INTRODUCTION

CrystalLink USB-3-2-1 CATx Extender Manual 1

Disclaimer

While every precaution has been taken in the preparation of this manual, the manufacturer assumes no

responsibility for errors or omissions. Neither does the manufacturer assume any liability for damages resulting

from the use of the information contained herein. The manufacturer reserves the right to change the

specifications, functions, circuitry of the product, and manual content at any time without notice.

The manufacturer cannot accept liability for damages due to misuse of the product or other circumstances

outside the manufacturer’s control. The manufacturer will not be responsible for any loss, damage, or injury

arising directly or indirectly from the use of this product (See limited warranty).

System Introduction

Thank you for choosing the Rose Electronics CrystalLink USB-3-2-1 CATx extender.

The CrystalLink USB-3-2-1 CATx extender provides simultaneous transparent USB extension for all USB3.1,

2.0 and 1.1 devices up to 330 feet (100 meters) over a single CAT6a/7 UTP cable.

Up to four USB devices such as a USB3.1 conferencing camera, flash drives, hard drives, keyboards, mice,

interactive white boards, touchscreens, docking stations, USB to video converters, audio devices, and/or any

other USB3.1, 2.0 and 1.0 device can be extended away from the host PC using the CrystalLink USB-3-2-1

CATx extender. Additional USB devices can be connected using a powered USB hub.

The CrystalLink USB-3-2-1 CATx extension system consists of two units, a transmitter and a receiver. The

transmitter connects to your computers’ USB port. The transmitter is linked directly to the receiver using

industry standard CAT6a/7 cable and the USB devices connect to the receiver.

To support the USB3.1 SuperSpeed of up to 5Gbps, the CrystalLink USB-3-2-1 CATx extender must be

connected directly to the USB3.1 port of a host device.

The instructions in this manual assume a general knowledge of computer installation procedures, familiarity

with cabling requirements, and some understanding of USB device operation.

Features

■Supports a single CAT6a/7 cable up to 330 feet (100 meters)

■Supports transparent USB3.1 Gen 1 SuperSpeed data rates up to 5Gbps

■Supports all USB3.1, 2.0, 1.1 devices simultaneously at full bandwidth

■Backwards compatible with USB2.0 and USB1.1 devices

■Four USB3.1 Gen 1 receiver ports, each with up to 1.2 Amp (6W) power

■Attach up to 3 powered USB hubs for additional remote USB device support

■Ethernet 100/1000 pass-through for connecting to network enabled devices

■Plug and Play. No software drivers required

■Supports all major operating systems: Windows®, MAC OS™, Linux® and Chrome OS™

■Made in North America

CrystalLink USB-3-2-1 CATx Extender Manual 2

Package Contents

The package contents consist of the following:

■Transmitter unit

■Receiver unit

■USB3.1 Gen 1 cable

■24V DC Power Adapter (2) and AC power cable (2). (Transmitter is 1A, Receiver is 2.71A)

■Installation & Operation Manual

Additional Items Required

■USB compatible computer (host computer) with a USB compliant operating system

■USB compatible device(s) for remote-end connection

■Solid core CAT6a/7 Unshielded Twisted Pair (UTP) cable, shielded (STP) cable or foiled (FTP) cable up to

a maximum of 330ft (100m).

■For optimum performance, the CAT6a/7 cable should be run straight and not coiled, and not routed close

to electrical cables or radio interference. Terminate the cables according to T568A/T568B.

All references to CAT6a/7 cable in this document refer to solid-core cable and represent the minimum CAT6a/7

specification requirements. Use of UTP/STP/FTP patch-cables may reduce the recommended cable extension

distances.

Application Examples

The CrystalLink USB-3-2-1 CATx is ideal for use with USB3.1 conferencing cameras or in computer room or

industrial environments where USB devices need to be connected remotely from a host PC.

■Industrial control

■Interactive whiteboard

■Connection to network attached devices

■Boardroom and conferencing presentations. Connect to a USB3.1 videoconferencing camera to provide

video, control and power over a single CAT6a/7 cable

■Extension of multiple USB devices including hard drivers, printer, scanner, camera control, touchscreens

MODELS

CrystalLink USB-3-2-1 CATx Extender Manual 3

CrystalLink USB-3-2-1 CATx Models

The CrystalLink USB-3-2-1 CATx enables users to extend beyond the standard 5m cable limit for USB

peripherals by locating high-speed USB device(s) up to 330 feet (100 meters) from the computer.

