Rosewill RC218 Manual de usuario

4 channel PCIex4 to SATA II Card RC218

User Manual

4 channel PCIe x 4 to SATA II Card RC218 UserManual

Features

•Marvell 88SX7042 chipset

•Compliant with PCI Express Base Specification 1.0a

•Compliant with Serial ATA 1.0 specification with support for full

complement of SATA II optional features

•Supports SATA II Native Command Queuing (NCQ)

•Provides four independent channels to support up to four Serial

ATA dr ives

•Supports SATA up to 300MB/Sec

•Supports Windows® 2000, XP/2003 32/64 bit, Vista 32bit

Bus Interface

•PCI-Express x 4

Connectors

•4 x internal SATA connectors

•2 x external eSATA connectors

Package Contents

•1 x PCIe SATA II 300 4-Channel Adapter RC218

•1 x Driver CD

•2 x SATA Data Cable

•1 x Manual

•1 x Low Profile bracket

•1 x Floppy disk for fresh installation

4 channel PCIe x 4 to SATA II Card RC218 UserManual

System Requirements

•PCI Express-enabled system with one available PCI Express slot.

•Windows® 2000, XP/2003 32/64 bit, Vista 32bit

Hardware Description

G (Jumper Settings)

JP Description Active Port

1-2 close Enable SATA Connector DJ2-J5

2-3 close Enable SATA Connector E

1-2 close Enable SATA Connector CJ6-J9

2-3 close Enable SATA Connector F

4 channel PCIe x 4 to SATA II Card RC218 UserManual

Note: There are six SATA ports in PCIe SATA II 300 4-Channel Adapter.

We name these ports A to F. Ports A to D are internal SATA ports and E &

F are external SATA ports. By changing the jumper setting on the PCIe

SATA II 300 4-Channel Adapter that allows you to select between

external and internal ports to use.. By default, Port A, B, C and D are

working.

Hardware Installation

1. Turn Off the power to your computer and any other connected

peripheral devices.

2. Unplug the power cord from the back of the computer.

3. Remove your computer’s cover.

4. Remove the slot bracket from an available PCI Express slot.

5. To install the card, carefully align the card’s bus connector with

the selected PCI Express slot on the motherboard. Push the

board down firmly, but gently, until it is well seated.

6. Replace the slot bracket’s holding screw to secure the card.

Device Connection

The PCIe SATA II 300 4-Channel Adapter is a four channel Serial ATA

controller that supports up to four Serial ATA hard disk drives.

1. Install your hard disk drive(s) in chassis.

2. Connect the Serial ATA hard disk drive to the system power

supply using the included Serial ATA power cable.

3. Connect one end of the Serial ATA cable to the hard disk drive.

4. Attach the other end of the Serial ATA cable to the Serial ATA

4 channel PCIe x 4 to SATA II Card RC218 UserManual

controller on the PCIe SATA II 300 4-Channel Adapter.

5. Follow the same instructions to connect up to four hard drives.

Device connection is now complete.

6. Replace the computer cover and reconnect the power cord.

Driver Installation

For Windows® 2000

For New Installation

1. Follow Windows® 2000 installation procedure.

2. Restart the computer when prompted by the installation.

3. At the Windows® 2000 Setup screen, press F6 to install the

driver.

4. When prompted, press S to specify the location of the driver.

5. Insert the floppy disk, then press Enter.

6. Select Marvell 88SX7042 Serial ATA Adapter for Windows

2000/XP/Server2003/Vista, then press Enter.

7. Press Enter to finish driver installation, then follow the on-screen

instruction to complete the Windows installation.

Note: If the Security Alert warning pops up, click Yes. Our driver has

passed Microsoft compatibility testing, this message appears during

new installation.

For An Existing Installation

1. At Found New Hardware Wizard, click Next.

2. Select Search for a suitable driver for my device(recommend)

then click Next.

