Sage Bambino Plus Manual de usuario

the Bambino™Plus

SES500

EN USER GUIDE

DK BETJENINGSVEJLEDNING

SE INSTRUKTIONSBOK

NO INSTRUKSJONSBOK

FI OHJEKIRJA

PAGE HEADER.....

additional safety when using

all electrical appliances.

Safety switches with a rated

operating current not more

than 30mA are recommended.

Consult an electrician for

professional advice.

• Remove and discard any

packaging materials safely,

before rst use.

• To eliminate a choking hazard

for young children, discard the

protective cover tted to the

power plug safely.

• Ensure the product is properly

assembled before rst use.

• This appliance is for household

use only.Do not use the

appliance for anything other

than its intended purpose.

Do not use in moving vehicles

or boats.Do not use outdoors.

Misuse may cause injury.

• Position the appliance on a

stable, heat resistant, level, dry

surface away from the counter

edge, and do not operate on or

near a heat source such as a

hot plate, oven or gas hob.

• Fully unwind the power cord

before operating.

• Do not let the power cord

hang over the edge of a counter

or table.Do not let the power

cord touch hot surfaces or

become knotted.

• Do not leave the appliance

unattended when in use.

SAGE®

RECOMMENDS

SAFETY FIRST

At Sage®we are very safety

conscious.We design and

manufacture appliances

with your safety foremost in

mind.We also ask that you

exercise a degree of care

when using any electrical

appliance and adhere to

the following precautions.

READ ALL INSTRUCTIONS

BEFORE USE AND SAVE

FOR FUTURE REFERENCE

• A downloadable version of this

document is also available at

sageappliances.com

• Before using for the rst

time, please ensure that your

electricity supply is the same

as shown on the rating label on

the underside of the appliance.

If you have any concerns

please contact your local

electricity company.

• The installation of a residual

current safety switch is

recommended to provide

CONTENTS

2Sage®Recommends Safety First

6Know your new appliance

8Operating your new appliance

14 Care & Cleaning

17 Troubleshooting

20 Guarantee

PAGE HEADER.....

WE RECOMMEND SAFETY FIRST

• If the appliance is to be:

- left unattended

- cleaned

- moved

- assembled; or

- stored

always switch o the espresso

machine by pressing the POWER

button to OFF. Switch o and

unplug from the power outlet.

• Regularly inspect the power cord,

plug and actual appliance for any

damage.If found to be damaged

in any way, immediately cease

use of the appliance and

return the entire appliance to

the nearest authorised Sage

Service Centre for examination,

replacement or repair.

• Keep the appliance and

accessories clean. Follow the

cleaning instructions provided

in this book. Any procedure not

listed in this instruction booklet

should be performed at an

authorised Sage Service Centre.

• The appliance can be used by

children aged 8 or older and

persons with reduced physical,

sensory or mental capabilities

or a lack of experience and

knowledge, only if they have

been given supervision or

instruction concerning use of

the appliance in a safe way and

understand the hazards involved.

• Children should not play with

the appliance.

• Cleaning of the appliance should

not be carried out by children

unless they are 8 years or older

and under adult supervision.

• The appliance and its cord should

be kept out of reach of children

aged 8 years and younger.

• Do not use attachments

other than those provided

with the appliances.

• Do not attempt to operate

the appliance by any method

other than those described in

this booklet.

• Do not move the appliance

whilst in operation.

• Do not use any other liquid apart

from cold mains/town water.

We do not recommend the use

of highly ltered, de-mineralised

or distilled water as this may

aect the taste of the coee and

how the espresso machine is

designed to function.

• Never use the appliance without

water in the water tank.

• Ensure the portalter is rmly

inserted and secured into

the brewing head before using

the machine.

• Never remove the portalter

during the brewing operation as

the machine is under pressure.

• Do not place anything on top of

the appliance.

PAGE HEADER.....

WE RECOMMEND SAFETY FIRST

• Use caution when operating

machine as metal surfaces are

liable to get hot during use.

