Ruijie RG-CS83-PD Series Manual de usuario

Ruijie RG-CS83-PD Series Switches

CS83-PD_RGOS 12.5(4)B0707

Configuration Guide

Document Version: V1.0

Date: 2023.04.27

All rights are reserved in this document and this statement.

Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document

or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks

is prohibited.

Trademark and are owned by Ruijie Networks.

All other trademarks or registered trademarks mentioned in this document are owned by their respective owners.

Disclaimer

The products, services, or features you purchase are subject to commercial contracts and terms. Some or all of

the products, services or features described in this document may not be within the scope of your purchase or

use. Unless otherwise agreed in the contract, Ruijie Networks does not make any express or implied statement

or guarantee for the content of this document.

Due to product version upgrades or other reasons, the content of this document will be updated from time to

time. Ruijie Networks reserves the right to modify the content of the document without any notice or prompt.

This manual is for reference only. Ruijie Networks endeavors to ensure content accuracy and will not shoulder

any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

Preface

Intended Audience

This document is intended for:

Network engineers

Technical support and servicing engineers

Network administrators

Technical Support

Ruijie Networks Website: https://www.ruijienetworks.com/

Technical Support Website: https://ruijienetworks.com/support

Case Portal: https://caseportal.ruijienetworks.com

Community: https://community.ruijienetworks.com

Technical Support Email: servi[email protected]

Live Chat: https://www.ruijienetworks.com/rita

Conventions

1. Conversions

Convention

Description

Bold font

Commands, command options, and keywords are in bold font.

Italic font

Arguments for which you supply values are in italic font.

[ ]

Elements in square brackets are optional.

{ x | y | z }

Alternative keywords are grouped in braces and separated by

vertical bars.

[ x | y | z ]

Optional alternative keywords are grouped in brackets and

separated by vertical bars.

&<1-n>

The argument before the sign (&) can be input for consecutive 1- n

times.

Double slashes at the beginning of a line of code indicate a

comment line.

2. Signs

The signs used in this document are described as follows:

Warning

An alert that calls attention to important rules and information that if not understood or followed can result in

data loss or equipment damage.

Caution

An alert that calls attention to essential information that if not understood or followed can result in function

failure or performance degradation.

Note

An alert that contains additional or supplementary information that if not understood or followed will not lead to

serious consequences.

Specification

An alert that contains a description of product or version support.

3. Note

The manual offers configuration information (including model, port type and command line interface) for

indicative purpose only. In case of any discrepancy or inconsistency between the manual and the actual version,

the actual version prevails.

Basic Configuration

CLI Configuration

ZAM Configuration

Basic Management Configuration

RBAC Configuration

Line Configuration

File System Configuration

USB Configuration

HTTP Configuration

Syslog Configuration

Software Upgrade Configuration

Uboot Configuration

Rboot Configuration

Time Range Configuration

UFT Mode Management Configuration

Supervisor Module Redundancy Configuration

Hot Swapping Configuration

Process Restarting Configuration

Python Configuration

License Management Configuration

Configuration Guide Contents

Contents

1 Configuring the CLI............................................................................................................................1

1.1 Introduction................................................................................................................................1

1.1.1 Accessing the CLI..........................................................................................................1

1.1.2 Command Modes...........................................................................................................1

1.1.3 System Help...................................................................................................................3

1.1.4 Abbreviated Commands ................................................................................................4

1.1.5 No and Default Options of Commands..........................................................................4

1.1.6 Prompts for Incorrect Commands..................................................................................5

1.1.7 History Commands ........................................................................................................5

1.1.8 Featured Editing.............................................................................................................6

1.1.9 Searching and Filtering of the Show Command Output................................................7

1.1.10 Command Alias............................................................................................................8

1.1.11 Character Set Encoding...............................................................................................9

1.2 Restrictions and Guidelines.......................................................................................................9

1.3 Configuration Task Summary..................................................................................................10

1.4 Operating the Python Script.....................................................................................................10

1.5 Configuring a Command Alias.................................................................................................10

1.6 Configuring the Privilege Level of a Command.......................................................................11

1.7 Configuring the Character Set Encoding Format....................................................................11

1.8 Monitoring................................................................................................................................12

Configuration Guide Configuring the CLI

1 Configuring the CLI

1.1 Introduction

The command line interface (CLI) is a window for text instruction interaction between users and network

devices. Users can enter commands in the CLI to configure and manage network devices.

1.1.1 Accessing the CLI

Before using the CLI, you need to connect a terminal or PC to a network device. After you start the network

device and initialize the hardware and software of the network device, you can use the CLI. If you use the

network device for the first time, you can connect it only through the console port. This is called out-of-band

management. After performing relevant configuration, you can connect and manage the network device by

telnetting to the virtual terminal.

