RS PRO RSSA3000X Manual de usuario

Quick Guide

RSSA3000X

Spectrum Analyzer

General Safety Summary

Carefully read the following safety precautions to avoid any personal

injury or damage to the instrument and any products connected to it.

To avoid potential hazards, please use the instrument as specified.

Use Proper AC Power Line

Only the power cord designed for the instrument and authorized by

local country should be used.

Ground the Instrument

The instrument is grounded through the protective earth conductor of

the power line. To avoid electric shock, please make sure the

instrument is grounded correctly before connecting its input or output

terminals.

Connect the Probe Correctly

If a probe is used, do not connect the ground lead to high voltage since

it has isobaric electric potential as the ground.

Look Over All Terminals’ Ratings

To avoid fire or electric shock, please look over all ratings and sign

instruction of the instrument. Before connecting the instrument, please

read the manual carefully to gain more information about the ratings.

Use Proper Overvoltage Protection

Make sure that no overvoltage (such as that caused by a thunderstorm)

can reach the product, or else the operator might be exposed to danger

of electrical shock.

Electrostatic Prevention

Operate the instrument in an electrostatic discharge protective area

environment to avoid damages induced by static discharge. Always

ground both the internal and external conductors of the cable to release

static before connecting.

Maintain Proper Ventilation

Inadequate ventilation may cause an increase in the instrument’s

temperature, which will eventually damage the instrument. So keep well

ventilated and inspect the intake and fan regularly.

Avoid Exposed Circuit or Components

Do not touch exposed contacts or components when the power is on.

Do Not Operate Without Covers

Do not operate the instrument with covers or panels removed.

Use Only the Specified Fuse.

Keep Product Surfaces Clean and Dry

To avoid the influence of dust and/or moisture in the air, please keep

the surface of the device clean and dry.

Do Not Operate in Humid Conditions

In order to avoid short circuiting to the interior of the device or electric

shock, please do not operate the instrument in a humid environment.

Do Not Operate in an Explosive Atmosphere

In order to avoid damage to the device or personal injury, it is important

to operate the device away from an explosive atmosphere.

General Safety Summary

Safety Terms and Symbols

Terms on the product. These terms may appear on the

product: DANGER Indicates direct injuries or hazards

that may happen. WARNING indicates potential

injuries or hazards that may happen.

CAUTION Indicates potential damages to the instrument or other property that may happen.

Symbols on the product. These symbols may appear on the product:

Warning

Hazardous Protective Earth

Voltage Earth Ground Ground

Chassis

Ground

General Care and Cleaning

Care

Do not store or leave the instrument in direct sunshine for extended periods of time.

Notice:

To avoid damages to the instrument, please do not leave it in fog, liquid, or solvent.

Clean

ing

Please perform the following steps to clean the instrument regularly according to its operating conditions.

1. Disconnect the instrument from all power sources, and then clean it with a soft cloth.

2. Clean the loose dust on the outside of the instrument with a soft cloth. When cleaning the LCD, take care to avoid scratching it.

Notice:

To avoid damages to the surface of the instrument, please do not use any corrosive liquid or chemical

cleanser. Make sure that the instrument is completely dry before restarting it to avoid short circuits or

personal injuries.

General Inspection

1.Inspect the shipping container

Keep the damaged shipping container or cushioning material until the contents of the shipment have been completely checked and the instrument has

passed both electrical and mechanical tests.

2. Inspect the instrument

If the instrument is found to be damaged, defective or fails in electrical or mechanical tests, please contact your sales representative.

3. Check the accessories

Please check the accessories according to the packing list. If the accessories are incomplete or damaged, please contact your sales representative.

Appearance and Dimension

Figure 1 Front View Figure 2 Top View

Adjust the Supporting Legs

Adjust the supporting legs properly to use them as stands to tilt the Spectrum Analyzer upwards for stable placement as well as easier operation and

observation of the instrument.

Before adjusting After adjusting

Connect to AC Power Supply

The Spectrum Analyzer accept 100-240V, 50/60/440Hz AC power supply. Please use the power cord provided as accessories to connect the instrument to

the power

source as shown in the figure below.

General Description

This model of spectrum analyzer has a frequency range from 9 kHz up to 2.1 GHz/3.2 GHz.It is lightweight, small and precise, offering a user friendly

interface, clear display with plenty of RF measurement functions. The product can be used for research and development, education, production,

maintenance and other relevant applications.

The Front Panel

1、User Graphical Interface

2、Menu Control Keys

3、Function Keys

4、Numeric Keyboard

5、Knob

6、Arrow Keys

7、RF Input

8、TG Output

9、Earphone interface

10、USB Host

11、Power Switch
