Samsung SHR-4160N/P Manual de usuario

16 Channel DVR

SHR-4160N/P User’s Manual

Please be sure to keep the following in mind for the right use of the product to

pre-vent proprietary risk or damage.

■Do not use multiple plugs at once.

●This may cause abnormal heat generation or fire

■Do not put a vase, flowerpot, cup, cosmetics, medicine, or vessel

with water around you.

●This may cause fire.

■Do not bend the power cord forcibly nor put a heavy material on it.

●This may cause fire.

■Do not touch the power plug with wet hands.

●This may cause electric shock.

■Insert the power plug firmly enough not to shake.

●This imperfect connection may cause fire.

■Keep the product off humidity, dust, or soot.

●This may cause fire or electric shock.

■Do not put metals(coin, hair pin, metal piece, etc.) or inflammable

materials(match, paper, etc.) in the ventilation hole.

●This may cause fire.

■Keep the surrounding temperature between 0˚C to 40˚C and keep the

product off humidity.

●This may cause breakdown.

■Secure sufficient ventilation.

●This may cause abnormal operation due to high temperature.

■Keep the product off direct ray of light or heat from the heating

device

●This may cause fire.

■Do not disassemble, repair, or remodel the product.

●This may cause fire, electric shock, or injury due to abnormal operation.

■Do not pull out the power cord.

●This may destroy the power cord, eventually, cause fire or

electric shock.

■Plug out in the event of thunder or lightning.

●This may cause fire.

■Keep your children off the battery after you take it out of the product.

They tend to swallow it unconsciously.

●If your children swallow it, please see the doctor immediately.

■Install the product at a safe place or attach the product to the wall or

ceiling with a stand firmly enough not to fall to the ground.

●This may injure people.

Safety Regulations

SHR-4160N/P USER’S MANUAL

iii

WARNING

[Battery]

As wrong exchange of the battery in SHR-4160N/P may cause explosion, you shall

use the certified battery for SHR-4160N/P.

The battery specification is as follows.

-Normal Voltage: 3V

-Normal Capacity: 220mAh

-Continuous Standard Load: 0.2mA

-Operating Temperature: -30 ~ +60˚C

[System Shutdown]

- Power-off without terminating the system in the System Shutdown menu may incur

improper motion like data loss and disk failure. Power-off shall be done in the

System Shutdown menu.

This User’s Manual describes the basic usage of SHR-4160N/P. This Manual con-

tains all the matters necessary for using SHR-4160N/P such as brief instruction, part

name, function, connecting other equipment, and menu setup of SHR-4160N/P.

- SEC retains the copyright on this User’s Manual.

- This User’s Manual cannot be copied without SEC’s prior written approval.

- We are not liable for any or all losses to the product incurred by your use of non-

standard product or violation of User’s Manual.

- If you want to open the system case to touch the inside, please consult with an

expert who works for the shop where you bought the product.

- You may download open source codes from the following website.

(See CCTV Part of http://www.sec.co.kr)

Before we start

Stan ar s Approvals

Note : This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

when the equipment is operated in a commercial environment. This equip-

ment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance whit the instruction manual, may cause

harmful interference to radio communications. Operation of this equipment

in a residential area is likely to cause harmful interference in which case the

user will be required to correct the interference at his own expense.

Safety Regulations

Before we start

Standards Approvals

Chapter 1 Overview

1. Introduction

2. Features

3. Part Names and Functions

Chapter 2 Installation

1. Installation Environment Setup

2. Checking Product & Accessories

3. Additional HDD Installation

Chapter 3 Connecting with Other

Equipment

1. Connecting Video, Audio, & Monitor

2. Connecting Network

3. Connecting IEEE1394 Device

4. Connecting USB Device

5. Connecting Alarm Input/Output

6. Connecting RS-485 Device

Chapter 4 Live

1. System Motion

2. Live Screen Mode

3. Live Channel Selection and Audio On/Off

Setup

4. Freeze and Zoom

5. Event Monitoring

6. Spot-out Monitoring

Contents

iii

1-1

1-2

1-3

2-1

2-2

2-3

3-1

3-2

3-3

3-5

3-6

3-8

4-1

4-2

4-5

4-6

4-7

4-8

Chapter 5 Menu Setup

Before Use

1. System

2. Camera

3. Monitoring

4. Record Mode

5. Event Record Mode

6. Record Schedule

7. Backup

8. Network

9. Network Setup

Chapter 6 PTZ Device Control

1. PTZ device Control Mode

2. Basic Operation of PAN, TILT, & ZOOM

3. PRESET Setup

4. Camera Menu Setup

5. Preset View

6. Other Views

Chapter 7 Recording

1. PANIC (Emergency Recording)

2. REC (Normal Recording)

3. Record Schedule

4. Event Recording

Chapter 8 Search & Play

Before Use

1. Calendar Search

2. Event Search

3. Date/Time Search

4. Go to First Search

5. Go to Last Search

6. Play

5-1

5-2

5-12

5-16

5-18

5-19

5-24

5-26

5-28

5-32

6-1

6-3

6-4

6-6

6-7

6-8

7-1

7-2

7-3

7-4

8-1

8-2

8-3

8-4

8-5

8-6

8-7

Chapter 9 Back up and Back up Search

1. Backup

2. Backup Search

Chapter 10 Smart Viewer

1. Introduction

2. Feature

3. PC Specification(Recommendation)

4. Smart Viewer Installation

5. Smart Viewer Program Execution

6. Smart Viewer Initial Screen

7. Monitoring Mode

8. Search Mode

9. SETUP MODE

Backup Viewer

1. Introduction

2. Features

3. PC Specification(Recommendation)

4. Backup Viewer Installation

5. Executing Backup Viewer Program

6. Initial Screen of Backup Viewer

7. Using Backup Viewer

Appendix

1. Product Specification

2. HDD Specifications

3. Outline Drawing

4. Factory Default

SHR-4160N/P Smart Viewer Play Frame Specification

6. Troubleshooting(FAQ)

9-1

9-4

10-1

10-2

10-3

10-4

10-7

10-8

10-9

10-23

10-30

11-1

11-2

11-3

11-4

11-8

11-9

11-10

12-1

12-4

12-5

12-6

12-8

12-10

Chapter 1 Overview

Introduction

1-1

The Digital Video Recorder(DVR) compresses the camera input data from 16

channels into a MPEG4 video file and the voice input data into a G.726 audio file

respectively to record them in the Hard Disk or retrieve them from the Hard Disk

simultaneously.

In addition, it transmits the video or audio file out through a network on real time basis

so that you can monitor either file remotely by your PC.

SHR-4160N/P USER’S MANUAL

Features

1-2

■16 CH Composite Input Connectors

■NTSC/PAL Video Source Compatible

■Able to record the CIF size (NTSC : 352 x 240 / PAL : 352 x 288) video image at

the speed of 360ips(NTSC) / 300ips(PAL)

■16 CH Loop Through Video Connectors

■Hard Disk Overwrite Mode

■Large quantity HDD backup function by using IEEE1394 and USB2.0, USB2.0

Memory, Backup function by using an external CD/DVD writer.

■Able to record, play, and transmit both audio and video files to Windows Network

Viewer(Smart Viewer) simultaneously

■Able to reacord and replay 8 channels of Audio

■Variable Search Mode (Time/Date, Event, Camera)

■Variable Recording Mode (Time Lapse, Event, Schedule, Emergency)

■Extended Hard Disk Connection (IEEE1394, USB2.0)

■Alarm Interface (Input:16, Output:4, Reset:1)

■Remote Monitoring by Windows Network Viewer(Smart Viewer)
