Samsung MWR-SH11UN Manual de usuario

Air conditioner

User manual

Wired remote controller MWR-SH11UN

• Thank you for purchasing this Samsung Product.

• Before operating this unit, please read this user manual carefully and retain it for future

reference.

DB68-08198A-01

ENGLISH-2

Contents

Preparation

Safety precautions ..........................................................................................................3

Names of the parts ..........................................................................................................6

Basic function

Basic operation of air conditioner............................................................................................9

Advanced function

Selecting the air ow direction ............................................................................................11

Selecting quiet operation .................................................................................................11

Wind-Free Cooling ........................................................................................................12

Long reach................................................................................................................13

Clean .....................................................................................................................13

Resetting lter cleaning alarm.............................................................................................14

On-timer..................................................................................................................14

O-timer..................................................................................................................15

Sleep .....................................................................................................................15

Lock ......................................................................................................................16

S-Plasma Ion ..............................................................................................................16

Outing ....................................................................................................................17

Others

How to set additional user functions.......................................................................................18

ENGLISH-3

01 PREPARATION

Safety precautions

California Proposition 65 Warning (US)

WARNING

Cancer and Reproductive Harm - www.P65Warnings.ca.gov.

This content is intended to protect the user’s safety and prevent property damage. Please

read it carefully for correct use of the product.

WARNING Hazards or unsafe practices that may result in severe personal

injury or death.

CAUTION Hazards or unsafe practices that may result in minor personal

injury or property damage.

Follow directions.

Do NOT attempt.

Make sure the machine is grounded to prevent electric shock.

Unplug the power plug from the wall socket.

Do NOT disassemble.

FOR INSTALLATION WARNING

The installation of this appliance must be performed by a qualied technician or

service company.

f Failing to do so may result in electric shock, re, explosion, problems with the

product, or injury.

You must connect the product with rated power upon installation.

f Failing to do so may result in problems with the product, electric shock, or re.

Do not install this appliance near a heater, inammable material. Do not install

this appliance in a humid, oily or dusty location, in a location exposed to direct

sunlight and water (rain drops). Do not install this appliance in a location where

gas may leak.

f This may result in electric shock or re.

FOR INSTALLATION CAUTION

Install the product on a hard and even place that can support its weight.

f If the place cannot support its weight, the product may fall down and it may cause

product damage.

ENGLISH-4

Safety precautions

FOR POWER SUPPLY WARNING

Do not bend or pull the power cord excessively.

Do not twist or tie up the power cord.

f This may result in electric shock or re.

FOR OPERATION WARNING

If the appliance generates a strange noise, a burning smell or smoke, stop the

operation immediately and contact your nearest service center.

f Failing to do so may result in electric shock or re.

To reinstall the air conditioner, please contact your nearest service center.

f Failing to do so may result in problems with the product, water leakage, electric

shock, or re.

f A delivery service for the product is not provided. If you reinstall the product in

another location, additional construction expenses and an installation fee will be

charged.

If the malfunction diagnosis indicator appears or abnormal operation occurs,

stop operation immediately.

f If you detect any burning smells from the product or abnormal operation occurs,

then immediately turn o the air conditioner and power, and then contact the

service center. Continuing to use the device in this state can cause electric shock,

re, or damage to the product.

Do not attempt to repair, disassemble, or modify the appliance yourself.

f Failing to do so may result in electric shock, re, problems with the product, or

injury.

ENGLISH-5

01 PREPARATION

FOR OPERATION CAUTION

Do not allow water to enter the product.

f This may result in re or explosion.

Do not operate the appliance with wet hands.

f This may result in electric shock.

Do not spray volatile material such as insecticide onto the surface of the

appliance.

f As well as being harmful to humans, it may also result in electric shock, re or

problems with the product.

Do not apply a strong impact to the remote controller and do not disassemble

the remote controller.

Do not use this product for other purposes.

f This product is designed to only be used for a system air conditioner.

Do not press the buttons with any sharp objects.

f This may result in electric shock or part damage.

FOR CLEANING WARNING

Do not clean the appliance by spraying water directly onto it. Do not use

benzene, thinner, alcohol or acetone to clean the appliance.

f This may result in discoloration, deformation, damage, electric shock or re.

ENGLISH-6

Names of the parts

Wired remote controller

IR receiver (hidden)

Display

Buttons

t In case of duct type indoor unit, you can use wireless remote controller using IR receiver of this wired remote controller

without "Display and receiver kit". You can set this function in the user setting mode.

