User Manual

SL50

Thank you for buying a Samsung Camera.

This manual will help you learn to capture

images, share or print your photos, and edit

photos with the accompanying software.

Please read this manual thoroughly.

001

Thank you for buying a Samsung Digital Camera.

åPrior to using this camera, please read the user manual

thoroughly.

åIf you require After Sales service, please bring the camera and the

cause of the camera malfunction (such as battery, memory card

etc.) to an Authorised Service center.

åPlease check that the camera is operating properly prior to when

you intend to use it (e.g. for a trip or an important event) to avoid

disappointment. Samsung takes no responsibility for any loss or

damage that may result from camera malfunction.

åKeep this manual in a safe place.

If you use a card reader to copy the images on the memory card to

your PC, the images could be damaged. When transferring the

images taken with the camera to your PC, be sure to use the

supplied USB cable to connect the camera to your PC. Please note

that the manufacturer holds no responsibility for loss or damage of

images on the memory card due to the use of a card reader.

åThe contents and illustrations of this manual are subject to change

without prior notice for upgrading the camera functions.

ÄMicrosoft, Windows and Windows logo are registered trademarks

of Microsoft Corporation incorporated in the United States and/or

other countries.

ÄAdobe and Reader are either trademarks or registered

trademarks in the United States and/or other countries.

ÄAll brand and product names appearing in this manual are

registered trademarks of their respective companies.

ÄFor Open Source License information, refer to the

"OpenSourceInfo.pdf" in the provided CD-ROM.

Getting to know your cameraInstructions

Setting up the applica-

tion software

Use this camera in the following order.

To use this camera with a PC,

install the application software

rst. After this has been done, the

stored images in the camera can be

moved to the PC and can be edited

by an image editing program. (p.89)

Take a picture. (p.21)

Insert the supplied USB cable

into the PC’s USB port and the

camera’s USB connection

terminal. (p.89)

Check the camera’s power. If the

power is turned off, preset the

camera button to turn it on.

Open Windows Explorer and

search for [Removable Disk].

(p.90)

Take a picture

Insert the USB cable

Check the camera's

power

Check [Removable Disk]

002

Warning

WARNING indicates a potentially hazardous situation which, if not

avoided, could result in death or serious injury.

å Do not use the ash in close proximity to people or animals.

Positioning the ash too close to your subject’s eyes may cause

eyesight damage.

åFor safety reasons keep this product and accessories out of reach

of children or animals to prevent accidents e.g.:

- Swallowing battery or small camera accessories. If an accident

should occur, please consult a doctor immediately.

- There is the possibility of injury from the camera’s moving parts.

åBattery and camera may become hot during prolonged use and it

may result in camera malfunction. Should this be the case, allow

the camera to sit idle for a few minutes to allow it time to cool.

åDo not leave this camera in places subject to extremely high tem-

peratures, such as a sealed vehicle, direct sunlight or other places

of extremes in temperature. Exposure to extreme

temperatures may adversely affect the camera’s internal

components and could cause a re.

When in use, do not cover the camera or charger. This may cause

heat to build up and distort the camera body or cause a re. Always

use the camera and its accessories in a well ventilated area.

Danger

DANGER indicates an imminently hazardous situation which, if not

avoided, will result in death or serious injury.

åDo not attempt to modify this camera in any way. To do so may

result in re, injury, electric shock or severe damage to you or your

camera. Internal inspection, maintenance and repairs should only

be carried out by your dealer or Samsung Camera Service center.

å Please do not use this product in close proximity to ammable or

explosive gases, as this could increase the risk of explosion.

åShould any form of liquid or a foreign object enter the camera, do

not use it. Switch off the camera, and then disconnect the power

source. You must contact your dealer or Samsung Camera Service

center. Do not continue to use the camera as this may cause a re

or electric shock.

å Do not insert or drop metallic or inammable foreign objects into

the camera through access points e.g. the memory card slot and

battery chamber. This may cause a re or electric shock.

åDo not operate this camera with wet hands. This could pose a risk

of electric shock.

003

Caution

CAUTION indicates a potentially hazardous situation which, if not

avoided, may result in a minor or moderate injury.

å Leaking, overheating or damaged battery could result in re or injury.

- Use battery with the correct specication for the camera.

