the Oracle™Touch

Instruction Book – SES990

SAGE®

RECOMMENDS

SAFETY FIRST

At Sage‰we are very safety

conscious. We design and

manufacture consumer

products with the safety of you,

our valued customer, foremost

in mind. In addition we ask

that you exercise a degree of

care when using any electrical

appliance and adhere to the

following precautions.

IMPORTANT

SAFEGUARDS

READ ALL

INSTRUCTIONS BEFORE

USE AND SAVE FOR

FUTURE REFERENCE

•Before using for the ﬁrst

time please ensure that

your electricity supply

is the same as shown

on the rating label on

the underside of the

appliance. If you have any

concerns please contact

your local electricity

company.

•Your Sage‰appliance

includes a BS 13 amp

moulded mains plug on

the supply cord.

•Should you need to

change this plug, please

complete the rewiring as

follows (after safe disposal

of the moulded plug).

•Please note that a cut off

plug inserted into a socket

is a serious danger risk.

2 Important Safety Information

7 Components

10 Assembly

11 Functions

17 Tips

19 Care & Cleaning

23 Troubleshooting

Contents

•Wires are coloured

as follows:

– Blue = Neutral

– Brown = Live

•As the colours of the

wire may not correspond

with the coloured

markings which identify

the terminals in your

plug, please refer to the

following:

− The Blue wire must be

connected to the terminal

which is marked ‘N’

− The Brown wire must

be connected to the

terminal which is

marked with the letter ‘L’.

• Please note that if a 13 amp

plug is used, a 13 amp

fuse should be used.

•Remove any packaging

material and promotional

labels or stickers before

using the product for the

ﬁrst time.

•To eliminate a choking

hazard for young children,

remove and safely discard

the protective cover ﬁtted

to the power plug of this

appliance.

•Do not place the product

near the edge of a bench

or table during operation.

Ensure the surface is level,

clean and free of water

and other substances.

•Do not let the cord hang

over the edge of a bench

or table, or become

knotted. Keep away from

hot gas or electric burner,

or where it could touch

a heated oven.

•This appliance can be

used by children aged

from 8 years and above

if they have been given

supervision or instruction

concerning use of the

appliance in a safe

way and understand

the hazards involved.

Cleaning and user

maintenance shall not be

made by children unless

they are aged from 8 years

and above and supervised.

Keep the appliance and

its cord out of reach of

children aged less than

8 years.

•Appliances can be used

by persons with reduced

physical, sensory or

mental capabilities or

lack of experience and

knowledge if they have

been given supervision

or instruction concerning

use of the appliance in a

safe way and understand

the hazards involved.

•Children shall not play

with the appliance.

• Regularly inspect the

supply cord, plug and

actual appliance for any

damage. If found damaged

in any way, immediately

cease use of the appliance

and please contact Sage

Customer Service or go

to sageappliances.com.

•Keep the appliance

and accessories clean.

Follow the cleaning

instructions provided in

this book. Any procedure

not listed in this instruction

booklet should be referred

to Sage Customer

Service or go to

sageappliances.com.

•The installation of

a residual current

device (safety switch)

is recommended to

provide additional safety

protection when using

electrical appliances.

It is advisable that

a safety switch with

a rated residual operating

current not exceeding

30mA be installed in the

electrical circuit supplying

the appliance. See your

electrician for professional

advice.

SPECIFIC

INSTRUCTIONS

FOR SES990 THE

ORACLE™TOUCH

•This appliance is

recommended for

household use only. Do

not use this appliance for

any purpose other than

its intended use. Do not

use in moving vehicles

or boats. Do not use

outdoors.

•If the appliance is to be:

- left unattended

- cleaned

- moved

- assembled; or

- stored

•Always switch Off the

espresso machine by

pressing the Power button

to Off, switch Off at the

power outlet and unplug.

•Ensure the product is

properly assembled

before ﬁrst use.

•Do not use any other

liquid apart from cold

mains/town water.

We do not recommend

the use of highly ﬁltered,

de-mineralised or distilled

water as this may affect

the taste of the coffee and

how the espresso machine

is designed to function.

•Ensure the portaﬁlter

is ﬁrmly inserted and

secured into the group

head before starting an

extraction. Never remove

the portaﬁlter during the

extraction process.

•Do not touch hot surfaces.

Allow the product to cool

down before moving or

cleaning any parts.

