Thank you for purchasing this Samsung product.

MIM-D00A_DMS2_IB_E 33388-1.indd 165 2011-02-17 오후 1:12:02

E-2

Safety Precautions

 Do not attempt to install or repair this DMS2 by yourself.



This DMS2 contains no user-serviceable parts.

Always consult authorized service personnel for repairs.

 When moving, consult authorized service personnel for

disconnection and installation of the DMS2.

 Ensure that the wall is strong enough to support the

weight of the DMS2.

 Must install the DMS2 with rated power supply.

 In the event of a malfunction (burning smell, etc.),

immediately stop operation, turn off the electrical

breaker, and consult authorized service personnel.

WARNING

CAUTION



Do not use inflammable gases near the DMS2.



Do not spill water into the DMS2.



Do not operate the DMS2 with wet hands.



Do not install the DMS2 in a location where it will come

into contact with the combustible gases, machine oil,

sulphide gas, etc.



Do not press buttons with a pointed thing.



Do not pull or bend the DMS2 cable excessively.



Do not use this DMS2 for other purpose.



Do not spray an insecticide or other combustible things

on the DMS2.



Do not clean the DMS2 with benzene, solvents or other

chemicals.



Do not give a shock to the DMS2 or disassemble it by

yourself.

• Before using the DMS2, read carefully these instructions.

• After reading the instructions, keep this user's manual in a handy and safe place.

If a user is changed, you must hand over the manuals.

• Never attempt to install the air conditioning system or to move the DMS2 by yourself.

MIM-D00A_DMS2_IB_E 33388-1.indd 2 2011-02-17 오후 1:11:25

E-3

Contents



General Description

....................................................... 4



ViewinG the parts

........................................................... 6



Before Use

...................................................................... 8



Main fUnction

............................................................. 10



startinG DMs2

........................................................... 14



control anD MonitorinG

............................................. 18



Zone ManaGeMent

....................................................... 59



scheDUle

..................................................................... 64



ehp power consUMption inspection

............................ 74



control loGic ManaGeMent

........................................ 85



systeM settinGs

........................................................... 98



check Before UsinG panel

.......................................... 147



settinG network inforMation

................................... 148



checkinG inDoor/oUtDoor Unit inforMation

............ 150



checkinG DMs2 Version

............................................ 151



Data BackUp settinG

................................................. 154



checkinG error inforMation

..................................... 156



reset passworD

......................................................... 157



BUtton lock

.............................................................. 158



safety halt

............................................................... 159



troUBleshootinG

....................................................... 160



specifications

............................................................ 162



license

....................................................................... 163

Note

 The contents and pictures used in this user manual

may be changed without advance notice for the

functional reinforcement and improvement of a

product.

MIM-D00A_DMS2_IB_E 33388-1.indd 3 2011-02-17 오후 1:11:25

E-4

General Description

The DMS2 is an Internet based device for central management of Samsung system

air-conditioners. It supports LAN & WAN and operates 24 hours without a separate PC.

Introduction of DMS2 (Data Management Server2)

The DMS2 provides the following advantages:

 Everyday Device–The DMS2 is operational all year long 24 hours.



Independent Operation–The DMS2 can operate schedule control and power distribution

without a PC.

Note In order to run power distribution, relevant controllers need to be installed.

 Internet Control

 Web – The DMS2 has a built-in web server function and can be accessed from a

remote location to operate status

monitoring, control, trouble history, and schedule setting of the system

air-conditioners.

 Using an Upper Level Controller–When a separate upper level controller (S-NET

series) is used, a number of DMS2 can be controlled with one central management

system.

 Data Storage–The DMS2 has its own database built-in, therefore, trouble history,

indoor unit installation information, and power distribution data can be saved and

retrieved.

 Large Scale Management–At most 256 indoor units can be connected to one DMS2

and therefore, only one DMS2 can manage small and medium size buildings.

 Automatic ”e-mail” sending–When an error is occurred, inform the error details to an

e-mail saved on DMS2.

Advantages of DMS2 System

MIM-D00A_DMS2_IB_E 33388-1.indd 4 2011-02-17 오후 1:11:25

E-5

General Description

 DMS2: The abbreviation of Data Management Server2.

 Upper Controller: It means S-NET Series, a local controller of the DVM system.

S-NET 3, S-NET mini and RMS are linked to a DMS2.

 Centralized Controller: A device that controls 16 groups of the DVM air conditioner.