Transmitter Unit

The transmitter connects to the host device using the supplied USB3.1 Gen 1 cable. Power for the transmitter

is provided by included 24V 1A power adapter. Power and status LED’s are conveniently located on the front

panel for user reference.

Transmitter unit – front panel view

Transmitter unit – rear panel view

Item Type Description

1 Power LED LED is SOLID ON when DC power is supplied to the extender unit. LED is

OFF when no power is supplied by the AC adapter.

2 Mode/Config Reserved for engineering use

Status LED

LED is SOLID ON when the system is functioning normally. LED BLINKS

when the system is booting or to indicate a temperature warning together

with the LINK, USB2, and USB3 LEDs.

Link LED

LED is SOLID ON when the transmitter is linked to an opposite receiver

unit. LED is OFF when there is no connection between the transmitter and

receiver.

USB2.0 LED

LED is SOLID ON when an active USB2.0 connection is established through

the extender system. LED BLINKS when the USB2.0 connection is

suspended/asleep. LED is OFF when no USB2.0 connection is detected.

USB3.1 LED

LED is SOLID ON when an active USB3.1

connection is established through

the extender system. LED BLINKS when the USB3.1 connection is

suspended/asleep. LED is OFF when no USB3.1 connection is detected.

4 LAN port

(100/1000 Mbps) Ethernet pass through channel connects to a network or Ethernet device.

CrystalLink USB-3-2-1 CATx Extender Manual 4

5 Link port (RJ45) Accepts the RJ45 connector for CAT6a/7 cabling to connect the transmitter

to the receiver.

6 USB host port USB3.1 Type B connector used to connect the transmitter to the USB3.1

host computer.

7 DC power port Locking connector for the included 24VDC 1A power adapter

Figure 1. transmitter unit – LED’s and connectors

Receiver Unit

The receiver has four USB3.1 Type-A ports for connecting up to four USB devices. Additional devices may be

connected by attaching a USB hub to the receiver unit. The receiver is powered directly by the included 24V

2.71A power supply, delivering 1.2 Amp of current per USB port.

Receiver unit – front panel view

Receiver unit – rear panel view

Item Type Description

1 Power LED LED is SOLID ON when DC power is supplied to the extender unit. LED is OFF

when no power is supplied by the AC adapter.

2 Mode/Config Reserved for engineering use

Status LED

LED is SOLID ON when system is functioning normally. LED BLINKS when system

is booting OR to indicate a temperature warning in unison with the LINK, USB2,

and USB3 LEDs.

Link LED LED is SOLID ON when transmitter is linked to an opposite receiver. LED is OFF

when there is no connection between the transmitter and receiver.

USB 2 LED

LED is SOLID ON when an active USB 2 connection is established through the

extender system. LED BLINKS when the USB 2 connection is suspended/asleep.

LED is OFF when no USB 2 connection is detected.

USB3 LED

LED is SOLID ON when an active USB3.1 connection is established through the

extender system. LED BLINKS when the USB3.1 connection is suspended/asleep.

LED is OFF when no USB3.1 connection is detected.

CrystalLink USB-3-2-1 CATx Extender Manual 5

4 LAN Port

(100/1000 Mbps) Ethernet pass through channel connects to a network or Ethernet device.

5 Link Port (RJ45) Accepts RJ45 connector for CAT6a/7 cabling to connect the transmitter to the

receiver

6 Device Ports

(USB3.1 Type A) Accepts all USB devices.

7 DC Power Port Locking connector for the included 24VDC 2.71A power adapter

Figure 2. Receiver unit – LED’s and connectors

INSTALLATION

CrystalLink USB-3-2-1 CATx Extender Manual 6

Installation Procedure

Before beginning an installation, ensure you have all products and components ready for the installation

Cabling Requirements

The CrystalLink USB-3-2-1 CATx extender requires a minimum grade of Category 6a cabling to be used in

order to reach 330ft (100m) of extension distance. For full distance extension, patch cable can be used up to

35ft (10m) only. The remaining 295ft (90m) must be solid core premise cabling.

