Samsung YP-Z5 Manual de usuario
For Your Safety
Read this manual carefully to ensure proper use of the product and
to avoid any danger or physical damage.
2
WARNING
Product Use
Improper use can result in explosion,
fire or electric s ock. Take care to avoid p ysical damage.
Do not disassemble, repair
or modify t is product on
your own.
Do not get t e product wet
or drop it in water.
If the product gets wet,
do not switch it on.
Contact a Service Center.
Do not place t e product in
damp, dusty or sooty areas,
as it could result in fire or
electric s ock.
Avoid using your product at
ig volume levels, as it may
result in permanent earing
damage. If you experience
ringing in your ears w ile
using t e earp one, remove
t e earp one immediately
and lower t e volume.
Do not leave t e product in
areas above 35°C(95°F)
(suc as a sauna or inside
a parked car).
During the summer the
temperature inside a car may
rise up to 80 C(176 F).
Take care not to tangle t e
earp one cable around your
arms or neig boring objects
w ile driving, working out or
walking, as it could result in
a car accident or ot er
injuries.
Failing to heed the product instructions may cause serious injury.
C apter 1. Preparation
3
CAUTION
Product Use
Take care to avoid product malfunction
and p ysical damage.
Management of Important Data
Avoid malfunction
W en wearing t e product
around your neck, take
care not to exert excessive
force on t e neck string.
Be sure to backup
important data.
Please be aware that we claim no
responsibility for damage from data
loss due to breakdown, repair or
other causes.
Failure to follow all instructions lead to physical injuries or damage to the product.
Do not cause excessive
impact on t e product by
dropping it. Do not place
eavy objects on top of t e
product.
Prevent any foreign
particles or dust from
entering into t e product.
Always use t e accessories
provided by or approved by
Samsung.
Do not spray water on t e
product. Never clean t e
product wit c emical
substances suc as
benzene or t inner, as it may
cause fire, electric s ock or
deteriorate t e surface.
Do not place t e product
near magnetic objects, as it
may cause a malfunction.
Contents
4
C apter 1. Preparation
C ecking t e Product and
Accessories .................................................7
Checking the Accessories...........................7
Components ................................................8
Screen Display Information .......................10
Button Functions .......................................11
C arging t e battery ...............................13
Basic Use ...................................................14
C apter 2. Connecting to a PC
Connecting to a PC..................................18
Transferring Music to your Player.........19
Chapter 3. Listening to Music
Listening to Music....................................22
Transferring Playlists from WMP10.......25
To Play a Playlist.......................................27
S uffle Play (Random Repeat)...............28
C ecking t e Music Information ...........30
Chapter 4. Picture Viewing
Picture Viewing..........................................32
Picture Enlarging/Slides ow Viewing...33
Safety Precautions ....................................2
Contents ......................................................4
5
Chapter 5. Setup
Setup ...........................................................35
Audio Setup ..............................................35
Display Setup.............................................36
Slideshow Setup .......................................37
Repeat Setup.............................................38
Timer Setup...............................................39
Language Setup ........................................40
Reset .........................................................41
Checking the System Infomation...............42
Chapter 6.
Troubleshooting & Appendix
System Reset.............................................44
To Upgrade Firmware ..............................45
Troubles ooting........................................47
Menu Tree ..................................................50
Product Specifications............................51
License........................................................52
Safety Information....................................54
Warranty .....................................................56
C apter 1. Preparation
C ecking t e Product and
Accessories .................................................7
C arging t e battery ...............................13
Basic Use ...................................................14
C apter 1. Preparation
C ecking t e Product and Accessories
7
C ecking t e Accessories
The following diagrams are a guide and
may differ slightly from the actual product
appearance.
C ecking t e Product and Accessories
Player Earphones USB Cable
Easy Start CD
AH30-00086D(White) AH39-00783B AH80-00131A
AH30-00087D(Black)
Easy Start CD Overview
W at is Easy Start CD?
■
The Easy Start CD provides a simple way for you to get started using a PlaysForSureTM‚ portable music device
by quickly and easily installing any necessary software needed including Windows Media Player 10 and support
for online music stores.This CD will also show you how to rip CDs, download new music from an online store,
manage your music with Windows Media Player 10 and take it with you on your new portable music device.
W at is PlaysForSure?
■PlaysForSure is a logo and testing program that ensures content compatibility of online music stores and
portable music devices.When you see the PlaysForSure logo on the product box of a music device, you
know it will work with content from the widest range of online stores and services that also carry this
logo.
■
Design of accessories is subject to change for the purpose of improvement, without notice.
8
Components
C ecking t e Product and Accessories
Front, Rig t Side and Top
Earphone Connection Port
Neck String Hole
Lock Switch
Screen Display
Volume Control Button
Back Button
Move Track/Quick Search Button
Outer Ring
Touch Pad/Select Button
Power & Play/Pause Button
C apter 1. Preparation
C ecking t e Product and Accessories
9
Bottom
Power/USB Connection Port
Reset Button
Earp one Connection
√ Top
Earphones
0:49 2/2 1:36
MP3 DNSe STR REP
Rising Sun
Samsung MP3
Samsung
2:10 AM
Screen Display Information
C ecking t e Product and Accessories
10
1Current Time Display
3Album Display
2Album Title Display
43D Sound Displays
5File Type Display
(MP3, WMA etc)
6Play Status Bar
7Play Time Display
8Play/Pause Display
10 Street Mode Display
9Music Title Display
11 Repeat Play Display
12 Total Play Time Display
13 Current Music Number/
Total Number Display
NOTE
■ The screen pictures are for illustration purposes only.The actual screen may differ.
1
2
3
4
5
6
7
8
10
11
12
13
9
