Rosewill RC-611 Manual de usuario

4-Ports High-speed USB 2.0 ExpressCard

RC-611

User Manual

4-Ports High-speed USB 2.0 ExpressCard RC-611 User Manual

1

Features and Benefits

zFully compliant with ExpressCard Specification 1.0

zExpressCard/34 Form Factor Module

zHot-swapping feature allows to connect or disconnect devices

without powering down system

zFully supports EHCI and OHCI Compliant standards

zCompliant with Universal Serial Bus specification revision 2.0

zProvides four external USB2.0 high speed port

zSupports simultaneous operation of multiple USB 2.0 and USB

1.1 devicesSupports data transfer rates of high-speed (480Mbps),

full-speed (12Mbps), and low-speed (1.5Mbps)

zSupport Windows® 2000, XP/2003 32/64 bit, Vista 32/64 bit

System Requirements

zWindows® 2000/XP/Server 2003/Vista

zExpressCard-enabled system with an available ExpressCard slot

Package Contents

z1 x RC-611

z1 x User Manual

4-Ports High-speed USB 2.0 ExpressCard RC-611 User Manual

2

Hardware Description

CAUTION:

Use only switching power adapter with following specifications:

zSwitching power adapter DC 5V, 2A

Polarity: Outside negative voltage(-) & Inside positive voltage(+)

3.5mm power jack

4-Ports High-speed USB 2.0 ExpressCard RC-611 User Manual

3

Hardware Installation

General instructions for installing the card are provided below. Since the

design of system may vary, refer to your system’s reference manual for

further information, if needed.

Insert the Card into the ExpressCard slot of your system. Make sure it is

inserted all the way in for a solid connection.

Driver Installation

Important: If your system doesn’t boot to Windows properly with our

card installed, check with your system’s manufacturer for the latest

system firmware update.

For Windows® 2000/XP/Server 2003/Vista

Once the Windows® 2000, XP, Server 2003 and Vista startup, USB 2.0

ExpressCard will be installed automatically without driver installing.

Please update your operating system to Windows® 2000 Service Pack 4,

Windows® XP Server Pack 1 or later version.

To Verify Windows Installation

Click on the “Device Manager” tab in System Properties, which you

access from the Windows Control Panel. You should see an entry of the

4-Ports High-speed USB 2.0 ExpressCard RC-611 User Manual

4

driver you installed under the Universal Serial Bus controllers item.

Start > Control Panel > System >Device Manager

Thank you for purchasing a quality Rosewill Product.

Please register your product at :

www.rosewill.com for complete warranty information and future support for your product.
