Samsung VLUU PL100 Manual de usuario

User Manual

Basic Operation

PL100/PL101

This User Manual has been specially designed to guide you

through the basic functions and features of your device.

Please read this User Manual and the User Manual on the

CD-ROM carefully to ensure safe and correct use.

For more information, refer to

the User Manual included on the

supplied CD-ROM.

ENG / TUR

PL100_QSM_TUR.indb 3 2010-01-27 오후 3:19:11

Contents

Get answers to common questions …3

Health and safety information ……… 4

Camera layout ………………………… 6

Setting up your camera ……………… 8

Unpacking …………………………………8

Inserting the battery and memory card …9

Removing the battery and memory card… 9

Charging the battery …………………… 10

Turning on your camera………………… 10

Performing the initial setup …………… 11

Selecting options …………………… 12

Capturing photos or videos ……… 13

Transferring ﬁles to a PC (Windows) 17

Speciﬁcations ……………………… 18

Microsoft Windows and the Windows logo are registered•

trademarks of the Microsoft Corporation.

Mac is a registered trademark of the Apple Corporation.•

Camera speciﬁcations or contents of this manual may•

be changed without prior notice due to upgrade of

camera functions.

For Open Source License information, refer to the•

“OpenSourceInfo.pdf” in the provided CD-ROM.

PL100_QSM_TUR.indb 2 2010-01-27 오후 3:19:11

English

Get answers to common questions

You can easily solve most problems by setting shooting options.

There are more details about how to set shooting options in the CD version of the user manual.

The subject's

eyes appear red.

This is caused by a reﬂection from the camera ﬂash.

Set the ﬂash option to• Red-eye or Red-eye Fix.

If the photo has already been taken, select• Red-eye Fix in the edit menu.

Photos have

dust spots.

Dust particles ﬂoating in the air may be captured in photos when using the ﬂash.

Turn off the ﬂash or avoid taking photos in a dusty place.•

Set ISO speed options.•

Photos are

blurred.

This may be caused by taking photos in low light conditions or holding the camera

incorrectly.

Press [• Shutter] halfway down to make sure the subject is focused.

Use the• dmode.

Photos are

blurred when

shooting at night.

As the camera tries to let in more light, the shutter speed slows.

This can make it difﬁcult to steady the camera and may result in camera shake.

Rotate the mode dial to• N.

Turn on the ﬂash.•

Set ISO speed options.•

Use a tripod to prevent your camera from shaking.•

PL100_QSM_TUR.indb 3 2010-01-27 오후 3:19:14

Health and safety information

Comply with the following precautions to avoid dangerous

or illegal situations while operating the camera and keep

this manual handy for future reference.

Warnings

Do not use your camera near ﬂammable or explosive

gases and liquids

Do not use your camera near fuels, combustibles, or

ﬂammable chemicals. Do not store or carry ﬂammable

liquids, gases, or explosive materials in the same

compartment as the camera or its accessories.

Keep your camera away from small children and pets

Keep your camera and all accessories out of the reach

of small children and animals. Small parts may cause

choking or serious injury if swallowed. Moving parts and

accessories may present physical dangers as well.

Prevent damage to subjects’ eyesight

Do not use the ﬂash in close proximity (closer than 1m/3

ft) to people or animals. Using the ﬂash too close to

your subject’s eyes can cause temporary or permanent

damage.

Handle and dispose of batteries and chargers

with care

Use only Samsung-approved batteries and chargers.•

Incompatible batteries and chargers can cause serious

injuries or damage to your camera.

Never dispose of batteries in a ﬁre. Follow all local•

regulations when disposing of used batteries.

Never place batteries or cameras on or in heating•

devices, such as microwave ovens, stoves, or

radiators. Batteries may explode when overheated.

PL100_QSM_TUR.indb 4 2010-01-27 오후 3:19:14

English

Protect batteries, chargers, and memory cards from

damage

Avoid exposing batteries or memory cards to very cold•

or very hot temperatures (below 0° C/32° F or above

40° C/104° F). Extreme temperatures can reduce the

charging capacity of your batteries and can cause

memory cards to malfunction.

Prevent batteries from making contact with metal•

objects, as this can create a connection between the +

and – terminals of your battery and lead to temporary

or permanent battery damage.

Prevent memory cards from making contact with•

liquids, dirt, or foreign substances. If dirty, wipe the

memory card clean with a soft cloth before inserting in

your camera.

Use only Samsung-approved accessories

Using incompatible accessories may damage your

camera, cause injury, or void your warranty.

Protect your camera’s lens

Protect your lens from ﬁngerprints and scratches. Clean

your lens with a soft, clean, debris-free lens cloth.

Cautions

Handle and store your camera carefully and sensibly

Do not allow your camera to get wet—liquids can•

cause serious damage. Do not handle your camera

with wet hands. Water damage to your camera can

void your manufacturer’s warranty.

Avoid using or storing your camera in dusty, dirty,•

humid, or poorly-ventilated areas to prevent damage

to moving parts and internal components.

Protect your camera from impact, rough handling, and•

excessive vibration to avoid serious damage.

Exercise caution when connecting cables or adapters•

and installing batteries and memory cards. Forcing

the connectors, improperly connecting cables, or

improperly installing batteries and memory cards can

damage ports, connectors, and accessories.

Do not insert foreign objects into any of your camera’s•

compartments, slots, or access points. This type of

damage may not be covered by your warranty.

PL100_QSM_TUR.indb 5 2010-01-27 오후 3:19:14

Camera layout

Battery chamber cover

Tripod mount

USB and A/V port

AF-assist light/timer lamp

Flash

Lens

Microphone

Front display

Front LCD button

Shutter button

POWER button

PL100_QSM_TUR.indb 6 2010-01-27 오후 3:19:14

English

Mode dial

Navigation button/OK button

Function button

Playback button

MENU button

Status lamp

Main display

Zoom button

Speaker

PL100_QSM_TUR.indb 7 2010-01-27 오후 3:19:14

Setting up your camera

Unpacking

Camera AC adapter/USB cable Rechargeable battery Strap

Software CD-ROM

(User manual included)

User Manual

Basic Operation

Optional accessories

Camera case Memory card A/V cable Battery charger

PL100_QSM_TUR.indb 8 2010-01-27 오후 3:19:16

English

Inserting the battery and memory card Removing the battery and memory card

Note

The internal memory can be used as a temporary storage

device when the memory card is not inserted.

Insert a memory card

with the gold-coloured

contacts facing up.

Insert the battery with the

Samsung logo facing up.

Push gently until the card

disengages from the

camera and then pull it

out of the slot.

Push the lock up to

release the battery.

Battery

Battery lock

Memory card

PL100_QSM_TUR.indb 9 2010-01-27 오후 3:19:17

Press [POWER].

Setting up your camera

Turning on your cameraCharging the battery

Press [P] to turn on the camera

in Playback mode.

Indicator light

Red▪: Charging

Green▪: Fully charged

Before using the camera for the ﬁrst time, you must

charge the battery.

PL100_QSM_TUR.indb 10 2010-01-27 오후 3:19:17