A central control device of a DVM system which is located

between a DMS2 and an outdoor unit interface module.

 Interface module: A data interface module of a DVM system which is located between

a central controller and an outdoor unit.

 AHU(Air Handling Unit): Excutes heat exchange between air and cooling unit using

central air conditioning duct method.

 ERV(Energy Recovery Ventilator): Ventilating system using heat recovery function.

Terms

MIM-D00A_DMS2_IB_E 33388-1.indd 5 2011-02-17 오후 1:11:25

E-6

Viewing the Parts

Front View

No. Name Description



LCD Display Display current time/ Check menu



Menu button Access to main menu

▼/▲ button Select the function you want and set detailed functions in

main menu

Set button Check the function you want from main menu

and select it



Bottom cover Unfasten 2 screws on the bottom and separate the bottom

cover from DMS2. Then check cable connection part.







Name Description

Power Turns blue when the power is supplied.

CPU Alive Blinks in orange with 1 second intervals during normal

operation.

Ethernet–Linked Turns green during normal connection.

Ethernet–Active Blinks in orange during normal transmission/reception.

COM1~5 – TX Blinks in green during normal transmission.

COM1~5 – RX Blinks in green during normal reception.

Check Turns green when notice occurs.

Indicator

MIM-D00A_DMS2_IB_E 33388-1.indd 6 2011-02-17 오후 1:11:26

E-7

Viewing the Parts

DI Terminal1

Connect Digital Input

- Channel 1~Channel 5

DI Terminal2

Connect Digital Input

- Channel 6~Channel10

DO Terminal 2

Connect Digital Output

- Channel 6~Channel 10

DO Terminal1

Connect Digital Output

- Channel 1~Channel 5

Power

Terminal

Connect

DMS2 adapter

Reset Button

Reset DMS2

RS485

Communication

terminal

Connect for RS485

communication

with devices such as

centralized controller/

interface module

- COM1 ~ COM5

Cable tie groove

Arrange cables connected to

DMS2

LAN Terminal

Connect LAN cable

Serial Terminal

Service agent checks error

status

SD Card Socket

Socket for sub memory (SD or MMC)

( Sub memory is for DMS2 program update and set

information saving)

※ Purchase SD card separately.

 Separate bottom cover by unfastening 2 screws on the bottom.

Bottom View

MIM-D00A_DMS2_IB_E 33388-1.indd 7 2011-02-17 오후 1:11:26

E-8

 Connecting centralized controller and DMS2 (ⓐ type )

You can control up to 16 centralized controllers and 256 indoor units using DMS2.

 Connecting interface module and DMS2 (ⓑ type)

- You can control up to 80 interface modules and 256 indoor units using DMS2.

※ 16 interface modules can be connected to RS485 communication channel of DMS2.

- The more interface modules are connected, the longer time takes for tracking.

S-NET mini

Centralized

controller

DMS2

Internet

S-NET 3

Interface module

ⓐ ⓑ

Interface module Interface module

Before Use

System Configuration

MIM-D00A_DMS2_IB_E 33388-1.indd 8 2011-02-17 오후 1:11:27

E-9

Before Use

 Install Windows XP SP2, Windows 2000 SP4 or later version

 Install Internet Explorer 7.0 or later version

※ You can use Internet Explorer 6.0 but it is not recommended.

 Install Silverlight 2.0 or later version

Web Browser Specification

Note

 Visit internet homepage (http://www.microsoft.

com/silverlight/) to download Silverlight. Or you can

download it through the download link which is noticed

automatically when the PC is connected to the Internet

and you access to DMS2 for the first time.

 Silverlight operates normally with Windows XP SP2 or

later version.

It may not operate normally with former version of

Windows.

All settings of DMS2 will be arranged in web page which built in

DMS2.

You should access to DMS2 IP to use DMS2 web page.

There are 2 ways to access DMS2 IP.

(For about settings, refer to installation manual.)

 Static IP setting

 Dynamic IP(DHCP) setting

Computer Settings for DMS2 Connection



When connecting centralized controller and interface module to the DMS2 of same

communication channel, only one of them will communicate according to the

communication channel mode setting of [System Settings][Tracking].

Therefore, do not connect the centralized controller and interface module to the same

communication channel.



If you set the communication channel mode as interface module, virtual centralized

controller address will be assigned. Therefore if you connect centralized controller

at the same time and set the address as virtual centralized controller address, it may

cause trouble for bringing device information.

