Samsung EO-BG930 Manual de usuario
www.samsung.com
User Manual
EO-BG930
English (EU). 07/2016. Rev.1.0
2
Table of Contents
Read me first
Getting started
4 Package contents
5 Device layout
6 Indicator light
7 Charging the battery
8 Checking the remaining battery power
8 Turning the headset on and off
9 Preparing and wearing the headset
Connecting via Bluetooth
13 Bluetooth
14 Connecting to a mobile device
15 Connecting additional mobile devices
16 Reconnecting or disconnecting the
devices
Using the headset
17 Using the headset
Appendix
20 Troubleshooting
23 Removing the battery
3
Read me first
Please read this manual before using the device to ensure safe and proper use.
•
Images may differ in appearance from the actual product. Content is subject to change
without prior notice.
•
Before using the headset, make sure the mobile device you want to connect to is
compatible with this headset.
Instructional icons
Warning: situations that could cause injury to yourself or others
Caution: situations that could cause damage to your device or other equipment
Note: notes, usage tips, or additional information
4
Getting started
Package contents
Check the product box for the following items:
•
Headset
•
Earbud tip (3 sets, S/M/L)
•
Wingtip (2 sets, S/L)
•
Quick start guide
•
The items supplied with the device and any available accessories may vary
depending on the region or service provider.
•
The supplied items are designed only for this device and may not be compatible
with other devices.
•
Appearances and specifications are subject to change without prior notice.
•
You can purchase additional accessories from your local Samsung retailer. Make
sure they are compatible with the device before purchase.
•
Use only Samsung-approved accessories. Using unapproved accessories may cause
the performance problems and malfunctions that are not covered by the warranty.
•
Availability of all accessories is subject to change depending entirely on
manufacturing companies. For more information about available accessories, refer
to the Samsung website.
Getting started
5
Device layout
Power button
Right earbud
Earbud tip
Volume (+) button
Multifunction/Talk
button
Ear hook
Left earbud
Charger port
Microphone
Indicator light
Volume (-) button
Cable holder
Charger port cover
Cable holder
Left Right
Buttons and functions
Name Function
Power button
•
Press and hold for one second to turn the headset on.
•
Press and hold for approximately four seconds to turn the headset
off.
•
Press to check the remaining battery power.
Getting started
6
Name Function
Multifunction/
Talk button
•
Press to answer or end calls.
•
Press to play or pause multimedia files.
•
When the Bluetooth connection ends, press to reconnect the
devices.
•
During a call, press and hold for one second to turn the
microphone on or off.
•
Press and hold for one second to reject a call or launch the
S Voice
app.
•
Press and hold for approximately three seconds to enter Bluetooth
pairing mode.
•
Press twice to skip to the next file during media playback.
Volume buttons
•
Press to adjust the volume during a call or media playback.
•
Press and hold the Volume (-) button for one second to skip to the
next file during media playback.
•
Press and hold the Volume (+) button for one second to skip to the
previous file during media playback.
Indicator light
The indicator light alerts you to the headset’s status.
Colour Status
Flashes blue three times
•
Power on
Flashes red three times
•
Power off
Flashes red and blue
•
Bluetooth pairing mode
Quickly flashes blue three
times
•
Connected to mobile devices via Bluetooth
Flashes blue
•
Incoming call
Red
•
Charging
Blue
•
Fully charged
Off
•
During use or in sleep mode
Getting started
7
Charging the battery
Charge the battery before using the headset for the first time or when the headset has been
unused for extended periods.
Use only Samsung-approved chargers. Unapproved chargers can cause the battery to
explode or damage the headset.
•
You can charge the headset using the charger (sold separately).
•
Using a power source other than the charger, such as a computer, may result in a
slower charging speed due to a lower electric current.
•
The headset can be used while it is charging, but it may take longer to fully charge
the battery.
•
While charging, the headset may heat up. This is normal and should not affect the
headset’s lifespan or performance. If the battery gets hotter than usual, the charger
may stop charging.
•
If the headset is not charging properly, take the headset and the charger to a
Samsung Service Centre.
1 Open the charger port cover and connect the headset to a charger.
12
•
Do not pull the charger port cover excessively. This can damage the charger port
cover.
•
Connecting the charger improperly may cause serious damage to the headset. Any
damage caused by misuse is not covered by the warranty.
Getting started
8
2 After fully charging, disconnect the headset from the charger.
•
To save energy, unplug the charger when not in use. The charger does not have a
power switch, so you must unplug the charger from the electric socket when not in
use to avoid wasting power. The charger should remain close to the electric socket
and easily accessible while charging.
•
The socket-outlet shall be installed near the equipment and shall be easily
accessible.
Checking the remaining battery power
Press the Power button. The indicator lights will alert you to the remaining battery power.
Colour Battery power
Flashes red three times
•
Less than 30 %
Flashes violet three times
•
30-60 %
Flashes blue three times
•
60-100 %
Turning the headset on and off
To turn the headset on, press and hold the Power button for one second. The indicator light
will flash blue three times.
To turn the headset off, press and hold the Power button for approximately four seconds. The
indicator light will flash red three times.
Follow all posted warnings and directions from authorised personnel in areas where
the use of wireless devices is restricted, such as aeroplanes and hospitals.
Getting started
9
Preparing and wearing the headset
Attaching an earbud tip to the earbud
1 Select the earbud tip that fits your ear.
2 Cover the latch at the bottom of the earbud with the earbud tip.
•
Do not put the earbuds in your ears without earbud tips. Doing so may hurt your
ears.
•
Do not pull the earbud tip excessively. The earbud tip may tear.
3 Follow the same procedure for the other earbud.
Getting started
10
Replacing the ear hooks with wingtips
Ear hooks are attached to the earbuds by default. You can replace them with wingtips.
1 Remove the ear hook by holding the hook as shown in the image below, slightly pulling
it upwards, and then pulling it towards the earbud tip.
•
Do not pull the ear hook in the wrong direction. This can damage the ear hook.
•
Do not pull the ear hook excessively. This can damage the ear hook.
2 Select the wingtip that fits your ear.
The left wingtip has microphone holes in it.
3 Cover the earbud with the wingtip. Then, adjust the left wingtip so that the microphone
holes are not blocked.
•
Do not put the wingtip in the wrong direction. This can damage the wingtip.
•
Do not put the earbuds in your ears without wingtips. Doing so may hurt your ears.
•
Do not pull the wingtip excessively. The wingtip may tear.
