Samsung SHR-4080P Manual de usuario

Real Time DVR

SHR-4080P User’s Manual

SHR-4080P USER’S MANUAL

Please be sure to keep the following in mind for the right use of the product to pre-

vent proprietary risk or damage.

■Do not use multiple plugs at once.

●This may cause abnormal heat generation or fire

■Do not put a vase, flowerpot, cup, cosmetics, medicine, or vessel

with water around you.

●This may cause fire.

■Do not bend the power cord forcibly nor put a heavy material on it.

●This may cause fire.

■Do not touch the power plug with wet hands.

●This may cause electric shock.

■Insert the power plug firmly enough not to shake.

●This imperfect connection may cause fire.

■Keep the product off humidity, dust, or soot.

●This may cause fire or electric shock.

■Do not put metals(coin, hair pin, metal piece, etc.) or inflammable

materials(match, paper, etc.) in the ventilation hole.

●This may cause fire.

■Keep the surrounding temperature between 0˚C to 40˚C and keep the

product off humidity.

●This may cause breakdown.

■Secure sufficient ventilation.

●This may cause abnormal operation due to high temperature.

■Keep the product off direct ray of light or heat from the heating

device

●This may cause fire.

■Do not disassemble, repair, or remodel the product.

●This may cause fire, electric shock, or injury due to abnormal operation.

■Do not pull out the power cord.

●This may destroy the power cord, eventually, cause fire or

electric shock.

■Plug out in the event of thunder or lightning.

●This may cause fire.

■Keep your children off the battery after you take it out of the product.

They tend to swallow it unconsciously.

●If your children swallow it, please see the doctor immediately.

■Install the product at a safe place or attach the product to the wall or

ceiling with a stand firmly enough not to fall to the ground.

●This may injure people.

Safety Regulations

iii

WARNING

[Battery]

As wrong exchange of the battery in SHR-4080P may cause explosion, you shall use

the certified battery for SHR-4080P.

The battery specification is as follows.

-Normal Voltage: 3V

-Normal Capacity: 220mAh

-Continuous Standard Load: 0.2mA

-Operating Temperature: -30 ~ +60˚C

[System Shutdown]

- Power-off without terminating the system in the System Shutdown menu may incur

improper motion like data loss and disk failure. Power-off shall be done in the

System Shutdown menu.

This User’s Manual describes the basic usage of SHR-4080P. This Manual contains

all the matters necessary for using SHR-4080P such as brief instruction, part name,

function, connecting other equipment, and menu setup of SHR-4080P.

- SEC retains the copyright on this User’s Manual.

- This User’s Manual cannot be copied without SEC’s prior written approval.

- We are not liable for any or all losses to the product incurred by your use of non-

standard product or violation of User’s Manual.

- If you want to open the system case to touch the inside, please consult with an

expert who works for the shop where you bought the product.

- You may download open source codes from the following website.

(See CCTV Part of http://www.samsung.com.)