• Do not touch hot surfaces.

Allow the product to cool

down before moving or cleaning

any parts.

• Heating element surface is

subject to residual heat

after use.

• Always ensure the appliance

is turned OFF, unplugged at

the power outlet and has been

allowed to cool before cleaning,

attempting to move or storing.

• The appliance is not intended

to be operated by means of

an external timer or separate

remote-control system.

• The use of attachments

not sold or recommended

by Sage may cause re,

electric shock or injury.

• Always turn the appliance to

the o position, switch o at

the power outlet and unplug

at the power outlet when the

appliance is not in use.

• Any maintenance other than

cleaning should be performed

by an authorised Sage®

service centre.

• Do not use the appliance

on a sink drain board.

• Do not operate the appliance

if it is in an enclosed space,

or within a cupboard.

• Use caution when descaling

as hot steam may be released.

Before descaling, ensure

drip tray is empty and inserted.

Refer to‘Care & Cleaning’ for

further instructions.

• Use caution after milk texturing

as the ‘Auto Purge’ function

may purge hot steam when

the steam wand is lowered.

PAGE HEADER.....

WE RECOMMEND SAFETY FIRST

NOTICE TO CUSTOMERS

REGARDING MEMORY

STORAGE

Please note that in order to better

serve our customers, internal

memory storage has been

imbedded into your appliance.

This memory storage consists

of a small chip to collect certain

information about your appliance

including the frequency of use

of the appliance and the manner

in which your appliance is being

used. In the event your appliance

is returned for service, the

information collected from the

chip enables us to quickly and

eciently service your appliance.

The information collected also

serves as a valuable resource

in developing future appliances

to better serve the needs of our

consumers. The chip does not

collect any information regarding

the individuals who use the

product or the household where

the product is used. If you have

any questions regarding the

memory storage chip please

priv[email protected]

SPECIFIC INSTRUCTIONS

FOR WATER FILTER

• Filter cartridge should be kept

out of reach of children.

• Store lter cartridges in a dry

place in the original packaging.

• Protect cartridges from heat and

direct sunlight.

• Do not use damaged

lter cartridges.

• Do not open lter cartridges.

• If you are absent for a prolonged

period of time, empty the water

tank and replace the cartridge.

The symbol shown

indicates that this appliance

should not be disposed of

in normal household waste.

It should be taken to a local

authority waste collection centre

designated for this purpose or to

a dealer providing this service.

For more information, please

contact your local council oce.

To protect against electric

shock, do not immerse

the power cord, power plug

or appliance in water or any

other liquid.

FOR HOUSEHOLD USE ONLY

SAVE THESE INSTRUCTIONS

PAGE HEADER.....

KNOW YOUR NEW APPLIANCE

A. 1.9L removable water tank

B. Control panel

1 CUP, 2 CUP and STEAM buttons

With preset shot durations or programmable

durations and volumes

C. MILK TEMP settings

Select from Warm, Ideal and Hot

D. MILK FOAM settings

Select from Low, Medium and High

E. Group head

F. 54mm stainless steel portalter

G. Steam wand grip

H. Extra-tall cup clearance for tall mugs

I. Steam wand

With automatic milk texturing

J. Milk jug temperature sensor

K. Removable drip tray grid

L. Removable drip tray

With full indicator

PAGE HEADER.....

KNOW YOUR NEW APPLIANCE

ACCESSORIES

A. Stainless steel milk jug

With MIN and MAX markings

B. 54mm tamper

C. Steam tip cleaning tool

D. The Razor™ precision trimming tool

Rating Information

220–240V ~50–60Hz 1300–1600W

E. Dual wall lter baskets (1 cup & 2 cup)

F. Single wall lter baskets (1 cup & 2 cup)

G. Espresso cleaning tablets

H. Cleaning disc

I. Water lter holder with lter

PAGE HEADER.....

OPERATING YOUR NEW APPLIANCE

BEFORE FIRST USE

Machine Preparation

Remove and discard all labels and packaging

materials attached to your machine. Ensure you

have removed all parts and accessories before

discarding the packaging.

