Samsung WMN550M/XC Manual de usuario

Mini Wall Mount

Quick setup guide

WMN550M / XC

VESA 200x200, 400x400, 600x400

LED, LCD, PDP TV 32

″

~ 65

″

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service, please register your product at

www.samsung.com / register

Model Serial No.

Year LED TV PDP TV LCD TV

2017

Q9F~Q7F

MU9800~MU6400

M5500~M6300

- -

2016

KS7000~9900

KU6400~6700

K5500~6300

- -

2015

JS8000~9900

- -

2014

H8000~8800

HU8700~9800

″

, 65

″

- -

Year LED TV PDP TV LCD TV

2017

MU6100~MU6300

M5000~M5300

- -

2016

KU6000~6100

K5100

- -

2015

J4000~6590

JU5900~7800

- -

2014

H4000~7150

HU5900~8550 H4000~5000

Assembly to Wall

Assembly to TV

: x4

(M5X65mm-Wood)

600 400 200 200 400 600

Gx2

Mini wall mount

Fx8

Ⅰ

17mm

(0.67”)

40mm

(1.57”)

17mm (0.67”)

16mm (0.62”)

17mm (0.67”)

16mm (0.62”)

Ⅰ

17mm

(0.67”)

40mm

(1.57”)

Ⅱ

17mm

(0.67”)

40mm

(1.57”)

Ⅱ

17mm

(0.67”)

40mm

(1.57”)

or Only

2Tx4

K L

1Tx4

S-1

(M8X28)

S-2

x4 (M8X35)

S-5

x4 (M8x40)

S-6

x4 (M8x30)

S-8

x4 (M8x64)

: x4

(M5X65mm-Wood)

Fx8

Mini wall mount

S-4

(M5X15)

600 400 200 200 400 600

S-2

(M8X35)

S-3

(M6X28)

S-5

(M8X40)

S-6

(M8X30)

S-7

(M8X42)

S-8

(M8X64)

1 2

Assembly to Wall

600

Mini wall mount

200 mm

400 mm

600 mm

(7.88″)

(15.75″)

(23.62″)

600 400 200 200 400 600

Mini wall mount

Mini wall mount Mini wall mount

Mini wall mount

200 mm

400 mm

600 mm

(7.88″)

(15.75″)

(23.62″)

600 400 200 200 400 600

Mini wall mount

Mini wall mount Mini wall mount

Mini wall mount

200 mm

400 mm

600 mm

(7.88″)

(15.75″)

(23.62″)

600 400 200 200 400 600

Mini wall mount

600 400 200 200 400 600

Concrete, Wood

13mm(0.5″)

12345

0~48mm(1.8”)

0~11mm(0.4”)

G + I + S S-2

x4 (M8x35) Q9F 65″

JS8500 ~ JS9500 48″ ~ 65″

KS9500 ~ KS9800 65″

Assembly to TV

2017 Premium Curved TV 49″~ 65″2017 Premium Flat TV 49" ~ 65"

I I

Holder-Ring

(supplied with the TV)

Holder-Ring

(supplied with the TV)

G + I + S

S-6 (M8x30) ■2017 TV MU8000 ~ MU9000 (Curved TV)

S-2 (M8x35) ■2017 TV MU8000 ~ MU9000 (Flat TV)

2016 Premium Curved TV 49″~ 65″2016 Premium Flat TV 49" ~ 65"

I I

Holder ring

(supplied with the TV)

Holder ring

(supplied with the TV)

Holder ring

(supplied with the TV)

S S-6 (M8x30) ■2016 TV KS8000 ~ KS9000

S S-8 (M8x64)

■2017 TV Q8C, Q7C, Q7F

■2017 TV MU6400 ~ MU7000

■2017 TV M5500 ~ M6300

■2016 TV KS7000 ~ KS7500

■2016 TV KU6400 ~ KU6700

■ 2016 TV K5500 ~ K6300

G + I + S

※2013 UHD F9000 55″ ~ 65″

G + I + S-5 (M8x40)

J +

S-5

※ 2013 UHD F9000 55″~ 65″

※2014 UHD TV HU8500 55″

G + I + S-5 (M8x40)

G G

S-5 S-5

※ 2014 UHD TV HU8500 55″

Cover Wall top

(supplied with the TV)

Holder ring

(supplied with the TV)