When planning your installation, first determine the path of the link cable and whether to use Unshielded,

Shielded or Foiled cable where appropriate.

When installing this product, it is appropriate to use Unshielded (UTP) cabling if the cable installation meets the

following requirements:



The cable is not bundled with other cables



The cable is run loosely with other Category cables



The cable is not placed close to sources of interference such as power lines and radios



The cable is not looped or coiled

For optimum performance, Shielded (STP) or Foiled (FTP) cabling should be used if the cable installation

encounters any of the following conditions:



The cable is bundled with other cables



The cable is run tight against other Category cables



The cable is placed near sources of interference like power lines and radios



The cable is looped or coiled

Figure 3. CrystalLink USB-3-2-1 CATx extender – standard installation

USB3.1 Host

TX Unit

RX Unit

CAT6a/7

Cable

USB

Devices

Network Camera

Local LAN

Otros manuales para CrystalLink USB-3-2-1 Fiber

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Extensor de Rose electronics

Rose electronics

Rose electronics UltraLink 2 Manual de usuario

Rose electronics

Rose electronics CrystalView HDT Manual de usuario

Rose electronics

Rose electronics CRK-1USB Manual de usuario

Rose electronics

Rose electronics CrystalView CrystalView TWISTED PAIR KVM... Manual de usuario

Rose electronics

Rose electronics CrystalView CAT5 Rack CRV-12SLP Manual de usuario

Rose electronics

Rose electronics CrystalLink CLK-4U2FMB-500M Manual de usuario

Rose electronics

Rose electronics CLK-4U2TP-100M Manual de usuario

Rose electronics

Rose electronics CrystalLink USB2.0 CATx Manual de usuario

Rose electronics

Rose electronics CrystalLink CLK-1U1TP-40M Manual de usuario

Rose electronics

Rose electronics RJ45 Manual de usuario

Rose electronics

Rose electronics CrystalView Micro LT Manual de usuario

Rose electronics

Rose electronics CrystalView CAB-MD6M2MD6F Manual de usuario

Rose electronics

Rose electronics CrystalView DVI Fiber CRK-2DFMPD1D Manual de usuario

Rose electronics

Rose electronics CrystalView DVI CATx CRK-2DTXPD1D Manual de usuario

Rose electronics

Rose electronics CrystalLink USB3.1 Fiber Dual Port Manual de usuario

Rose electronics

Rose electronics CRYSTALVIEW USB 1.1 Manual de usuario

Rose electronics

Rose electronics CrystalView USB2 Manual de usuario

Rose electronics

Rose electronics CrystalView DVI Mini Manual de usuario

Rose electronics

Rose electronics CrystalView HDT Manual de usuario

Rose electronics

Rose electronics CrystalLink USB2.0 CATx Manual de usuario

Rose electronics

Rose electronics CRK-2DTPPDVI Manual de usuario

Rose electronics

Rose electronics CrystalView DVI Plus Manual de usuario

Rose electronics

Rose electronics CrystalLink USB Fiber Manual de usuario

Rose electronics

Rose electronics ORION Manual de usuario

Manuales populares de Extensor de otras marcas

SY HDBT-60T Manual de usuario

Appsys ProAudio

Appsys ProAudio ADX-16 Manual de usuario

Atlona

Atlona RS232 Manual de usuario

IDK

IDK OPF-TH1000-A Manual de usuario

Enable-IT

Enable-IT 824WP Manual de usuario

Worx

Worx Landroid RadioLink WA0864 Hoja de especificaciones

TP-Link

TP-Link TL-WA730RE Manual de usuario

Camplex

Camplex CMX-HDMI-SFPL Manual de usuario

SC&T

SC&T HE03-4K Manual de usuario

Marmitek

Marmitek MegaView70 Manual de usuario

Samsung

Samsung SCS-26UC4 Manual de usuario

Foxun

Foxun SX-GES24 Manual de usuario

MuxLab

MuxLab 500771 Manual de usuario

foxunhd

foxunhd SX-AEX01 Manual de usuario

TERK Technologies

TERK Technologies LFIRX2 Manual de usuario

Devolo

Devolo Audio Extender Manual

Edimax

Edimax EW-7438RPn V2 Manual de usuario

Shinybow USA

Shinybow USA SB-6335T5 Manual de usuario