Before we start

Code Certification

Safety Regulations

Before we start

Code Certification

Chapter 1 Overview

1. Introduction

2. Features

3. Part Names and Functions

Chapter 2 Installation

1. Installation Environment Setup

2. Checking Product and Accessories

3. Additional HDD Installation

Chapter 3 Connecting with Other

Equipment

1. Connecting Video, Audio, & Monitor

2. Connecting SCSI Device

3. Connecting Network

4. Connecting IEEE1394 Device

5. Connecting Alarm Input/Output

6. Connecting RS-485 Device

Chapter 4 Live

1. System Motion

2. Live Screen Mode

3. Live Channel Selection and Audio On/Off

Setup

4. Freeze and Zoom

5. Event Monitoring

6. Spot-out Monitoring

Contents

iii

1-1

1-2

1-3

2-1

2-2

2-3

3-1

3-2

3-3

3-4

3-6

3-8

4-1

4-2

4-5

4-6

4-7

4-8

Chapter 5 Menu Setup

Before Use

1. System

2. Camera

3. Monitoring

4. Record Mode

5. Event Record

6. Record Schedule

7. Backup

8. Network

Chapter 6 PTZ Device Control

1. PTZ Control MODE

2. Basic Operation of PAN, TILT, & ZOOM

3. PRESET Setup

4. CAMERA MENU Setup

5. PRESET VIEW

6. Other VIEWs

Chapter 7 Recording

1. PANIC (Emergency Recording)

2. REC (Normal Recording)

3. Timer Recording

4. Event Recording

Chapter 8 Search & Play

Before Use

1. Calendar Search

2. Event Search

3. Date/Time Search

4. Go to First Search

5. Go to Last Search

6. Backup Data Search

7. Play

5-1

5-2

5-12

5-16

5-18

5-19

5-24

5-26

5-27

6-1

6-3

6-4

6-6

6-7

6-8

7-1

7-2

7-3

7-4

8-1

8-2

8-3

8-4

8-5

8-6

8-7

8-8

Chapter 9 Back up

1. Backup Start

2. Backup Stop

3. Backup Play

Chapter 10 PC Viewer

1. Introduction

2. Feature

3. Recommended PC Specification

4. Installation

5. Program Execution

6. Initial Screen

7. Monitoring Mode

8. Search Mode

9. Setup Mode

Appendix

1. Product Specification

2. HDD Specifications

3. Outline Drawing

4. Factory Default

5. SHR-4080P Smart Viewer Play Frame

Specification

6. Troubleshooting (FAQ)

9-1

9-2

9-3

10-1

10-2

10-3

10-4

10-11

10-12

10-13

10-25

10-32

11-1

11-4

11-5

11-6

11-8

11-9

Chapter 1 Overview

Introduction

1-1

The realTime Digital Video Recorder(DVR) compresses the camera input data from 8

channels into a MPEG4 video file and the voice input data into a G.726 audio file

respectively to record them in the Hard Disk or retrieve them from the Hard Disk

simultaneously.

In addition, it transmits the video or audio file out through a network on real time basis

so that you can monitor either file remotely by your PC.

SHR-4080P USER’S MANUAL

Features

1-2

■8 CH Composite Input Connectors

■PAL Video Source Compatible

■Able to record the normal sized (720 x 288) video image at the speed of

200IPS(image per second)

■8 CH Loop Through Video Connectors

■Hard Disk Overwrite Mode

■Large Quantity Hard Disk Backup by IEEE1394

■Able to record, play, and transmit both audio and video files to Windows Network

Viewer(Smart Viewer) simultaneously

■Recording and Play of Audio 8CH

■Variable Search Mode (Time/Date, Event, Camera)

■Variable Recording Mode (Time Lapse, Event, Schedule, Emergency)

■Extended Hard Disk Connection (SCSI, IEEE1394)

■Alarm Interface (Input:8, Output:4, Reset:1)

■Remote Monitoring by Windows Network Viewer(Smart Viewer)

SHR-4080P USER’S MANUAL

Part Names and Functions

1-3

No Name Function

Channel Button

Play Back

Channel Button

Power LED

Network LED

Back Up LED

HDD Access

LED

Split Screen

Selection

Button

Mode Selection

Button

REC Button

Display

Mode

Audio Setup

Button

Displays power on/off condition.

Displays both network connection and data transmis-

sion conditions.

Displays Back Up Mode.

Indicates Normal Access to HDD.

Upon Access to HDD, LED repeats on and off.

Selects Single Channel in the Display Mode.

Used for Number Input Button in the Number Input Mode.

Recording starts as set in the Normal Record Mode

while LED is on.

...

1 8

MODE

REC

Displays the Play Back screen.

Sets up Audio On/Off.

9 Displays Split Screen.

8 Displays Split Screen.

4 Displays Split Screen.

6 Displays Split Screen.

7 Displays Split Screen.

Displays PIP(Picture In Picture)

Screen.

Auto Sequence Mode

Enters Single Channel Screen

by the time set in MENU.

4 Displays Split Screen.

Displays the selected channel

in Full Screen.

Displays both LIVE Channel and

Play Channel in PIP Screen

simultaneously.

9 Displays Split Screen.
