will be turned on with the

most recently used mode.

The air conditioner has a built-in protection

mechanism to prevent the unit from being damaged

when it is started immediately after being:

 Plugged in

 Stopped

The air conditioner will start up after 3 minutes.

To select the FAN mode, press the button until Fan is

displayed on the remote controller.

Result:  The air conditioner will operate in fan mode.

 You cannot adjust the temperature in fan

mode.

Select the fan speed by pressing the button.

Result: Each time the button is pressed, fan speed will

change in the following order:

Low Med High

To adjust the air swing direction, refer to page 13.

MWR-WH00_IB_E_31218-1.indd 9 2009-12-14 ｿﾀﾀ・9:47:02

Get user manuals: See SafeManuals.com

E-10

Select the heat mode to raise the room temperature.

Press the (ON/OFF) button to turn on the indoor unit.

- Do not press the (ON/OFF) button if the remote

controller is on.

Result: The air conditioner will be turned on with the

most recently used mode.

The air conditioner has a built-in protection

mechanism to prevent the unit from being damaged

when it is started immediately after being:

 Plugged in

 Stopped

The air conditioner will start up after 3 minutes.

To select the HEAT mode, press the button until Heat is

displayed on the remote controller.

Result: The air conditioner will operate in heating mode.

To adjust the temperature, press the buttons.

The temperature can be set between 16°C(61°F) and

30°C(86°F).

Result:  The temperature will be adjusted by 1°C(1°F)

when the buttons are pressed.

 The air conditioner will start heating if the

set temperature is higher than the room

temperature.

 The fan will operate even if the set

temperature is lower than the room

temperature.

Select the fan speed by pressing the button.

Result: Each time the button is pressed, fan speed

will change in the following order:

Low Med High Auto

To adjust the air swing direction, refer to page 13.

Note

 After starting heating operation, the air may not come out

immediately to prevent the cold air from coming out.

 (Defrost indicator)

- Defrost indicator will be on while your outdoor unit

defrosts the frost formed during heating operation.

After defrosting is completed, the indicator will be off.

(Air will not come out of the indoor unit while defrosting.)

 If you stop running the air conditioner after heating

operation, the air will come out for a while to radiate heat.

 If you select cooling mode while the heating mode is in

operation, heating mode will be canceled.

Selecting the Heating Mode

The heating mode can be selected only on the heat pump models.

MWR-WH00_IB_E_31218-1.indd 10 2009-12-14 ｿﾀﾀ・9:47:03

Get user manuals: See SafeManuals.com

Tabla de contenidos

Otros manuales de Mando a distancia de Samsung

Samsung

Samsung MWR-TH00 Manual de usuario

Samsung

Samsung SolarCell SE-GL-2002861 Manual de usuario

Samsung

Samsung MWR-WE10N Manual de usuario

Samsung

Samsung MWR-SH11N Manual de usuario

Samsung

Samsung MWR-WH00 Manual de usuario

Samsung

Samsung MWR-WE13N Manual de usuario

Samsung

Samsung MWR-WH02 Manual de usuario

Samsung

Samsung UE43MU6179UXZG Manual de usuario

Samsung

Samsung MWR-VH01 Manual de usuario

Samsung

Samsung MWR-WE10 Manual de usuario

Samsung

Samsung MWR-SH00N Manual de usuario

Samsung

Samsung MWR-WG00JN Manual de usuario

Samsung

Samsung TM2180E/F Manual de usuario

Samsung

Samsung RMC30C2 Manual de usuario

Samsung

Samsung BN68-03092A-02 Manual de usuario

Samsung

Samsung MWR-WE11N Manual de usuario

Samsung

Samsung MWR-SH00 Manual de usuario

Samsung

Samsung SolarCell QN85C Manual de usuario

Samsung

Samsung SRF1 Guía de instalación

Samsung

Samsung bn59-01178w Manual de usuario

Samsung

Samsung SolarCell Remote Manual de usuario

Samsung

Samsung MWR-WS00 Manual de usuario

Samsung

Samsung Smart Remote BN68 Series Manual de usuario

Samsung

Samsung SMART TV Guía

Manuales populares de Mando a distancia de otras marcas

Panasonic

Panasonic EUR7622KB0 Manual de usuario

Bang & Olufsen

Bang & Olufsen Beo4 Manual de usuario

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manual de usuario

Multiplex

Multiplex PROFI TX 9 Manual de usuario

One Remote

One Remote RMB4 Manual de usuario

FUTABA

FUTABA 9ZAP - PART2 Manual de usuario

HR Matic

HR Matic HR MULTI 3 Manual de usuario

Yamaha

Yamaha ACC-GNRST-30-20 Manual de usuario

EisSound

EisSound KBSOUND Manual de usuario

Marantz

Marantz RC101 Manual de usuario

Conrad

Conrad FS20 TC6 Manual de usuario

Anritsu

Anritsu MP1777A Manual de usuario

Niles

Niles WVC100 Guía de solución de problemas

RCA

RCA RCU1300 Manual de usuario

Bang & Olufsen

Bang & Olufsen BEO6 Manual de usuario

GE 94901 Manual de usuario

Onbon

Onbon YQ1-75 Manual de usuario

FUTABA

FUTABA R7108SB Instrucciones de instalación