S-2

※2014 LED TV H8000

※2014 UHD TV HU8200

※2014 UHD TV HU8500 65"

G + I + S-2 (M8x35)L +

21 3

Ⅱ

Assembly to Wall

: x4

(M5X65mm-Wood)

E D

600 400 200 200 400 600

40mm (1.57”)

17mm

(0.67”)

40mm

(1.57”)

18~40mm

(0.8”~1.57”)

18~40mm

(0.8”~1.57”)

18~40mm

(0.8”~1.57”)

1 2

600

Mini wall mount

200 mm

400 mm

600 mm

(7.88″)

(15.75″)

(23.62″)

600 400 200 200 400 600

Mini wall mount

Mini wall mount Mini wall mount

Mini wall mount

200 mm

400 mm

600 mm

(7.88″)

(15.75″)

(23.62″)

600 400 200 200 400 600

Mini wall mount

Mini wall mount Mini wall mount

Mini wall mount

200 mm

400 mm

600 mm

(7.88″)

(15.75″)

(23.62″)

600 400 200 200 400 600

Mini wall mount

HIJ K

2Tx4

1Tx4x2 x2 x4

S-1

S-2

S-3

x4 (M8X28)

x4 (M6X28)

x4 (M8X35)

S-5

S-6

S-7

x4 (M8X30)

x4 (M8X40)

x4 (M8X42)

Mini wall mount

S-8

S-4

x4 (M8X64)

x2 (M5X15)

S-4

600 400 200 200 400 600

Concrete, Wood

13mm(0.5″)

12345

0~48mm(1.8”)

0~11mm(0.4”)

5 6

Assembly to TV

G + H + I +

S-1

(M8x28)

■LED TV (Slim)

■PDP TV

■2013 LED TV (F6500 ~ F6800) 40", 55"

■ 2014 LED TV (FH series) 46″ ~ 60″

■ 2014 LED TV (H5203,5303,6203) 46″ ~ 65″

S-2

(M8x35)

■ 2015 LED JS8500 ~ JS9500 48″ ~ 65″ ■ 2017 QLED TV Q9F 65"

S-3

(M6x28)

■ LCD TV 32″ ~ 40″ ■ 2014 LED TV (FH series) 32″ ~ 40″

■ 2014 LED TV (H5203,5303,6203) 32″ ~ 40″

S-5

(M8x40)

■ 2015 LED J4000 ~ J6000 32″ ~ 65″

■ 2015 LED J6300 ~ J6500 32″ ~ 65″

■ 2015 LED JU6510 40″

■ 2015 LED JU6500 32″ ~ 65″

■ 2015 LED JU7000, JU7500 32″ ~ 65″

■2016 LED TV K5100 ~ K5300

■ 2016 LED TV KU6000

■ 2017 LED TV MU6100

■ 2015 LED J6200 ~ J6270 32″ ~ 40″

■ 2015 LED JU6000 ~ U6495 32″ ~ 65″

■ 2015 LED JU6580 ~ U6850 40″

■ 2015 LED JU6550 ~ JU6570 32″ ~ 65″

■2014 UHD TV (HU7100 ~ 7200)

■ 2014 LED TV (H4000 ~ 7150) 32″ ~ 40″

■2016 LED TV KU6100 40"

■2017 LED TV M5000

S-6

(M8x30)

■ 2014 LED TV(H6300 series) 65″

■ 2014 LED TV(H6400 series) 55″ ~ 65″

■ 2014 LED TV(H7000~7150) 65″

S-7

(M8x42)

■ 2015 LED JU6510 48″ ~ 65″

■ 2016 LED TV KU6100 49″ ~ 65″

■ 2015 LED JU6580~JU6850 48″ ~ 65″

■ 2017 LED TV MU6300

S-7

※2014 LED TV (H4500) 32"

※2014 LED TV (H5000 ~ 6300, 6410 ~ 7150) 46" ~ 60"

※2014 LED TV (H6400 series) 48" ~ 50"

※2014 LED TV H6800 ~ 6870

※2014 UHD TV (HU5900 ~ 8550) 40" ~ 65"

G + H + I + S-2 (M8x35)L +

G + H + I + S-7 (M8x42)L +

S-7 x4 (M8x42) ■ J6200 ~ J6270 48″ ~ 60″

G + H + I + SL +

S-7
