A copy of the original signed declaration for this instrument is available

from the below UK address:

Electromagnetic Compatibility Statement for North America

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference when the equipment is

operated in a residential installation. This equipment generates, uses and can

radiate radio frequency energy and if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television

reception which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one of the following measures:

Re-orient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment to an outlet different from that to which the receiver is

connected.

Consult the dealer or an experienced radio / TVtechnician for help.

USER'S

MANUAL

Model MS-20

IN-0787 3014H

Declaration of Conformity

Manufacturer Salter Brecknell

Type MS-20

Corresponds to the requirements of the following EC directives

Electro Magnetic Compatibility Directive EMC 89/336/EEC

Low Voltage Directive LVD 73/23/EEC

The application harmonised standards are: EN60950,

EN50081-1

EN50082-1

Salter Brecknell Weighing

UK & Europe

PO box 9533, Smethwick,

West Midlands, B66 2TE

United Kingdom

Tel: +44 (0) 870 444 6132

Fax: +44 (0) 870 010 2241

Email: sales @salterbrecknell.co.uk

Salter Brecknell Weighing

Products USA

1000 Armstrong Drive,

Fairmont, MN56031

TollFree:800-637-0529

Phone: 507-238-8702

Fax:507-238-8271

Email:sales@salterbrecknell.com

www.salterbrecknell.com

SETTING UP YOUR MS-20 SCALE

To insure that your scale operates correctly, position the scale on a level sturdy

worktop.

The display head can be either attached to the wall or positioned in front of the

scale.

Pull down feet on back of display head enable the operator to change the

viewing angle of the display head.

Any excess cable can be stored in the cavity on the underside of the display

head.

POWER SUPPLY

The MS-20 uses 9V alkaline battery or

9V 100mA AC adapter.

CAUTION: alwaysconnect the AC

adapter to the MS-20 before

connecting to the mains power supply.

Disconnect from the mains power

supply before disconnecting the

adapter from the MS-20

KEY FUNCTION

ON/TARE (1) Press once to switch scale on.

OFF - (2) Press while scale is switched on to

re-zero the scale.

(3) Press and hold this key for 2 seconds

to switch scale off. Scale will auto shut-off

if not used after 120 seconds

UNIT - Selects between kg mode and lb mode.

HOLD - When pressed the displayed weight will be

held on the display once the weight becomes

stable.

By repressing the Hold key again will release

the held display and allow the scale to return

back to normal weighing mode.



ERROR MESSAGES

1. Low Battery

2. High zero counts

3. Low zero count

4. Overload

SPECIFICATIONS

Model # MS-20

MaximumCapacity44 lb / 20 kg

Readability½ oz/ 10 g

Weight unitslb / kg

Power supply 9V alkaline battery or 9V 100mA AC adapter

Dimensions 20” x 12” x 2 ½” / 505mm x 300mm x 65 mm

Display 1.0” LCD display with 4 active digits

Tray Plastic top cover

Operating Temperature 5°C ~ 35°C

Function keys ON/TARE/OFF, UNIT, HOLD

CALIBRATION PROCEDURE

1) With the scale switched off, press and hold the “ON/OFF/TARE key, without

releasing press the kg/lb key three times and then release.

2) Display will show zero (4000~12000).

3) Press the “UNITS” key, switch to LB mode or KG mode

4) Press “ON/OFF/TARE” key once.

5) Display will show “CAL” and then “0”.

6) Load 20kg weight onto the scale, or load 40 lb in case of switched to LB mode

at step 3.

7) Display will show span count (8000~16000)for KGmode or(7260~14520) for

LB mode.

8) Press “ON/OFF/TARE” key again.

9) Display will show “CAL” and then “20.00 kg” for KG mode or “40:00 lb” for LB mode.

10)Remove the weight from the scale and the calibration isfinished.
