Rosewill RK-8200 Manual de usuario

Backlit Gaming Keyboard with 10 Macro Keys RK-8200

User Manual

Backlit Gaming Keyboard with 10 Macro Keys RK-8200 UserManual

Thank you for your purchase of our Gaming Keyboard. For your own safety

and convenience, please read this manual thoroughly before using this

product. After you have read this manual, please keep it in a place for

reference when necessary.

Contents in the package

These following items are included in the package. Please make sure all items

are complete when open the package at first time. If there is any item missing

or damaged, please contact the reseller where the product was purchased or

our support center.

RK-8200 Gaming Keyboard x 1

Installation CD x 1

Manual x 1

7 PCS Swap Gaming Keycap.

Keycap Puller.

Attention

Any malfunction, damage or personal injury caused by the malfunctioning or

damage of the user’s personal computer or misuse of this product. Any

attempt to dismantle, change or modify this product in any manner.

Warning

Please do not use this product in ashy, wet, or oily environment(s). Failure to

do so may shorten the life of this product and may cause bodily harm.

Please keep this product away from radio frequency interruption area(s).

This is not an outdoor product. This product is not for outdoor use. Exposing

the product outdoors may cause damage to it.

Please do not use alcohol, petroleum, benzene or thinner-based solutions to

clean this product. We recommend wiping this product with a damp cloth.

Backlit Gaming Keyboard with 10 Macro Keys RK-8200 UserManual

Warranty Information

This product is backed by a One-Year Manufacturer’s Warranty, starting from

the date of purchase. The warranty covers for free repair in accordance with

the contents stated herein but does not cover wear and tear and any

malfunction or damages as results of improper usage as stated in this manual.

Product Appearance

Front View

Side View

Replaceable Keys and Key Cap Remover

Hot Keys Media Keys

Macro Keys

Audio/Mic/USB port (optional)

Backlit Gaming Keyboard with 10 Macro Keys RK-8200 UserManual

Hot Key Functions

Icons Functions Descriptions

Mode Switch to Gaming mode

Profile Switch to Macro Profile setting

LED ON/OFF Turn on back light

Windows Lock Lock the Windows “ Start ” Hotkey

Volume Down Decrease the Volume Level

Volume up Increase the Volume Level

Mute Mute the Volume

Play and Pause Play and Pause the Media Player

Product Features

The Keyboard is designed for on-line game players and PC game users.

Ergonomic palm rest with leather wrapping for a comfortable touch

Ideally spaced hot-keys increase productivity and speed.

One Hot Key of locking "Windows Key" for users to play game without operating

error

4 Multimedia hot keys

3 sets 10 Macro keys allow game user to set any key code easily.

Backlit Gaming Keyboard with 10 Macro Keys RK-8200 UserManual

Support delay time setting. Allow users to do multi-actions in game.

Equipped with replaceable colorful QWERASD Gaming function keys with a key cap

remover

Backlight Blue LED Key Module -The basic model will be designed with an On/ Off

button to turn on/ off blue LED backlight to control backlight ambience.

On Screen Display (OSD) function - A vary of information can be displayed with On

Screen Display function bases on user selection.

Audio & Mic jack, one USB hub (optional).

Product Specification

Dimensions 543 x 223.9 x 30mm

Weight 1000± 20g

Key number 122 Key for US Version (By Language)

Hot Key 20 (Including Windows Hotkeys and Marco Keys)

Cable Length 1.7meter

Interface USB

Links USB Hub and Audio Ports (Optional)

Keystroke Life 5 Millions

Key Switch Type Membrane

Key Operating Force 55±8g

Power Consumption DC 5V ± 5%, 400mA max

Safety Approval FCC Class B, CE, BSMI

Operation System Windows 2000 / XP / XP x64 / Vista x86 x64 /7 x86 x64

Accessory Replaceable Colorful QWERASD Gaming Function Keys with a Key

Cap Remover

Installing the Software

1. System Requirement:

Have USB port on PC.

Windows 7/Windows7 64/Vista/Vista 64/ XP/XP64.

CD/ DVD-Rom Drive.

35 MB free hard disk space.

Backlit Gaming Keyboard with 10 Macro Keys RK-8200 UserManual

2. Install Software

3-1. Software installation step

Step1: Plug keyboard's USB Cable into PC's USB port.

Step2: Please place software CD into CD or DVD ROM Drive.

Step3: System will automatically install, if the autorun function doesn’t

activate, please click "setup.exe” to install driver.

Step4: Please follow the screen display step to install.

Step5: After the installation, please click finish button to complete. The system

may need to be rebooted after the installation.

3-2. Uninstall

Step1: Open control panel.

Step 2: Select “Add/Remove Program."

Step 3: From program list to remove, please select gaming keyboard program.

Step 4: Click “remove" and system will uninstall this program.

3. Operation Explain

The features listed here require the gaming keyboard software driver to be installed

and the gaming keyboard Tray Icon will be activated. Each setting will be saved to the

current Profile on the keyboard.

Backlit Gaming Keyboard with 10 Macro Keys RK-8200 UserManual

Function List Below

Macro key functions

User can set M1~M10 button to Macro function. When click macro of function key, then

keyboard will send macro key to game.

Macro Assignment:

Enter your macro or single key in the new Macro Assignment box. You can also choose to

insert a delay time. Macro can be up to 64 keystrokes.

Office commands

You can set some office command to this key. Ex (Copy, paste, print)

Launch Program

You can set exe or website link to this button.

Select Profile

You can set this key to switch profile function.

Reset key

Click this button can reset key mapping into default setting.

Backlit Gaming Keyboard with 10 Macro Keys RK-8200 UserManual

Swap Key Setting

Standard key swap function

To enter a single key to this box then click apply button will swap this key function. All

standard key code can be assigned to specific key code. For example; user can assign

“Q” as “A.” After completing the setting, user presses “Q” key, and keyboard will send “A”

key code to PC. The button will be highlighted green color on the key map you have

selected.

NOTE:If users want to reset the swapped key to default setting, Please launch the

driver’s GUI and choose the single key which you want to set. Click “Reset to Default” key

and the value will return to original factory setting.

Auto Switch Profile

Auto profile can be set to be automatically launched while the selected application is

activate.

Backlit Gaming Keyboard with 10 Macro Keys RK-8200 UserManual

FCC Statement on CLASS B

This equipment has been tested and found to comply with the limits foe a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try to correct the interference by one or

more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into and outlet on a circuit different from that to which the receiver is

connected.

-Consult the dealer or an experienced radio / TV technician for help.

Caution

As shielded-type power cord is required in order to meet FCC omission limits and also to

prevent interference to the nearby radio and television reception. It is essential that only the

supplied power cord be used.

Use only shielded cables to connect I/O devices to this equipment.

You are cautioned that changes or modifications not expressly approved by the party

responsible for compliance could void your authority to operate the equipment.

All brand names, trademarks and logos are the properties of their respective owners.

Thank you for purchasing a quality Rosewill Product.

Please register your product at : www.rosewill.com for complete warranty information and future support for your

product.