•Use caution after milk

texturing as the ‘Auto

Purge’ function may

purge hot steam when the

steam wand is lowered.

•Use caution when

operating machine as

metal surfaces are liable

to get hot during use.

FOR HOUSEHOLD USE ONLY

SAVE THESE INSTRUCTIONS

•Use caution when using

the de-scale feature as hot

steam may be released.

Before de-scaling, ensure

drip tray is empty and

inserted. Refer to page 22

for further instructions.

• The symbol shown

indicates that this

appliance should not

be disposed of in

normal household waste.

It should be taken to

a local authority waste

collection centre

designated for this

purpose or to a dealer

providing this service.

For more information,

please contact your local

council ofﬁce.

SPECIFIC

INSTRUCTIONS

FOR WATER

FILTER

•Filter cartridge should

be kept out of reach

of children.

•Store ﬁlter cartridges in

a dry place in the original

packaging.

•Protect cartridges from

heat and direct sunlight.

•Do not use damaged ﬁlter

cartridges.

•Do not open ﬁlter

cartridges.

•If you are absent for a

prolonged period of time,

empty the water tank and

replace the cartridge

Components

A. Integrated conical burr grinder

With removable 280g bean hopper.

B. Top-ﬁll 2.5L removable water tank

With integrated water ﬁlter and backlit

level indicator.

C. Grind size dial

Adjust grind size to suit your coffee beans.

D. Touch screen control panel

Displays current settings and provides

touch interface.

E. Grind outlet

With auto grind, dose & tamp function.

F. Heated 58mm group head with

embedded element

G. 58mm full stainless steel portaﬁlter

H. Drop down swivel foot

Lifts the machine upwards for

easy manoeuvrability.

I. Heated cup warming tray

J. Cool touch steam wand

With integrated temperature sensor.

K. Dedicated hot water outlet

Delivers hot water for Long Black

and pre-heating cups.

L. Descale access point

M. Tool storage tray

Houses accessories when not in use.

N. Removable drip tray

With Empty Me! indicator.

A. Stainless steel milk jug

B. 2 cup ﬁlter basket

C. 1 cup ﬁlter basket

D. Water ﬁlter holder with ﬁlter

E. Cleaning disc

F. Mini grinds bin

G. Grinder burr brush

H. Grind outlet brush & tamp

removal magnet

I. Cleaning tool for steam wand tip

J. Two allen keys

K. Steam wand cleaning powder

L. Water hardness test strip

M. Espresso cleaning tablets

ACCESSORIES

COLOUR TOUCH SCREEN

CONTROL PANEL

Swipe & Select from the drinks menu.

Adjust your coffee strength, milk texture

or milk temperature, then save it as your

personal favourite.

HANDS FREE AUTOMATIC

GRIND, DOSE & TAMP

Automatically grinds, doses and tamps the

required amount of coffee, mess free.

GRIND SIZE DIAL

Adjustable grind settings from ﬁne to coarse

for optimal espresso extraction.

STAINLESS STEEL CONICAL BURRS

Maximise ground coffee surface area for a

full espresso ﬂavour.

AUTOMATIC HANDS FREE

MILK TEXTURING

Automatically textures milk to the selected

temperature and style from silky smooth

latté to creamy cappuccino. Automatic purge

removes residual milk from the steam wand

when returned to the downward position.

SIMULTANEOUS COFFEE & STEAM

Dedicated stainless steel espresso and steam

boilers for simultaneous milk texturing and

espresso extraction.

PRECISION CONTROL

Electronic PID Temperature Control

Electronic temperature control delivers

precise water temperature for optimum

espresso ﬂavour.

Actively Heated Group Head

Commercial size 58mm group head with

embedded element for thermal stability

during extraction.

Regulated Extraction Pressure

Over pressure valve (OPV) limits maximum

pressure for optimal espresso ﬂavour.

Low Pressure Pre-Infusion

Gradually increases water pressure to gently

expand grinds for an even extraction.

Dual Pumps

Dedicated Italian made espresso and steam

boiler pumps.

Programmable Shot Temperature

Adjust water temperature to achieve optimal

espresso ﬂavour depending on coffee origin

and degree of roast.

ADDITIONAL FEATURES

Auto Start

Switches machine on at a speciﬁed time.

Auto Off

Switches machine off after 30 minutes.

