Samsung YP-Z5F Manual de usuario
For Your Safety
Read this manual carefully to ensure proper use of the product and
to avoid any danger or physical damage.
2
WARNING
Product Use
Improper use can result in explosion,
fire or electric shock. To avoid your hearing damage
Do not disassemble, repair
or modify this product on
your own.
Do not get the product wet
or drop it in water.
If the product gets wet,
do not switch it on.
Contact a Service Center.
Do not place the product in
damp, dusty or sooty areas,
as it could result in fire or
electric shock.
Using the earphone or headphone for an extended
time can cause a serious damage to your hearing.
If you are exposed to a sound in higher than 85db for an
extended time, you will be adversely affected on your hearing.
The higher the sound is, the more seriously damaged your
hearing is (an ordinary conversation is made in 50 to 60 db
and the noise level on the road is approximately 80 db).
You are strongly advised to set the volume level to medium
(the medium level is usually less than 2/3 of the maximum).
If you feel a ringing in the ear(s), lower the volume
or stop using the earphone or headphone.
To avoid a risk of traffic accident
Do not use the earphone while you are driving a
bicycle, automobile or motorcycle.
Otherwise it can cause a serious accident and, furthermore, it
is prohibited by the law in some areas.
Using the earphone on the way, in particular, on the crosswalk
can lead to a serious accident.
For your safety, make sure the earphone
cable should not get in the way of your arm
or other surrounding objects while you are
taking exercise or a walk.
Do not leave the product in
areas above 35°C(95°F)
(such as a sauna or inside
a parked car).
During the summer the
temperature inside a car may
rise up to 80°C(176°F).
Failing to heed the product instructions may cause serious injury.
Chapter 1. Preparation
3
CAUTION
Product Use
Take care to avoid product malfunc-
tion and physical damage.
Management of Important Data
Avoid malfunction
When wearing the product
around your neck, take
care not to exert excessive
force on the neck string.
Be sure to backup
important data.
Please be aware that we claim
no responsibility for damage
from data loss due to break-
down, repair or other causes.
Failure to follow all instructions lead to physical injuries or damage to the product.
Do not cause excessive
impact on the product by
dropping it. Do not place
heavy objects on top of the
product.
Prevent any foreign
particles or dust from
entering into the product.
Always use the accessories
provided by or approved by
Samsung.
Do not spray water on the
product. Never clean the
product with chemical
substances such as
benzene or thinner, as it may
cause fire, electric shock or
deteriorate the surface.
Do not place the product
near magnetic objects, as it
may cause a malfunction.
Product Features........................................7
Checking the Product and Accessories
....8
Components ................................................8
Screen Display Information .......................10
Button Functions........................................11
Charging the battery................................13
Basic Use ...................................................14
Contents
4
Chapter 1. Preparation
Chapter 2. Loading Your Desired File
Loading Your Desired File......................18
Loading Your Desired File.....................18
Installing Media Studio..........................19
Connecting to your PC..........................21
Adding Files/Folders in Media Studio...22
Adding Files/Folders in
Media Studio with Autoscan..................24
Transferring Files with Media Studio ....26
Using as a Removable Disk ...................28
Disconnecting from your PC..................29
Chapter 3. Multmedio funtion
Listening to Music....................................31
Listening to Music......................................31
To Play a Playlist.......................................34
Shuffle Play (Random Repeat)..................35
Checking the Music Information................38
Picture Viewing.........................................39
Picture Viewing..........................................39
Picture Enlarging/Slideshow Viewing
...........40
Listening to FM Radio .............................41
Listening to FM Radio ...............................41
Setting a Frequency ..................................43
Setting FM Radio.......................................46
Recording...................................................48
Voice Recording ........................................48
For Your Safety ..........................................2
Contents .......................................................4
5
Chapter 4. Setup
Setup ...........................................................51
Audio Setup ..............................................51
Display Setup ............................................52
Slideshow Setup .......................................53
Repeat Setup.............................................54
Timer Setup...............................................55
Language Setup........................................56
Reset .........................................................57
Checking the System Infomation...............58
Chapter 5. Troubleshooting
System Reset.............................................60
Troubleshooting........................................61
Chapter 6. Appendix
Menu Tree ..................................................65
Manual USB Driver Installation..............66
Product Specifications............................69
Chapter 1. Preparation
Product Features........................................7
Checking the Product and Accessories
....8
Components ................................................8
Screen Display Information .......................10
Button Functions........................................11
Charging the battery................................13
Basic Use ...................................................14
Chapter 1. Preparation
Product Features
7
Product Features
Freedom of my favorite
selection with your player! Longer Play Time and Shorter
Downloading!
■
You can easily search for music files by the
artist, album or genre and make you own
selection of favorite songs in Playlist.
■
A fully charged battery can operate the
player in a maximum of 39 hours.
■
The player supports USB 2.0 capability,
much faster than USB 1.1, to enable faster
communication with the PC.
Supporting Various File
Formats! 3D Surround Sound!
High-Definition Quality!
■
Supports various file formats including
MP3, WMA and Ogg.
■
You can enjoy photo files in different
formats on the display by converting them
into JPG.
■
The player has built-in DNSe (Digital
Natural Sound engine), Samsung’s unique
sound technology for richer sound.
Touchpad Mechanism! Ergonomic Design!
■
Put your finger on the touchpad and move
or press it slightly to select a file or function
that you want to use.
■
Experience the good sense of grip and
easy operation.
8
Components
Checking the Product and Accessories
Front, Right Side and Top
Earphone Connection Port
Neck String Hole
Lock Switch
Screen Display
Volume Control Button
Back Button
Move Track/Quick Search Button
Outer Ring
Touch Pad/Select Button
Power & Play/Pause Button
Chapter 1. Preparation
Checking the Product and Accessories
9
Bottom
Checking the Accessories
The following diagrams are a guide and may differ slightly from the actual product appearance.
Power/USB Connection Port
Reset Hole
Player Earphones USB Cable
Installation CD
■
Design of accessories is subject to change for the purpose of improvement, without notice.
Screen Display Information
Checking the Product and Accessories
10
NOTE
■ The screen pictures are for illustration purposes only. The actual screen may differ.
0:49 2/2 1:36
MP3 DNSe STR REP
Rising Sun
Samsung MP3
Samsung
2:10 AM
1Current Time Display
3Album Display
2Album Title Display
4Sound Mode Display
5File Type Display
(MP3, WMA etc)
6Play Status Bar
7Play Time Display
8Play/Pause Display
10 Battery Display
9Music Title Display
11 Street Mode Display
12 Repeat Play Display
13 Total Play Time Display
14 Current Music Number/
Total Number Display
1
2
3
4
5
6
7
8
11
10
12
13
14
9