Clean the drip tray, drip tray grid, portalter, lter

baskets and milk jugs using warm water and a

gentle dish washing liquid. Rinse well and dry

thoroughly before use.

INSTALLING THE WATER FILTER

1. Remove the water lter and water lter

holder from the packaging.

2. Set the reminder for the next month of

replacement.We recommend to replace

the lter after 3 months.

3. Soak the lter in cold water for 5 minutes.

4. Wash the lter holder with cold water.

5. Insert the lter into the two parts of the

lter holder. Ensure they are connected.

6. Remove the water tank from the

machine. Align the base of the lter

holder with the adapter inside the water

tank. Push down to lock into place.

7. Fill the water tank with cold potable water

and reattached the machine, ensuring it is

properly attached and sitting ush to the

back of the machine.

FIRST USE

1. Remove the water tank and ll with potable

water to the indicated MAX line. Replace

the water tank onto the machine.

2. Ensure that the drip tray is correctly

positioned on the machine.

3. Plug the power cord into the power outlet

and switch on.

4. Press the 1 CUP, 2 CUP or STEAM buttons

to turn the machine on.

5. Press the 1 CUP button and the machine

will commence its rst use cycle.

6. Once complete, the machine will go into

ready mode and all lights will be illuminated.

The rst use cycle is to rinse the machine

and prime the heating system.

TURNING OFF MACHINE

To turn the machine o, press the 1 CUP

and STEAM button simultaneously.

+OFF

FILLING THE WATER TANK

Lift the water tank from the machine. Remove the water

tank lid and add potable water to the water tank, lling

to the MAX marking indicated.

MAX

PAGE HEADER.....

OPERATING YOUR NEW APPLIANCE

Replace the water tank onto the machine, ensuring

it is properly attached and sitting ush against the

back of the machine.

If the 1 CUP, 2 CUP and STEAM buttons illuminate,

the water tank has been correct attached.

The machine will detect when the water level is low.

The 1 CUP, 2 CUP and STEAM buttons will not be

illuminated.

When this occurs, add water to the water tank.

Once there is sucient water, all buttons will be

illuminated and the machine can be used.

FILTER BASKETS

This machine includes 4 lter baskets:

2 x Single Wall and 2 x Dual Wall.

Use the 1 cup lter basket when brewing a single

cup and the 2 cup lter baskets when brewing

2 cups or a stronger single cup or mug.

The provided lter baskets are designed for:

1 Cup lter basket = 8–10g.

2 Cup lter basket = 19–22g

SINGLE WALL FILTER BASKETS

Single W all lter baskets should be used when

grinding fresh whole coee beans . They allo w you

to experiment with grind, dose and tamp to create

a more balanced espresso.

1 CUP 2 CUP

DUAL WALL FILTER BASKETS

Dual W all lter baskets should be used when using

pre-ground coee . They regulate the pressure and

help to optimise the extraction regardless of the

grind, dose and tamp pressure or freshness.

NOTE

You may need to experiment with how

much coee is dosed into the lter baskets

or how long the grinder needs to run to

achieve the correct dose. For example;

when using a ner espresso grind with the

Single Wall lter baskets, you may need to

increase the grind amount to ensure the

lter basket is correctly dosed.

1 CUP 2 CUP

PAGE HEADER.....

OPERATING YOUR NEW APPLIANCE

COFFEE DOSE AND TAMPING

• Insert the lter basket into the portalter.

• Grind enough coee to ll the lter basket.

• Tap the portalter several times to collapse

and distribute the coee evenly in the

lter basket.

• Using the tamper, tamp down rmly (approx.

15-20kgs of pressure). The amount of

pressure is not as important as the consistent

pressure every time.

• As a guide, the top edge of the cap on the

tamper should be level with the top of the lter

basket AFTER the coee has been tamped.

NOTE

Use Razor™ dose trimming tool to

precisely control the dose of ground coee

AFTER you tamp.