Channel 0: Virtual centralized controller 11,

Channel 1: Virtual centralized controller 12,

Channel 2: Virtual centralized controller 13,

Channel 4: Virtual centralized controller 14,

Channel 5: Virtual centralized controller 15

MIM-D00A_DMS2_IB_E 33388-1.indd 9 2011-02-17 오후 1:11:27

E-10

Device Type

Indoor Unit

Indoor unit communication error

Indoor unit sensor related error

Other errors

Outdoor Unit

Outdoor unit communication error

Pipe inspection error

Outdoor unit sensor related error

Outdoor unit related other errors

Communication error

such as centralized controller

Option device related communication

error

Main Function

The DMS2 saves at most 1024 cases of trouble history.

If the number of errors exceeds 1024, only the latest 1024 cases

are stored by deleting the oldest trouble history.

 Device name, address, error occurrence time, error solvation

time, trouble history will be saved. You can check it in web

page or upper controller.

 When an error occurs, it sends trouble history to e-mail saved

in DMS2.

Save Trouble History

The DMS2 receives/manages setting and control data from the

upper level controller and sends the received data to the lower

level system.



The upper level controllers of the DMS2 are the S-NET series

and the connectible S-NET series are S-NET 3, S-NET mini and

RMS.



S-NET 3: System air conditioner controlling and monitoring

program that is used by installing on a PC.



S-NET mini: System air conditioner controlling and monitoring

device with touchscreen



RMS: A device which supervises operation status and break

down status by connecting to DMS2 for system air

conditioner remote service. If break down is detected,

it notifies service agent and makes fast service possible.

Interface with Upper Level Controller

MIM-D00A_DMS2_IB_E 33388-1.indd 10 2011-02-17 오후 1:11:27

Otros manuales para MIM-B17

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Puerta de Samsung

Samsung

Samsung SMG-400 Manual de usuario

Samsung

Samsung MIM-D00A Manual de usuario

Samsung

Samsung WMG160 Manual de usuario

Samsung

Samsung MIM-B17 Manual de usuario

Samsung

Samsung GX-MC990CL Manual de usuario

Samsung

Samsung IPX-G5X0 series Manual de usuario

Samsung

Samsung MIM-B18N Manual de usuario

Samsung

Samsung HHG-3004H2 Manual de usuario

Samsung

Samsung DRGW Manual de usuario

Samsung

Samsung OFFICESERV 7100 Manual de usuario

Samsung

Samsung DCS Manual de usuario

Samsung

Samsung Ubigate iBG3026 Manual de usuario

Samsung

Samsung WMG100 Manual de usuario

Samsung

Samsung GT-B1110 Manual de usuario

Samsung

Samsung SMG-3000 Manual de usuario

Samsung

Samsung OFFICESERV 7100 Manual de usuario

Samsung

Samsung LCD 24B Manual de usuario

Samsung

Samsung SSA-S3010 Manual de usuario

Samsung

Samsung SMG-3200 Manual de usuario

Samsung

Samsung OFFICESERV 7100 Instrucciones de funcionamiento e instalación

Samsung

Samsung BACnet Gateway MIM-B17N Manual de usuario

Samsung

Samsung WEC8500 Manual de usuario

Samsung

Samsung GX-MC990CL Manual de usuario

Samsung

Samsung MIM-B18 Manual de usuario

Manuales populares de Puerta de otras marcas

LST

LST M500RFE-AS Manual de usuario

Kinnex

Kinnex Media Gateway Manual de usuario

2N Telekomunikace

2N Telekomunikace 2N StarGate Manual de usuario

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Manual de usuario

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Manual de usuario

Telsey

Telsey CPVA 500 - SIP Manual de usuario

RTA

RTA 460A-NNA4 Hoja de especificaciones

Shaw

Shaw Gateway HDPVR Manual de usuario

ABB

ABB VSN900 Guía de inicio rápido

Commander

Commander Pulse Manual de usuario

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Manual de usuario

NETGEAR

NETGEAR C6300BD Manual de usuario

Amit

Amit CDW531AM Manual de usuario

HMS

HMS Netbiter EasyConnect EC150 Manual de usuario

Huawei

Huawei EchoLife HG620 Manual de usuario

AT&T

AT&T U-verse 3801 Manual de uso y cuidado

Logic IO

Logic IO RTCU MX2 turbo Manual de usuario

Suttle

Suttle MediaMAX MXM-521 Manual de usuario