- Do not short circuit, heat or dispose of battery in re.

- Do not insert the battery with the polarities reversed.

åRemove the battery when not planning to use the camera for a

long period of time. Otherwise the battery may leak corrosive

electrolyte and permanently damage the camera’s components.

å Do not re the ash while it is in contact with hands or objects. Do

not touch the ash after using it continuously. It may cause burns.

åDo not move the camera while it is switched on if you are using

the AC adapter. After use, always switch off the camera before

unplugging the cable from the wall socket. Then make sure that

any connector cords or cables to other devices are disconnected

before moving the camera. Failure to do so may damage the cords

or cables and cause a re or electric shock.

åTake care not to touch the lens or lens cover to avoid taking an

unclear image and possibly causing camera malfunction.

å Avoid obstructing the lens or the ash when you capture an image.

åWhen using this camera in low temperatures, you may experience

the following. These are not camera malfunctions and usually

recover at normal temperature.

- It takes longer to turn on the LCD monitor and the color may differ

from the subject.

- When changing the composition, there may be an after image on

the LCD monitor.

åCredit cards may be demagnetized if left near the case. Avoid

leaving magnetic strip cards near the case.

åNever connect the 20 pin connector to the USB port of a PC. This

carries a high risk of computer malfunction.

Contents

READY

RECORDING

007 System chart

007 Package Contents

007 Sold Separately

008 Identification of features

008 Front & Top

009 Back

010 Bottom

010 5 Function button

011 Self-timer lamp

011 Camera Status Lamp

011 Mode icon

012 Connecting to a power source

015 Inserting the memory card

016 Instructions on how to use the memory

card

018 When using the camera for the first time

019 LCD monitor indicator

020 How to use the menu

021 Starting the recording mode

021 Selecting modes

021 How to use the Smart Auto mode

023 How to use the Program mode

023 How to use the DIS mode

024 Using the Photo Help Guide mode

025 How to use the Scene modes

004

SETUP

Contents

026 How to use the Movie mode

027 Recording the movie clip without sound

027 Pausing while recording a movie clip

(Successive Recording)

028 Things to watch out for when taking

pictures

029 Using the camera buttons to set the camera

029 POWER button

029 SHUTTER button

029 ZOOM button

031 Info(DISP) / Up button

031 Macro / Down button

033 Focus lock

033 Flash / Left button

035 Self-timer / Right button

037 MENU button

037 OK button

037 Shooting

038 How to enable functions using the MENU

button

038 Photo Size / Movie Size

039 Quality / Frame rate

039 Exposure compensation

040 ISO

040 White balance

041 Face Detection

043 Face Tone

043 Face Retouch

044 Auto Focus type

044 Metering

045 Photo Style Selector

046 Image Adjust

047 ACB

047 Drive mode

048 Voice Memo

048 Voice Recording

049 Recording the movie clip without voice

050 Sound

050 Volume

050 Start up sound

050 Shutter sound

050 Beep sound

051 AF sound

051 Display

051 Language

051 Function Description

052 Start up image

052 Display Brightness

052 Quick View

052 Display Save

053 Settings

053 Formatting the memory

053 Initialization

054 Setting up the Date / Time / Date type

054 Time Zone

005

PLAY

Contents

054 File name

055 Imprinting the recording date

055 Auto power off

056 Auto Focus lamp

056 Selecting Video out type

057 Setting the USB

058 Starting play mode

058 Playing back a still image

058 Playing back a movie clip

059 Movie clip capture function

059 Playing back a recorded voice

059 Playing back a voice memo

060 LCD monitor Indicator

061 Using the camera buttons to set the

camera

061 Thumbnail / Enlargement button

061 Smart Album

063 Info (DISP) / Up button

063 Play & Pause / OK button

064 Left / Right / Down / MENU button

064 Delete button

065 Setting up the play back function using

the LCD monitor

067 Edit

067 Resize

068 Rotating an image

068 Photo Style Selector

069 Image Adjust

071 Starting the Multi Slide Show

071 Start the Multi Slide Show

071 Selecting Images

072 Congure Multi Slide show effects

072 Setting play interval

072 Setting Background Music

073 File Options

073 Deleting images

073 Protecting images

074 Voice memo

075 DPOF

077 Copy to Card

078 PictBridge

079 PictBridge : Picture Selection

079 PictBridge : Print Setting

080 PictBridge : Reset

080 Important notes

082 Warning indicator

083 Before contacting a service center

085 Specifications

006

SOFTWARE

Contents

088 Transferring files to your computer

(for Windows)