TRIMMING THE DOSE

The Razor™ precision dose trimming tool

allows you to trim the puck to the right level

for a consistent extraction.

the Razor™

Precision dose trimming tool

• Insert the Razor™ tool into the coee basket

until the shoulders of the tool rest on the rim

of the basket.

• Rotate the Razor™ dosing tool back and forth

while holding the portalter on an angle over

the knock box to trim o excess coee grinds.

Your coee lter is now dosed with the correct

amount of coee.

• Wipe excess coee from the rim of the lter

basket to ensure a proper seal is achieved

in the group head.

PURGING THE GROUP HEAD

Before placing the portalter into the group

head, run a short ow of water through the

group head by pressing the 1 CUP button.This

will stabilise the temperature prior to extraction.

INSERTING THE PORTAFILTER

Place the portalter underneath the group head

so that the handle is aligned with the INSERT

position. Insert the portalter into the group

head and rotate the handle towards the centre

until resistance is felt.

LOCK

INSERT

Place your cup/s under the portalter on the drip tray.

PRE-PROGRAMED SHOT VOLUME

– 1 CUP

Press the 1 CUP button once, the button will ash

indicating that it has been selected. A preset single

espresso volume of approximately 30mls will be

extracted.The machine will automatically stop

once the pre-set volume has been extracted.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Cafetera de Sage

Sage

Sage Barista Express BES875 Manual de usuario

Sage

Sage Barista Express Impress SES876 Manual de usuario

Sage

Sage the Oracle Manual de usuario

Sage

Sage Oracle Touch SES990 Manual de usuario

Sage

Sage CREATISTA UNO Manual de usuario

Sage

Sage Barista Express Impress BES876 Manual de usuario

Sage

Sage Barista Pro Manual de usuario

Sage

Sage Precision Brewer SDC400 Manual de usuario

Sage

Sage the Dual Boiler BES920 Manual de usuario

Sage

Sage Barista Touch Impress Manual de usuario

Sage

Sage Barista Touch SES880BTR Manual de usuario

Sage

Sage the Oracle Manual de usuario

Sage

Sage the Dual Boiler BES920 Manual de usuario

Sage

Sage the Dual Boiler BES920 Manual de usuario

Sage

Sage Barista Touch SES880 Manual de usuario

Sage

Sage Bambimo SES450 Manual de usuario

Sage

Sage Barista Express SES870 Manual de usuario

Sage

Sage SES990BTR Manual de usuario

Sage

Sage Precision Brewer BDC400 Manual de usuario

Sage

Sage the Oracle Touch BES990 Manual de usuario

Sage

Sage Nespresso Vertuo Creatista Manual de usuario

Sage

Sage The Oracle BES980 Manual de usuario

Sage

Sage Precision Brewer SDC400 Manual de usuario

Sage

Sage the Dual Boiler BES920 Manual de usuario

Manuales populares de Cafetera de otras marcas

Taurus

Taurus Livorno 6 Manual de usuario

Delta-q

Delta-q QUICK Manual de usuario

Bunn

Bunn LCA-1 Guía de solución de problemas

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Instrucciones de instalación

Saeco

Saeco Vienna Plus Sup 018M Manual de usuario

DeLonghi

DeLonghi DC300 Manual de usuario

INCAPTO

INCAPTO BXCO1470E Manual de usuario

Bosch

Bosch TASSIMO finesse TAS16B Series Manual de usuario

Exido

Exido 245-072 Manual de usuario

Animo

Animo OptiVend Choco Manual de usuario

Siemens

Siemens TQ505DF Series Manual de usuario

DeLonghi

DeLonghi ECI341 Manual de usuario

Krups

Krups KT406511 Manual de usuario

Cimbali

Cimbali M32 Classic Manual de usuario

Philips

Philips HL3844N Manual de usuario

Bosch

Bosch TES 515 SERIES Manual de usuario

Tekmatix

Tekmatix TMFM - 65 Manual de usuario

Scarlett

Scarlett SC-CM33005 Manual de usuario