1.1.2 Command Modes

Since the device has many commands, you can classify them by function to facilitate their use. The CLI

provides several commands modes, and all commands are registered in one or several command modes. You

must enter the mode of a command before using this command. Command modes are related with each other

but differ from each other.

As soon as a new session is set up between a user and the management interface of a network device, you

enter user EXEC mode. In this mode, you can use a few commands and the command functions are limited,

such as the show command. Execution results of commands in user EXEC mode are not saved.

To use more commands, enter privileged EXEC mode. Generally, you must enter a password to enter privileged

EXEC mode. In privileged EXEC mode, you can use all commands registered in this command mode, and

further enter global configuration mode.

Using commands in configuration modes (such as global configuration mode and interface configuration mode)

affects configurations in use. If you save the configurations, these commands are saved and run when the

system restarts. To enter another configuration mode, enter global configuration mode. If you perform

configuration in global configuration mode, you can enter various configuration sub-modes, such as interface

configuration mode.

Configuration Guide Configuring the CLI

Table 1-1 Description of the Command Modes (suppose that the name of the network device is

"Device")

Command

Mode

Access Method

Prompt

Exit or Entering Next

Mode

Function

Description of the

Mode

User EXEC

mode

A user enters

user EXEC

mode by default

when accessing

a network

device.

Device>

Run the exit

command to exit this

mode.

Run the enable

command to enter

privileged EXEC

mode.

Use this command

mode to conduct

basic tests or

display system

information.

Privileged

EXEC mode

In User EXEC

mode, run the

enable

command to

enter privileged

EXEC mode.

Device#

Run the disable

command to return

to user EXEC mode.

Run the configure

command to enter

global configuration

mode.

Use this command

mode to check

whether the

configurations take

effect. This mode is

password-protected.

Global

configuration

mode

In Privileged

EXEC mode, run

the configure

command to

enter global

configuration

mode.

Device(config)#

Run the exit or end

command, or press

Ctrl+C to return to

privileged EXEC

mode.

Run the interface

command to enter

interface

configuration mode.

In the interface

command, you must

specify the interface

configuration

sub-mode you want

to enter.

Run the vlan vlan-id

command to enter

VLAN configuration

mode.

Use commands in

this mode to

configure global

parameters that

affect the entire

network device.

Interface

configuration

mode

In global

configuration

mode, run the

interface

gigabitethernet

0/1 command to

enter interface

configuration

mode.

Device(config-if-

gigabitethernet

0/1)#

Run the end

command or press

Ctrl+C to return to

privileged EXEC

mode.

Run the exit

command to return

to global

configuration mode.

In the interface

command, you must

specify the interface

configuration

sub-mode you want

to enter.

Use this command

mode to configure

various interfaces of

the network device.

Configuration Guide Configuring the CLI

Command

Mode

Access Method

Prompt

Exit or Entering Next

Mode

Function

Description of the

Mode

Config-vlan

(VLAN

configuration

mode)

In global

configuration

mode, run the

vlan vlan-id

command to

enter VLAN

configuration

mode.

Device(config-vlan)#

Run the end

command or press

Ctrl+C to return to

privileged EXEC

mode.

Run the exit

command to return

to global

configuration mode.

Use this command

mode to configure

VLAN parameters.

1.1.3 System Help

When entering commands in the CLI, you can obtain help information by using the following methods:

At the command prompt in any mode, enter a question mark (?) to list the commands supported in current

command mode and command description.

Device> ?

Exec commands:

<1-99> Session number to resume

disable Turn off privileged commands

disconnect Disconnect an existing network connection

enable Turn on privileged commands

exit Exit from the EXEC

help Description of the interactive help system

lock Lock the terminal

ping Send echo messages

show Show running system information

telnet Open a telnet connection

traceroute Trace route to destination

Enter a space and a question mark (?) after a keyword of a command to list the next keyword or variable

associated with the keyword.

Device(config)# interface ?

Aggregateport Aggregate port interface

Dialer Dialer interface

GigabitEthernet Gigabit Ethernet interface

Loopback Loopback interface

Multilink Multilink-group interface

Null Null interface

Tunnel Tunnel interface

Virtual-ppp Virtual PPP interface

Virtual-template Virtual Template interface

Vlan Vlan interface

Configuration Guide Configuring the CLI

range Interface range command

Note

If a keyword is followed by a parameter value, the value range and description of this parameter are

displayed as follows:

Device(config)# interface vlan ?

<1-4094> Vlan port number

Enter a question mark (?) after an incomplete string of a command keyword to list all command keywords

starting with the string.

