RSA Lighting ACCURUS TRIM ACT1985 Manual de usuario

DESCRIPTION Catalog # Type

Project

Comments Date

Prepared by

www.cooperlighting.com

SPECIFICATION FEATURES

+/- 15º

5.00"

DIA.

3.00"

DIA.

A...Trim

5” round adjustable downlight trim ﬁxture

for downlighting purposes. Includes

clear anodized reﬂector and clear glass

protective lens.

B ...Lamp

For use with 12V MR16 lamp 71W max.

Metal Halide MR16 20W or 39W. Lamp

not included. Lamp holder has 15º

adjustability. Includes clear protective

glass lens and can accept up to three (3)

optical accessories total.

C ...Socket

Posi-Grip bi-pin socket for 12V MR16.

GX10 for metal halide lamps. (Included

with Accurus Housing sold separately)

D...Finish

Trim face is powder coated in white,

black, industrial silver, stainless steel. All

other internal components are ﬂat black.

E ...Safety

Steel safety cable provided. Attaches

to tab inside housing to prevent falling

during maintenance or as a result of

accidental dislodging of the trim.

ACCURUS

TRIM

ACT1985

5” Round Recessed

Downlight Fixture

12V MR16 71W max.

METAL HALIDE MR16 20W or 39W

Compatible Housings:

ACT950 / ACT950MH

ACT952IC / ACT952ICMH

ACT954RM / ACT954RMMH

ORDERING INFORMATION

Fixture

ACT1985 =

5” Round Trim Downlight

Fixture

5” round recessed adjustable downlight ﬁxture. For use with 12V MR16

lamp 71W max. Metal Halide MR16 20W or 39W. For use with Accurus

housings.

For use in downlighting applications.

Speciﬁcations and Dimensions subject to change without notice.

RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031

Finish

WH =White

BK =Black

S =Industrial Silver

SS =Stainless Steel (painted)

PM =Primer

ACT1985

rev 121907

• 12V MR16 71W max.

• Metal Halide MR16 20W or 39W

Suitable for Damp

Location
