Samsung Yepp Sports YP-60 Manual de usuario

Connecting the USB cable

1Connect a USB cable to the USB port on the computer.

2Connect the opposite end of the USB cable to the

USB cable port on the right side of the yepp.

● If you disconnect the USB cable from your PC while

implementing a command or initializing during

USB driver installation, your PC may not function correctly.

3The USB driver is installed with a message saying that it

is searching for a new device. You may not see the

display screen during installation.

Go to the device manager to check that

installation has been successfully completed.

Upon installation of the USB driver

"SAMSUNG YP-60”

will appear in the

[Start] →[Settings] →[Control Panel] →

[System Properties] →[Device Manager].

➤Before connecting the yepp to PC, make sure to install yepp Studio.

Location of Controls

Turning Power On and Off

Playing Music Pausing Music

YP-60 Quick Guide

ENC/NAVI.

Button

Move to Track/

Speed Search Button Volume Button

MENU/

Loop Repeating Button

Sports Function Button

Play/Stop/Pause

On/Off Button

Display Hold Switch

Reset Hole

USB Cable

Connection Port

ENC Jack

Earphone JackHeart Rate Measurement Sensor

●Power On : Press and hold the button to turn on the power.

●Power Off : Press and hold the button to turn off the power.

Press the button.

●Playback starts. Press the button to pause playback.

●While in Pause mode, briefly press again to resume playback.

●If the device won’t respond even after pressing the buttons,

reboot it by pressing the Reset Hole with a pin.

USB connect cable

Downloading files

1Turn on the yepp and connect it to your PC.

2Select the file you wish to download from the Play List Window or File List Window.

●If the Play List Window is empty, use the [Open Files] button on the main window or

drag-and-drop the desired files from the File List Window to the Play List Window.

3Drag-and-drop the selected files to the Music folder in the yepp window or

click the [Transmit to yepp] button to move the files.

NNoo

oott

ttee

●Refer to Help for more detailed information about using yepp Studio.

●When running the yepp Studio for the first time, input the serial number listed on the back of the yepp when the

Product Number Registration Window appears.

●You cannot use yepp Studio while Fitness Manager is running.

Viewing Help on yepp Studio

3 4

AH68-01563A (Rev 0.0)

: [Open Files] button

: [Transmit to yepp]

button

Run yepp Studio and press F1.

●Help will appear.

Move the arrow to the top of yepp Studio and right click on the

mouse. The following selection window will appear.

●Click on Help and the Help window will appear.