088 For Windows users

092 Transferring files to your computer (for Mac)

092 For Mac users

094 FAQ

007

Package Contents

Camera Rechargeable battery

(AD43-00194A)

AC adapter (AD44-00143A) /

USB cable (AD39-00165A)

Camera strap

(Black : AD63-02604A/

Silver : AD63-02596A)

Software CD

(User manual included)

(AD46-00301A)

Quick Start Manual

(AD68-04630A)

Sold Separately

SD/SDHC memory card

(see p.17) Camera case AV cable

(AD39-00146A)

Battery charger

(AD44-00164A)

Please check that you have the correct contents before using this product. The contents can vary depending on the sales region. To buy the

equipment contact your nearest Samsung dealer or Samsung service center. Parts and accessories illustrated below may differ from

exact appearance.

System chart

008

Identication of features

Front & Top

Flash

Lens/ Lens cover

AF sensor /

Self-timer lamp

Shutter button

POWER button

Microphone

Speaker

009

Back

Identification of features

Camera status lamp

LCD monitor

Play mode button

Fn / Delete button

5 function button

MENU button

USB / AV / DC terminal

Zoom Tele(T) button / Digital zoom

Zoom Wide(W) button / Thumbnail

Strap eyelet

Otros manuales para SL50

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara digital de Samsung

Samsung

Samsung PL65 Manual de instrucciones

Samsung

Samsung S850 - Digital Camera - Compact Manual de usuario

Samsung

Samsung NX100 Manual de usuario

Samsung

Samsung DIGIMAX 4500 Manual de usuario

Samsung

Samsung EC-NV4ZZSBA/US - NV4 Digital Camera Guía de configuración

Samsung

Samsung TL34HD - Digital Camera - Compact Guía del usuario

Samsung

Samsung i85 Manual de instrucciones

Samsung

Samsung CL65 Manual de instrucciones

Samsung

Samsung ES25 Manual de usuario

Samsung

Samsung SBC-330A Manual de usuario

Samsung

Samsung TL500 Manual de usuario

Samsung

Samsung SDC-9442DC Manual de usuario

Samsung

Samsung DualView TL210 Instrucciones de montaje

Samsung

Samsung Pro 815 Manual de usuario

Samsung

Samsung SCP-2430 Manual de usuario

Samsung

Samsung TL34HD - Digital Camera - Compact Manual de instrucciones

Samsung

Samsung ST500 Manual de instrucciones

Samsung

Samsung ST550 Manual de instrucciones

Samsung

Samsung GX-20 - Digital Camera SLR Manual de usuario

Samsung

Samsung SL420 - Digital Camera - Compact Manual de usuario

Samsung

Samsung CL80 Manual de usuario

Samsung

Samsung S1000 - Digimax Digital Camera Manual de usuario

Samsung

Samsung ST65 Manual de usuario

Samsung

Samsung L210 - Digital Camera - Compact Manual de usuario

Manuales populares de Cámara digital de otras marcas

Mercury

Mercury 350K Manual de usuario

Pentax

Pentax Optio LS 465 Manual de usuario

Sanyo

Sanyo VPC-S1085 Manual de usuario

GE SMART A1255 Manual de usuario

Point Grey

Point Grey Gazelle Manual de usuario

Nikon

Nikon COOLPIX A Manual de usuario

Pentax

Pentax P-5 Manual de usuario

BlazeVideo

BlazeVideo A280 Manual de usuario

Sony

Sony MCA-20 Manual de usuario

Sony

Sony Alpha DSLR-A290 Manual de usuario

ATIK Cameras

ATIK Cameras One Manual de usuario

CohuHD Costar

CohuHD Costar 3930 Series Manual de usuario

Leica

Leica M10-R Manual de usuario

FujiFilm

FujiFilm FinePix A700 Manual de usuario

Lorex

Lorex LNZ81P25 Series Manual de usuario

GE J1470S Manual de usuario

Sony

Sony A6700 Guía del usuario

Canon

Canon EOS ELAN7 Manual de usuario