Oracle™Touch

Features

Assembly

BEFORE FIRST USE

Machine Preparation

Remove and discard all labels and packaging

materials attached to your espresso machine.

Ensure you have removed all parts and

accessories before discarding the packaging.

Remove the packaging and the plastics bags

containing the water ﬁlter and water ﬁlter

holder. Clean parts and accessories (water tank,

portaﬁlter, ﬁlter basket, jug) using warm water

and a gentle dish washing liquid. Rinse well

then dry thoroughly.

TIP

To easily manoeuvre your machine, use the

drop down swivel foot located under the drip

tray. When turned to UNLOCK, the swivel

foot drops down & lifts the machine upwards,

making it easier to access the removable water

tank or reposition the machine to another

location.

INSTALLING THE WATER FILTER

• Remove the water ﬁlter and water ﬁlter holder

from the plastic bag.

• Soak the ﬁlter in cold water for 5 minutes.

• Wash the ﬁlter holder with cold water.

• Set the reminder for next month of

replacement. We recommend to replace the

ﬁlter after 3 months.

• Insert the ﬁlter into the two parts of the ﬁlter

holder.

• To install the assembled filter holder into the

water tank, align the base of the ﬁlter holder

with the adapter inside the water tank.

Push down to lock into place.

• Fill the water tank with cold water before

sliding back into position at the back of the

machine and locking into place.

NOTE

If you replace the ﬁlter every 3 months or

40 litre use, you don't have to descale the

machine. For information on purchasing

additional ﬁlters visit sageappliances.com.

NOTE

DO NOT use highly ﬁltered, demineralised or

distilled water in this machine. This may affect the

taste of the coffee and how the machine operates.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cafetera de Sage

Sage

Sage Bambino Plus SES500 Manual de usuario

Sage

Sage Oracle Touch SES990 Manual de usuario

Sage

Sage the Oracle Manual de usuario

Sage

Sage the Dual Boiler BES920 Manual de usuario

Sage

Sage Nespresso Vertuo Creatista Manual de usuario

Sage

Sage Precision Brewer SDC400 Manual de usuario

Sage

Sage the Barist Express SES875 Manual de usuario

Sage

Sage Barista Express BES870UK Manual de usuario

Sage

Sage Bambino Plus SES500 Manual de usuario

Sage

Sage the Barista Pro SES878 Manual de usuario

Sage

Sage Smart Grinder Pro BCG820 Manual de usuario

Sage

Sage Nespresso Vertuo Creatista SVE850 Manual de usuario

Sage

Sage Precision Brewer SDC400 Manual de usuario

Sage

Sage Barista Express SES875UK Manual de usuario

Sage

Sage The Oracle BES980 Manual de usuario

Sage

Sage the Dual Boiler BES920 Manual de usuario

Sage

Sage Barista Express BES875 Manual de usuario

Sage

Sage the Dual Boiler BES920 Manual de usuario

Sage

Sage Oracle SES980 Manual de usuario

Sage

Sage Oracle Touch SES990 Manual de usuario

Sage

Sage Oracle Touch SES990 Manual de usuario

Sage

Sage the Barista Pro SES878 Manual de usuario

Sage

Sage Barista Express Impress BES876 Manual de usuario

Sage

Sage Bambino Plus Manual de usuario

Manuales populares de Cafetera de otras marcas

Taurus

Taurus Livorno 6 Manual de usuario

Delta-q

Delta-q QUICK Manual de usuario

Bunn

Bunn LCA-1 Guía de solución de problemas

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instrucciones de instalación

Saeco

Saeco Vienna Plus Sup 018M Manual de usuario

DeLonghi

DeLonghi DC300 Manual de usuario

INCAPTO

INCAPTO BXCO1470E Manual de usuario

Bosch

Bosch TASSIMO finesse TAS16B Series Manual de usuario

Exido

Exido 245-072 Manual de usuario

Animo

Animo OptiVend Choco Manual de usuario

Siemens

Siemens TQ505DF Series Manual de usuario

DeLonghi

DeLonghi ECI341 Manual de usuario

Krups

Krups KT406511 Manual de usuario

Cimbali

Cimbali M32 Classic Manual de usuario

Philips

Philips HL3844N Manual de usuario

Bosch

Bosch TES 515 SERIES Manual de usuario

Tekmatix

Tekmatix TMFM - 65 Manual de usuario

Scarlett

Scarlett SC-CM33005 Manual de usuario