NOTE

ENGLISH-7

01 PREPARATION

Display

⑨

①

③

⑧

⑦

⑫

⑮⑬

⑤

⑥

⑯

⑰

②

④

⑭

⑩

⑪

Classication Indication Function

①Displays air conditioner operation.

②Displays quiet operation.

③Displays Indoor temperature/Set temperature.

④Displays AC fan speed.

⑤Displays air swing (Up/Down).

⑥Displays ON/OFF time (scheduled time).

⑦Displays lter cleaning (lter cleaning period).

⑧Displays check.

⑨Displays centralized control.

⑩Displays S-Plasma Ion operation.

⑪Displays outing mode.

⑫Displays defrost operation.

⑬Displays partial locking/all locking/invaild operation.

⑭Displays IR receiver for wireless remote controller. (Default : disuse, indication on)

⑮Displays Clean operation.

⑯Displays Wind-Free Cooling operation.

⑰Displays Long reach operation.

ENGLISH-8

Names of the parts

Buttons

①

⑥

⑪

⑩

⑧

②③

⑦

⑤

⑨

④

Classication Button Function

①Operation on/o button Turn the air conditioner power on/o

②Mode button Select a desired air conditioner operation

③

Temperature setting button

Set a desired temperature and adjust the time

④Fan speed button Change the air conditioner's fan speed

⑤Air swing button Select the air ow direction of the air conditioner

⑥Wind-Free button Select Wind-Free Cooling operation

⑦OK/Cancel button

Conrm or cancel (by pressing and holding the button for 3 seconds)

⑧Long button Select Long reach function

⑨Outing/Lock button Select outing operation for the air conditioner/Lock the wired

remote controller

(by pressing and holding the button for 3 seconds)

⑩Sleep/Clean button Select sleep/Clean operation for the air conditioner

(by pressing and

holding the button for 3 seconds)

⑪Timer/Quiet button Select the timer function/quiet operation for the air conditioner

(by

pressing and holding the button for 3 seconds)

ENGLISH-9

02 BASIC FUNCTION

Basic operation of air conditioner

Basic operations can be selected by pressing the [ Mode ] button.

Auto

This operation allows you to automatically adjust the temperature and the fan speed to maximize your comfort.

t When the indoor temperature is very high, the device will produce a strong, cold breeze. When the indoor temperature

cools down, then weaker breeze will be produced.

Cool

This is a frequently used operation that allows you to adjust the fan speed, temperature, and air ow direction the way you

like.

t If you select heating operation during cooling operation, then the cooling operation is canceled.

Dry

This operation eectively removes all excess humidity so that you can feel refreshed during rainy days.

Fan

This operation produces breeze, just like a powerful fan, so that you can enjoy a refreshing breeze.

Heat

This function produces warm breeze so that you can use it in the fall or winter.

t Immediately after starting the heating operation, the air conditioner system may stop producing any breeze at all for a

while to avoid generating cold breeze.

t Defrost indicator ( )

- If you start removing frost from the outdoor unit during heating operation, the indicator will turn on.

When defrosting is over, the indicator will turn o.

(When the frost is being removed, the indoor unit does not generate any breeze.)

t If you stop the air conditioner after the heating operation, the air conditioner will produce some breeze to discharge all the

heat from the indoor unit.

t If you select the cooling operation during heating operation, then the heating operation is canceled.

ENGLISH-10

Basic operation of air conditioner

Press the button to operate the air conditioner.

Press the button to select a desired operation.

Press the button to select a fan speed.

Auto (Auto)

Cool (Low) , (Medium), (High), (Auto)

Dry (Auto)

Fan (Low) , (Medium), (High)

Heat (Low) , (Medium), (High), (Auto)

t (Turbo) will be displayed if turbo fan speed is valid on the indoor unit.

NOTE

Press the button to set a desired temperature.

Auto You can adjust the desired temperature by 1 °C(1 °F) within a range of 18 °C~30 °C (65 °F~86 °F).

Cool You can adjust the desired temperature by 1 °C(1 °F) within a range of 18 °C~30 °C (65 °F~86 °F).

Dry You can adjust the desired temperature by 1 °C(1 °F) within a range of 18 °C~30 °C (65 °F~86 °F).

Fan You can’t change the desired temperature.

Heat You can adjust the desired temperature by 1 °C (1 °F) within a range of 16 °C~30 °C (61 °F~86 °F).

* Nordic models (AC✴✴✴✴XSC✴H) : 8 °C~30 °C (46 °F~86 °F).