Device# d?

debug delete diagnostic dir disable disconnect

After an incomplete command keyword is entered, if the suffix of this keyword is unique, press the Tab key

to display the complete keyword.

Device# show conf<Tab>

Device# show configuration

In any command mode, you can run the help command to obtain brief description of the help system.

Device(config)# help

Help may be requested at any point in a command by entering

a question mark '?'. If nothing matches, the help list will

be empty and you must backup until entering a '?' shows the

available options.

Two styles of help are provided:

1. Full help is available when you are ready to enter a

command argument (e.g. 'show ?') and describes each possible

argument.

2. Partial help is provided when an abbreviated argument is entered

and you want to know what arguments match the input

(e.g. 'show pr?'.)

1.1.4 Abbreviated Commands

If a command is long, you can enter a part of the command keyword characters that are used to identify the

command keyword.

For example, the interface gigabitethernet 0/1 command for entering the configuration mode of interface

GigabitEthernet 0/1 is abbreviated as follows:

Device(config)# int g0/1

Device(config-if-GigabitEthernet 0/1)#

1.1.5 No and Default Options of Commands

Most commands have the no option. Generally, the no option is used to disable a feature or function, or perform

an operation opposite to a command. For example, run the no shutdown command on an interface to perform

the operation opposite to the shutdown command, that is, enable the interface. The keyword without the no

option is used to enable a disabled feature or a feature that is disabled by default.

Tabla de contenidos

Otros manuales de Cambiar de Ruijie

Ruijie

Ruijie RG-S6930-2C Manual de instalación y funcionamiento

Ruijie

Ruijie RG-S5310-E Series Manual de instalación y funcionamiento

Ruijie

Ruijie RG-SF2920U Series Manual de instalación y funcionamiento

Ruijie

Ruijie RG-S6000C-48GT4XS-E-AC DCN Manual de instalación y funcionamiento

Ruijie

Ruijie RG-IS2700-P Series Manual de instalación

Ruijie

Ruijie RG-S6510-48VS8CQ Manual de instalación y funcionamiento

Ruijie

Ruijie RG-CS83 Series Manual de instalación y funcionamiento

Ruijie

Ruijie RG-ES100 Series Manual de instalación y funcionamiento

Ruijie

Ruijie RG-S6220-48XS6QXS-H Manual de instalación y funcionamiento

Ruijie

Ruijie RG-N18000-E Series Manual de instalación y funcionamiento

Ruijie

Ruijie RG-PF2920 Series Manual de instalación y funcionamiento

Ruijie

Ruijie RG-NBS1805C-P Manual de usuario

Ruijie

Ruijie RG-S6510-4C Series Manual de instalación y funcionamiento

Ruijie

Ruijie RG-S6150-X Series Cómo utilizar

Ruijie

Ruijie RG-S6100 Series Manual de instalación y funcionamiento

Ruijie

Ruijie RG-ES126S-P Manual de instalación y funcionamiento

Ruijie

Ruijie RG-S6980-64QC Manual de instalación y funcionamiento

Ruijie

Ruijie RG-IS2712G Manual de instalación y funcionamiento

Ruijie

Ruijie RG-S6510-32CQ Manual de instalación y funcionamiento

Ruijie

Ruijie RG-CS83 Series Manual de usuario

Ruijie

Ruijie RG-S3760E Series Manual de usuario

Ruijie

Ruijie RG-CS85 Series Manual de instalación y funcionamiento

Ruijie

Ruijie RG-S2928G-E Manual de instalación y funcionamiento

Ruijie

Ruijie RG-S6510-48VS8CQ Manual de instalación y funcionamiento

Manuales populares de Cambiar de otras marcas

URC

URC Total Control MFS-8 Manual de usuario

Azbil

Azbil HPQ-D11 Manual de usuario

Sony

Sony DFS-900M Manual de usuario

SICK

SICK i17S Manual de usuario

F&F

F&F SZR-277 Manual de usuario

Shure

Shure UAMS/BK Manual de usuario

Dräger

Dräger X-zone Switch Off Manual de usuario

Asco

Asco Joucomatic 349 Series Manual de usuario

BT Mini Hub Manual de usuario

D-Link

D-Link DES-1226G Manual de usuario

Johnson Controls

Johnson Controls FS80-C Manual de usuario

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manual de usuario

MicroNet

MicroNet SP1200A Manual de usuario

Altinex

Altinex DA1914SX Manual de usuario

MiLAN

MiLAN MIL-SM2401M Manual de usuario

RJM

RJM MASTERMIND PBC/6X Manual de usuario

Atlas

Atlas MMK-KVM8 Manual de usuario

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manual de usuario
