Samsung YP-U4 Manual de usuario
SERVICE
Manual
YEPP
Model Name: YP-U4
Model Code : YP-U4JAB/EDC
YEPP
Refer to the service manual in the GSPN (see the rear cover) for the more information.
CONTENTS
1. Precaution
2. Product Specification
3. Disassembly & Reassembly
4. Troubleshooting
5. Exploded View & Part List
6. PCB Diagram
7. Schematic Diagram
YP-U4
This Service Manual is a property of Samsung Electronics
Co.,Ltd. Any unauthorized use of Manual can be punished
under applicable International and/or domestic law.
GSPN (Global Service Partner Network)
Area Web Site
North America service.samsungportal.com
Latin America latin.samsungportal.com
CIS cis.samsungportal.com
Europe europe.samsungportal.com
China china.samsungportal.com
Asia asia.samsungportal.com
Mideast & Africa mea.samsungportal.com
© Samsung Electronics Co.,Ltd. Aug. 2008
Printed in Korea
Contents
1. Precaution
1-1 Safety Precautions...........................................................................................1-1
1-2 Static Electricity Precautions............................................................................1-2
2. Product Specification
2-1 Product Feature ...............................................................................................2-1
2-2 Specifications...................................................................................................2-2
2-3 Specifications Analysis.....................................................................................2-3
2-4 Accessories......................................................................................................2-4
3. Disassembly & Reassembly
3-1 Overall Disassembly & Reassembly................................................................3-1
4. Troubleshooting
4-1 Checkpoints by Error Mode..............................................................................4-2
4-2 Upgrade Methods.............................................................................................4-10
5. Exploded View & Part List
5-1 Exploded View .................................................................................................5-2
5-2 Electrical Part List ............................................................................................5-4
6. PCB Diagram
6-1 MAIN PCB Top.................................................................................................6-2
6-2 MAIN PCB Bottom ...........................................................................................6-4
7. Schematic Diagram
7-1 Overall Block Diagram .....................................................................................7-2
7-2 MAIN................................................................................................................7-3
Samsung Electronics 1-1
Precaution
1. Precaution
1-1 Safety Precautions
1. To remove dust from cabinet, use a dry cloth without using liquid and aerosol cleaner.
2. You should not use attachments not recommended by the company. Otherwise, it may cause critical damage.
3. You should not use this product near water such as bathtub, swimming pool or lake etc.
4. Power supply: A type of battery as displayed on the label should be only used.
5. You should not put any object or liquid into product. Otherwise, it may cause failure or mal-operation.
6. If replacement material is required, service engineer should use materials with the same standard.
The use of non-standardized materials may cause failure of product.
1-2 Samsung Electronics
Precaution
1-2 Static Electricity Precautions
Some semi-conductor parts may be easily damaged due to static electricity.
These elements are generally called as static electricity sense device (ESD). Typically examples of EST include
IC, some transistor and chip element for semi-conductor with electrical field effect.
The following methods should be used to reduce damage of elements occurred due to static electricity:
1. Contact and emit all the grounding objects with static electricity from your body before handling with elements
for semi-conductor or devices with elements for semi-conductor. You should purchase and use static electricity
arm rings or commercially available. You should remove it due to potential shock before supplying power to the
device under test.
2. You should place appliance on the conductive surface like aluminum film to prevent that static electricity is
accumulated or the device is disclosed outside after removing electrical appliance with the ESD device.
3. You should use only soldering iron that is ground when soldering the ESD device.
4. Minimize physical operation when handling with the ESD device for replacement without packing (Otherwise,
namely friction between cloth fibers or lifting of the foot from the carpet floor may cause static electricity enough
to damage the ESD device).
Samsung Electronics 2-1
Product Specification
2. Product Specification
2-1 Product Feature
Convergence
- UMS/MTP Dual Support
Feature
- Supports Music Subscription SVC
- FM Radio & FM Recording
- Voice Recording
- Playback Speed Adjustment
- Interval Skip Playback
- (A-B) Section Repeat
- Data Cast
Usability
- Recently added playlist
- User Button
- DNSe 2.0
Semiautomatic Sliding USB
Light Effect Using White-LED
4Line 16-Gray OLED Display (128 x 64)
Sleek Touch Pad
2-2 Samsung Electronics
Product Specification
2-2 Specifications
Basic Specification
Rating DC 3.7V / 500mA
Built-in Battery Power 300 mAh / DC 3.7V
File Compatibility MPEG1/2/2.5 Layer3 (8kbps ~ 320kbps, 8kHz ~ 48kHz)
WMA (48kbps ~ 192kbps, 8kHz ~ 48kHz)
Supported Number of Files Folder: Max. 1000 / File: Max. 3000
Earphone Output 20mW/Ch. (based on 16Ω)
Output Frequency Range 40Hz ~ 20kHz
Signal to Noise Ratio 90 dB with 20 kHz LPF (based on 1kHz 0 dB)
Play Time Maximum of 16 hours for music playback
(based on: MP3 128kbps, Volume: 15, Normal Mode, Display Off)
Temperature Range for
Operation -5 ~ 35°C (23~95°F)
Case Plastics
Weight 0.97 oz
Dimensions (W x H x D) 1.06˝ x 3.27˝ x 0.51˝
FM Radio
FM Frequency 87.5 ~ 108.0MHz
FM Signal to
Noise Ratio 55 dB
FM T.H.D 1%
FM Useable
Sensitivity 38dBu
Samsung Electronics 2-3
Product Specification
2-3 Specifications Analysis
Model Name YP-U4 YP-U3
Color Black/Red/Blue Black/White/Pink/Green/Blue
PC Interface USB 2.0 USB 2.0
Power Battery time: Li-poly 16 Hours Battery time: Li-poly 15 Hours
LCD 16Gray 4Line OLED (128x64) Mono 4Line OLED (128x64)
Key Tact Key: Play (Power)/Rec (User)
Touch: FF/REW/Select/Vol+/Vol-/Back Tact Key: Play (Power)/Rec (User)
Touch: FF/REW/Menu/Vol+/Vol-
External Material IN-Mold Surface Deposition, IN-Mold
Accessory EP-370/Quick Guide/Install CD EP-360/Quick Guide/Install CD
PC Software Samsung Media Studio Samsung Media Studio
Minimum System
Requirements Windows 2000/XP/Vista
Pentium 500MHz Windows SE/ME/2000/XP
Pentium 133MHz
2-4 Samsung Electronics
Product Specification
2-4 Accessories
2-4-1 Supplied Accessories
Accessories Item Item code Remark
Earphones AH59-01884A
Samsung Service Center
Program Installation CD AH46-00058C
Samsung Electronics 3-1
Disassembly & Reassembly
3. Disassembly & Reassembly
3-1 Overall Disassembly & Reassembly
- Be careful to follow the disassembly sequence described in the manual. Otherwise, the product
may be damaged.
- Be sure to carefully read and understand the safety instructions before performing any work as
the IC chips on the PCB are vulnerable to static electricity.
- Assemble in the reverse order of disassembly.
No. Part Name Description Description Photo
1 ASSY-
WINDOW
LCD
1) With the USB hinge out, put the
disassembling tool into the hole in the
back of the serial label.
When separating them, be careful
not to make scratches.
2) Press on the disassembling tool
and lift the ASSY-WINDOW LCD.
3) Lift the Connector Locker and then
remove the ASSY-WINDOW LCD.