4 channel PCIe x 4 to SATA II Card RC218 UserManual

3. Insert the driver CD, check CD-ROM drives, uncheck the other

boxes, click Next, then click Next again.

4. If the Digital Signature Not Found message appears, click Yes.

Our driver has been thoroughly tested for stability and

compatibility.

5. Click Finish.

For Windows® XP/Server 2003

For New Installation

1. Follow Microsoft’s Windows installation procedure.

2. Restart the computer when prompted by Windows’ installation.

3. At the Windows Setup screen, press F6 to install the driver.

4. When prompted, press S to specify the location of the driver.

5. Insert the floppy disk, then press Enter.

6. Select Marvell 88SX7042 Serial ATA Adapter for Windows

2000/XP/Server2003/Vista, then press Enter.

7. Press Enter to finish driver installation, then follow the on-screen

instructions to complete the Windows installation.

Note: If the Security Alert warning pops up, click Yes . Our driver has

passed Microsoft compatibility testing, this message appears during

new installation.

For An Existing Installation

1. At the Found New Hardware Wizard:

XP(w/SP1 or earlier)/Server 2003: continue to step #2

XP(w/SP2 or later)/Server 2003(w/SP1 or later): select No, not

4 channel PCIe x 4 to SATA II Card RC218 UserManual

this time, then click Next.

2. Insert the driver CD, select Install the software automatically

(Recommended), and click Next.

3. If the Hardware Installation window pops up, click Continue

Anyway, then Finish. Our driver has been thoroughly tested for

stability and compatibility.

4. Click Finish.

For Windows® XP-x64/Server 2003-x64

For New Installation

1. Follow Microsoft’s Windows installation procedure.

2. Restart the computer when prompted by Windows’ installation.

3. At the Windows Setup screen, press F6 to install the driver.

4. When prompted, press S to specify the location of the driver.

5. Insert the floppy disk, then press Enter.

6. Select Marvell 88SX7042 Serial ATA Adapter for Windows

XP/Server2003x64, then press Enter.

7. Press Enter to finish driver installation, then follow the on-screen

instructions to complete the Windows installation.

Note: If the Security Alert warning pops up, click Yes . Our driver has

passed Microsoft compatibility testing, this message appears during

new installation.

For An Existing Installation

At the Found New Hardware Wizard, select No, not this time,

then click Next.

1. Insert the driver CD, select Install the software automatically

4 channel PCIe x 4 to SATA II Card RC218 UserManual

(Recommended), and click Next.

2. If the Hardware Installation window pops up, click Continue

Anyway, then Finish. Our driver has been thoroughly tested for

stability and compatibility.

3. Click Finish.

For Windows® Vista

For New Installation

1. Follow Microsoft’s Windows installation procedure.

2. At the Windows Setup screen, press Load Driver to install the

driver.

3. Insert the floppy disk, please select Marvell Serial ATA Gen 2

PCI Express Adapter (A:\i386\mvsata.inf), then press Next.

(Change A:\ to match your floppy drive letter)

4. Follow the on-screen instructions to complete the Windows

installation.

For An Existing Installation

1. At Found New Hardware Wizard, select Locate and install driver

software (recommended).

2. Please insert the CD driver into your CD-ROM Drive, click Next.

3. If the system prompts the user informing the drivers are not signed,

select the option Install this driver software anyway.

4. Click Close to complete the installation.

4 channel PCIe x 4 to SATA II Card RC218 UserManual

To Verify Windows® Installation

1. Right click My Computer and click Manage.

2. Select Device Manager.

3. Double click SCSI and RAID Controller or Storage controllers

in Vista, then double click Marvell Serial ATA Gen 2 PCI

Express Adapter to display driver properties. A message this

device is working properly is displayed in the dialog box, the

driver has been correctly installed.

Thank you for purchasing a quality Rosewill Product.

Please register your product at : www.rosewill.com for complete warranty

information and future support for your product.
